Baumatic GELATO1SS User manual

a
GELATO1SS 1.5 Litre
freestanding automatic ice
cream and sorbet maker

USER MANUAL FOR YOUR BAUMATIC
GELATO1SS
1.5 Litre freestanding
automatic ice cream and
sorbet maker
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference, for
you or any person not familiar with the operation of the appliance.
DD 30/04/10
2

3
Contents
Environmentalnote 4
Important safety information 5 – 6
Specifications of your GELATO1SS 7
Descriptionoftheappliance 7
Using your Baumatic ice cream maker 8-11
Beforeswitchingon 8
Prior to making ice cream 8 – 9
Makingicecream 9
Removal and storage of ice cream 10
Extendedcoolingfunction 11
Adjustingsettings 11
Installation 12-13
Electrical connection (UK only) 12
Electrical connection (European countries) 13
Positioning 14
Contact details 14-15
Guarantee 14

Environmental note
Note: Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.
4

Important safety information
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If
you are unsure of any of the information contained in
this booklet, please contact the Baumatic Advice Line.
IMPORTANT: Any installation work must be
carried out by a qualified electrician or
competent person.
Use of the appliance
oYour appliance is only designed to be used in the
home. It is suitable for making ice cream and
sorbets. If it is used for any other purpose or it is
not used correctly, then Baumatic Ltd. will accept
no liability for any damage that is caused.
oAltering the specification of the appliance must not be attempted
for reasons of safety.
Before using your appliance
oCheck the appliance for any signs of transport damage. If you
notice any damage, then you should not connect your appliance
to your mains supply and should contact your retailer.
Refrigerant
oYour appliance contains R134a refrigerant, which is a natural gas
that does not contain CFCs that can damage the environment.
However it is a flammable substance, therefore care should be
taken:
During the transportation and installation of the
appliance, make sure that the refrigeration pipework
does not get damaged.
If it does become damaged then sources of ignition
and open flames should be avoided. Also the room
that the appliance is situated in should be thoroughly
ventilated.
5
oDo not place any objects on top of the appliance,
as this may damage the table top.

Child safety
6
oPackaging material should be kept away from
children.
oChildren should not be allowed to touch the
controls or play with the appliance.
General safety
oDo not pull on the power supply cable to remove the plug from
your mains supply socket.
oDo not pull out or insert the plug with wet hands.
oDo not attempt to use your appliance outdoors or
any place where it is likely to come into contact
with the elements.
oBefore cleaning the appliance or performing
maintenance work, ensure that the appliance has been
disconnected from your mains supply.
oAlways ensure that the location where you are installing your
appliance is free of stored items such as papers and other
flammable materials.
oNever block the ventilation openings of the appliance on its
exterior.
oIt is vital to keep your appliance well ventilated.
Service
You should not attempt to repair the appliance
yourself, as this could cause injury or a more serious
malfunction. If your appliance is not functioning
correctly, then you should contact the Customer Care
Department.

Specifications of your GELATO1SS
Congratulations on purchasing a Baumatic ice cream maker
oPush button/control knob operation
oCapacity: 1.5 litres
oChurning and chilling time: 10 – 60 minutes
oTimer dial
oON/OFF button
oTransparent cover
oRemovable ice cream bowl
oFixed bowl with mixing arm
oStainless steel exterior
Dimensions of appliance
Height: 245 mm
Width: 402 mm
Depth: 281 mm
Description of the appliance
7

Using your Baumatic ice cream maker
Before switching on
oMake sure that it has been installed by a suitably qualified
person, as per the information contained in Baumatic’s
installation instructions.
oAfter delivery, wait for a couple of hours before connecting the
appliance to your mains supply. This will allow any oil from the
compressor that may have been disturbed during the
transportation process to settle.
oThe outside of the appliance and the removable accessories
contained within it, should be cleaned with a solution of liquid
detergent and water.
oThe interior of the appliance should be cleaned
with a solution of sodium bicarbonate dissolved in
lukewarm water. The interior and accessories
should be thoroughly dried, after the cleaning
process has been completed.
oThere can be an odour when you first switch on the appliance. It
will lessen when the appliance is used.
Prior to making ice cream
oYour appliance MUST be placed on a flat surface, to ensure that
the built in compressor operates properly.
oThe appliance MUST have 20 cm of space each side of it and the
ventilation slot should not be obstructed.
oIMPORTANT: The appliance MUST NOT be connected to your
mains supply until all of the steps below have been followed.
oThoroughly wash all parts of the appliance that will come into
contact with ingredients and ice cream (including the fixed bowl,
removable bowl, mixing arm and transparent cover).
oPrepare the required recipe ingredients, by following your own
recipe or from one contained in this user manual.
oPlace the prepared ingredients into the removable bowl.
IMPORTANT: There is no need to freeze the ingredients prior to
placing them inside the ice cream maker. The appliance has a
built in compressor which will do this.
8

9
oIMPORTANT: DO NOT fill the removable bowl more than 80%
full, as the contents will expand during the cooling process and
there is the chance of the bowl overflowing.
oPlace the removable bowl inside of the fixed bowl and then place
the mixing arm inside of the removable bowl. The mixing arm
should just rest inside the centre of the bowl, with the circle side
facing upwards.
oInsert the mixing arm into the socket that is found in the base of
the motor section. IMPORTANT: You must ensure that the
mixing arm is securely fixed into the socket.
oPlace the transparent cover on the top of the appliance, making
sure that it is firmly fixed in position. Finally make sure that the
small lid is securely in place on the transparent cover.
Making ice cream
oConnect your appliance to your mains supply, making sure that
the electrical connection information contained in this booklet
has been read and followed.
oPress the ON/OFF button and then set the required time by
turning the timer dial.
oA 40 minute time setting will give soft textured ice cream, the
default operating time of 50 minutes will give medium textured
ice cream and a 60 minute time setting will give hard textured
ice cream.
oThe LCD display will show the temperature progressively
decreasing as the appliance begins to function. It will indicate
that it has entered its cooling phase by showing the temperature
it’s reached.
oWhen the countdown period ends, the cooling process will end
automatically and an audible signal will sound.
oSwitch the appliance off using the ON/OFF button and unplug the
appliance from your mains supply.

Removal and storage of ice cream
10
IMPORTANT: Before attempting to remove the
ice cream, YOU MUST disconnect the appliance
from your mains supply.
oTake out the removable bowl from the fixed bowl.
oThe removable bowl should not be used for long term storage of
ice cream in a freezer. The maximum time period that the
removable bowl should be placed in a freezer for is 30 minutes.
If the removable bowl is placed in a freezer for longer than this,
it may be damaged.
oIf you wish to store the ice cream for longer than 30 minutes,
then you should use a plastic scoop or wooden spoon to remove
the ice cream. IMPORTANT: DO NOT use a metal scoop or
spoon to remove the ice cream; otherwise the removable bowl
will get scratched.
oOnce removed, you should place the ice cream in a plastic,
airtight container. We do not recommend that ice cream made
in this appliance is stored for a prolonged period. After 1 – 2
weeks, the structure of the ice cream will deteriorate and the
fresh taste will be lost.
oYou should ensure that the freezer is maintaining a temperature
of at least -18°.
oYou should mark the date that you prepared the ice cream on
the lid of the container.
oIf you partially or fully defrost the ice cream, then DO NOT
refreeze it.
oThoroughly wash all parts of the appliance that came into
contact with the ingredients and ice cream (including the fixed
bowl, removable bowl, mixing arm and transparent cover).

11
Extended cooling function
oAfter the ice cream making process has completed, if the
appliance is not switched off within 10 minutes, then it will enter
the extended cooling function.
oThe extended cooling function will keep the ice cream frozen and
stop it from defrosting.
oThe extended cooling function will run for a maximum of 1 hour,
after which the appliance will enter stand-by mode. After 1 hour,
the ice cream will no longer remain frozen.
Adjusting settings
oIf you wish to stop the ice cream making process before the
countdown time has elapsed, you should press the ON/OFF
button.
oWhilst a countdown time is in progress, it is possible to adjust
the countdown time by turning the timer dial to your required
setting.
oWhen the appliance has finished a countdown time, if the ice
cream is not to your required consistency then it is possible to
extend the cooling time. Turn the timer dial to your required
additional countdown time.

Installation
Electrical connection (UK only)
oYour ice cream maker comes supplied with a 13 amp plug fitted.
If in future you need to change the fuse in this plug, then a 13
amp ASTA approved (BS 1362) fuse must be used.
The wiring in the mains
lead is coloured as follows:
Brown- Live
Blue- Neutral
Green and yellow- Earth
oAs the colours of the wires in the appliance’s mains lead may not
correspond with the coloured markings identifying the terminals
in your spur box, please proceed as follows:-
The brown wire must be connected to the terminal marked “L”
(live), or coloured red.
The blue wire must be connected to the terminal marked “N”
(neutral), or coloured black.
The green and yellow wire must be connected to the terminal
marked “E” (earth), or by the earth symbol, or coloured green
and yellow.
oWhen the connection is completed, no stray strands or cut wire
should be present. The cord clamp must be secured over the
outer sheath.
12

13
Electrical connection (European countries)
Your ice cream maker comes supplied with a European plug.
oAs the colours of the wires in the appliance’s mains lead may not
correspond with the coloured markings identifying the terminals
in your spur box, please proceed as follows:-
The brown wire must be connected to the right hand terminal.
The blue wire must be connected to the left hand terminal.
oWhen the connection is completed, no stray strands or cut wire
should be present. The cord clamp must be secured over the
outer sheath.
Positioning
oYour appliance should not be located in direct sunlight or
exposed to continuous heat or extremes of temperature (e.g.
next to a radiator or boiler). If this is not feasible, then you
should install an insulation plate between the appliance and the
adjacent heat source.
oYou should check whether there is an electrical socket available,
which will be accessible after your appliance is installed.
oPlace the appliance flatly and firmly on a solid base.
oThe appliance MUST have 20 cm of space each side of it and the
ventilation slot should not be obstructed.

IMPORTANT: If your appliance appears not to be
operating correctly, then you should disconnect it
from your mains supply and then contact
Baumatic Customer Care on telephone number
[phone] for guidance.
* If you are not based in the UK, then please refer to the
telephone number for the relevant Baumatic country on the
next page for guidance.
DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF.
IMPORTANT: Baumatic Ltd. operates a policy of continuous
improvement and reserves the right to adjust and modify its
products without prior notification.
14

15
United Kingdom
Baumatic Ltd.,
Baumatic Buildings,
6 Bennet Road,
Reading, Berkshire
RG2 0QX
United Kingdom
Sales Telephone
[phone]
Sales Fax
[phone]
Customer Care Telephone
[phone]
Customer Care Fax
[phone]
Spares Telephone
[phone]
Advice Line Telephone
[phone]
E-mail:
[email protected]k
[e-mail]
[e-mail]
[email protected]
Website:
www.baumatic.co.uk
Republic of Ireland
Service Telephone
1-890 812 724
Spares Telephone
091 756 771
Czech Republic
Baumatic CR spol s.r.o.
Průmyslová zóna Sever 696
460 11 Liberec 11
Czech Republic
[phone]
www.baumatic.cz
Slovakia
Baumatic Slovakia, s.r.o.
Galvániho 7/D
Slovakia
[phone]
Germany
Baumatic Gmbh
Lilienthalstrasse 1
320 52 Herford
Deutschland
[phone]
www.baumatic.de
Italy
Baumatic Italia S.R.L.
Via Galvani N.3
35011 Campodarsego (PD)
[phone]
www.baumatic.it
Holland
Baumatic Benelux B.V.
Grindzuigerstraat 22
1333 MS ALMERE
Nederland
[phone]
www.baumatic.nl

16
