Bauknecht GSI 4743/1 SW User manual

SERVICE Whirlpool Europe
Customer Services
Model GSI 4743/1 SW
Version 8546 743 01320 Page
Technical data 2 - 4
Spare part list 5 - 6
Exploded view 7 - 8
Circuit diagram 9
Program diagram 10
Text/Legend 11 - 17
Family Global B4
Service Manual
Dishwasher
integratable
GSI 4743/1 SW
GSI 4743/1 SW
This documentation is only intended for qualified technicians who are aware of the respec-
tive safety regulations.
Date: 05.05.1998 Subject to modification
Document-No.: 4812 718 13281

SERVICE
05.05.1998 / Page 2 GSI 4743/1 SW Whirlpool Europe
Doc. No: 4812 718 13281 8546 743 01320 Customer Service
Technical data
Dimension
Height 82.0-87.0 cm
Width 59.5 cm
Depth 57.5 cm
Weight 52.7 kg
Wooden door
Thickness min. 16 mm
Thickness max. 20 mm
Width min. 592 mm
Width max. 595 mm
Height min. 515 mm
Height max. 600 mm
Weight max. 5.5 kg
Max. stick out over lower
edge of appliance door 92 mm
Electronic boards
Service boards see spare part list
Serial boards
UB 4619 720 77941
DB 4619 720 77951
CB 4619 720 80681
Succession of programs
Programs see program diagram
Succession 1-4a-5a-6a
Alarms
Refill salt
Refill rinse aid
Program information
Start indicator
Pre wash
Main wash
Drying
End
Volume (normal program)
Water Volume Level
Regeneration 0.3 l 15 mm
Back rinse 3x 1.0 l 68 mm
Prewash 4.8 l 122 mm
Main wash 4.5 l 121 mm
Intermediate rinse 1 4.0 l 120 mm
Clear rinse 4.0 l 120 mm
Safety / overflow 8.5 l 141 mm
Measuring the level
Remove the coarse sieve, put in a measuring
meter into the sump, measure the hight of the
water level.
Detergent max.
Pre-wash 10 cm
Main-wash 45 cm
Rinse aid 125 cm
6 Dosage steps 1 - 6 ml
Water softener
Saltcontainer 2 kg
Resin container 900 cm
Regeneration dosage 300 cm
Water pressure
Inlet pressure 0.3-10 bar
Spray pump pressure 0.4 bar
Rotations
Spray pump motor 2800 RPM
Drain pump motor 3000 RPM
Spray arm lower 20 - 40 RPM
Spray arm upper 25 - 35 RPM
Ceiling rotor 45 - 65 RPM
Flow rates / Inlet volume
Flow meter (at 0.3 bar
= quantity 1.1 l/min) 208 lmp/l
Spray pump ~ 70 l/min
Drain pump 16 l/min
Pump height max. 1.1 m
Inlet valve 4.5 l/min
Spray arm lower 33 l/min
Sprayarm upper 27 l/min
Ceiling rotor 10 l/min
Electrical data
Base data
Voltage 220/230 V
Frequency 50 Hz
Total power 2.0-2.2 kW
Fuse 10 A

SERVICE Whirlpool Europe GSI 4743/1 SW 05.05.1998 / Page 3
Customer Service 8546 743 01320 Doc. No: 4812 718 13281
Technical data
Motor
Spray pump motor
Voltage 220/230 V
Power consumption 160 W
HI 81 Ω
HA 44 Ω
Capacitor 4 F
Drain pump motor
Voltage 220/240 V
Power consumption 30 W
Resistance 146 Ω
Heating
1 Element system
Voltage 220/230 V
Power consumption 1.87/2.04 kW
Resistance 24.5 Ω
Heating speed ~ 2.0 ˚C/min
Temperature on surface ~ 115 ˚C
Safety thermostat
self reset 85 ˚C
Potentiometer
Position 0 0.0 kΩ
Position 1 0.5 kΩ
Position 2 1.0 kΩ
Position 3 1.4 kΩ
Position 4 1.8 kΩ
Position 5 2.3 kΩ
Position 6 2.6 kΩ
Water valves
Single valve at inlet hose
Voltage 220/240 V
Frequency 50/60 Hz
Resistance 3,76 kΩ
Regenerating valve
Voltage 220/240 V
Frequency 50/60 Hz
Resistance 3.13 kΩ
Coil of dispenser
Voltage 220/240 V
Frequency 50/60 Hz
Resistance 1.5 kΩ
Reedcontact
flow meter
salt control
rinse aid control

SERVICE
05.05.1998 / Page 4 GSI 4743/1 SW Whirlpool Europe
Doc. No: 4812 718 13281 8546 743 01320 Customer Service
Technical data
NTC
15 ˚C 75 kΩ
20 ˚C 62 kΩ
30 ˚C 43 kΩ
40 ˚C 28 kΩ
50 ˚C 19 kΩ
60 ˚C 13 kΩ
70 ˚C 9 kΩ
80 ˚C 6 kΩ
85 ˚C 5 kΩ
Regeneration
Volume 300 cm
Position 0
after wash cycles 10
water hardness 0-5 ˚dh
0-0.9 mmol/l
0-9 ˚Fh
Position 1
after wash cycles 8
water hardness 6-10 ˚dh
1-1.8 mmol/l
10-18 ˚Fh
Position 2
after wash cycles 6
water hardness 11-15 ˚dh
1.9-2.7 mmol/l
19-27 ˚Fh
Position 3
after wash cycles 4
water hardness 16-21 ˚dh
2.8-3.7 mmol/l
28.37 ˚Fh
Position 4
after wash cycles 3
water hardness 22-28 ˚dh
3.8-5.0 mmol/l
38-50 ˚Fh
Position 5
after wash cycles 2
water hardness 29-35 ˚dh
5.1-6.3 mmol/l
51-63 ˚Fh
Position 6
after wash cycles 1
water hardness 36-60 ˚dh
6.4-10.7 mmol/l
64-107 ˚Fh
Salt consumption for regeneration 77 g
Number of cycles with 2 kg salt 26

SERVICE Whirlpool Europe GSI4743/1SW 05.05.1998 / Page 5
Customer Service 8546 743 01320 Doc. No: 4812 718 13281
Spare part list
Model GSI 4743/1 SW
Service No. 854674301320
Version 854674301320
Pos. No. 12NC Code Description
003 0 4812 440 19382 Traverse
004 0 4812 440 18952 Drip tray assy
004 1 4812 401 18402 Holder
011 0 4812 505 18369 Foot long
011 1 4812 528 98004 Shaft flexible
011 2 4812 528 78032 Slide disc f.foot
011 3 4812 535 98054 Gear
011 4 4812 528 98001 Roll f.foot
022 0 4812 440 19398 Side panel left
022 1 4812 440 19397 Side panel right
022 2 4812 440 18953 Spacer
024 0 4812 440 19401 Panel, rear
040 1 4812 417 18774 Hinge left
040 2 4812 417 18773 Hinge right
044 0 4812 492 38362 Spring f.door
044 1 4812 492 38365 Spring f.door
047 0 4812 404 48591 Brake f.door
047 1 4812 401 18397 Band,brake
047 2 4812 404 68023 Hook
053 0 4812 440 88884 Plinth
103 0 4812 440 18986 Door outer
105 0 4812 404 48611 Fastener door
105 2 4812 505 68004 Clip
120 0 4812 440 19456 Door,inner
120 1 4812 440 18969 Batten
130 0 4812 417 58361 Tilt lock
131 0 4812 401 18416 Hook lock
175 3 4812 466 68532 Batten
191 0 4812 466 68534 Gasket door
192 0 4812 466 68467 Gasket, door lower
200 0 4812 418 18207 Container cpl.
241 0 4812 458 18267 Basket upper inclined
241 1 4812 458 18324 Holder cups right white
241 2 4812 535 78036 Bearing
241 3 4812 528 88068 Wheel,basket upper (set)
241 6 4812 458 18333 Holder glasses
241 8 4812 466 68553 Spacer cap set
242 0 4812 458 18919 Basket lower cpl.
242 1 4812 528 88069 Wheel,basket lower
242 4 4812 466 48059 Striker
243 0 4812 458 18272 Basket cutlery
261 0 4819 462 38271 Rail telescope, inner
261 1 4819 404 48819 Cap rail
261 2 4812 462 78995 Cap rail ahead
263 0 4819 520 18013 Ball cage cpl.
263 1 4812 520 48001 Ball Niro 8 D
265 0 4812 404 48599 Basket adjustm. cpl.
265 2 4812 404 48589 Grip basket adjustment
301 0 4812 453 79513 Control panel BK
303 1 4812 460 38072 Plate,handle BK
305 0 4812 440 19374 Batten BK
305 1 4819 502 18241 Screw synthetic
305 2 4819 505 18191 Nut
305 3 4812 440 19366 Batten adjustable 5mm BK
305 4 4812 440 19367 Batten adjustable 10mm BK
Pos. No. 12NC Code Description
305 5 4812 440 19375 Batten adjustable 7,5mm BK
322 0 4812 453 79649 Insert panel BK
331 0 4812 413 58901 Knob program cpl. BK
332 0 4812 410 28532 Push button cap BK
332 3 4812 410 28568 Push button cap ON/OFF BK
350 0 4812 276 58077 Display board (DB)
400 0 4812 361 58126 Motor + spraypump cpl.
405 0 4812 360 18371 Spray pump
405 1 4819 515 28158 Gasket
420 0 4812 121 18132 Capacitor
421 0 4812 121 18161 Interf.filter
430 0 4812 360 18357 Pump,draining
430 1 4812 466 68506 Shaft seal
450 0 4812 259 28684 Heating element
480 0 4812 321 28385 Cable harness set
480 1 4812 321 28371 Cable
480 2 4812 321 28383 Cable 6poles
480 3 4812 401 18418 Protector f.wiring
490 0 4819 321 18136 Cable,mains 2m
490 1 4812 321 28367 Strain relief
521 0 4812 214 78194 Control board (CB)
531 0 4812 273 18055 Switch waterhardness
531 1 4812 273 18056 Wheel,fingertip
575 0 4812 281 28361 Regen.valve
583 0 4812 271 28355 Switch diaphragm
616 0 4812 281 18047 Contact,reed salt
616 1 4812 271 58161 Contact,reed rinsing agent
620 0 4812 218 38045 User board (UB)
621 0 4812 276 18237 Power switch ON/OFF
623 0 4812 271 38356 Microswitch
633 0 4812 271 38355 Microswitch
680 0 4812 418 68129 Combidosage
680 1 4812 466 68495 Gasket
681 1 4812 466 68497 Gasket
681 2 4812 440 18976 Flap
682 0 4812 466 68496 Gasket
691 0 4812 282 68012 Feeler NTC
700 0 4812 530 28804 Hose, inlet aqua stop 4,2m
700 0 4812 530 28848 Hose, inlet aqua stop 2m
700 1 4812 480 48019 Sieve
700 2 4812 520 58002 Gasket set
701 1 4812 310 18153 Yoke clamp set
701 2 4819 401 18423 Holder
710 0 4812 418 68128 Monoblock
710 2 4819 310 38536 Nut threaded ring set
710 3 4819 466 69562 Gasket set
714 0 4812 462 78993 Threaded cap
714 2 4812 440 18963 Cabinet non-return flap
716 0 4812 418 68147 Reg.dosage
716 1 4812 466 68475 Gasket
716 2 4812 462 78994 Cover
721 1 4812 360 68058 Spray arm lower cpl.
721 2 4812 466 68491 Gasket 25x2,3B
721 3 4812 466 68558 Gasket 30x3,0
721 4 4812 440 19455 Flange

SERVICE
05.05.1998 / Page 6 GSI4743/1SW Whirlpool Europe
Doc. No: 4812 718 13281 8546 743 01320 Customer Service
Spare part list
Model GSI 4743/1 SW
Service No. 854674301320
Version 854674301320
Pos. No. 12NC Code Description
722 0 4812 360 68044 Spray arm upper
722 2 4812 360 68057 Hub upper inclined cpl.
723 0 4812 360 68049 Spray arm ceiling
723 1 4812 466 68483 Gasket
723 2 4812 404 48597 Clip,fix spray arm
723 3 4812 505 18362 Screwed joint
726 0 4812 530 28786 Tube
726 1 4812 530 28787 Tube
726 2 4812 505 18358 Nut
726 3 4812 466 68512 Gasket
726 4 4812 462 79633 Centering
743 0 4812 511 48171 Capacitor
743 1 4812 530 28102 Hose, inlet
743 3 4812 505 18364 Nut
743 4 4812 530 28807 Hose 9x1,5x270+10
743 7 4812 466 68514 Gasket
751 0 4812 418 18205 Water collector
751 1 4812 418 18203 Water guide
751 2 4812 440 19454 Fastener frame
755 0 4812 530 28849 Bend
755 2 4812 530 48148 Tray,leak
756 0 4812 360 58099 Floater
761 0 4812 480 58082 Sieve fine
761 2 4812 418 18204 Cover sieve
762 0 4812 480 58084 Microfilter
763 0 4812 480 58083 Sieve coarse
781 0 4812 530 28737 Hose,draining
781 1 4819 530 28286 Sleeve hose
781 2 4819 492 68405 Clip f.non-return valve
781 3 4812 281 28364 Flap non-return
783 5 4812 530 78028 Distributor
783 6 4812 530 28796 Hose 10x3x180+10
791 0 4812 532 68067 Gasket
791 2 4812 530 58093 Gasket
791 4 4812 466 68503 Gasket
791 5 4812 466 68504 Gasket
794 1 4819 530 58032 Gasket 20x2,5
901 0 4812 401 18191 Strap 017,8
901 1 4812 401 18424 Strap 050,0
901 2 4812 401 18422 Strap W1-1 AL 32-50
901 5 4812 401 48573 Strap 028,6
901 6 4812 401 48574 Strap 038,1
901 7 4812 401 18427 Strap 031,6
901 8 4812 401 18075 Strap 20-32/9 mm
902 1 4812 466 78361 Fastener f.buildt-in models
902 2 4812 404 78241 Holder
904 2 4812 462 79635 Cover WH 3,5x5
910 1 4812 502 18394 Screw 3,5x14-H
910 2 4812 502 18363 Screw 4,0x12-H
910 3 4812 502 18389 Screw NIRO A2
910 4 4812 502 18386 Screw 3,5x8-TORX T15
910 5 4812 502 18393 Screw 3,5x9-1 Tx15
910 7 4812 502 38132 Screw DIN 965
964 1 4812 466 68511 Gasket housing upper
993 1 4812 466 78362 Foil protection
Pos. No. 12NC Code Description
993 2 4812 404 48609 Socket wreng foot
993 5 4822 532 80216 Funnel salt

SERVICE Whirlpool Europe GSI 4743/1 SW 05.05.1998 / Page 7
Customer Service 8546 743 01320 Doc. No: 4812 718 13281
Exploded view

SERVICE
05.05.1998 / Page 8 GSI 4743/1 SW Whirlpool Europe
Doc. No: 4812 718 13281 8546 743 01320 Customer Service
Exploded view

SERVICE Whirlpool Europe GSI 4743/1 SW 05.05.1998 / Page 9
Customer Service 8546 743 01320 Doc. No: 4812 718 13281
Circuit diagram
C1 Capacitor
CB Control board
DB Display board
DPM Drain pump motor
DD Cleaning agent dosage
DON Additional sensor
DR Final rinse dosage
DS Door switch
FM Flow meter
HEWI Heating
IF Interference filter
LS6 Water leakage switch
L Line
MS Main switch
NTC Thermostat temp. sensor
N Neutral
PRG Plug to program
RV Water hardness switch
RE2 Heating relay
RR SA Reed relay salt
RR RA Reed relay rinsaid
SAB Sprayarm blocked
SPM Sprayarm motor
THS Safety thermostat
THS 2 Fuse
TBL Power supply terminal
TL Winding protective
contact
UB User board
VM Fan ventilator
WV1 Water inlet valve
WV2 Water regenerating valve
WI Water indicator
ZW Zone washing
00 black
66 blue
88 grey
99 white

SERVICE
05.05.1998 / Page 10 GSI 4743/1 SW Whirlpool Europe
Doc. No: 4812 718 13281 8546 743 01320 Customer Service
Program diagram

SERVICE Whirlpool Europe GSI 4743/1 SW 05.05.1998 / Page 11
Customer Service 8546 743 01320 Doc. No: 4812 718 13281
Text/Legend

SERVICE
05.05.1998 / Page 12 GSI 4743/1 SW Whirlpool Europe
Doc. No: 4812 718 13281 8546 743 01320 Customer Service
Text/Legend

SERVICE Whirlpool Europe GSI 4743/1 SW 05.05.1998 / Page 13
Customer Service 8546 743 01320 Doc. No: 4812 718 13281
Text/Legend

SERVICE
05.05.1998 / Page 14 GSI 4743/1 SW Whirlpool Europe
Doc. No: 4812 718 13281 8546 743 01320 Customer Service
Text/Legend

SERVICE Whirlpool Europe GSI 4743/1 SW 05.05.1998 / Page 15
Customer Service 8546 743 01320 Doc. No: 4812 718 13281
Text/Legend

SERVICE
05.05.1998 / Page 16 GSI 4743/1 SW Whirlpool Europe
Doc. No: 4812 718 13281 8546 743 01320 Customer Service
Text/Legend

SERVICE Whirlpool Europe GSI 4743/1 SW 05.05.1998 / Page 17
Customer Service 8546 743 01320 Doc. No: 4812 718 13281
Text/Legend
