Bartscher Saladette 900T2 User manual

900T2 - 1365T3 - 900T2 - 438T1 -
900T2+GL
200356 - 200357 - 200358 - 200570 -
200575

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Technical Support Hotline: [phone]
www.bartscher.com
Version: 1.0
Date of preparation: 2021-09-29
EN

200356 1 / 32
Original instruction manual
1Safety............................................................................................................2
1.1 Explanation of Signal Words....................................................................2
1.2 Safety instructions....................................................................................3
1.3 Intended Use ...........................................................................................6
1.4 Unintended Use.......................................................................................6
2General information.......................................................................................7
2.1 Liability and Warranty ..............................................................................7
2.2 Copyright Protection ................................................................................7
2.3 Declaration of Conformity ........................................................................7
3Transport, Packaging and Storage................................................................8
3.1 Delivery Check.........................................................................................8
3.2 Packaging................................................................................................8
3.3 Storage....................................................................................................8
4Technical Data...............................................................................................9
4.1 Technical Specifications ..........................................................................9
4.2 Functions of the Appliance.....................................................................12
4.3 List of Components of the Appliance .....................................................13
5Installation and operation ............................................................................18
5.1 Installation..............................................................................................18
5.2 Operation...............................................................................................20
6Cleaning and Maintenance..........................................................................24
6.1 Safety Instructions for Cleaning.............................................................24
6.2 Cleaning.................................................................................................25
6.3 Maintenance ..........................................................................................26
7Possible Malfunctions..................................................................................27
8Disposal....................................................................................................... 30

Safety
2 / 32 200356
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des Geräts u ndg ilt als wichtige Infor mationsquelle und Nach schlagewerk. Die Ken ntnis aller enthaltene nSic herheitshinweis eun dH andlungsanweisu ngen schafft die Vora ussetzung f ürdas si chere und sachger echte Arbeiten mit de mG erät.D arüber hinaus müssen die für den Einsatz bereich des Geräts gelte nden örtlichen Un fallverhütungsvorsc hriften und allgemein en Sicherheitsb estimmungen eingehalt en werden. Diese Bedi enungsanleitung ist Bestandt eild es Produkts und muss in u nmittelbarer Nähe d es Geräts für das In¬stallatio ns-, Bedienungs- , Wartungs- und Reinigu ngspersonal jederzeit z ugänglich auf¬b ewahrt werden. Wenn d as Gerät an eine dritte Person
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.

Safety
200356 3 / 32
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
1.2 Safety instructions
Electrical Current
•Too high a mains voltage or incorrect installation may cause electric shock.
•The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
•To avoid short-circuit, the appliance should be kept dry.
•If there are malfunctions during operation, disconnect the appliance from the
power supply.
•Do not touch the appliance’s plug with wet hands.
•Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
•Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
•Do not transport the appliance, holding it by the power cord.
•Do not allow the power cord to come into contact with heat sources or sharp
edges.
•Do not bend, pinch nor knot the power cord.

Safety
4 / 32 200356
EN
•Always completely unwind the power cord.
•Never place the appliance or other objects on the power cord.
•Always take hold of the plug to disconnect the appliance from the power supply.
•Check the power cord regularly for damage. Do not use the appliance if the
power cord is damaged. If this cable is damaged, it must be replaced by
customer service or a qualified electrician in order to avoid dangers.
Incorrect operation of th e appliance may cause fire or explosion hazard d uet oig nition of its content.
Fire hazard / flammable materials hazard / explosion hazard!
•Do not use any electric devices in the appliance.
•Do not store nor use petrol or other flammable liquids and gases in the vicinity of
this or any other appliance. Those gases may cause fire or explosion hazard.
•Do not put into the appliance any explosive materials, like sprays filled with
flammable propellants. Contents of containers filled with flammable gases and
liquids may leak in low temperatures, and the contents may catch fire from
sparks generated by an electric appliance. Explosion hazard!
•In the case of coolant leakage, pull the plug from the socket. Remove all
sources of ignition in the vicinity, ventilate room and contact technical service.
Avoid coolant getting in contact with eyes, as it may cause serious eye damage.
•Never use any flammable liquids for cleaning the appliance or its parts. Gases
released may cause fire or explosion hazard.
•In the case of fire, disconnect the appliance from the power supply before
attempting adequate fire-extinguishing actions.
•Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.
•Defrosting process may not be sped up with mechanical means or heat energy
sources (candles or heaters) nor with any other means. Vapour produced may
cause short-circuit and too high temperatures may damage the appliance.
•All ventilation slots should not be obstructed during operation.
•Never attempt to damage cooling installation of the appliance.
Operating Personnel
•The appliance may only be operated by qualified personnel and trained
specialist personnel.
•This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
•Children should be supervised to ensure that they are not playing with or
switching on the appliance.

Safety
200356 5 / 32
EN
Improper Use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used when its technical condition is flawless and
allows for safe operation.
•The appliance may only be used when all connections are executed according
to rules of law in force.
•The appliance may only be used when it is clean.
•Use only original spare parts. Never attempt to repair the appliance on your own.
•Do not introduce any changes in the appliance nor modify it.
•Do not drill hole in the appliance nor install any objects on it.
•Do not place any heavy objects on the appliance.

Safety
6 / 32 200356
EN
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–Cooling, preparation and sales of salads, fruit, vegetables and cold
dishes.
The appliance is intended for operation in maximum ambient temperature of 30°C
and relative humidity of 55%.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
–Storing flammable or explosive objects and liquids, such as ether,
petroleum or adhesives;
–Storing explosive materials, like sprays filled with flammable propellants;
–Storing pharmaceutical products or preserved blood;
–Storing live pets.

General information
200356 7 / 32
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
The warranty period for this appliance is 24 months, counted from the purchase
date.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, Packaging and Storage
8 / 32 200356
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.

Technical Data
200356 9 / 32
EN
4 Technical Data
4.1 Technical Specifications
Version / Characteristics
•Material: chrome-nickel steel
•Cooling: circulating air
•Climate class: 4
•Cooling cabinets and drawers
•Temperature control: digital
•Thermostat
•Control: electronic, button
•Digital display
•ON/OFF switch
•Indicator light: ON/OFF
•Automatic defrost function
•Evaporation of condensed water
•With foamed evaporator
•Insulation: 45 cm
• Removable cutting board (polyethylene)
• Lockable technical compartment cover
•Stainless steel filter behind the cover of the technical compartment
–removable
–dishwasher-safe
•Cabinet Gastro Norm: GN 1/1
•Door type: leaf door
•Door with no possibility for door hinge to be changed
•Self-closing door
•The set does not include: GN containers
We reserve the right to implement technical modifications.

Technical Data
10 / 32 200356
EN
Name:
Saladette 900T2
Art. No.:
200356
Volume, in l:
260
Number of cabinets:
2
Cabinet dimensions (W x D x H), in mm:
428 x 570 x 590
GN capacity:
2 x 1/1 GN + 3 x 1/6 GN
Number of doors:
2
Coolant, amount in kg:
R290 / 0,056
Connected load:
0,204 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
900 x 700 x 887
Weight, in kg:
66,5
The set includes:
2 bars, length 326 mm, width 25 mm
2 bars, length 535 mm, width 35 mm
4 bars, length 174 mm, width 25 mm
Name:
Saladette 1365T3
Art. No.:
200357
Volume, in l:
390
Number of cabinets:
3
Cabinet dimensions (W x D x H), in mm:
428 x 570 x 590
GN capacity:
4 x 1/1 GN
Number of doors:
3
Coolant, amount in kg:
R290 / 0,064
Connected load:
0,321 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
1.365 x 700 x 887
Weight, in kg:
90,0
The set includes:
3 bars, length 326 mm, width 25 mm
3 bars, length 535 mm, width 35 mm
4 bars, length 174 mm, width 25 mm

Technical Data
200356 11 / 32
EN
Name:
Pizza Saladette 900T2
Art. No.:
200358
Volume, in l:
260
Number of cabinets:
2
Cabinet dimensions (W x D x H), in mm:
428 x 497 x 590
GN capacity:
5 x 1/6 GN
Number of doors:
2
Coolant, amount in kg:
R290 / 0,056
Connected load:
0,204 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
900 x 700 x 1.175
Weight, in kg:
91,0
The set includes:
4 bars, length 174 mm, width 25 mm
Name:
Saladette 438T1
Art. No.:
200570
Volume, in l:
140
Number of cabinets:
1
Cabinet dimensions (W x D x H), in mm:
368 x 570 x 590
GN capacity:
1 x 1/1 GN
Number of doors:
1
Coolant, amount in kg:
R290 / 0,048
Connected load:
0,23 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
455 x 700 x 887
Weight, in kg:
45,5
The set includes:
2 bars, length 535 mm, width 35 mm
1 grate 1/1 GN

Technical Data
12 / 32 200356
EN
Name:
Saladette 900T2 +GL
Art. No.:
200575
Volume, in l:
250
Number of cabinets:
2
Cabinet dimensions (W x D x H), in mm:
428 x 570 x 590
GN capacity:
2 x 1/1 GN + 3 x 1/6 GN
Number of doors:
2
Coolant, amount in kg:
R290 / 0,056
Connected load:
0,187 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
900 x 700 x 845
Weight, in kg:
63,5
The set includes:
2 GN 1/1 grates, stainless steel
2 bars, length 326 mm, width 25 mm
2 bars, length 535 mm, width 35 mm
4 bars, length 174 mm, width 25 mm
4.2 Functions of the Appliance
In the refrigerated salad table, you can cool and store for a specified time in
appropriate GN containers with appropriate temperature settings, salads, fruit,
vegetables and cold dishes.

Technical Data
200356 13 / 32
EN
4.3 List of Components of the Appliance
200356
Fig. 1
1. Cooling tube cover
2. Cooling tube
3. Cutting board
4. Appliance door (2 pcs.)
5. Housing
6. Feet (4 pcs.)
7. Ventilation openings
8. GN containers shelves (8 pcs)
9. ON/OFF switch with integrated
power indicator light (green)
10.Digital temperature controller

Technical Data
14 / 32 200356
EN
200357
Fig. 2
1. Cooling tube cover
2. Cooling tube
3. Cutting board
4. Appliance door (3 pcs.)
5. Housing
6. Feet (4 pcs)
7. Ventilation openings
8. GN crossbars for containers (10 pcs.)
9. ON/OFF switch with integrated
power indicator light (green)
10.Digital temperature controller

Technical Data
200356 15 / 32
EN
200358
Fig. 3
1. Cooling top
2. Cooling tube
3. Granite worktop
4. Appliance door (2 pcs.)
5. Housing
6. Feet (4 pcs.)
7. Ventilation openings
8. GN crossbars for containers (4 pcs)
9. ON/OFF switch with integrated
power indicator light (green)
10.Digital temperature controller

Technical Data
16 / 32 200356
EN
200570
Fig. 4
1. Cover of the sliding part of the
chamber for the GN containers
2. Cover of the folding part of the
chamber for the GN containers
3. Cutting board
4. Appliance door
5. Housing
6. Ventilation openings
7. Feet (4 pcs.)
8. ON/OFF switch with integrated
power indicator light (green)
9. Digital temperature controller
10.1/1 GN grid (1 pcs.)
11.Grate guides
12.Crossbars for GN containers (2 pcs.)

Technical Data
200356 17 / 32
EN
200575
Fig. 5
1. GN shelves for containers
2. Cutting board
3. Appliance door (2 pcs.)
4. Housing
5. Feet (4 pcs.)
6. Ventilation openings
7. ON/OFF switch with integrated
power indicator light (green)
8. Digital temperature controller
9. GN containers shelves (8 pcs)
10.1/1 GN grid (2 pcs.)
11.Grate guides

Installation and operation
18 / 32 200356
EN
5 Installation and operation
5.1 Installation
CAUTION!
Incorrect installation, positioning, operation, maintenance or misuse of
the appliance may lead to personal injury or property damage.
Positioning and installation, as well as repairs may be performed by
authorised technical service only and in compliance with the applicable
national law.
Unpacking / Positioning
•Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
•If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
•Be careful not to damage the rating plate and warning labels fixed on the
appliance.
•Never place the appliance in humid or wet environment.
•Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
•The appliance should be placed on surfaces that are:
–even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
–sufficiently large, and thus enabling usage of the appliance with no
problems;
–easily accessible;
–well ventilated.
•Nie należy umieszcz ać urządzeni a w gorącym o toczeniu ani w pobliżu materiał ów łatwopalnych.
•The appliance requir ess ufficient airflow for proper operation. Assure a minimum lateral cl earance of the appliance of 1 0c m.
•DieÖ ffnungen am Gerät niemals abdec keno der blockieren.
