Barnes UT17 User manual

A Crane Co. Company
BARNESBARNES®
Portable Utillity Submersible Pump
Model: UT17 - 1/6 Hp, 120 Volt, 60Hz, 1Ph
IMPORTANT! Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
 changeproductwithoutpriorwrittennotication.
420 Third Street 83 West Drive, Bramton
Piqua, Ohio 45356 Ontario, Canada L6T 2J6
Phone: [phone] Phone: [phone]
Fax: [phone] Fax: [phone]
www.cranepumps.com Form No. 113829-Rev. G
SPECIFICATIONS
DISCHARGE ............................................... 3/4” G.H.T. Male, Vertical
LIQUID TEMPERATURE ............................. 77°F (25°C) Continuous
MOTOR HOUSING ...................................... Thermoplastic
PUMP STRAINER........................................ Thermoplastic
IMPELLER .................................................. 2 Vane Semi Open, Thermoplastic
SHAFT ........................................................ Steel
O-RINGS ...................................................... Buna-N
HARDWARE ............................................... Stainless Steel
CABLE ENTRY ............................................ 15 Ft. (4.5M) Cord with Plug and Pressure
Grommet for Sealing and Strain Relief
CABLE TYPE............................................... 18/3 SJTW
SEAL............................................................ Single Mechanical
Material ............................... Carbon/Ceramic/Buna-N
Hardware - 300 Series Stainless
UPPER BEARING........................................ Single Row, Ball, Sealed
LOWER BEARING....................................... Single Row, Ball, Sealed
MOTOR ........................................................ Air-Filled. With Class B Insulation
SINGLE PHASE........................................... Permanent Split Capacitor (PSC).
Includes Thermal Overload Protection in Motor
DIMENSIONS PERFORMANCE

2
Please Read This Before Installing Or Operating
Pump. This information is provided for SAFETY and
to PREVENT EQUIPMENT PROBLEMS. To help
recognize this information, observe the following
symbols:
IMPORTANT! Warns about hazards that
can result in personal injury orIndicates
factors concerned with assembly,
installation, operation, or maintenance
which could result in damage to the
machine or equipment if ignored.
CAUTION! Warns about hazards that can or will
cause minor personal injury or property damage if
ignored. Used with symbols below.
WARNING! Warns about hazards that can or
will cause serious personal injury, death, or major
property damage if ignored. Used with symbols
below.
Only qualied personnel should install, operate
and repair pump. Any wiring of pumps should be
performed by a qualied electrician.
WARNING! To reduce risk of electrical
shock, pumps and control panels must
be properly grounded in accordance
with the National Electric Code (NEC)
or the Canadian Electrical Code (CEC)
and all applicable state, province,
local codes and ordinances. Improper
grounding voids warranty.
WARNING! To reduce risk of electrical
shock, always disconnect the pump
from the power source before handling
or servicing. Lock out power and tag.
CAUTION ! Never operate a pump
with a plug-in type power cord without
a ground fault circuit interrupter.
CAUTION ! Pumps build
up heat and pressure
during operation-allow time
for pumps to cool before
handling or servicing.
WARNING! Do not pump hazardous
materials (ammable, caustic, etc.)
unless the pump is specically designed
and designated to handle them.
CAUTION! Do not block or restrict
discharge hose, as discharge hose may
whip under pressure.
WARNING! Do not wear loose clothing
that may become entangled in moving
parts.
WARNING! Keep clear of suction and
discharge openings. DO NOT insert
ngers in pump with power connected.
Always wear eye protection when working
on pumps.
Make sure lifting handles are securely
fastened each time before lifting. DO
NOT operate pump without safety
devices in place. Always replace safety
devices that have been removed during
service or repair. Secure the pump in its
operating position so it can not tip over,
fall or slide.
DO NOT exceed manufacturers
recommendation for maximum
performance, as this could cause the
motor to overheat.
DO NOT remove cord and strain relief.
DO NOT connect conduit to pump.
WARNING! Cable should be protected
at all times to avoid punctures, cut,
bruises and abrasions. Inspect frequently.
Never handle connected power cords
with wet hands.
WARNING! To reduce risk of
electrical shock, all wiring and junction
connections should be made per the
NEC or CEC and applicable state or
province and local codes. Requirements
may vary depending on usage and
location.
WARNING! Submersible Pumps are
not approved for use in swimming pools,
recreational water installations decorative
fountains or any installation where human
contact with the pumped uid is common.
WARNING! Products returned must be
cleaned, sanitized, or decontaminated
as necessary prior to shipment, to insure
that employees will not be exposed to
health hazards in handling said material.
All Applicable Laws And Regulations
Shall Apply.
Bronze/brass and bronze/brass tted
pumps may contain lead levels higher
than considered safe for potable water
systems. Lead is known to cause cancer
and birth defects or other reproductive
harm. Various government agencies
have determined that leaded copper
alloys should not be used in potable
water applications. For non-leaded
copper alloy materials of construction,
please contact factory.
Crane Pumps & Systems, Inc. is not
responsible for losses, injury, or death
resulting from a failure to observe these
safety precautions, misuse or abuse of
pumps or equipment.
GENERAL INFORMATION:
To The Purchaser - Congratulations! You are the
owner of one of the nest pumps on the market
today. Barnes® Pumps are products engineered
and manufactured of high quality components. Over
one hundred years of pump building experience
along with a continuing quality assurance program
combine to produce a pump which will stand up to
the toughest applications.
The pump is packaged ready for installation and no
connections or adjustments are necessary except
for attaching a standard 3/4 inch NPT garden hose
to the discharge and plugging in service cord.
Receiving - Upon receiving the pump, it should be
inspected for damage or shortages. If damage has
occurred, le a claim immediately with the company
that delivered the pump. If the manual is removed
from the crating, do not lose or misplace.
Storage:
Short Term- Barnes Pumps are manufactured for
e󰀩cient performance following long inoperative
periods in storage. For best results, pumps can be
retained in storage, as factory assembled, in a dry
atmosphere with constant temperatures for up to six
(6) months.
Long Term- Any length of time exceeding six (6)
months, but not more than twenty four (24) months.
The units should be stored in a temperature
controlled area, a roofed over walled enclosure that
provides protection from the elements (rain, snow,
wind blown dust, etc..), and whose temperature can
be maintained between +40 deg. F and +120 deg.
F. Pump should be stored in its original shipping
container and before initial start up, rotate impeller
by hand to assure seal and impeller rotate freely.
Service Centers - For the location of the nearest
Barnes Service Center, check your catalog,
your Barnes representative or Barnes Service
Department in Piqua, Ohio, telephone (937) 778-
8947, in Bramton, Ontario, Canada, [phone]
or www.cranepumps.com.
INSTALLATION:
Location - This product is designed to pump water
only and is NOT recommended for use in a sump
or basin. Product failures due to pumping mud, tar,
cement, wood chips, or damage from corrosive
materials are NOT covered under the manufacturing
warranty and will not be accepted as a return. Never
install the pump in a trench, ditch, or hole with a dirt
bottom where the suction will become plugged.
This unit shall NOT be installed in locations
classied as hazardous in accordance with the
National Electrical Code (NEC), ANSI/NFPA 70 or
the Canadian Electrical Code (CEC).
Submergence - The minimum liquid level should
never be less than 1/8 inch (3.2mm) above the
pump bottom. Unplug this unit when water has
drained to 1/8 inch (3.2mm).
Discharge - Discharge hose should be as short
as possible. The installation of a check valve in the
discharge piping is recommended for each pump
being used. The check valve is used to prevent
backow into the sump.
SAFETY FIRST!
Hazardous uids can cause re or ex-
plosions, burnes or death could result.
Extremely hot - Severe burnes can
occur on contact.
Biohazard can cause serious personal
injury.
Hazardous uids can Hazardous
pressure, eruptions or explosions could
cause personal injury or property damage.
Rotating machinery
Amputation or severe laceration can
result.
Hazardous voltage can shock, burn or
cause death.
Other brand and product names are trademarks or registered trademarks of their respective holders.
® Barnes is a registered trademark of Crane Pumps & Systems, Inc.
2002, 8/2004, 5/06, 9/06, 3/07 Alteration Rights Reserved

Airlocks - If the pump runs but dose not move any
water, an airlock has occurred. An airlock will cause
pump to overheat. If you suspect an airlock unplug
the pump, tip the pump on its side and submerse
in water and restart. Never restart the pump in less
than 1/2 inch of water.
ELECTRICAL CONNECTIONS:
Power Cable - The cord assembly mounted to the
pump must not be modied in any way. This pump
comes complete with a 3 wire cord and 3 prong
grounded plug that must be connected into a 3
wire grounded Ground Fault receptacle. DO NOT
remove ground pin from electrical plug. It is NOT
recommended to use an extension cord with this
pump. Never place pump in water or remove from
water while the unit is plugged in. DO NOT USE
THE POWER CABLE TO LIFT PUMP.
Overload Protection - Automatic thermal overload
protects the motor. Running dry may overheat the
motor and trip the overload. This means that the
overload protector will trip out and shut the pump o󰀨
if the windings become too hot, or the load current
passing through them becomes too high. It will then
automatically reset and start the pump up after the
motor cools to a safe temperature. In the event of
an overload, the source of this condition should be
determined and rectied immediately. DO NOT LET
THE PUMP CYCLE OR RUN IF AN OVERLOAD
CONDITION OCCURS !
SERVICE AND REPAIR:
Strainer - Remove screws, and remove strainer
from volute and remove volute. Clean and examine
impeller. If impeller vanes are clogged, or it is
excessively worn or broken, the pump should be
replaced.
WARRANTY:
Information Needed:Always furnish the following
information:
1. Pump Part Number
2. Pump model number
3. Pump Serial number
Typical Name Plate
IMPORTANT !
WARRANTY REGISTRATION
Your product is covered by the enclosed Warranty.
Complete the Warranty Registration Form and
returned to Crane Pumps & Systems, Inc. Warranty
Service Group
IMPORTANT! If you have a claim under the
provision of the warranty, contact your local Crane
Pumps & Systems, Inc. Distributor.
RETURNED GOODS:
Return Of Merchandise Requires A “Returned
Goods Authorization”. Contact Your Local Crane
Pumps & Systems, Inc. Distributor.
Products Returned Must Be
Cleaned, Sanitized, Or Decontami-
nated As Necessary Prior To Ship-
ment, To Insure That Employees
Will Not Be Exposed To Health
Hazards In Handling Said Material.
All Applicable Laws And Regulations Shall Apply.

IMPORTANT!
WARRANTY REGISTRATION
Your product is covered by a warranty:
www.cranepumps.com/downloadables/CATALOGS_OIPMs/Warranty/24MonthWarranty.pdf
If you have a claim under the provisions of the warranty, contact your local
Crane Pumps & Systems, Inc. Distributor.
