Baudcom EDFA-1550 User manual

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
Operating Manual
64 Port High power amplifier

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
Catalog
Using Safety Precautions........................................................................................................................................................... 1
Application ................................................................................................................................................................................ 2
Feature .................................................................................................................................................................................. 2
Description: ........................................................................................................................................................................... 2
Block Diagram ...................................................................................................................................................................... 2
Optical characteristics .......................................................................................................................................................... 4
Environmental characteristics .............................................................................................................................................. 4
Electrical Characteristics ...................................................................................................................................................... 4
Starting up ................................................................................................................................................................................. 5
Equipment Powered Instructions ......................................................................................................................................... 5
LED/ Key Description ........................................................................................................................................................... 5
Display Menu Description ..................................................................................................................................................... 5
Indicator ................................................................................................................................................................................ 6
Interface ................................................................................................................................................................................ 7
Web............................................................................................................................................................................................ 8
Login ..................................................................................................................................................................................... 8
Device Infomation ................................................................................................................................................................. 9
Network Config ..................................................................................................................................................................... 9
User Management ............................................................................................................................................................... 10
SNMP Config ...................................................................................................................................................................... 12
SNMP ...................................................................................................................................................................................... 13
Laser Safety Information ........................................................................................................................................................ 13
Order Information .................................................................................................................................................................. 13

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
Using Safety Precautions
Before installing and using this product, please read the following carefully. The Company does not
assume any responsibility for any loss due to security breaches caused.
Lasers and erbium-doped fiber amplifier output power laser radiation is not visible, can not
look directly at the device connector end when it works to avoid burning eyes and skin.
Equipment includes precision optics, in order to avoid damage to the severe impact of its
constitution, please avoid excessive vibration and impact. Pigtail easily sacrificed, so be
careful.
Equipment containing electrostatic sensitive devices, handle it carefully and make sure the
ground is good, the power supply is normal.
Attention of optic fiber end face:
1、Before using, please be sure to keep the input and output end face of the optic fiber clean,
especially if the output end face is dirt, then it is easy to make the output end face burned
and the output power will be decreasing. When cleaning the optical fiber end face or
insert patch cords, please turn off the input light first.
2、The correct order of plugging optical port is:
Inserting: first insert optical patch cord of output port, then insert optical patch cord of
input port.
Pulling out: first pull optical patch cord of input port, then pull optical patch cord of
output port.
3、This kind amplifier is a high precision and high stability product, in order to have high
stability output power, please use optical patch cord with good quality and which
connectors are match with the device to connect with the output port. In principle, the
optical patch cord should be as short as possible, and do not let it voluntary movement.
If there are any questions, please contact our company. Do not disassemble the module,
otherwise it will cause irreparable damage

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
Application
◆Analog CATV Transmission
◆FTTH Optical Access
◆Optical Distribution
◆Free Space Optical
◆R&D and Training
Feature
◆High Power：Up to 2W total，1 Unit for 2000～4000 optical node
◆Low Noise Figure：Below 5.5dB ( +5dBm input)
◆Er Yb co-doped DCF Amplify Technology：Patent Pump Dump Technology
◆Low CSO: ＜-70dBc
◆23dBm×N，20dBm×N or 17dBm×N output is optional
◆Controllability and maneuverability: Dual CPU to deal Control loop and Communication separately
◆High Stability And Reliability：MTTF＞150000 Hours
◆Redundancy Hot Swap power module: 110/220VAC and 48VDC can plug Mix
◆Perfect Network Interface：Ethernet
◆Support SNMP network management
◆Intelligent Temperature Control System: using a dedicated Temperature control chip which make
cooling and power loss reduce 30% than competitors
◆Output Power can be Adjustable by network and manual
◆Integrated 1310nm，1490nm，1550nm WDM (Optional)
◆OEM, Module is available
Description
The product is high output power C-Band Er-Yb co-doped double cladding optical fiber amplifier. The
key components of the product are high reliability multimode PUMP laser and the double cladding optical
fiber. A proprietary ATC (Automatic Temperature Control) and APC (Automatic Power Control) circuit
insures the high stability and reliability output power, the unique optical circuit design ensures the excellent
optical performance. The high stability and high precision MPU system to ensure the control, adjustment
and display are intelligent and easy.
This amplifier employ double cladding Erbium Ytterbium co-doped fiber, and employ the high power
multimode pump, with a 10 times Conversion efficiency higher than the single mode general technology,
and therefore have a lower relative cost and more compact size and lower power consumption, in
particular, for FTTH or FTTB or other large distribution system applications.
Employ intelligent temperature control system: (1)Adopt special temperature control circuit，heat
radiating and power consumption can be reduced 30%, (2)The professional air flow design can also
ensure the best temperature stability, at the same time powerful fan will start when the case temperature is
over 45℃, meanwhile it will stop as the temperature is under 40℃.The technology makes sure the thermal
stability of system and fan’s long life.
Intelligent network management system. Perfectly network interface: Ethernet network，and the open
network management interface ensure the connectivity with all other network management system.
These products are widely used in CATV transmission system and the high power distributing system
FTTH requirement. It can be used for CATV analog/digital signal distribution, or match with PON system to
construction the triple network integration. (Triple wavelength WDM is optional)
Block Diagram

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
Optical characteristics
Parameter Symbol MIN TYP MAX UNITS
Operating Wavelength λc 1540 1550 1565 nm
Saturated Output Power Note1
Po 13 ------ 33 dBm
Input Power Pi -3 ------ +10 dBm
Gain G ------ ------ 30 dB
Noise Figure Note2 NF ------ ------ 5.5 dB
Output Power Stability ΔPo ----- ±0.05 ±0.2 dB
Input Isolator ISOi 30 ------- ------ dB
Output Isolator ISOo 30 ------- ------ dB
Input Pump Leakage PLi ------- ------- -35 dBm
Output Pump Leakage PLo ------- ------- -45 dBm
Return Loss RL ------- ------- -45 dB
Polarization Dependent Gain PDG ------ ------- 0.3 dB
Polarization Mode Dispersion PMD ------ ------- 0.5 ps
Note 1：Optional
Note 2：Tested at +5dBm Input
Environmental characteristics
Parameter Symbol MIN TYP MAX UNITS
Operating Temperature Tw -5 ----- 60 ℃
Storage Temperature Ts -40 ----- 80 ℃
Humidity Note ------ 10 ------ 90 %
Note: No Condensate
Electrical Characteristics
Parameter Symbol MIN TYP MAX UNITS
Power Supply（1） Vps 170 264 VAC
Power consumption P ----- ----- 50 W
1: 110VAC，220VAC and -48VDC is optional, and duplicate supply is optional.

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
Starting up
Before starting up, Please check the input voltage to the rated input voltage, grounding is good.
The product adopts independent 220 VAC power supply.
Equipment Powered Instructions
Special Note:
1. The power module must be properly inserted in the device, so it can be supplied power.
2. Do not insert the charged power module into the device directly.
LED/ Key Description
key ： Upper button. Press this button can check each parameter of products from
bottom to top.
key ： Down button. Press this button can check each parameter of products from top to
bottom.
key ： Menu button. Press it can enter the menu.
key ： Return button. Press it can return to the standby screen。
Display Menu Description
（1）Display device start up process when power on：
（2） Press the Menu button to display products model：
（3）Press the down button to display internal temperature：
（4）Press the down button to display the current of pump 1：
（5）Press the down key to display the cooling current of pump 1：
（6）Press the down button to display the current of pump 2：
High Power Amplifier
MODEL : EDFA 1550
INTERNAL TEMP **℃
LD1 CURRENT ***MA
TEC1 CURRENT ***MA
LD2 CURRENT *.* A

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
（7）Press the down button to display the temperature of pump 2：
（8） Press the down button to display the operating current of pump 3：
（9）Press the down button to display the temperature of pump tube 3:
（10） Press the down button to display input optical power:
（11） Press the down button to display output optical power:
（12）Press the down button to display working status:
In this screen, press the Menu button to display "ON" opens AGC function . If a high-power pump
is damage, the other pump will increase the pumping power automatically to maintain the stability
of output power. Press the Return key to display "OFF", this function is off.
（13） Press the down button to display the status of the pump:
In this screen, press the Menu button to display "ON" pump working.
Press the Return key to display "OFF" pumped off.
Indicator
 Pump1： Pump 1 indicator off is normal, pump 1 flashing is alarming.
 Pump2： Pump 2 indicator off is normal, pump 2 flashing is alarming.

 Alarm： Alarm Indicator: input and output light turns red when alarming.
LD2 COOLER **.* ℃
LD3 Current *.* A
LD3 COOLER **.*℃
Input *.**mW *.*dBm
OUTPUT ***MW **.*DBM
AGC Conerol ***
PUMP CONTROL **

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]

 AGC ： When the AGC function is turned on the light turns green.
Interface
Front-Panel、Back-Panel
Connectors
Description
Input Optical input port
1~16 Optical output ports
RJ45 Ethernet control port
Power1/2 Power input 110/220V AC
Reset(optional) Short press: reboot net control board
Long press: reset all net parameter to default

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
Web Managment
Login
1. Open Internet Explorer;
2. Input IP address into address box;
3. After the [Login] page have shown up, input UserName and password;
4. Press Login botton;
Note:
*1: Default IP address is 192.168.1.1 which can be modified at [Network Config] web page;
*2: Default UserName and password both are admin which can be modified at [User Management] web page;

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
Device Infomation
After at successful login, the [Device Information] page will show up. There’re three sections.
1. Device
PowerMode: The name of electrical power source is using;
LaserCount: Total number of laser pump is used;
LaserType: 01=standard pump;
Temperature: The case temperature of the device;
InputPower: The input optical power of the device;
OutputPower: The output optical power of the device;
SystemStatus: OK=every thing goes well; otherwise the error message will be shown;
2. Laser
Bias: the current of main pump;
TEC: the current of the Thermo Electric Cooler;
Temperature: the core temperature of the pump;
3. Power
The main electrical power and backup electrical power supply status;
Network Config

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
This page modifies the network parameters.
User Management
This page modifies the login account. You can change the user name and password here.

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
SNMP Config
This page modifies the SNMP Community. You can changed the community of read or write here.(Only read
community is using.)

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
SNMP Management
SNMP Version 1 protocol is supported. The device related mib are defined as below.
mib function
1.3.6.1.4.1.17409.1.11.2.0 Optical Input Power value*0.1dBm
1.3.6.1.4.1.17409.1.11.3.0 Optical Output Power value*0.1dBm
1.3.6.1.4.1.17409.1.11.4.1.2.1 Bias Current.1 value*1mA
1.3.6.1.4.1.17409.1.11.4.1.2.2 Bias Current.2 value*1mA(Reserved)
1.3.6.1.4.1.17409.1.11.4.1.2.3 Bias Current.3 value*1mA(Reserved)
1.3.6.1.4.1.17409.1.11.4.1.3.1 Tec Current.1 value*0.1A
1.3.6.1.4.1.17409.1.11.4.1.3.2 Tec Current.1 value*0.1A(Reserved)
1.3.6.1.4.1.17409.1.11.4.1.3.3 Tec Current.2 value*0.1A(Reserved)
1.3.6.1.4.1.17409.1.11.4.1.4.1 Pump Temperature.1 value*0.1deg
1.3.6.1.4.1.17409.1.11.4.1.4.2 Pump Temperature.1 value*0.1deg(Reserved)
1.3.6.1.4.1.17409.1.11.4.1.4.3 Pump Temperature.2 value*0.1deg(Reserved)
1.3.6.1.4.1.17409.1.11.7.1.2.1 DCPower Voltage.1 value*0.1V
1.3.6.1.4.1.17409.1.11.7.1.2.2 DCPower Voltage.2 value*0.1V
1.3.6.1.4.1.17409.1.3.1.13.0 Internal Temperature value*1deg
1.3.6.1.4.1.17409.1.3.3.2.2.1.12.1 Device Temperature value*1deg
Laser Safety Information
Class IV laser products.
9μm/125μm single-mode fiber pigtail with connector.
Wavelength=0.90~1.68μm
Maximum Power=10W
Order Information

SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: www.baudcom.com.cn Tel: [phone] Email: [e-mail]
Note 1：EDFA-1500 for 1U rack，Maxim ports number： 16（w/ WDM），or 32（w/o WDM）
Note 2：High End configure with SNMP Net management.
Note 3: 2U and 3U rack maxim 64 port with WDM
Category Application Input Power
—
Output
Power
— ports Power
supply1
Power
supply2
Interfa
ce
Network
Management
EDFA-1500 1 X
－
20 － 64 2 4 2 0
1U/ 2U/3U Rack
Dual power
supply
1: CATV
2: DCM
3.Telecom single channel
4:Telecom DWDM
5:Wide Band single Channel
1-5~+10dBm；
2:+5~+15dBm；
3:0~+10dBm；
4:-8~+10dBm；
5:-35dBm~-25dBm(
Pre)；
6:-25dBm~-10dBm(
Online)；
7:-10dBm~+6dBm(
Booster)；
9:Other
13:13dBm
24:24dBm
1:1 port
2:2 port
4:4 port
8:8 port
16:16 port
32:32 port
64:64 port
1：110VAC
2：220VAC
4：-48VDC
1：110VAC
2：220VAC
4：-48VDC
0: None
1:SC/UPC
2:SC/APC
3:FC/UPC
4:FC/APC
5:LC/UPC
6:LC/APC
0：None
1：SNMP
