Baton VPOS1CP12-H20 User manual

OWNERS MANUAL
VPOS1CP12-H20
20200903

Chapter 1: Function
1.1 : Function____Page 1
Chapter 2: Safe and explaining
2.1 : Emergency Stop____Page 2
2.2 : Stop____Page 3
2.3 : Power____Page 4
Chapter 3: Installation
3.1 : Power Installation____Page 5
3.2 : Installation____Page 6
Chapter 4: Operation
4.1 : Mode 1____Page 7
4.2 : Turntable Speed____Page 8
4.2.1：CW/CCW____Page 9
4.2.2：Cylinder(Take the LR60 machine as an example)____Page 10
4.2.2：Reserve Device(Take the LR60 machine as an example)____Page 11
4.3 : Automatic Mode____Page 12
4.3.1：Mode 1____Page 13
4.3.1.1：START 1P+2 cycle____Page 14
4.3.1.2：Optional Mode____Page 15
4.3.1.3：Setting Parameters 1____Page 16
4.3.1.4：A____Page 17
4.3.1.5：B____Page 18
4.3.2：Mode 2____Page 19
4.3.2.1：START 1P+4 cycle____Page 20
4.3.2.2：Optional Mode____Page 21
4.3.2.3：Setting Parameters 2____Page 22
4.3.2.4：C____Page 23
4.3.2.5：D____Page 24
4.3.3：Mode 3____Page 25
4.3.3.1：START 3P+2 cycle____Page 26
4.3.3.2：Optional Mode____Page 27
4.3.3.3：Setting Parameters 3____Page 28
4.3.3.4：E____Page 29
4.3.3.5：F____Page 30
4.3.3：Mode 4____Page 31
4.3.3.1：START 3P+4 cycle____Page 32
4.3.3.2：Optional Mode____Page 33
4.3.3.3：Setting Parameters 4____Page 34
4.3.3.4：G____Page 35
4.3.3.5：H____Page 36
4.4 : System Setting____Page 37
Appendix
CONTENTS

Chapter 1: Function

Function
1.1 Page 1
Specification / No.
Power
Table axis centre hole
Table Dia
Table angle
Welding current
Table speed
Rotate load
Rotate torque
Workpiece Max. Dia
Workpiece Max. length
Clamp center strok
Clamp center hole
Cylinder control
otate the direction
Memory
Automatic Welding Function
Clamping Timer
Pre-flow Timer
Delay Welding Timer
Start Arc Timer
Overlap Timer
Crater Timer
Post-flow time
Delay give wire time
Finish back wire time
Arc way of the welder
Line welder
Stop the brake
H.F. Protect
Start the device
Size(Not included controller)
N.W. / G.W.
VPOS1CP12-H20
V1: AC 110V/60Hz/4A/1Ø
V2: AC 230V/50Hz/3A/1Ø
I.D 55mm
O.D. 340mm
0 - 90o
300A / 100%
0.6 - 6 rpm
200 Kg
65 Kg-cm.
O.D. 400mm
200mm
100mm
8 - 56mm
Electric(AA1)
cw/ccw
99 sets
Overlap
0.0 - 9.9sec
0.0 - 9.9sec
0.0 - 9.9sec
0.0 - 9.9sec
0.0 - 9.9sec
0.0 - 9.9sec
0.0 - 9.9sec
0.0 - 9.9sec
0.0 - 9.9sec
Standard(2 cycle) / Cater(4 cycle)
2st
Magnetism brake
92%
Pedal switch (Line 2M)
L : 390mm,W : 340mm,H : 1297mm
80Kg / 112Kg
TIG
or
MIG
Link
Limit
run
arc
1
1
2
2
2 Cycle 4 Cycle
TIG
or
MIG
Link
Limit
run
arc
1
1
2
2
Overlap Overlap
0
50
100
150
200
250
300
350
0 0.5 1 1.5 2 2.5 3 3.5
VPOS1CPositioner Eccentric Load
A : Eccentric Center (cm.)
W : Load (kg.)
0
50
100
150
200
250
300
350
4.5 6.5 8.5 10.5 12.5 14.5 16.5 18.5
VPOS1CCenter of Gravity
B : Center of Gravity (cm.)
W : Load (kg.)

Chapter 2: Safe and explaining

!
Emergency Stop
2.1 Page 2
E
M
E
R
G
E
N
E
M
E
R
G
E
N
E
M
E
R
G
E
N
E
M
E
R
G
E
N
Emergency Stop
Remove
●The power and all control movements are closed at the same time.
●The power and all control movements resume the function.

Stop
2.2 Page 3

POWER
INPUT
POWER LAMP
POWER
INPUT
POWER LAMP
Power
2.3 Page 4

Chapter 3: Installation

Power Installation
3.1 Page 5
AC 220V/50Hz/3A/1Ø

Installation
3.2 Page 6
Foot switch

Chapter 4: Operation

!
Mode 1
4.1 Page 7

!!
Turntable Speed
4.2 Page 8
Or
Maximum value 100 %
Minimum value 0 %

!
Switch on
Switch on
!
CW/CCW
4.2.1 Page 9

!
Cylinder(Take the LR60 machine as an example)
4.2.2 Page 10

Off(dark)
On(Bright)
!
Reserve Device(Take the LR60 machine as an example)
4.2.3 Page 11

or
!
Automatic Mode
4.3 Page 12

+
!
Mode 1
4.3.1 Page 13

or
or
Maximum value 100 %
Minimum value 0 %
!
START 1P+2 cycle
4.3.1.1 Page 14
