Bartscher GWH2 / 105210 Quick start guide

0051 CN 4225
V2/0415
GWH
3
/
1053103
GWH
2
/
1052103

- 29 -
ENGLISH
Translation
of the original instruction manual
Table of contents
1.Safety ........................................................................................................................ 30
1.1 Safety instructions............................................................................................... 30
1.2 Key to symbols.................................................................................................... 31
1.3 Hazard sources................................................................................................... 32
1.4 Intended use ....................................................................................................... 33
2. General information................................................................................................ 34
2.1 Liability and Warrantees...................................................................................... 34
2.2 Copyright protection............................................................................................ 34
2.3 Declaration of conformity..................................................................................... 34
3. Transport, packaging and storage......................................................................... 35
3.1 Delivery check..................................................................................................... 35
3.2 Packaging ........................................................................................................... 35
3.3 Storage................................................................................................................ 35
4. Technical data......................................................................................................... 36
4.1 Technical specification........................................................................................ 36
4.2 Overview of parts ................................................................................................ 38
4.3 Rating/information plate ...................................................................................... 40
5. Installation and operation....................................................................................... 42
5.1 Instructions for the installer................................................................................ 42
5.1.1 Assembly of the lower section................................................................. 43
5.1.2 Installation............................................................................................... 44
5.1.3 Gas connection ....................................................................................... 45
5.2 Instructions for the user ..................................................................................... 52
5.2.1 Safety instructions................................................................................... 52
5.2.2 First start-up............................................................................................ 53
6. Cleaning and maintenance..................................................................................... 54
7. Possible failures...................................................................................................... 55
8. Removing of waste material................................................................................... 56
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
GB/UK

- 30 -
Read these instructions before using and keep
them available at all times!
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
1.Safety
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
All persons using the device must follow the recommendations and instructions
in this instruction manual.
1.1 Safety instructions
•This device may only be operated in technically proper and safe condition.
•The device is not intended for use by individuals (including children) with physical or
mental disabilities, insufficient experience, and/or insufficient knowledge unless such
persons are under the care of a person responsible for their safety or have received
instructions regarding appropriate use of the device.
•Children should be observed to ensure that they are not playing with the device.
•Only a qualified technician and using original spare parts and accessories should
carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.
•Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the device
or personal injury, and further, the warranty expires.

- 31 -
•To prevent hazards and to ensure optimum efficiency, no modifications or alterations
to the device that are not explicitly approved by the manufacturer may be undertaken.
•Before cleaning and maintenance of the device and if not using the device for an
extended period of time, disconnect the gas supply (close the main gas valve).
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
DANGER!
This symbol highlights hazards which could lead to injury.
To avoid them please follow the instructions very carefully and proceed
with particular attention in these cases.
WARNING!
This symbol highlights dangerous situations which could lead to injury or death.
To avoid them please follow the instructions very carefully and proceed
with particular attention in these cases.
CAUTION!
This symbol highlights dangerous situations which could lead to light
injuries, or damage, malfunction, and/or destruction of the device.
To avoid them please follow the instructions very carefully and proceed
with particular attention in these cases.
NOTE!
This symbol highlights recommendations and information aimed for effective
and trouble-free device operation.

- 32 -
1.3 Hazard sources
DANGER!
In order to avoid any danger from gas please follow the safety instructions listed below.
Do not use the device if it is not operating properly, has been damaged or
dropped.
Incorrect installation, maintenance, cleaning or any modifications to the device may
cause serious injuries or may damage the device.
In order to ensure safe operation of the device, the personnel must undergo regular
technical trainings.
NEVER attempt to disassemble or repair the device. Only qualified gas installers
may perform this work while following the legal regulations in force.
DANGER! Risk of suffocation!
In order to avoid this risk please follow the instructions listed below.
Prevent kids from accessing the packaging material such as plastic
bags and Styrofoam elements.
WARNING! Risk of burning!
In order to avoid this risk please follow the instructions listed below.
DO NOT lean over the cooking stations while igniting the flame. High flame may
cause serious injuries.
NEVER touch hot surface of gas burners during their operation and
directly afterwards. Allow the device to cool down. Use the cloth for pots or
protective gloves.
DO NOT USE FLAT-BOTTOM POTS on the wok ring insert.
Both with the work ring insert and without it, at full burner output the flames
go out from the sides or above the insert. This may lead to serious burns.

- 33 -
WARNING! Risk of fire or explosion!
In order to avoid this risk please follow the instructions listed below.
Do not leave the device unattended when heating fats or oils, because they
may combust spontaneously.
Do not place any flammable objects near the device.
NEVER put out the flames or fire with water, close the gas shut-off valve and
extinguish the flames with a lid or fire-proof blanket
DO NOT use the aluminium foil or similar materials to cover the burners, dripping
trays or ventilation holes in the side walls. It may cause insufficient air flow and
gas combustion and lead to overheating and fire.
1.4 Intended use
CAUTION!
The device has been designed and built for commercial use and should be
operated only by qualified personnel in kitchen facilities.
Safe operation is only guaranteed when using the device for its intended purpose.
Any technical interventions, as well as assembly and maintenance are to be made by
a qualified customer service only.
The gas wok cooker has been designed for preparation of Western and Oriental
food by frying, baking and cooking, and is designed only for preparation of food.
-DO NOT use the device for heating of non-food products.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use
are impossible.
The operator is liable for all damages resulting from inappropriate use.

- 34 -
2. General information
2.1 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology.
CAUTION!
Read this manual carefully and thoroughly before any operation
of the device, and especially before turning it on!
Manufacturer is not liable for any damages or faults caused by:
-violation of advice concerning operation and cleaning;
-use other than designed;
-alterations made by user;
-use of inadequate spare parts.
We reserve the right to make technical changes for purposes of developing and improving
the useful properties.
2.2 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are
copyright and subject to other protection rights. Any person unlawfully
using this publication is liable to criminal prosecution.
2.3 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity. If required we will be
glad to send you the according declaration of conformity.

- 35 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in
your country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-Do not store outdoors.
-Keep it dry and dust-free.
-Do not expose it to aggressive media.
-Do not expose it to direct sunlight.
-Avoid mechanical shocks and vibration.
-In case of longer storage (> 3 months) make sure you check
the state of the packaging and the parts regularly.
If required refresh or renew.

- 36 -
4. Technical data
4.1 Technical specification
Description Gas wok cooker GWH2
Code-no.:
1052103
Material: CHS 18/10
No. of burners/power 2 of 11.5 kW
Gas connection: R 3/4"
Gas pressure at connection: G 30/G 31 : 28 – 30/37 mbar
G 30/G 31 : 50 mbar G 20 : 20 mbar G 25 : 25 mbar
Rated heat load: natural gas: 26 kW, liquid gas: 23 kW
Dimensions: W 900 x D 600 x H 960 mm
Dimensions of cooking
station w/o wok ring:
for pots of Ø 200 mm
Weight: 58.0 kg
Equipment: 2 removable wok ring inserts, Ø 290 mm
We reserve the right to make technical changes!
Installation dimensions 1052103 / GWH2
Fig. 1
A
–
cooking adjustment knob
G
– gas connection

- 37 -
Description Gas wok cooker GWH3
Code-no.:
1053103
Material: CHS 18/10
No. of burners/power 3 of 11.5 kW
Gas connection: R 3/4"
Gas pressure at connection: G 30/G 31 : 28 – 30/37 mbar
G 30/G 31 : 50 mbar G 20 : 20 mbar G 25 : 25 mbar
Rated heat load: natural gas: 39 kW, liquid gas: 34.5 kW
Dimensions: W 1500 x D 600 x H 960 mm
Dimensions of cooking
station w/o wok ring:
for pots of Ø 200 mm
Weight: 85.0 kg
Equipment: 3 removable wok ring inserts, Ø 290 mm
We reserve the right to make technical changes!
Installation dimensions 1053103 / GWH3
Fig. 2
A
–
cooking adjustment knob
G
– gas connection

- 38 -
4.2 Overview of parts
1052103 / GWH2
Fig. 3
①
Burner
⑤
Feet of adjustable height
②
Round wok insert
⑥
Base with shelf
③
Cooking station knob
⑦
Base
④
Tray for dripping fat
⑧
Cooker housing
①
④
⑦
⑧
②
⑤
⑥
③

- 39 -
1053103 / GWH3
Fig. 4
①
Burner
⑤
Feet of adjustable height
②
Round wok insert
⑥
Base with shelf
③
Cooking station knob
⑦
Base
④
Tray for dripping fat
⑧
Cooker housing
①
③
④
⑦
⑧
②
⑤
⑥

- 40 -
Features of gas wok cookers
•high-efficient burner of power of 11.5 kW, manual ignition
•burners removed without tools
•burners with thermoelectric protection
•dripping fat collecting tray under the burners
•base with adjustable feet
•preset to liquid gas, natural gas jets are enclosed
4.3 Rating/information plate
Fig. 5
The rating plate shows information about the current settings for gas and rated
data for the gas wok cooker.
1052103 / GWH2
1053103 / GWH3

- 41 -
Fig. 6
The information plate shows warning information in the languages of target countries.
DE
Dieses Gerät muss nach geltenden Vorschriften angeschlossen und darf
nur in einem gut belüfteten Raum betrieben werden. Bitte beachten Sie
vor Inbetriebnahme des Gerätes die Gebrauchs- und Wartungsanleitung.
GB
This device must be connected according to the valid regulations, and must
be operated in properly ventilated room only. Before starting the device read
the operation and maintenance manual.
FR
Ce dispositif doit être connecté conformément à la réglementation en vigueur
et ne peut être utilisé que dans un endroit bien ventilé. Veuillez lire les
instructions d'utilisation et d'entretien avant la mise en service de l'appareil.
IT
La presente apparecchiatura dovrà essere collegata in conformità con le
norme vigenti e potrà essere utilizzata unicamente in ambienti ben ventilati.
Prima dell'avvio, rispettare le istruzioni per l'uso e la manutenzione.
ES
El presente dispositivo debe conectarse conforme a la normativa vigente y
puede utilizarse solo en una estancia bien ventilada. Antes de poner en
marcha el dispositivo, se deben observar las instrucciones de uso y
mantenimiento.
NL
Het apparaat moet worden aangesloten in overeenstemming met de
geldende voorschriften en mag uitsluitend worden gebruikt in een goed
geventileerde ruimte. Houdt u aan de gebruiksaanwijzing en de
onderhoudsvoorschriften voordat u het apparaat in gebruik neemt.
PL
Niniejsze urządzenie musi byćpodłączone zgodnie z obowiązującymi
przepi-sami i może byćużywane wyłącznie w dobrze wietrzonym
pomieszczeniu. Przed uruchomieniem urządzenia należy przestrzegać
instrukcji użytkowania i konserwacji.
Fig. 7
The rating plate on the device packaging includes warnings and information about
current settings of the device (see an example below).
GB
II2H3+ G20; 2H; 20 mbar
G30/31; 3+; 28-30/37 mbar
This appliance must be installed according to the regulations in force
and used only in o well aired place. Consult the instuctions before
installing and using this appliance.
This package must be disposed according to the regulations in force.

- 42 -
5. Installation and operation
5.1 Instructions for the installer
CAUTION!
Any installation, connection and maintenance work related to the device must
be performed by the qualified gas installer, according to the international,
national and local regulations in force in the installation country.
Remove the external packages (wooden crates and/or carton boards) and take them out
of the installation area according to the valid regulations.
1. The device with the gas-powered equipment should be installed according to the
following regulations:
a local requirements and international standards;
b local recommendations, like building standards and
recommendations for the combustion devices;
c recommendations and regulations of the gas and electric
energy suppliers;
d work safety regulations.
2. Make sure that the gas supply for the device is sufficient.
3. Install the device with use of appropriate gas filter.
4. Before the test start-up place the device in well ventilated room and remove all
flammable materials in the vicinity.
5. Before starting the device perform the tightness test with the use of a soap solution.
Spread the soap solution on screw unions and pipe connections. The leaks
become visible by appearance of bubbles on the screw unions and pipe
connections. Observing of the gas meter is another test method. No meter
movement indicates that there are no gas leaks. Do not use open flame for
testing the tightness of the gas installation!
6. Before cleaning and maintenance of the device close the gas supply in the safe place.

- 43 -
5.1.1 Assembly of the lower section
Fig. 8
A. Place 4 pipes on the lower storage surface.
Use external toothed washers, washers and nuts M8.
B. Put the stabilizer strips on the upper tips of pipes (2 strips on the sides,
1 strip in the front and 1 strip in the back).
Use external toothed washers, washers and nuts M6.
C. Install the device (1) on the lower section (2).
Use external toothed washers, washers and hexagonal nuts M6.

- 44 -
5.1.2 Installation
•DO NOT install the device in toxic or explosion-threatened environment.
•DO NOT install the device in the vicinity of flammable materials, like gasoline, glue,
liquid gas, paper, etc.
•DO NOT install the device in wet or humid room or conditions, like in the rain or next
to the water, etc.
•The installation must be performed by the authorized person. Install the device
according to the national safety standards for the gas-powered devices.
•Place the device in well-ventilated room with permanent ventilation ducts in order to
assure sufficient air replacement and for safe work station. If the gas cooker is not
connected directly with the extraction system, place it under the hood of high
efficiency in order to remove the combustion gases and cooking vapours.
•The following is valid for the housing types listed below while following the national
regulations:
- A1: The device without air intake or connection with the extraction system or
other device for removing the combustion products from the room.
The combustion air and gases are mixed in the same room.
•Make sure that no objects next to and under the gas cooker limit the amount of air
required for combustion.
•Remove all flammable materials from the cooker vicinity.
•In case of free standing device maintain at least 20 cm of space to the side walls
and 10 cm to the back wall. It is especially important when the device is positioned
next to the wall and is not protected by the refractory material.
•Position the device separately or next to another device of the same type.
•Position the device on a stable, even and flat surface near the gas connection.
•Remove the protective foil before start-up. Remove all stickers using appropriate
solvent.
•Remove the package material according to the national regulations.
CAUTION!
Never remove the rating plate and any warning signs from the device.

- 45 -
5.1.3 Gas connection
Gas supply connection
•Before the installation and connection to the gas supply carefully check the
permanent part of the gas device which should conform to the national building
regulations.
•Check if the cross section of pipes assures sufficient supply for all gas-powered
devices. In order to avoid the excessive pressure losses install the device in the
similar conditions.
•The pipelines must be made from steel pipes (with fittings from hardened cast iron
or galvanized steel, or pipes connected by gas welding), or from copper pipes (with
mechanical connections and connections without seals, putty or soldering).
•Check if the gas cylinder (if applicable) is positioned and protected according to the
regulations in dry place.
•Make sure that the gas pipelines are accessible for inspection. In case of pipelines
installed in the floor and walls make sure that they are installed professionally and
that there are the reference points allowing for finding the pipeline.
•Before the installation of the gas wok cooker make sure that the device is
designed for gas and the pressure in the gas installation (see the rating plate on
the device and packaging). If the initial settings are inconsistent, the device must
be modified for a different type of gas (see section „Modification for a different
type of gas / required settings”).
•Connect the gas wok cooker to the gas installation with rigid or flexible steel pipes of
cross section appropriate for the rated power and length.
•Make sure that the flexible pipes are not placed next to hot surfaces or directly on
them, are not pressed or loaded and do not touch the sharp edges or other objects
which may damage the pipes.
•Install the easily accessible certified gas shut-off valve between the gas installation
and the device, to ensure that if necessary the gas supply could be quickly shut off.
•After installation of the gas wok cooker perform the tightness test of the connections of
the pressurized gas installation using the spray for detection of leaks or other non-
corrosive foaming agent.

- 46 -
Control of gas pressure and rated heat load (fig. 9)
•During the first installation the installer must check the rated heat load of the device
and if necessary introduce appropriate changes or modify the device for a different
type of gas.
•DO NOT attempt to increase the rated efficiency or heat load of the device.
•Check the heat load with use of gas meter and stop-watch. Thoroughly measure the
amount of gas consumed by the device in the time unit at maximum efficiency.
•Compare the measured value with the data in section 4.1 “Technical specification”.
The allowable deviation is ±5%.
•If the deviation during the measurement is higher check the diameter and quality of
installed injectors and the gas pressure in the network. If the gas pressure it the
network is to be measured with use of liquid gauge (e.g. U-tube manometer with
calibration every 0,1 mbar), proceed as below:
•Connect hose “E” to the manometer “M” after unscrewing the cover of the
pressure inlet “C”.
•Measure the connection pressure: If the measured value in outside of range
listed in the table below the device may not operate correctly. In such case
contact the gas supplier in order to find the solution of that problem.
•Install the pressure reducer when required.
•After the pressure measurement disconnect hose “E” and retighten the
cover of the pressure inlet “C”.
•Reinstall all parts in the opposite sequence.
Fig. 9
C = pressure inlet
D = gas line
E = hose
G = inlet connection
M = manometer
R = gas valve

- 47 -
Table 1: Inlet pressure
Gas type Inlet pressure (mbar)
normal minimum value maximum value
natural gas G20 20 18 25
liquid gas G 30/G 31 50 42.5 57.5
Table 2: Use of gas categories and pressures in various countries
CAUTION!
The device operates correctly only when the pressure in the gas line is
in range specified in the table below for the individual gas types.
Country Categories Gas type
Gas pressure
(mbar)
AT Austria
II
2H3B/P
G20 - G30/G31 20 - 50/50
BE Belgium
II
2E+3+
G20/G25 - G30/G31 20/25 - 28-30/37
BG Bulgaria
II
2H3B/P
G20 - G30/G31 20 - 30/30
CH Switzerland
II
2H3+
II
2H3B/P
G20 - G30/G31
G20 - G30/G31 20 - 28-30/37 20 - 50/50
CY Cyprus
II
2H3+
II
2H3B/P
G20 - G30/G31
G20 - G30/G31 20 - 28-30/37 20 - 30/30
CZ Czech Republic
II
2H3+ G20 - G30/G31 20 - 28-30/37
DE Germany
II
2ELL3B/P G20 - G25 - G30/G31 20 - 20 - 50/50
DK Denmark
II
2H3B/P
G20 - G30/G31 20 - 30/30
EE Estonia
II
2H3B/P
G20 - G30/G31 20 - 30/30
ES Spain
II
2H3+ G20 - G30/G31 20 - 28-30/37
FI Finland
II
2H3B/P
G20 - G30/G31 20 - 30/30
FR France
II
2E+3+ G20/G25 - G30/G31 20/25 - 28-30/37
GB United Kingdom
II
2H3+ G20 - G30/G31 20 - 28-30/37
GR Greece
II
2H3+
II
2H3B/P
G20 - G30/G31
G20 - G30/G31 20 - 28-30/37 20 - 30/30
HR Croatia
II
2H3B/P
G20 - G30/G31 20 - 30/30
HU Hungary
I
3B/P G30/G31 30/30
