Bartell B446 User manual

TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
INSTRUCTION MANUAL & PARTS BOOK
WALK-BEHIND
POWERTROWEL
MODELS
B436 / B446
Use this guide along with the parts lists attached to locate and identify components of your trowel. When
ordering replacement parts be sure to provide the model number and serial number from the trowel.
POWERFUL -EFFICIENT -DEPENDABLE

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-2-
SAFETY PRECAUTIONS
DANGER
EXPLOSION HAZARD
Never operate the machine in an
explosive atmosphere, near
combustible materials or where
ventilation does not clear exhaust
fumes.
WARNING
BURN HAZARD
Never come into contact with the
engine or muffler when engine is
operating or shortly after it is
turned off. Serious burns may
occur.
CAUTION
ROTATING HAZARD
Never place hands or feet inside
safety guard rings. Serious injury
will result from contact with rotating
blades.
CAUTION
MOVING PARTS
Before starting the machine ensure
that all guards and safety devices
are in place and functioning
properly.
ATTENTION
READ OWNERS MANUAL
Read and understand operator's
manual before using this machine.
Failure to follow operating
instructions could result in serious
injury or death.
!
!
!
!

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-3-
TABLE OF CONTENTS
QUALITY ASSURANCE/MACHINE BREAK-IN ........................................................................... 4
WALK-BEHIND POWER TROWEL WARRANTY......................................................................... 5
MAINTENANCE RECORD........................................................................................................... 6
ROUTINE SERVICE INTERVALS ................................................................................................ 7
FOREWORD................................................................................................................................ 9
SAFETY PRECAUTIONS............................................................................................................. 9
ASSEMBLY INSTRUCTIONS....................................................................................................... 9
1. TROWELS................................................................................................................................ 9
2. STABILIZER RING ................................................................................................................... 9
3. HANDLE ASSEMBLY............................................................................................................... 9
4. STATIONARY RING................................................................................................................. 9
5. ENGINE CONTROLS ............................................................................................................... 9
6. BELT GUARD........................................................................................................................... 9
DIAGRAM 1................................................................................................................................ 10
OPERATION (FLOATING)......................................................................................................... 11
OPERATION (FINSHING) .......................................................................................................... 11
1. STARTING PROCEDURES -WARM TEMPERATURES........................................................ 11
2. STARTING PROCEDURES -COLD TEMPERATURES.......................................................... 11
3. STOPPING PROCEDURES.................................................................................................... 11
LUBRICATION........................................................................................................................... 11
1. ENGINE OIL........................................................................................................................... 11
2. SPIDER PLATE...................................................................................................................... 11
3. GEARBOX.............................................................................................................................. 11
4. GEARBOX OIL CHANGE....................................................................................................... 11
5. GREASE FITTINGS................................................................................................................ 11
ENGINE OIL SPECIFICATIONS................................................................................................. 11
STORAGE.................................................................................................................................. 12
MAINTENANCE......................................................................................................................... 12
1. AIR CLEANER........................................................................................................................ 12
2. LUBRICATION........................................................................................................................ 12
3. SPARK PLUG......................................................................................................................... 12
4. BELT TENSION...................................................................................................................... 12
TROWEL ARM ADJUSTMENT FIXTURE .................................................................................. 13
1. ADJUSTMENT PROCEDURE ................................................................................................ 13
ASSEMBLY DRAWINGS AND PARTS LIST.............................................................................. 14
1. WALK-BEHIND POWER TROWEL ASSEMBLY (FIGURE 1).................................................. 15
WALK-BEHIND POWER TROWEL PARTS LIST.................................................................... 16
2. BASE UNIT ASSEMBLY (FIGURE 2)...................................................................................... 17
BASE UNIT PARTS LIST........................................................................................................ 18
3. SPIDER PLATE ASSEMBLY (FIGURE 3)............................................................................... 19
BASE UNIT PARTS LIST........................................................................................................ 20
4. PRESSURE PLATE ASSEMBLY (FIGURE 4)......................................................................... 19
PRESSURE PLATE ASSEMBLY............................................................................................ 20
5. GEARBOX ASSEMBLY (FIGURE 5)....................................................................................... 21
GEARBOX ASSEMBLY PARTS LIST..................................................................................... 22
6. HANDLE ASSEMBLY (FIGURE 6).......................................................................................... 23
HANDLE ASSEMBLY PARTS LIST........................................................................................ 24
7. INSTAPITCH HANDLE ASSEMBLY (FIGURE 7).................................................................... 25
INSTAPITCH HANDLE ASSEMBLY PARTS LIST .................................................................. 26
8. BLADE KIT (FIGURE 7).......................................................................................................... 27
BLADE KIT PARTS LIST........................................................................................................ 28
TROUBLESHOOTING................................................................................................................ 29
SPECIFICATIONS...................................................................................................................... 30
COMPANY INFORMATION........................................................................................................ 31
NOTES....................................................................................................................................... 32

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-4-
QUALITY ASSURANCE / MACHINE BREAK IN
The Terex Bartell Walk-Behind Power Trowel is the product of extensive engineering
development designed to give long life and unmatched performance. The Walk-Behind
Power Trowels are shipped partially assemble, and only require filling with fuel and a brief
check of lubricant levels in preparation for operation.
You can help ensure that your Power Trowel will perform at top levels by observing a
simple routing on first use. Consider that your new Power Trowel is like a new car. Just
as you would break in a new car to the road or any new machine to the job, you should
start gradually and build up to full use. Learn what your machine can do and how it will
respond. Refer to the engine manufacturer’s manual for run-in times. Full throttle and
control may be used after this time period, as allowed by material. This will serve to
further break in the machine on your specific application, as well as provide you with
additional practice using the machine.
We thank you for the confidence you have placed in us by purchasing a Terex Bartell
Walk-Behind Power Trowel and wish you many years of satisfied use.

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-5-
WALK-BEHIND POWER TROWEL WARRANTY
TEREX Bartell agrees to furnish without charge, F.O.B. our plant, a replacement for
any part or portion thereof, comprising the main unit of the TEREX Walk-Behind
Power Trowel, consisting of the drive shaft assembly and the gear case
assemblies, save and except drive belts, and power units, and/or bearing or
electrical controls which prove upon our examination, to be defective in either
material or workmanship within a period of twelve (12) months from date of
purchase, provided that notice of such defective part or portion thereof is given to
TEREX Bartell Ltd. within the twelve month warranty period. No further or other
guarantee or warranty expressed or implied in connection with the sale of the
Walk-Behind Power Trowel is given and our sole liability consists in replacing
defective parts or portions thereof. We shall not be responsible for any special,
indirect or consequential damages arising in any manner whatsoever.
This guarantee is for the sole benefit of the original purchaser as end user. Our
responsibility under this guarantee ends in the case the original purchaser
transfers ownership of the Walk-Behind Power Trowel, makes any changes or adds
any parts or devices not of our manufacture to the Walk-Behind Power Trowel.

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-6-
MAINTENANCE RECORD
PREVENTATIVE MAINTENANCE AND ROUTINE SERVICE PLAN
This Walk-Behind Power Trowel has been assembled with care and will provide years of service. Preventative
maintenance and routine service are essential to the long life of your Power Trowel. Your dealer is interested in
your new machine and has the desire to help you get the most value from it. After reading through this manual
thoroughly, you will find that you can do some of the regular maintenance yourself. However, when in need of parts
or major service, be sure to see your Terex Bartell dealer. For your convenience we have provided this space to
record relevant data about your Walk-Behind Power Trowel. When in need of parts or service be prepared to
provide your Trowel serial number. Locate the serial number now and record in the space below.
Date Purchased:
Type of Machine:
Dealer Name:
Model:
Dealer Phone:
Serial Number:
REPLACEMENT PARTS USED MAINTENANCE LOG
PART NO. QUANTITY COST DATE DATE OPERATION

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-7-
Routine Service
Intervals
Each
use After 1.5 months
or
50 hrs
Each 3
months
or
100 hrs
Each 6
months
or
200 hrs
Each 9
months
or
300 hrs
Each 12
months
or
400 hrs
General Inspection:
Guards Check ooooo
Warning stickers Check ooooo
Test run: Check operation ooooo
Controls:
Dead-man switch operation
Check
oooooo
Check
oooooo
Pitch control
Lubricate
ooooo
Engine:
Check Level oooooo
Engine oil Change
ooo
Engine oil filter Replace oo
Oil cooler Clean oooo
Cooling Fins Clean ooooo
Check -clean oooooo
Air cleaner Replace
o
Check o
Air Intake Line Replace
2 yrs
Check tightness oo
Fan Belt Replace
500 hrs
Valve clearance Check-adjust oo
Check & Clean oooo
Fuel filter Replace
oo
Fuel Tank Clean 500 hrs
Engine wiring Check o

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-8-
Routine Service Intervals
Due to the nature and environment of use, Walk-Behind Power Trowels could be exposed to severe
operating conditions. Some general maintenance guidelines will extend the useful life of your trowel.
•The initial service for your power trowel should be performed after 25 hours of use, at which time your
mechanic (or authorized repair shop) should complete all of the recommended checks in the schedule
above. The chart on page 6 (six) is handy for keeping a record of the maintenance performed and the parts
used for servicing your trowel.
•Regular service according to the schedule above will prolong the life of the Walk-Behind Power Trowel and
prevent expensive repairs.
•Keeping your Walk-Behind Power Trowel clean and free from debris is the single most important regular
maintenance operation, over and above the checks in the service schedule above, that can be performed.
After each use your Walk-Behind Power Trowel should be cleaned to remove any dust and debris from the
undercarriage and surrounding components. Use of a power washer will make clean up quick and easy,
especially if a non-stick coating was applied prior to use.
•In the Service Schedule above, items that should be checked, replaced or adjusted are indicated by “o” in
the appropriate column. Not all Walk-Behind Power Trowel models include the same features and options
and as such not all service operations may have to be performed. For ease of recording place a checkmark
(√) through the “o” when the item is complete. If an item is not required or not completed place an “x”
through the “o” in the box.
•All Walk-Behind Power Trowels have governed engine speed of 3600 rpm. See engine manufacturer’s
manual for exact specifications. Care should be used when making any adjustments to the Walk-Behind
Power Trowel not to change the governed speed. Running the engine at lower rpm’s will result in a
decrease of compaction force and lower travel speed. It will create excessive “out-of-synch” vibrations
resulting in poor compaction, maneuverability, excessive wear to the machine, and discomfort to the
operator.
•Failure to have your Walk-Behind Power Trowel regularly serviced and properly maintained in accordance
with the manufacturer’s instructions will lead to premature failure and void the warranty.

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-9-
FOREWORD
The Terex Bartell Walk-Behind Power Trowel is highly
effective for a wide variety of surface, sub-soil, and
back-fill materials. Although relatively light in weight and
easy to operate, the Walk-Behind Power Trowel delivers
a tremendous impact to the soil. Pound for pound, the
Walk-Behind Power Trowels provide a higher impact
force. That means more productivity from our ideal
combination of speed and deeper compaction.
SAFETY PRECAUTIONS
•Always keep unauthorized, inexperienced, untrained
people away from this machine.
•Rotating and moving parts will cause injury if
contacted. Make sure guards are in place. Keep
hands and feet away from moving parts.
•Fuel the machine only when the engine is stopped,
using all necessary safety precautions.
•The engine must always be stopped before
attempting any repair or adjustments. Ignition switch
should be off.
•Be careful not to come in contact with the muffler
when the engine is hot, serious burns may result!
DANGER:
Never operate the machine in an explosive
atmosphere, near combustible materials or where
ventilation does not clear exhaust fumes. Repair
fuel leaks immediately. Refer to your engine
owner’s manual for more safety instructions.
ASSEMBLY INSTRUCTIONS
Your new Terex Bartell Walk-Behind Power Trowel has
been shipped to you partially assembled. Filling the fuel
tank and a brief check of lubricant levels in preparation
for operation is required. To complete the assembly the
following instructions will be helpful.
1. TROWELS –Attach trowel blades with screws and
lock washers supplied. See (A) and (B) Fig. 1. Be
careful that adjusting screw (C) does not protrude
below arm when attaching blades. This could cause
the machine to jump and promote excessive wear in
operation.
2. STABILIZER RING –(if supplied) Install using
screws, bushings and lock washers supplied. See
Fig. 1 (D)
3. HANDLE ASSEMBLY –Put cable end Fig. 2 (A)
through hole in yoke (B) and secure with nut (C),
then install handle bracket on gearbox. To get
proper cable tension, turn control knob Fig. 3,
counter-clockwise to stop position. Guide screw (B)
will now be at the bottom slot. Tighten nut Fig. 4 (A)
until slack is removed from point (B) as indicated. If
more than 2 or 3 threads show through, then nut
should be turned back.
Guide screw, Fig. 3 (B) should be moved to next
lower hole in slide bushing and cable re-adjusted as
above. Turn hand knob completely clockwise and
check for clearance between yoke and gearbox at
point (C) Fig. 4. There should be enough space to
pass a business card through.
4. STATIONARY RING –Install stationary ring as
shown in Fig. 5 with the side bar on engine recoil
side. (May not be exactly as shown). Install rubber
bushings (A) on top and bottom of mounting plate.
Install metal caps (B). Place ring on top and run
screw (C) through caps and rubbers. Tighten lock nut
(D) securely on bottom. It is best to start nuts on all 4
corners before tightening.
5. ENGINE CONTROLS –Attach throttle control to
handle with screws provided. See DIAGRAM 1 below
for your engine model hook-up. For safety switch
connection, attach wire to terminal provided at
“ON/OFF” location.
The throttle cable must be cut and formed to fit. Feed
the cable through the cable clamp on the engine. Pull
the cable through the clamp until it forms a smooth
arc from the handle to the engine. Mark the cable at
the clamp and pull the cable back from the casing at
the throttle. Without cutting the cable, Cut casing at
the mark and push the cable back through fresh cut
end. Form a small “L” bend in the cable, hook the
inner cable into the throttle block and tighten cable
clamp down onto the casing. With thumb lever and
throttle block in the fully open position, cut the inner
cable by the thumb lever, leaving enough wire
exposed to secure to the lever. Insert the cable into
the fitting and tighten the screw. Restore throttle to
idle position.
IMPORTANT:
Before running machine with belt installed, ensure
that engine idles properly and that the safety-switch
shuts off the engine.
6. BELT GUARD –Install after machine has been
tested, taking care that it does not touch clutch or
pulley.
ATTENTION:
For any information regarding engine adjustments,
please refer to the engine manual supplied.

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-10 -
DIAGRAM 1
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-11 -
OPERATION (Floating)
When the slab has set sufficiently firm that the
operator’s footprint leaves a very slight depression on
the surface of the slab, it is ready for the floating
operation.
Under normal operating conditions the machine should
cover as much as 1000 sq. ft. in about 15 minutes. It is
recommended that a slight tension on the trowel control
cable, (but not a definite tilt), during the floating
operation will cause the machine to operate much
smoother. After the floated slab has set sufficiently, it is
ready for the finishing operation.
CAUTION:
Do not let the machine stand in one spot on the
soft cement. Lift from the slab when the floating
operation is complete.
OPERATION (Finishing)
When starting the finishing operation, never set the
trowels up over 1/4” pitch. This is important. Guiding the
machine on the slab is very simple, a slight upward lift of
the handle causes the machine to travel to the left.
Holding the handle in the neutral position, will slowly
cause the machine to spin in one spot. Slight downward
pressure on the handle causes the machine to travel to
the right. Best results are obtained by covering
approximately 4” on each turn. In other words, let the
machine move right or left, backwards or forwards,
approximately 4” with each revolution of the trowels. To
fill a hole or cut down a hump, move the unit back and
forth over the problem area.
After the first pass over the slab, the waiting time
between operations is determined in the same manner
as if you were hand troweling. To repeat; the entire
application and action of the troweling machine in regard
to getting on the slab, and the correct pitch of the
trowels, is determined in the same manner as would be
used by a cement finisher when troweling by hand.
STARTING PROCEDURE: *WARM CLIMATE
Open fuel valve on gas tank. Set throttle lever to “Fast”
idle position, set choke to closed position, start engine.
Open choke slightly to prevent flooding. Move to “Open”
or “Run” position when engine is warm, increase throttle
to maximum operation position (3600 rpm).
STARTING PROCEDURE: *COLD CLIMATE
Follow same procedure as above but allow longer
warm-up period –3 to 5 minutes. In cold weather, oil is
much heavier to move and requires more time to work
its way into the moving parts. If maximum power is not
attained, allow further warm-up time. Fill fuel tank with
clean gasoline, use safety approved gas containers.
DO NOT MIX OIL WITH GASOLINE –USE UNLEADED
GAS ONLY.
STOPPING PROCEDURE
1. Throttle engine down.
2. Turn off stop switch.
LUBRICATION
1. ENGINE OIL
The long life and successful operation of any piece of
machinery is dependent on frequent and thorough
lubrication.
Before using the trowel, always check your engine for
oil. Use proper engine oil as recommended in the
engine manufacturer’s manual. Fill crankcase to
levels as recommended.
2. SPIDER PLATE
There are 8 (eight) grease fittings on the spider
plates, 4 (four) on each must be greased daily.
SPIDER PLATES MUST BE GREASED EVERY
TIME MACHINE IS USED.
3. GEARBOX
Check the oil level sight plugs on both gearboxes
daily to ensure the oil is half way on the site glass.
Top up with Agma 8 compounded gear oil only.
Gearbox capacity 16 oz. to 19 oz. (473ml. To 562ml.)
Example: Esso/Exxon Cylesstic TK680.
4. TO CHANGE GEARBOX OIL
Place a pan beneath the drain plug to catch the oil.
Remove the drain plug and the filler plug from the
gearbox. After the oil has drained completely, replace
the drain plug and tighten. Fill the gearbox through
the filler plug with 16 oz. to 19 oz. (473ml. To 562ml.)
of Agma 8 compounded gear oil. Replace the filler
plug and tighten.
5. GREASE FITTINGS
There are 6 bearings in total. Grease all bearings and
U-joints to ensure adequate supply of lubricant. They
are located above the gearboxes (2 per gearbox) and
2 located in the drive system. The U-joints are
located in the drive system as well.
ENGINE OIL SPECIFICATIONS
Season Temperature
Grade of Engine Oil
Spring to Autumn
+40°F (4°C) to +120°F (49°C)
Winter
+15°F (-9°C) to +40°F (4°C)
Below +15°F (-9°C) SAE 10W-30
SAE 30
SAE 20

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-12 -
STORAGE
The following steps should be taken to prepare your
Walk-Behind Power Trowel for extended storage.
1. Close fuel shut off valve.
2. Siphon excess gasoline from tank.
3. Start engine until it stops from lack of fuel. This will
use up all the fuel in the carburetor and prevent
formation of deposits due to evaporation of fuel.
4. Remove spark plug and pour 2 oz. of SAE-30 or
SAE-40 motor oil into the cylinder. Slowly crank the
engine 2 or 3 times to distribute the oil throughout
the cylinder. This will help prevent rust during
storage. Replace spark plug.
5. Store the unit in an upright position in a cool, dry,
well ventilated area.
MAINTENANCE
Maintaining your Walk-Behind Power Trowel will insure
long life to the machine and its components.
AIR CLEANER -Keep air filter clean at all times. Wash
away dust and debris using a non-oil based cleaning
solvent. Let the filter dry before re-installing.
LUBRICATION –Always check engine oil regularly.
Use proper engine oil as recommended. See chart
below. Fill crankcase to levels as recommended in
manufacture’s engine manual.
SPARK PLUG –Check and clean spark plugs
regularly. A fouled, dirty or carboned spark plug causes
hard starting and poor engine performance. Set spark
plug gap to recommended clearance. Refer to engine
manual.
BELT TENSION –IMPORTANT!
If there is excessive belt play, there will be a decrease
in the impact force and erratic vibration, which could
cause machine damage. The normal belt play should
be 1/2” to 5/8” which is attained by depressing the top
section of the belt at the belt guard mounting bracket
location. When adjusting the belt make sure that the
clutch is in alignment with exciter pulley. Tighten all
engine mount bolts, adjust the two engine-stop bolts,
and tighten lock nuts.

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-13 -
TROWEL ARM ADJUSTMEN
T FIXTURE
PART #20801
Ex: Unit 36” (B436)
1) 10810A –Trowel arm
2) 10817A–Lift lever
3) 10808 –Jam nut
4) 10809 –Set screw
5) 10824 –Block top
6) 10507 –Bolt
7) 10808 –Jam nut
8) 10807 –Carriage bolt
9) 10832 –Adjustment bar
10) 10507 –Bolt
Figure
The trowel arm adjustment fixture (20801) is reversible.
By rotating the arm clamping fixture and the ring bolt,
both left hand and right hand trowel arms may be
adjusted. Before attempting adjustment, determine
whether the trowel arm is right handed or left handed.
When adjusting left hand trowel arms use the side of the
fixture marked “L”. When adjusting right hand trowels
arms use the opposite side. The adjustment bar will be
set on “36” for the Walk-behind trowel arm.
ADJUSTMENT PROCEDURE
1. Remove all trowel arm assemblies (1 & 2 arm and
attached lift lever) from suspected maladjusted spider
plate.
2. Remove lift lever (2) from trowel arm (1) by first
loosening jam nut (3) then square head screw (4). If
upon inspection (method left to discretion of
serviceman) any trowel arm (1) is found to be in a
bent condition, it must either be brought back to its
original straight condition (method left to the
serviceman’s discretion) or replaced with new part.
3. Replace lift levers (2) on new or straightened arms
(1) by reversing procedure as described above.
NOTE: IT IS IMPORTANT THAT WHEN TIGHT-
ENING SQUARE HEAD NUT (4), IT SEATS ITSELF
SECURELY INTO DIMPLE MACHINED IN ARM.
4. Place trowel arm assembly (1 and 2) in fixture (5)
with lift lever (2) butting up against fixture. Secure in
place with bolts (6).
5a.
5. Loosen locknut (7) and screw carriage bold (8) down
to full depth allowable. This will provide for ample
clearance to swing precision ground adjustment bar
(9) over head of carriage bolt. Adjustment bar (9) is
stamped for appropriate size of machine. Swing
appropriate side directly over carriage bolt (8) and
secure in place with bolt (10).
6. Adjust carriage bolt (8) upwards until contact is made
with adjustment bar (9); holding carriage bolt in
position with one wrench, tighten locknut (7) to secure
in position with second wrench.
NOTE: IT IS VITALLY IMPORTANT TO ENSURE
THAT ONCE THE CARRIAGE BOLT IS ADJUSTED
TO THE CORRECT HEIGHT, IT DOES NOT MOVE
BEFORE, OR DURING THE TIGHTENING OF
LOCKNUT.
7. This same procedure is to be followed with ALL arms
from spider plate assembly, and will ensure correct
and exact adjustment.
TROWEL ARM ADJUSTMENT SCREW
When assembling trowel blades to trowel arms, the
adjustment screw should NEVER protrude below the
under-side surface to a trowel arm except when using for
emergency on-site adjustment to level trowel blades.
If the adjustment screw is not flush with the underside of
the trowel arm, then this will cause the power trowel to
bounce and vibrate especially at high speed. This will
also cause the trowel blades to leave an uneven finish to
the concrete due to the blades not being level to one
another.
Make certain that the adjusting screw is held firmly in
place while tightening the bolt which secures the blade to
the trowel arm.

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-14 -
A
AS SS SE EM MB BL LY Y D DR RA AW WI IN NG GS S A AN ND D P PA AR RT TS S L LI IS ST T

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-15 -
WALK-BEHIND POWER TROWEL ASSEMBLY
Figure 1-Complete Trowel
Note: Some parts shown above are optional and may not be included with your trowel. Refer to the attached parts lists for complete list of parts
applicable to your trowel.
Item # Description Item # Description Item # Description Item # Description
10 Base Unit 80 Hex Nut 150 Hex Nut 200 Emergency Stop
20 Blade Kit 90 Clutch/Drive Sheave 160 Guard Ring 240 Hoist Hook (opt.)
30 Handle Assy 100 Driven Sheave 165 Hex Hd. Screw 250 Flat Hd. Screw
40 Engine (opt.) 110 Key 170 Flat Washer 270 Carry Bar
50 Stud 120 V Belt 175 Rubber Washer
60 Flat Washer 130 Belt Guard 180 Hex Locknut
70 Lock Washer 140 Lock Washer 190 Stud
160
190120
150
130
140
100
110
2010 60 30807050 165
40
90
200
250
240 175180 270

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-16 -
CUSTOMER PARTS LIST
Assembly #
Walk-Behind Assembly
Assembly List
Item # Part # (436) Part # (446) Description Qty Eff. Date
10 20903 20901 Base Unit 16/8/2004
20 20033 20068 Blade Kit, 6 x 14, Finish Imperial 16/8/2004
30 20520A 20562 Handle Ass’m 36 Standard 16/8/2004
40 Engine Engine Honda, Robin, B&S 16/8/2004
50 14278 14280 Stud, Combo 46/8/2004
60 10919 10905 Flat Washer (5/16), (3/8) 26/8/2004
70 10402 10402 Lock Washer (5/16), (3/8) 46/8/2004
80 10915 10901 Hex Nut, (5/16-18), (3/8-16) 46/8/2004
90 21006A 21005 Clutch, B436 3/4" Bore 16/8/2004
95 11254A N/A Clutch Spacer 16/8/2004
100 14270 14285 Sheave,(5"x3/4"Bore),(MB58x3/4”Bore) 16/8/2004
110 10208A 10208A Key 3/16”Sq x 1-1/2”LG 16/8/2004
120 11030 ¹11178 V-Belt, (A25), ¹(B29)16/8/2004
130 21066 21065 Belt Guard 16/8/2004
140 10902 10902 Lock Washer, 3/8" Dia 16/8/2004
150 10901 10901 Hex Nut, 3/8-16 16/8/2004
160 20447A 20448A Safety Ring -Removable 16/8/2004
165 30019 30019 HHCS, 1/2-13 x 1 1/2"LG 46/8/2004
170 50026 50026 Flat Washer 1/2" 46/8/2004
175 11296 11296 5/8" Rubber Washer 86/8/2004
180 10547 10547 Nylock Nut, 1/2-13 46/8/2004
190 10910 10910 Stud, 3/8-16 x 1-3/4"LG 16/8/2004
240 20189 20189 Hoist Hook GX160, No Brake 16/8/2004
250 11256 11256 FHSCS 5/16-24 x 1”LG 46/8/2004
270 20512 20512 Carry Bar Ass’m 16/8/2004
Rev. 1 Belt for B446 changed, was 11047 (BP28) now 11178 (B29) 10/2005

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-17 -
BASE UNIT ASSEMBLY
Figure 2-Base Unit
Item # Description Item # Description Item # Description
10 Spider Plate Assy 70 Yoke arm 130 Mounting Rails
20 Pressure Plate Assy 80 Pin 140 Engine Plate
30 Key 90 Retaining Ring 150 Soc.Hd. Capscrew
40 Gearbox Assy 100 Stud 160 Cap Plug
50 Retainer 110 Lock Washer
60 Soc.Hd. Capscrew 120 Hex Nut
110
100
90
30
50
20
80
150
130
40
140
60
70
10
120
160

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-18 -
CUSTOMER PARTS LIST
Assembly #
20903, 20901
Base Unit, B436 / B446, Greased Spider
Item # Part # (436) Part # (446) Description Qty Eff. Date
10 20810A 20820T Spider plate Ass’y 15/1/2004
20 20627 20626T Pressure Plate Ass’y 11/1/1997
30 10608A 10608A Key, 1/4”Sq x 1-5/32”LG 15/1/2002
40 20921A 20928AT Gearbox Ass’y 14/7/1998
50 10814 10804 Retainer 11/1/1997
60 10812 10802 SHCS (7/16-14x1-1/4”LG),(1/2-13x1-1/2”LG) 11/1/1997
70 10312B 10311CYoke Arm 13/1/2004
80 10923 10914 Pin 11/1/1997
90 10922 10913 Retaining Ring, E Type 21/1/1997
100 10910 10910 Stud, 3/8-16 x 1-3/4"LG 41/1/1997
110 10902 10902 Lock Washer, 3/8" Dia, Medium 41/1/1997
120 10901 10901 Hex Nut, 3/8-16 41/1/1997
130 14274 14315B Mounting Rails (Incl LH & RH) 19/16/2003
140 14273 14316B Engine Mounting Plate, Metric 19/16/2003
150 12727 14317 SHCS (5/16-18x1-1/4"LG),(3/8-16x1-1/4”LG) 49/16/2003
160 10823 10823 Cap Plug EC-12 11/1/1997

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-19 -
10
20
30
SPIDER PLATE ASSEMBLY
Figure 3–Greased Spider Plate Assembly
Item # Description Item # Description
10 Spider Plate 70 Lift Lever
20 Grease Fitting 80 Jam Nut
30 Cap 90 Carriage Bolt
40 Trowel Arm 100 Square Head Setscrew
50 Dog Screw 110 Adjuster Bolt
60 Lock Washer
Figure 4-Pressure Plate Assembly
Item # Description
10 Pressure Plate
20 Thrust Bearing
30 Pressure Plate Cap
40
110
100 80 70 90 80 50 20 30 1060

WALK-BEHIND TROWEL INSTRUCTION MANUAL
TEREX BARTELL LTD.
31 SUN PAC BLVD, BRAMPTON, ONTARIO, CANADA, L6S 5P6, 905-458-5455 FAX [phone]
590 HUEY RD, SOUTH CAROLINA, USA, 29730, 800-247-8577 FAX [phone] Created:07/04
Revised:4/06
-20 -
CUSTOMER PARTS LIST
Assembly #
20810, 20820
Spider Plate Assembly, Greased
Item # Part # (436) Part # (446) Description Qty Eff. Date
10 10810A 10820A Grease Spider Plate 11/1/1997
20 10801 10801 Grease Fitting,1/8npt x 65° 41/1/1997
30 10822 10822 Caplug, Grease Nipple, Red 41/1/1997
40 10411A 10405A Trowel Arm 49/5/2000
50 10806 10806 HHCS, 3/8-16 x 7/8"LG 41/1/1997
60 10805 10805 Lock Washer, 3/8"Dia 41/1/1997
70 10817A 10819A Lift Lever 49/12/2000
80 10808 10808 Jam Nut, 3/8-16 81/1/1997
90 10807 10807 Carriage Bolt, 3/8-16 x 1-1/4"LG, 41/1/1997
100 10809 10809 SHSS, 3/8-16 x 1"LG, CUP PT. 41/1/1997
110 10404 10404 Adjusting Screw, 1-1/4" LG 41/1/1997
Assembly #
20627, 20626
Pressure Plate Assembly
Item # Part #
(436) Part # (446) Description Qty Eff. Date
10 10660P 10659P Pressure Plate 11/1/1997
20 10664 10663 Thrust Bearing P/P 11/1/1997
30 10668P 10667P Pressure Plate Cap 112/6/2002
