Baumalight CXC530 User manual

CXC530 And CXC550 Brush Cutt
OPERATOR’S MANUAL
Issue Date: April 2022

1 INTRODUCTION ��������������������������������������������������������������������������������������������������������������������������������� 1
1�1 Overview�������������������������������������������������������������������������������������������������������������������������������������� 1
1�2 Intended Use And Foreseeable Misuse������������������������������������������������������������������������������������ 1
2 SAFETY������������������������������������������������������������������������������������������������������������������������������������������������ 2
2�1 Safety Alert Symbol And Safety Words������������������������������������������������������������������������������������ 2
2�2 Operational Hazards������������������������������������������������������������������������������������������������������������������� 2
Prepare for Emergencies ����������������������������������������������������������������������������������������������������������� 3
Replace Safety Signs ����������������������������������������������������������������������������������������������������������������� 3
Do Not Allow Riders ������������������������������������������������������������������������������������������������������������������� 3
Lower Operating Speed ������������������������������������������������������������������������������������������������������������� 4
Avoid Rollover ���������������������������������������������������������������������������������������������������������������������������� 4
Avoid Powerlines & Underground Utilities ������������������������������������������������������������������������������ 4
Detach Cutter Safely������������������������������������������������������������������������������������������������������������������� 4
Hazards From Modifying Equipment ���������������������������������������������������������������������������������������� 4
2�3 Maintenance Hazards����������������������������������������������������������������������������������������������������������������� 6
3 SAFETY SIGNS����������������������������������������������������������������������������������������������������������������������������������� 8
3�1 CXC530 Decals ��������������������������������������������������������������������������������������������������������������������������� 8
3�2 CXC550 Decals ������������������������������������������������������������������������������������������������������������������������� 10
4 OPERATION �������������������������������������������������������������������������������������������������������������������������������������� 12
4�1 Preparation For Use ����������������������������������������������������������������������������������������������������������������� 12
��������������������������������������������������������������������������������������������12
4�2 Hydraulic Connections ������������������������������������������������������������������������������������������������������������ 12
4�3 Machine Components �������������������������������������������������������������������������������������������������������������� 13
4�4 Attach Brush Cutter������������������������������������������������������������������������������������������������������������������ 13
4�5 Transporting������������������������������������������������������������������������������������������������������������������������������ 14
4�6 First Time User Tips ����������������������������������������������������������������������������������������������������������������� 14
4�7 Field Operation ������������������������������������������������������������������������������������������������������������������������� 15
4�8 Detach Brush Cutter����������������������������������������������������������������������������������������������������������������� 16
5 SERVICE AND MAINTENANCE������������������������������������������������������������������������������������������������������ 17
5�1 Daily ������������������������������������������������������������������������������������������������������������������������������������������� 17
5�2 First Hour Of Use���������������������������������������������������������������������������������������������������������������������� 17
5�3 Every Four Hours ��������������������������������������������������������������������������������������������������������������������� 18
5�4 Every Week ������������������������������������������������������������������������������������������������������������������������������� 18
5�5 Replace Cutting Blades ����������������������������������������������������������������������������������������������������������� 18
5�6 Motor Shaft Seal ����������������������������������������������������������������������������������������������������������������������� 19
6 TROUBLESHOOTING ���������������������������������������������������������������������������������������������������������������������� 20
BAUMALIGHT ATTACHMENT WARRANTY������������������������������������������������������������������������������������� 21
TABLE OF CONTENTS
ii

1 INTRODUCTION
Congratulations on your choice of a Baumalight
Brush Cutt to complement your brush cutting
operation. This equipment has been designed and
manufactured to meet the needs of a discriminating
buyer for efcient brush cutting.
The unique rotor design reduces the brush
to mulch. Controlling the brush cutter is done
completely from the excavator providing the ability
for precise control and operator comfort.
Excavator must have suitable safety equipment
properly installed.
Safe, efcient and trouble free operation of your
Brush Cutt requires that you and anyone else
who will be operating or maintaining the Brush
Cutt, read and understand the Safety, Operation,
Maintenance and Troubleshooting information
contained within the Operator’s Manual.
This manual covers the Baumalight CXC530 and
CXC550 Brush Cutt. Use the Table of Contents as
a guide to locate required information.
Keep this manual handy for frequent reference
and to pass on to new operators or owners. Call
your Baumalight dealer, distributor or the factory
if you need assistance, information or additional
copies of the manuals.
OPERATOR ORIENTATION - The directions left,
right, front and rear, as mentioned throughout this
manual, are as seen from the driver’s seat and
facing in the direction of travel.
1�1 Overview
The cutter is designed to be used by an experienced
operator. Operator must be trained in the safe
operation of a excavator and hazards related to
using the brush cutter and the safe use of the
brush cutter for the intended purpose. Operators
will require personal protective equipment to
reduce the risk from some hazards that cannot be
completely eliminated or controlled by the design
of the cutter.
Care is required to ensure that the brush cutter will
not come in contact with metallic objects, stones or
other materials.
Brush cutters are not designed for use in
hazardous atmospheres where there is a risk
of re or explosion due to ammable gases or
vapors. Use in hazardous, explosive atmospheres
is prohibited. Serious injury or death of the operator
or bystanders may be caused if cutter is misused.
Misuse may also cause damage to the machine
carrying the cutter.
1�2 Intended Use And Foreseeable
Misuse
1

2 SAFETY
You must read, understand and follow the
instructions given by the excavator manufacturers,
as well as the instructions in this manual.
The safety information in this manual is denoted
by the safety alert symbol:
^
This symbol means ATTENTION! BECOME
ALERT! YOUR SAFETY IS INVOLVED!
The level of risk is indicated by the following signal
words:
^^ DANGER
DANGER - Indicates a hazardous
situation, which, if not avoided, WILL
result in death or serious injury�
^ WARNING
WARNING - Indicates a hazardous
situation, which, if not avoided, could
result in death or serious injury�
^ CAUTION
CAUTION - Indicates a hazardous
situation, which, if not avoided, could
result in minor or moderate injury�
NOTICE
NOTICE - Indicates a situation that could
result in damage to the equipment or
other property.
2�1 Safety Alert Symbol And Safety
Words
2�2 Operational Hazards
^ WARNING
Prevent death or serious injury�
Read and understand this manual before
operating cutter�
Always stop engine and remove key
before leaving operators seat�
Never allow anyone near the cutter
during operation�
Travel at a safe speed�
^ WARNING
Prevent death or serious injury from
moving parts�
Moving parts can crush and dismember�
Do not operate without guards and
shields in place�
Disconnect and lockout power source
before adjusting or servicing�
^ WARNING
Use cutter only for the designed
applications�
Any other use may result in personal
injury, damage to equipment and may
void the warranty�
2

^ WARNING
Prevent death or serious injury�
Verify cutter is locked to excavator
before operation or transport�
^ WARNING
Wear proper safety glasses, goggles,
debris�
Carefully read all safety messages in this manual
and on equipment safety signs. Keep safety signs
in good condition and replace missing or damaged
safety signs.
New equipment components and repair parts must
include the current safety decal.
Learn how to properly operate equipment.
NEVER operate or work around this equipment
without proper instruction, while fatigued or under
the inuence of alcohol, prescription or non-
prescription medication or if feeling ill.
Keep your equipment in proper working condition.
Know the regulations and laws that apply to you
and your industry. This manual is not to replace
any regulations or laws. Additional information
may be found at: www.asae.org or www.osha.gov.
If you do not understand any part of this manual,
contact Baumalight at 866-820-7603.
Prepare for Emergencies
• Be prepared in case of emergencies.
• Keep a re extinguisher and rst aid kit close
to the machine.
• Keep emergency phone numbers close to
your phone.
• Know your address so emergency services
can locate you if an emergency arises.
Replace Safety Signs
• Replace missing or damaged safety signs.
• Safety signs are identied in Section 3 of this
manual.
• Replacement safety signs are available from
your Baumalight dealer.
Do Not Allow Riders
• NEVER lift or carry anyone on cutter.
• NEVER use cutter as a work platform.
• NEVER allow passengers on cutter.
3

Lower Operating Speed
Keep cutter low and move at slow speeds on rough
or uneven terrain.
Lower operating speed while operating in heavy
conditions.
Avoid Rollover
The equipment may rollover, resulting in death or
serious injury. To help prevent rollover:
• Travel at a slow speed.
• Avoid sharp turns & sudden movement on
slopes.
• Carry cutter close to the ground.
• Avoid holes, ditches and other obstructions
which may cause equipment to rollover.
• Balance load so weight is evenly distributed
and load is stable.
• Use caution when operating on slopes and do
not operate on excessively steep slopes.
• Do not exceed load capacity of equipment.
Avoid Powerlines & Underground
Utilities
^ DANGER
Prevent electrocution�
Death or serious injury can result if
equipment comes near or contacts
power lines�
Electrocution can occur without direct
contact�
• Check clearance before raising equipment.
• Have local utilities locate and mark under
ground wires, cables, pipelines and other
hazards before operation.
DO NOT leave the operator’s seat if any part of the
equipment contacts electric lines or cables.
Detach Cutter Safely
Detach cutter on a rm and level surface. Be sure
people, livestock and pets are clear of machinery.
Raised Attachment
^ WARNING
Crushing hazard�
Raised, unsupported cutter can fall,
resulting in death or serious injury�
Never enter the area under a raised
cutter�
A raised cutter can lower unexpectedly, resulting in
death or serious injury.
NEVER enter area under a raised cutter.
Lower cutter to ground, engage parking brake,
shut off engine and remove key before servicing.
Hazards From Modifying Equipment
Do not make any alterations to your cutter. Altering
may cause your equipment to be unsafe and may
void the manufacturers’ warranty.
4

Avoid Loud Noise
^ WARNING
Prolonged exposure to loud noise can
cause impairment or loss of hearing�
Wear a suitable hearing protective device
such as earmuffs or earplugs to protect
against objectionable or uncomfortable
loud noises�
Stay Clear Of Moving Parts
^ WARNING
Moving parts can cause serious injury
or death�
Keep shields and guards in place at all
times� DO NOT operate without shields
and guards�
Avoid Wood Dust Inhalation
^WARNING
Drilling, sawing, sanding or machining
wood products can expose you to wood
dust, a substance known to the State of
California to cause cancer�
Avoid inhaling wood dust or use a dust
mask or other safeguards for personal
protection� For more information go to
www�P65Warnings�ca�gov/wood�
^WARNING
Wear an approved dust mask or
respirator�
Follow local, state and federal
regulations�
5

2�3 Maintenance Hazards
Before servicing, park machine on a rm and
level surface, set parking brake and place a “Do
Not Operate” tag on control panel. Read and
understand this manual. If you do not understand
any part of the manual, contact Baumalight at 866-
820-7603.
Always wear face and/or eye protection, safety
shoes, and other protective equipment appropriate
for the job.
Do not make unauthorized modications. Contact
Baumalight at 866-820-7603. Before you weld,
cut/drill holes, or make any other modications.
Always use Baumalight replacement parts.
^ WARNING
Moving parts can crush and cut�
Keep clear of moving components�
Follow lockout procedure before
servicing�
^ WARNING
Crushing hazard�
Before performing inspections, service
or maintenance:
•
• Engage parking brake�
• Turn engine off and remove key�
• Place “Do Not Operate” tag on
control panel�
^ WARNING
Entanglement hazard�
Keep clear of moving components�
Wear proper protective equipment
appropriate for the job�
^ WARNING
Burn hazard�
Hot and high pressure hydraulic oil�
Allow oil to cool before servicing�
^WARNING
Drilling, sawing, sanding or machining
wood products can expose you to wood
dust, a substance known to the State of
California to cause cancer�
Avoid inhaling wood dust or use a dust
mask or other safeguards for personal
protection� For more information go to
www�P65Warnings�ca�gov/wood�
^WARNING
Wear an approved dust mask or
respirator�
Follow local, state and federal
regulations�
6

7

3 SAFETY SIGNS
The two and four panel safety decals are pictorial
and have a yellow background. The panel with a
triangle indicates the potential hazard. The panel
without a triangle indicates how to avoid the
hazard.
If any of the decals are missing, are damaged, or
if you do not understand the decal, please contact
your dealer.
A
B
C
E
D
E
E
A. D005126 ^ WARNING - Pressurized uid
hazard. Pressurized uids can penetrate the
skin. Do not check for leaks with your hands.
Keep back a safe distance when pressurized.
D005253
B. D005262 ^WARNING - P65 warning
information.
WARNING: This product can expose you to chemicals
including 1,3-Butadiene and lead, which are known to the state of
California to cause cancer and birth defects or other reproductive
harm. For more information go to www.P65Warnings.ca.gov.
D005262
3�1 CXC530 Decals
8

C. D005125 ^WARNING - Read and understand
safety signs on the machine and operating
instructions in this manual before operating
machine.
D005252
D. D005517 ^WARNING - Remove key before
servicing.
D005517
E. D005223 ^WARNING - Rotating blade
hazard. Keep back 75 m while machine
is operating. Wait for blade to stop before
approaching machine.
D005255
75 M
9

The two and four panel safety decals are pictorial
and have a yellow background. The panel with a
triangle indicates the potential hazard. The panel
without a triangle indicates how to avoid the
hazard.
If any of the decals are missing, are damaged, or
if you do not understand the decal, please contact
your dealer.
A
B
C
E
D
E
E
E
E
A. D005126 ^ WARNING - Pressurized uid
hazard. Pressurized uids can penetrate the
skin. Do not check for leaks with your hands.
Keep back a safe distance when pressurized.
D005253
B. D005262 ^WARNING - P65 warning
information.
WARNING: This product can expose you to chemicals
including 1,3-Butadiene and lead, which are known to the state of
California to cause cancer and birth defects or other reproductive
harm. For more information go to www.P65Warnings.ca.gov.
D005262
3�2 CXC550 Decals
10

C. D005125 ^WARNING - Read and understand
safety signs on the machine and operating
instructions in this manual before operating
machine.
D005252
D. D005517 ^WARNING - Remove key before
servicing.
D005517
E. D005223 ^WARNING - Rotating blade
hazard. Keep back 75 m while machine
is operating. Wait for blade to stop before
approaching machine.
D005255
75 M
11

^WARNING
Drilling, sawing, sanding or machining
wood products can expose you to wood
dust, a substance known to the State of
California to cause cancer�
Avoid inhaling wood dust or use a dust
mask or other safeguards for personal
protection� For more information go to
www�P65Warnings�ca�gov/wood�
^WARNING
Wear an approved dust mask or
respirator�
Follow local, state and federal
regulations�
Although the cutter has been carefully inspected
and checked prior to shipment from manufacturer,
it is recommended that the unit be thoroughly
inspected.
Check all bolts for tightness and remove all
shipping tags, bags, skids, and blocking.
Remove any masking materials afxed during
painting. Inspect equipment to verify that
nameplates and all safety warning, caution signs
and decals provided with the equipment are in
place and clearly visible.
Visually inspect the cutter before each start up.
Check for loose or missing parts and any damage
that may have occurred during moving or shipping.
Review all excavator pre-start instructions, and
verify that all recommended steps and procedures
have been followed.
4 OPERATION
4�1 Preparation For Use
4�1�2 Excavator Adapter
1. Install excavator adapter (A) on either side of
machine mounting bracket (B) as shown.
2. Install and tighten mounting hardware.
Tightening the mounting hardware will pull the
anges into place.
4�2 Hydraulic Connections
^ WARNING
skin�
Disconnect and lock out power source
before disconnecting and/or connecting
hydraulic hoses�
Baumalight does not provide the hydraulic
hoses that connect brush cutter motor and
motor case drain to excavator�
The installer must determine a safe routing for
the hydraulic hoses to prevent damage�
Installer provided hoses are not covered by the
Baumalight warranty�
12

^ WARNING
To prevent injury or machine damage
put transmission in park�
Never position yourself between
excavator and cutter�
Only experienced and properly trained
operator may operate excavator and
cutter�
1. Read and follow all safety instructions.
2. Attach excavator to cutter. See excavator
operator’s manual.
3. Connect hydraulic hoses. Verify hydraulic
hoses are clear of pinch areas and moving
parts.
4. Move to a clear open area to test functions.
4�4 Attach Brush Cutter
A. Push Bar
B. Hydraulic Hose Holder
C. Excavator Mounting Rails
D. Hydraulic Motor
E. Rotor
F. Cutting Blade
A
B
C
E
F
A
D
4�3 Machine Components
13

1. Verify all reectors and Slow Moving Vehicle
(SMV) sign are visible.
2. Verify hydraulics to cutter are disengaged.
3. Raise cutter slightly off the ground.
4. Travel at a reasonable and safe speed.
4�6 First Time User Tips
Operate all functions in a clear area low speed to
get a good feel for the controls before you actually
move into any brush.
Choose low density brush and move into it slowly,
do not expect to get the rst area done fast.
Move cutter into brush slowly until you have a
better feel how much the unit can take.
Use push bar to push brush or small trees over
and allow blades to contact lower portion of brush
and mulch it or cut it off. The rest of the plant will
be mulched as the machine moves through the
working area.
Each operator must experiment to nd a technique
that works for them in their application.
Although it is best to mulch when it is dry, the
machine works well in wet conditions. However,
you must travel slower to do the same quality
mulching. It may be necessary to clean the
machine more frequently to prevent clogging.
^ WARNING
Always stop engine and remove key
before leaving operators seat�
4�5 Transporting
^WARNING
Drilling, sawing, sanding or machining
wood products can expose you to wood
dust, a substance known to the State of
California to cause cancer�
Avoid inhaling wood dust or use a dust
mask or other safeguards for personal
protection� For more information go to
www�P65Warnings�ca�gov/wood�
^WARNING
Wear an approved dust mask or
respirator�
Follow local, state and federal
regulations�
14

4�7 Field Operation
^ WARNING
Prevent serious injury or death caused
by unexpected movement:
1� Park on a level surface�
2� Lower cutter to ground�
3� Engage parking brake�
4� Shut off engine and remove key�
^ WARNING
Keep shields and guards in place at all
times� Do not operate without shields
and guards�
^ WARNING
Never operate brush cutter when other
people are in the vicinity�
Debris can be thrown from cutting area�
Do not allow riders�
^WARNING
Drilling, sawing, sanding or machining
wood products can expose you to wood
dust, a substance known to the State of
California to cause cancer�
Avoid inhaling wood dust or use a dust
mask or other safeguards for personal
protection� For more information go to
www�P65Warnings�ca�gov/wood�
^WARNING
Wear an approved dust mask or
respirator�
Follow local, state and federal
regulations�
1. Inspect work area to verify there are no rocks,
metal or other debris before cutting.
2. Attach cutter to excavator.
^ WARNING
Prevent serious injury or death�
Excavator must be equipped with a
forestry guard to protect the operator�
3. Set engine speed to low idle and engage cutter.
4. Slowly increase engine speed to high idle.
5. Verify cutter is operating smoothly and move
cutter into brush. When mulching standing
brush, angle cutter up and away from cab. This
will protect the operator and carrier from ying
debris. The rotor should not be visible from the
operator compartment. Attempting to mulch
top-down by raising the rotor horizontally will
result in the cutter throwing debris towards the
operator.
15

Correct Angle For Standing Brush
Incorrect Raised Position For Standing Brush
^ WARNING
Moving parts can crush and cut�
Keep clear of moving components�
Lockout excavator before clearing jams�
6. If cutter stalls, stop movement, slightly raise
cutter and allow rotor to regain speed. Slow
movement into brush to prevent further stalling.
7. Rotor will continue to spin freely when hydraulic
power is disengaged. The rotor can be slowed
by setting rotor against the soft ground and
letting the friction stop the rotor. Do not set
rotor on hard ground, stone or concrete. The
cutter can be set on the ground and the rotor
will gradually slow to a stop.
4�8 Detach Brush Cutter
^ WARNING
Prevent death or serious injury caused
by unexpected movement:
8� Park on a level surface�
9� Lower cutter to ground�
10� Engage parking brake�
11� Shut off engine and remove key�
1. Park excavator on a level surface.
2. Lower cutter to the ground.
3. Shut off engine and remove key.
4. Disconnect hydraulic hoses.
5. Detach excavator from cutter. See excavator
Operator’s Manual.
16

5 SERVICE AND
MAINTENANCE
^WARNING
Drilling, sawing, sanding or machining
wood products can expose you to wood
dust, a substance known to the State of
California to cause cancer�
Avoid inhaling wood dust or use a dust
mask or other safeguards for personal
protection� For more information go to
www�P65Warnings�ca�gov/wood�
^WARNING
Wear an approved dust mask or
respirator�
Follow local, state and federal
regulations�
5�1 Daily
^ WARNING
Prevent serious injury or death caused
by unexpected movement:
1� Park on a level surface�
2� Lower cutter to ground�
3� Engage parking brake�
4� Shut off engine and remove key�
Inspect the unit for buildup of dirt, mulch and
debris. Clean out as needed.
5�2 First Hour Of Use
^ WARNING
Prevent serious injury or death caused
by unexpected movement:
1� Park on a level surface�
2� Lower cutter to ground�
3� Engage parking brake�
4� Shut off engine and remove key�
Rotor bolts (A) must be retighten after the rst hour
of use on a new cutter. After initial check, check
bolt tightness before each startup.
A
17

5�3 Every Four Hours
^ WARNING
Prevent serious injury or death caused
by unexpected movement:
1� Park on a level surface�
2� Lower cutter to ground�
3� Engage parking brake�
4� Shut off engine and remove key�
Check cutting edge (A) of blades for wear and
damage. Keep blades in good condition. Unit will
cut faster and remaining blades will last longer if
broken or worn blades are replaced.
Rotation A
A
Note: Parts breakdown can be found on
Baumalight’s website. www.baumalight.com
5�4 Every Week
Verify cutting blade bolt cotter pins are in place
and not damaged.
5�5 Replace Cutting Blades
^ WARNING
Prevent serious injury or death caused
by unexpected movement:
1� Park on a level surface�
2� Lower cutter to ground�
3� Engage parking brake�
4� Shut off engine and remove key�
1. Park excavator and cutter on a level surface.
2. Lower cutter to the ground.
3. Shut off engine and remove key.
4. Inspect blades for damage and wear.
5. Remove cotter pin, castle nut, bolt (A) and
blade (B).
6. Reverse blade or install new blade if necessary.
7. Install blade (B), bolt (A) and castle nut. Tighten
to 170 lb/ft (230 Nm) of torque. Install cotter
pin.
A
B
Note: Parts breakdown can be found on
Baumalight’s website. www.baumalight.com
18
This manual suits for next models
1
Table of contents
Other Baumalight Brush Cutter manuals
Popular Brush Cutter manuals by other brands

Lawn-King
Lawn-King LK PBT3043 AUTO Translation of the original instructions for use

Husqvarna
Husqvarna 143R-II Operator's manual

GGP ITALY SPA
GGP ITALY SPA ETR 750 Operator's manual

Zenoah
Zenoah SGCZ2600 owner's manual

Swisher
Swisher Versa-RC owner's manual

Mitox
Mitox 260L User manual, maintenance instructions and spare parts
