Bauer 21107E-B Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference. 22j
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 59300
SAFETY OPERATION MAINTENANCESETUP
Table of Contents
Safety ......................................................... 2
Specifications ............................................. 6
Setup .......................................................... 6
Operation.................................................... 8
Maintenance.............................................. 11
Parts List and Diagram.............................. 14
Warranty .................................................... 16
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INFORMATION
General Tool Safety Warnings
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
1. KEEP GUARDS IN PLACE and in working order.
2. REMOVE ADJUSTING KEYS AND
WRENCHES. Form habit of checking to
see that keys and adjusting wrenches are
removed from tool before turning it on.
3. KEEP WORK AREA CLEAN.
Cluttered areas and benches invite accidents.
4. DON’T USE IN DANGEROUS ENVIRONMENT.
Don’t use power tools in damp or wet locations,
or expose them to rain. Keep work area well lighted.
5. KEEP CHILDREN AWAY. All visitors should
be kept safe distance from work area.
6. MAKE WORKSHOP KID PROOF with padlocks,
master switches, or by removing starter keys.
7. DON’T FORCE TOOL. It will do the job better
and safer at the rate for which it was designed.
8. USE RIGHT TOOL. Don’t force tool or attachment
to do a job for which it was not designed.

Page 3For technical questions, please call 1-888-866-5797.Item 59300
SAFETYOPERATIONMAINTENANCE SETUP
Table A: RECOMMENDED MINIMUM WIRE GAUGE
FOR EXTENSION CORDS
(120 VOLT)
NAMEPLATE
AMPERES
(at full load)
EXTENSION CORD
LENGTH
25′ 50′ 100′ 150′
0 – 6 18 16 16 14
6.1 – 10 18 16 14 12
10.1 – 12 16 16 14 12
12.1 – 16 14 12 Do not use.
9. USE PROPER EXTENSION CORD. Make sure your
extension cord is in good condition. When using
an extension cord, be sure to use one heavy
enough to carry the current your product will draw.
An undersized cord will cause a drop in line voltage
resulting in loss of power and overheating.
Table A shows the correct size to use depending
on cord length and nameplate ampere rating.
If in doubt, use the next heavier gauge.
The smaller the gauge number, the heavier the cord.
10. WEAR PROPER APPAREL. Do not wear
loose clothing, gloves, neckties, rings, bracelets,
or other jewelry which may get caught in moving
parts. Nonslip footwear is recommended.
Wear protective hair covering to contain long hair.
11. ALWAYS USE SAFETY GLASSES. Also use
face or dust mask if cutting operation is dusty.
Everyday eyeglasses only have impact resistant
lenses, they are NOT safety glasses.
12. SECURE WORK. Use clamps or a vise to
hold work when practical. It’s safer than using your
hand and it frees both hands to operate tool.
13. DON’T OVERREACH.
Keep proper footing and balance at all times.
14. MAINTAIN TOOLS WITH CARE. Keep
tools sharp and clean for best and safest
performance. Follow instructions for
lubricating and changing accessories.
15. DISCONNECT TOOLS before servicing;
when changing accessories, such as
blades, bits, cutters, and the like.
16. REDUCE THE RISK OF UNINTENTIONAL
STARTING. Make sure switch is in
off position before plugging in.
17. USE RECOMMENDED ACCESSORIES.
Consult the owner’s manual for recommended
accessories. The use of improper accessories
may cause risk of injury to persons.
18. NEVER STAND ON TOOL.
Serious injury could occur if the tool is tipped or
if the cutting tool is unintentionally contacted.
19. CHECK DAMAGED PARTS. Before further use
of the tool, a guard or other part that is damaged
should be carefully checked to determine that
it will operate properly and perform its intended
function – check for alignment of moving parts,
binding of moving parts, breakage of parts,
mounting, and any other conditions that may
affect its operation. A guard or other part that is
damaged should be properly repaired or replaced.
20. DIRECTION OF FEED.
Feed work into a blade or cutter against the
direction of rotation of the blade or cutter only.
21. NEVER LEAVE TOOL RUNNING UNATTENDED.
TURN POWER OFF. Don’t leave tool
until it comes to a complete stop.

Page 4 For technical questions, please call 1-888-866-5797. Item 59300
SAFETY OPERATION MAINTENANCESETUP
Grounding Instructions
TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT
GROUNDING WIRE CONNECTION READ AND FOLLOW THESE INSTRUCTIONS:
110-120 VAC Grounded Tools: Tools with Three Prong Plugs
1. In the event of a malfunction or breakdown,
grounding provides a path of least resistance for
electric current to reduce the risk of electric shock.
This tool is equipped with an electric cord having an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into a matching
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
2. Do not modify the plug provided – if it will
not fit the outlet, have the proper outlet
installed by a qualified electrician.
3. Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
The conductor with insulation having an outer
surface that is green with or without yellow
stripes is the equipment-grounding conductor.
If repair or replacement of the electric cord or
plug is necessary, do not connect the equipment-
grounding conductor to a live terminal.
4. Check with a qualified electrician or service
personnel if the grounding instructions are
not completely understood, or if in doubt as
to whether the tool is properly grounded.
5. Use only 3-wire extension cords that
have 3-prong grounding plugs and 3-pole
receptacles that accept the tool’s plug.
6. Repair or replace damaged or
worn cord immediately.
Grounding
Pin
125 VAC 3-Prong Plug and Outlet
(for up to 125 VAC and up to 15 A)
7. This tool is intended for use on a circuit that has
an outlet that looks like the one illustrated above in
125 VAC 3-Prong Plug and Outlet. The tool has
a grounding plug that looks like the plug illustrated
above in 125 VAC 3-Prong Plug and Outlet.
8. The outlet must be properly installed and grounded
in accordance with all codes and ordinances.
9. Do not use an adapter to connect
this tool to a different outlet.

Page 5For technical questions, please call 1-888-866-5797.Item 59300
SAFETYOPERATIONMAINTENANCE SETUP
Grinder Tool Safety Warnings
For Your Own Safety Read Instruction
Manual Before Operating Tool Grinder
1. Wear eye protection.
2. Use grinding wheel suitable for speed of grinder.
3. Replace cracked wheel immediately.
4. Always use guards and eye shields.
5. Do not overtighten wheel nut.
6. Use only flanges furnished with the grinder.
7. Adjust distance between wheel and work rest
to maintain 0.125 inch or less separation as the
diameter of the wheel decreases with use.
8. Frequently clean grinding dust from beneath grinder.
9. Wear a full face shield over ANSI-approved
safety goggles during use.
10. Do not grind with side of wheel unless wheel is
specifically designed for that type of grinding.
11. DO NOT OPERATE WITH ANY GUARD
DISABLED, DAMAGED, OR REMOVED. Moving
guards must move freely and close instantly.
12. The use of accessories or attachments not
recommended by the manufacturer may
result in a risk of injury to persons.
13. When servicing use only identical replacement parts.
14. Do not depress the spindle lock when
starting or during operation.
15. Only use safety equipment that has been approved
by an appropriate standards agency. Unapproved
safety equipment may not provide adequate
protection. Eye protection must be ANSI-approved
and breathing protection must be NIOSH-approved
for the specific hazards in the work area.
16. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication.
A moment of inattention while operating power
tools may result in serious personal injury.
17. Industrial applications must follow OSHA guidelines.
18. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
19. Avoid unintentional starting.
Prepare to begin work before turning on the tool.
20. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
21. The warnings, precautions, and instructions
discussed in this instruction manual cannot cover all
possible conditions and situations that may occur.
It must be understood by the operator that
common sense and caution are factors
which cannot be built into this product,
but must be supplied by the operator.
Vibration Safety
This tool vibrates during use. Repeated or
long-term exposure to vibration may cause
temporary or permanent physical injury,
particularly to the hands, arms and shoulders.
To reduce the risk of vibration-related injury:
1. Anyone using vibrating tools regularly or for an
extended period should first be examined by a
doctor and then have regular medical check-ups
to ensure medical problems are not being caused
or worsened from use. Pregnant women or
people who have impaired blood circulation to
the hand, past hand injuries, nervous system
disorders, diabetes, or Raynaud’s Disease should
not use this tool. If you feel any medical or
physical symptoms related to vibration (such as
tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury.
3. Wear suitable gloves to reduce the
vibration effects on the user.
4. Use tools with the lowest vibration when there
is a choice between different processes.
5. Include vibration-free periods each day of work.
6. Grip workpiece as lightly as possible (while still
keeping safe control of it). Let the tool do the work.
7. To reduce vibration, maintain the tool as
explained in this manual. If any abnormal
vibration occurs, stop use immediately.
SAVE THESE INSTRUCTIONS.

Page 6 For technical questions, please call 1-888-866-5797. Item 59300
SAFETY OPERATION MAINTENANCESETUP
Specifications
Electrical Rating 120VAC / 60Hz /5A
Motor No Load Speed 2,000 - 3,400 RPM
Max. Accessory Diameter 8″
Arbor Size 5/8″
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its electrical outlet
before performing any procedure in this section.
Note: For additional information regarding the parts listed in the following pages,
refer to the Assembly Diagram near the end of this manual.
Assembly/Mounting
The two mounting holes in the Base can be used
to attach this Grinder to a stable workbench
using appropriate hardware (sold separately).
1. Install Right Work Rest Support (63) to the
Right Inner Wheel Guard (62). Use two
Hex Bolts (72) and two Flat Washers (73)
to secure it in place. See below.
Work Rest
Support (63)
Flat Washers (73)
Hex
Bolt (72)
Inner Wheel
Guard (62)
2. Install Right Work Rest (64) to the Right Work
Rest Support using Washer (54) and a Work
Rest Locking Knob (65). See below.
Work Rest (64)
Washer (54)
Locking
Knob (65)
Work Rest
Support
3. Install Left Work Rest Support (68) to the Left Inner
Wheel Guard (39). Use two Hex Bolts (72) and
two Flat Washers (73) to secure it in place.
4. Install Left Work Rest (69) to the Left
Work Rest Support using Washer (54)
and a Work Rest Locking Knob (65).
5. Adjust the Work Rests to within 1/16″ of the
Grinding Wheel. To adjust this distance,
loosen Bolts (72) and move Work Rests (64/69).

Page 7For technical questions, please call 1-888-866-5797.Item 59300
SAFETYOPERATIONMAINTENANCE SETUP
6. Attach a Spark Guard (60,67) to each
Inner Wheel Guard (39,62) using two
Bolts, Spring Washers, Flat Washers (59)
on each side. See below.
Spark
Guard (60)
Inner Wheel
Guard
Bolt (59)
7. Adjust each Spark Guard to within 1/16″
(0.0625″) of the Grinding Wheels (32,35)
and tighten each Bolt (59).
8. Attach Eye Shield (56) and Support (55) to the Right
Spark Guard (60) using a Neck Screw (61), Eye
Shield Locking Knob (53) and Flat Washer (54).
9. Attach the other Eye Shield (56) and Support (55) to
the Left Spark Guard (67) using a Neck Screw (61),
Eye Shield Locking Knob (53) and Flat Washer (54).
Eye Shield (56)
Flat Washer (54)
Eye Shield
Locking Knob (53)
Support (55)
Neck Screw (61)
10. Upon completion of assembly, spin wheels by hand
to make sure there is no interference between
guards grinding wheels. If there interference inspect
all fasteners and guards to determine where the
interference is located and adjust accordingly.
Functions
Eye
Shield
LED Light
Work Rest
Work Rest
Support
Wheel
Cover
Power Switch Variable Speed Knob
Grinding
Wheel
Inner Wheel
Guard
Spark
Guard

Page 8 For technical questions, please call 1-888-866-5797. Item 59300
SAFETY OPERATION MAINTENANCESETUP
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Tool Set Up
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its electrical outlet
before performing any procedure in this section.
TO PREVENT SERIOUS INJURY:
DO NOT OPERATE WITH ANY GUARD DISABLED, DAMAGED, OR REMOVED.
Moving guards must move freely and close instantly.
Replacing a Grinding Wheel
1. The Grinding Wheel MUST be:
• rated to at least 2,000 - 3,400 RPM.
• no larger than 8″ (203.2 mm) in diameter.
• fitted with a 5/8″ round arbor hole.
• 1″ thick.
• suitable for edge grinding, not surface grinding.
• dry and clean.
• proven undamaged by inspection and
by the ring-test explained below.
2. Disconnect the Bench Grinder
from the power source.
3. Loosen each Eye Shield Locking Knob and move
both Eye Shields up to access the Work Rests.
4. Remove the Wheel Cover Locking Knobs (36)
holding Wheel Covers (19, 34) to the Bench Grinder.
5. Remove Wheel Covers.
6. Place a small wooden wedge between
the Grinding Wheel and Work Rest to
prevent Wheel from rotating.
7. Remove the right side Grinding Wheel (32)
by turning the Lock Nut (33) counterclockwise
with a wrench (not included).
8. Remove the left side Grinding Wheel (35)
by turning the Lock Nut (20) clockwise
with a wrench (not included).
9. Remove the Outer Flange and remove
Grinding Wheel. Keep the Inner Flange
in position on the Spindle.
10. Closely inspect the Grinding or Cut-
Off Wheel before mounting. Perform a
ring-test on the wheel as follows:
a. Suspend wheel using a dowel or
finger through the arbor hole.
Tap
Wheel
Here
45°45° 45°45°
45°45° 45°45°
Hang
Wheel
from
Dowel
VV
EE
RR
TT
II
CC
AA
LL
CC
EE
NN
TT
EE
RR
b. Tap the flat side of the wheel with a light non-
metallic object, such as a screwdriver handle,
at a point 45° from the vertical center line on
each side of the wheel and 1 – 2 inches from
the edge of the wheel (see Illustration).
c. Rotate the wheel and repeat the test until
the entire wheel has been checked.
d. An undamaged wheel will give a clear
tone. If cracked, there will be a dead
sound and not a clear ring.
11. For wheels with paper gaskets (blotters) or
metal gaskets: Slip the wheel onto the Spindle
with the gasket first. The gasket should be
centered on the wheel and the wheel and
gasket should rest flat against the Flange.
WARNING: To prevent serious injury,
gaskets must be used for all grinding
wheels they are provided with. Gaskets
help prevent grinding wheel damage and
wheel slippage, causes of wheel failure.

Page 9For technical questions, please call 1-888-866-5797.Item 59300
SAFETYOPERATIONMAINTENANCE SETUP
12. Thread the Flange Nut onto the Spindle.
Wrench tighten only enough so that the
wheel is securely held on the spindle.
WARNING: To prevent serious injury, do not overtighten Flange Nut.
Overtightening can damage the wheel, causing wheel failure.
Correcting Wheel Balance
Confirm Wheel balance by spinning the Wheel by
hand and observing the Wheel distance from the
Tool Rest as it spins; variations in this distance
indicates the Wheel balance needs to be corrected:
1. Loosen Nut, and manually (if possible) adjust
the Wheel closer to the Arbor centerline;
hold in place while tightening the Nut.
2. Use a Wheel Dresser to remove the outermost
layer and / or high spots of the Grinding Wheel
to achieve Wheel balance. Follow the Wheel
Dresser Manufacturer’s instructions.
Note: If Wheel still vibrates excessively after the
Wheel has been dressed or adjusted to center
as described above, and Wheel does not exhibit
wobble from side to side at speed, Wheel is
likely out of balance and should be replaced.
Eliminating Wheel Wobble (Side to Side)
Note: Slight side to side wobble may exist as the
Wheel spins up or down from full speed, but this will
not affect normal operation. Follow the instructions
below to remove excessive side to side wobble:
1. Loosen Nut and rotate Outer Flange slightly.
Snug the Nut and rotate the Wheel by
hand to confirm wobble is eliminated.
2. If Wobble still exists, continue repeating step 1 in
slight increments in the same direction, making sure
Wheel is in the same orientation as it was in step 1.
3. If Wobble is still not eliminated, continue holding
Wheel in same orientation as it was in step
1, and rotate Inner Flange 90o. Repeat Steps
1-2. Continue this sequence of Inner and Outer
Flange movements until Wobble is eliminated.
Note: If necessary, a shim made of paper / card
stock may be placed between the Inner or Outer
Flange and Wheel. If excessive Wobble still
exists, consult ″Troubleshooting″ on page 12,
remembering these possible sources of imbalance:
• Wheel is not balanced or is out-of-round.
• Wheel Arbor bushing has excessive play.
• Wheel is of poor quality.
• Inner or Outer Flanges are warped.

Page 10 For technical questions, please call 1-888-866-5797. Item 59300
SAFETY OPERATION MAINTENANCESETUP
Workpiece and Work Area Set Up
1. Designate a work area that is clean and well-lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. Route the power cord along a safe route
to reach the work area without creating a
tripping hazard or exposing the power cord to
possible damage. The power cord must
reach the work area with enough extra length
to allow free movement while working.
3. There must not be hazardous objects, such
as utility lines or foreign objects, nearby that
will present a hazard while working.
4. You must use personal safety equipment including,
but not limited to, ANSI-approved eye and hearing
protection, as well as heavy-duty work gloves.
5. Before beginning work, provide for sparks
and debris that will fly off the work surface.
General Operating Instructions
1. Make sure that the Switch is in the off-position,
then plug in the tool.
2. Adjust the spark arrestor and the work
rest frequently so as to compensate
for wear of the wheel.
3. Keep the distance between the spark arrestor/
work rest and the wheel as small as possible and
in any case not greater than 1/16″. Always adjust
the work rest so that the angle between the work
rest and the accessory is always greater than 85°.
WARNING! Replace the worn wheel when
these gaps are no longer able to be maintained.
Also replace damaged or deeply grooved wheels.
4. Always use the tool with accessories on
both spindles in order to limit the risk of
contact with the rotating spindle.
WARNING! Always use the guard, work
rest, transparent screen and spark arrestor
as required for the accessory(ies).
5. Insert the Safety Key and turn the Power Switch on.
6. Allow the tool to come up to full speed
before touching the wheel.
7. Control the tool’s speed using the Speed
Knob next to Power Switch.
8. Hold the workpiece properly (”using
both hands” if applicable).
9. Apply the workpiece to the wheel,
allowing the tool to operate at full speed.
If the tool bogs down, use lighter pressure.
10. To create a smoother surface,
keep the workpiece moving over the wheel.
11. When finished, turn the Power Switch
off and remove the Safety Key.
WARNING! The tool will restart automatically if stalled.
12. To prevent accidents, turn off the tool and
unplug it after use. Clean, then store the
tool indoors out of children’s reach.

Page 11For technical questions, please call 1-888-866-5797.Item 59300
SAFETYOPERATIONMAINTENANCE SETUP
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and unplug the tool from its electrical outlet
before performing any procedure in this section.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE, inspect the general
condition of the tool. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts,
• damaged electrical wiring, and
• any other condition that may
affect its safe operation.
2. AFTER USE, wipe external surfaces
of the tool with clean cloth.
3. Periodically, blow dust and grit out of the motor vents
using dry compressed air. Wear ANSI-approved
safety goggles and NIOSH-approved
breathing protection while doing this.
4. WARNING! TO PREVENT SERIOUS
INJURY: If the supply cord of this power
tool is damaged, it must be replaced only
by a qualified service technician.
Accessory Storage and Handling
1. Handle accessories carefully to prevent
dropping or bumping. Do not use wheels
that have been dropped or bumped.
2. Store accessories in shelves, racks, boxes, or
drawers. Keep storage area dry and above
freezing. Any grinding wheels exposed to humidity
or freezing temperatures must not be used.

Page 12 For technical questions, please call 1-888-866-5797. Item 59300
SAFETY OPERATION MAINTENANCESETUP
Troubleshooting
Problem Possible Causes Likely Solutions
Tool will not start. 1. Cord not connected.
2. No power at outlet.
3. Tool’s thermal reset
breaker tripped (if equipped).
4. Internal damage or wear. (Carbon
brushes or switch, for example.)
1. Check that cord is plugged in.
2. Check power at outlet. If outlet is unpowered,
turn off tool and check circuit breaker. If breaker
is tripped, make sure circuit is right capacity
for tool and circuit has no other loads.
3. Turn off tool and allow to cool.
Press reset button on tool.
4. Have technician service tool.
Tool operates slowly. 1. Excess pressure applied to workpiece.
2. Extension cord too long or
cord diameter too small.
1. Decrease pressure, allow tool to do the work.
2. Eliminate use of extension cord. If an extension
cord is needed, use one with the proper
diameter for its length and load. See Extension
Cords in GROUNDING section.
Performance
decreases over time.
Carbon brushes worn or damaged. Have qualified technician replace brushes.
Excessive noise
or rattling.
Internal damage or wear. (Carbon brushes or
bearings, for example.)
Have technician service tool.
Overheating. 1. Forcing tool to work too fast.
2. Blocked motor housing vents.
3. Motor being strained by long or
small diameter extension cord.
1. Allow tool to work at its own rate.
2. Wear ANSI-approved safety goggles and NIOSH-
approved dust mask/respirator while blowing
dust out of motor using compressed air.
3. Eliminate use of extension cord. If an extension
cord is needed, use one with the proper
diameter for its length and load. See Extension
Cords in GROUNDING section.
Tool does not
grind, sand or
brush effectively.
1. Disc accessory may be loose on Spindle.
2. Disc accessory may be damaged,
worn or wrong type for the material.
1. Be sure disc accessory is of correct
dimension and Flange Arbor Nut is tight.
2. Check condition and type of disc accessory.
Use only proper type of disc
accessory in good condition.
Grinding Wheels
do not spin true
1. Too much play in the Grinding
Wheel bushings.
2. Inner and / or Outer Flanges are
warped, damaged, or worn.
3. Arbor Nut is too tight.
1. Replace the bushings or install
a new Grinding Wheel.
2. Replace Inner and / or Outer Flanges.
3. Loosen Arbor Nut. Do not overtighten.
Excessive Grinding
Wheel vibration
1. Grinding Wheels not balanced.
2. Too much play in the Grinding
Wheel bushings.
3. Inner and / or Outer Flanges are
warped, damaged, or worn.
4. Incorrect type / size Wheel(s).
5. Worn Bearings in Bench Grinder.
1. Balance Grinding wheels and correct side
to side wobble as described in ″Replacing
a Grinding Wheel″ and ″Eliminating Wheel
Wobble (Side to Side)″ on page 9.
2. Replace the bushings or install
a new Grinding Wheel.
3. Replace Inner and / or Outer Flanges.
4. Use correct type / size Wheel(s) as described under
″Replacing a Grinding Wheel″ on page 8
5. Have qualified technician replace bearings.
Follow all safety precautions whenever diagnosing or servicing
the tool. Disconnect power supply before service.

Page 13For technical questions, please call 1-888-866-5797.Item 59300
SAFETYOPERATIONMAINTENANCE SETUP
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Replacement parts may be available for this item.
Visit harborfreight.com/parts for a list of in stock parts. Reference UPC 193175465481.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 14 For technical questions, please call 1-888-866-5797. Item 59300
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
Parts List
Part Description Qty
1 Phillips Screw + Flat Washer 2
2 Rubber Feet 4
3 Base Cover 1
4 Circuit Board 1
5Phillips Tapping Screw 2
6 Circuit Board Cover 1
7 Hex Bolt +Spring Washer 2
8 Screw + Flat Washer+Spring Washer 2
9 Capacitor 1
10 Base 1
11 Wire Clamp Plate 1
12 Phillips Screw 4
13 Lead Wire Clamp 1
14 Lead Wire With Plug 1
15 LED Light 1
16 Flat Washer 1
17 Hex Thin Nut-Fine Tread 1
18 Hex Flange Nut 4
19 Left Wheel Cover 1
20 Nut 1
21 Phillips Screw 1
22 Wiring Fixing Button 1
23 Hex Flange Nut 1
24 Potentiometer 1
25 Switch Plate 1
26 Knob Washer 1
27 Variable Speed Knob 1
28 Switch Guard Board 1
29 Phillips Screw 2
30 Self-Locking Switch 1
31 Flange 4
32 Grinding Wheel 1
33 Nut 1
34 Right Wheel Cover 1
35 Grinding Wheel 1
36 Wheel Cover Knob 6
37 Outer Locking Washer 2
38 Lead Wire Bushing 3
39 Left Inner Wheel Guard 1
40 Phillips Screw + Flat Washer 4
Part Description Qty
41 Left End Cover 1
42 Wave Type Spring Washer 1
43 Deep Groove Ball Bearing 2
44 Stator 1
45 Rotor 1
46 Right End Cover 1
47 Optical Coupler 1
48 Phillips Screw 2
49 Feedback Board 1
50 Hex Socket Set Screw 1
51 Right Guard Cover 1
52 Hex Flange Nut 8
53 Eye Shield Locking Knob 2
54 Flat Washer 4
55 Eye Shield Support 2
56 Eye Shield 2
57 Eye Shield Block Plate 2
58 Phillips Screw 4
59 Hex Bolt+Spring Washer+Flat Washer 4
60 Right Spark Guard 1
61 Neck Screw 2
62 Right Inner Wheel Guard 1
63 Right Work Rest Support 1
64 Right Work Rest 1
65 Locking Knob 2
66 Phillips Screw + Spring Washer 6
67 Left Spark Guard 1
68 Left Work Rest Support 1
69 Left Work Rest 1
70 Flat Washer 6
71 Spring Washer 6
72 Hex Bolt 4
73 Flat Washer 4
74 Locking Washer 1
75 nut 2
76 LED Transformer 1
77 Spring Washer 2
78 Spring Washer 4

Page 15For technical questions, please call 1-888-866-5797.Item 59300
SAFETYOPERATIONMAINTENANCE SETUP
Assembly Diagram

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
