Bauknecht TRAK 6230 User manual

5019 407 00204
Very
Wet
Load
Wet
Load Load
Fabric
programmes
& Drying levels
Drying options
Anti-Crease
Prevents laundry from
creasing
Gentle
Reduces drying
intensity
(recommended
for delicate items)
Indicative drying
times (in minutes) kg
80’
110’ 60’ 90’ 3.0 5.0 Cotton
Max 5 kg
Extra dry
65’
90’ 50’ 75’ 3.0 5.0 Cupboard dry *
55’
75’ 40’ 65’ 3.0 5.0 Iron dry *
30’
40’ 20’ 35’ 1.0 2.5 Synthetics
Max 2.5 kg
Extra dry
20’
35’ 15’ 30’ 1.0 2.5 Cupboard dry *
15’
30’ 10’ 25’ 1.0 2.5 Iron dry
- - - Airing Laundry is aired and refreshed for
30 minutes without heating. -
- - - Time
Completes drying or dries single
items (suitable for all fabrics). -
QUICK REFERENCE GUIDE
Please also carefully read the
“Instructions for Use”.
Cotton
Synthetics
Airing
Time
Starts the drying cycle.
The drying indicator lamp
is blinking during the
selection phase.
Press to confirm the final
selection.
Filter The indicator lamp lights up
when the filter needs cleaning.
Clean the filter at the end of
every cycle.
Overdry protection The indicator lamp lights up
when a humidity controlled
program is selected, to indicate
the working protection
function.
Function is not active in time
controlled programs and
Airing.
PROGRAMME SEQUENCE INDICATORS
Overdry
Protection
Drying
End
Anti-
Crease
Lit: Overdry protection is
working
Blinking: programme
selected; cycle need to
be started.
Lit: programme is
running.
Lit: End of programme.
Lit: Anti-Crease is
running.
* Test programmes according IEC 61121.
TRAK 6230
GB

5019 407 00204
1. Checkthatallfasteningsare closedand
that pockets are empty.
2. Turn the articles inside out.
3. Place laundry loosely in the drum to
make sure it doesn’t become tangled.
Sort laundry as follows:
A) By care symbols
(on the collar or inside seam):
Suitable for tumble drying
Tumble drying with reduced
drying intensity only. Press
Gentle button.
Do not tumble dry
B) By amount and thickness/weight
Whenever the load to be dried exceeds
dryer capacity, separate laundry according
to weight (e.g. towels from thin
underwear).
C) By type of fabrics
Cotton/linen: Towels, cotton jersey, bed
and table linen made of cotton or linen.
Synthetics/Easy Care: blouses, shirts,
overalls, etc. made of polyester or
polyamide, as well as cotton/synthetic
mixes.
D) By drying level
• Sort into: iron dry, cupboard dry, etc.
Do not tumble dry: Woollens, silk, nylon
stockings, delicate embroidery, fabrics
withmetallicdecorations,bulkyitemssuch
as sleeping bags, etc.
Important: only use specific indicated
dryer-safe additives and rinse items
that have been treated with stain remover
thoroughly in plenty of water before
drying. Only use specific indicated
dryer-safe plastic items and never dry
rubber or articles contaminated with
vegetable oil in the dryer.
Programme and Options:
• To select a programme, turn the
programme selector knob. The drying
indicator lamp is blinking, indicating
that the cycle needs to be started.
• To select an option, press the
corresponding button. The indicator
lamp in the button confirms that a
selection has been made.
• Press the button again to cancel the
option.
1. Having selected the desired
programme and options, press the
Start button.
Ifthelaundryisnotremovedattheend
of the drying cycle, an automatic anti-
crease cycle will operate for maximum
60 min. The drum rotates at regular
intervals, preventing the laundry from
creasing.
Anti-Crease protection re-distributes
laundry in the drum.
2. On completion of the programme, set
the programme selector knob to
position “0”.
When changing the programme during
the drying cycle, the dryer stops. The
drying indicator lamp is blinking.
To operate the new programme, press the
Start/Pause button again.
To interrupt the dryer during operation
1. Set the programme selector knob to
Airing.
2. Press the Start button.
Wait at least 5 minutes before opening
thedoortoallowthedryertocooldown.
For your safety the programme stops
automatically if you open the door.
3. To restart, after door opening, close
the door and press the Start/Pause
button again.
Clean the lint filter at the end of every
drying cycle:
1. Open the door.
2. Pull the filter upwards.
3. Remove lint using a soft brush or your
fingertips.
4. Push the filter back into place.
If a fault occurs, before contacting our
After-Sales Service, make the following
checks to try and remedy the problem:
Drying takes too long / laundry is not
dry enough:
• Was the correct programme selected?
• Was the inserted laundry too wet
(Washing machine spin speed less than
800 rpm)?
• Isthelintfilterdirty(filterindicator lamp
on)?
The dryer does not operate:
(after a power failure and/or
interruption to the mains supply,
always press the Start button).
• Is the plug properly inserted into the
mains electricity socket?
• Is there a power failure?
• Has the fuse blown?
• Is the door well closed?
• Has the programme been selected?
• Has the Start/Pause button been
pressed?
Lint filter indicator lamp light on:
• Is the lint filter clean?
• Is the vent hose blocked?
If, after carrying out the above checks
the malfunction persists or appears
again, turn the dryer off and call our
After-SalesService(refer toguarantee).
Please specify:
• The nature of the fault.
• The dryer type and model.
• The service code (the number after the
word Service on the adhesive rating
plate) on the right-hand side when the
door is open.
• Your full address and phone number.
PREPARING THE LAUNDRY SELECTING A PROGRAMME & OPTIONS
STARTING & COMPLETING A
PROGRAMME
CHANGING A PROGRAMME
INTERRUPTING A PROGRAMME
DAILY MAINTENANCE & CLEANING
TROUBLESHOOTING GUIDE
AFTER-SALES SERVICE
