Baxi 600 Combi 2 Manual

These instructions include the Benchmark Commissioning Checklist & Boiler Fiche and should be left
with the user for safe keeping. They must be read in conjunction with the Flue Installation Guide.
United Kingdom
en
600 Combi 2
24 - 30 - 36
For LPG conversion see p.48.
Installation and Service Manual & Boiler Fiche
High-efficiency wall-hung condensing gas boiler

Dear Customer,
Thank you very much for buying this appliance.
Please read through the manual carefully before using the product, and keep it in a safe place for later reference. In order to
ensure continued safe and efficient operation we recommend that the product is serviced regularly. Our service and customer
service organisation can assist with this.
We hope you enjoy years of problem-free operation with the product.
