baxter PW1E User manual

Baxter Mfg, a Division of ITW FEG, LLC • 19220 State Route 162 East • Orting, WA 98360-9236
Phone: [phone] • Fax: [phone]
www.baxtermfg.com
Model Number: ___________
Serial Number: ___________
Date of Installation: ___________
Operator
Manual
FORM 36756 (Feb. 2019)
PROOFER &
RETARDER/PROOFER
MODELS
PW1E
PW1S
PW2E
PW2S
PW3S
RPW1S
RPW2E
RPW2S

– 2 –
©ITW FEG, 2019
TABLE OF CONTENTS
GENERAL................................................................................................................................................ 3
INSTALLATION....................................................................................................................................... 3
OPERATION ........................................................................................................................................... 4
Proong .............................................................................................................................................. 4
Retarding ............................................................................................................................................ 4
Advanced Controls - Standard Proofer............................................................................................... 5
Advanced Controls - Retarder/Proofer .............................................................................................. 7
Operating parameter setup............................................................................................................... 14
Customized Operation...................................................................................................................... 16
Select Proofer Model VIA Bootloader ............................................................................................... 17
Update the Proofer Firmware VIA Bootloader .................................................................................. 18
Control Board Power Up................................................................................................................... 19
LCD Contrast Adjustment ................................................................................................................. 19
MAINTENANCE.................................................................................................................................... 20
Light Bulbs........................................................................................................................................ 20
Shut Down ........................................................................................................................................ 20
Cleaning ........................................................................................................................................... 20
Service and Parts Information .......................................................................................................... 20
TROUBLESHOOTING ......................................................................................................................... 20

– 3 –
OPERATION AND CARE OF
PROOFERS & RETARDER/PROOFERS
SAVE THESE INSTRUCTIONS
GENERAL
The Proofer and Retarder/Proofer cabinets proof racks of dough products under controlled temperatures
and humidity prior to baking. There are several to choose from. The standard proofers are equipped to proof
dough only. Retarder/Proofers gradually thaw frozen dough. The retarders operate like a refrigerator by
keeping the interior cool, which also provides an excellent environment for storing dough prior to proong.
The cooler temperature slows the yeast fermentation process and prevents the dough from rising. The
Automatic Retard/Proof feature adds the exibility of programming times to retard and automatically proof
in one operation.
The Proofers and Retarder/Proofers o󰀨er a unique modular design, allowing for a wide variety of sizes
in standard models. They can be ordered as one-, two-, or three-section roll-in models. All Proofer and
Retarder/Proofer cabinets have easy-to-clean stainless steel interior and exterior panels.
It is suggested that you thoroughly read this manual and carefully follow the instructions provided.
INSTALLATION
Proofers and Retarder/Proofers must be installed by authorized trained service technicians.

– 4 –
OPERATION
The following pages cover the operation procedures for the various control options of the Proofer
and Retarder/Proofer cabinets. The control panels come in two congurations: standard proofer and
retarder/proofer.
PROOFING
Controlled temperature and humidity in the proofer promotes yeast fermentation, which generates gas and
causes the dough to rise. Proong takes from 45 to 60 minutes, depending on the product. A temperature
setting of 95°F (35°C) and humidity at 85% are typical but will vary slightly, depending on the product
being proofed. To dry-proof, set the humidity to the lowest setting. The chart below is only a guide. Ask
your dough supplier for technical product reports to set up your own chart.
RETARDING
The retard feature gradually thaws frozen dough. Set the temperature between 36°F and 38°F (2°C
to 3°C) for best results. Thawing frozen dough at retarder temperatures takes approximately 6 hours
minimum. Retarding slows the yeast fermentation process, reduces gas formation and inhibits the dough
from rising. This also provides an excellent environment for storing dough products up to 48 hours by
keeping the dough interior cool. Dough should not be refrozen after thawing.
It is likely that condensation will form if product is placed directly into the proofer from the retarder. For
best results, allow the product to reach room temperature before placing into the proofer.
Units equipped with auto mode will slowly and automatically bring the proofer up to temperature without
removing the product from the unit.
Product Proong
Temperature % Humidity Proof Time Minutes
Rolls 95°F (35°C) 85% 55 min.
French Crust Bread 14 oz. 90°F (32°C) 90% 45 min.
French Crust Bread 10 oz. 90°F (32°C) 85% 45 min.
Bagels 85°F (29°C) 85% 50 min.
Croissants 75°F (24°C) 70% 30 min.

– 5 –
ADVANCED CONTROLS - STANDARD PROOFER
PROOF MODE
ON/OFF - Press to start/stop the proof mode.
TEMP UP or DOWN ARROW - Press to set the
temperature.
TEMP WINDOW - Displays the current
temperature.
%HUMIDITY UP or DOWN ARROW - Press to
set the humidity.
%HUMIDITY WINDOW - Displays the current
humidity.
NOTE: When the actual humidity is less than 26%,
the humidity window will show 25%. When the actual
humidity is higher than 25%, the humidity window will
show the actual humidity. To view the temperature or
humidity set point, touch the up or down arrow once.
TIMER NUMBER
UP ARROW - Press to select a timer
(1 through 4).
START/STOP - Press to start/stop the selected
timer.
TIMERS UP or DOWN ARROW - Press to set
the desired time on the selected timer.
TIMERS WINDOW - Displays the hours and
minutes remaining on the selected timer.
TEMP
%HUMIDITY
ON
ON
ON
OFF
TIMER
TIMERS
NUMBER
ON
START
STOP

– 6 –
Proof
The proof feature allows thawed dough to rise by gradually increasing the temperature and humidity of
the dough.
1. Press the ON/OFF button to start the proof mode.
The ON/OFF Indicator Light is lit.
2. Enter the desired temperature by pressing the UP
or DOWN arrow next to the TEMP window. The
small ON dot located in the lower right corner of
the TEMP window will light if the actual temperature
is below the set temperature and the unit is calling
for heat.
3. Enter the desired humidity by pressing the UP or
DOWN arrow next to the %HUMIDITY window.
4. Enter the desired time. (See Entering Time below.)
NOTE: For best results, allow the proofer to reach set temperature and humidity before putting product
in. Proof at lower temperatures rather than higher temperatures.
Entering Time
There are four individual timers that can be used for timed operations. Timers run independently and will
not start or stop an operation.
1. Press the UP arrow button next to the TIMER NUMBER window to select one of four timers. The
number will be displayed in the TIMER NUMBER window.
2. Enter the desired time by pressing the UP or DOWN
arrow next to the TIMERS window.
3. Press the START/STOP button to activate the timer.
The small ON dot located in the lower right corner
of the TIMER NUMBER window blinks to indicate
the timer is running.
4. When the timer expires, a beeper sounds and
the timer number ashes in the TIMER NUMBER
window. Press START/STOP to silence the beeper.
5. If more than one timer is needed, select another timer and enter the desired time. To begin the
timing countdown on the timer you want to run, select the timer and press the START/STOP button.
The START/STOP button only starts or stops the timing operation for the timer shown in the TIMER
NUMBER window.
6. When multiple timers are in use, the timer number will ash on the screen as each one times out.
7. Previous time settings remain in the timers until changed.
TEMP
%HUMIDITY
ON
ON
ON
OFF
TIMER
TIMERS
NUMBER
ON
START
STOP
TEMP
%HUMIDITY
ON
ON
ON
OFF
TIMER
TIMERS
NUMBER
ON
START
STOP

– 7 –
ADVANCED CONTROLS - RETARDER/PROOFER
The Retarder/Proofer has several options to choose from the control panel.
• Manual Proof Operation
• Manual Retard Operation
• Automatic Retard and Proof Operation
START-UP:
ON/OFF - Turn on/o󰀨 the setup mode.
TEMPERATURE UP or DOWN ARROW - Press to
set the temperature level.
TEMPERATURE WINDOW - Displays the current
temperature. Displays set temperature when being
adjusted.
HUMIDITY UP or DOWN ARROW - Press to set the
humidity level.
HUMIDITYWINDOW - Displays the current humidity.
Displays set humidity when being adjusted.
TIMER NUMBER ARROW - Press to select a timer
(1 to 4).
TIMER START/STOP BUTTON - Press to start/stop
the timer.
TIMERS UP or DOWN ARROW - Press to set the
desired time.
TIMERS WINDOW - Displays the hours and minutes
remaining on the timer.
ARROW BUTTONS - Use with LCD operation.
LCD PANEL - Displays all setup options of the Proofer,
Retarder, or automatic Retard/Proofer operation.
CONTROL
To enter the operation mode, press ON/OFF button
(Fig. 1).
OPERATION MODE:
The LCD panel displays three options after the ON/
OFF button is pressed (Fig. 2).
Fig. 1
Fig. 2

– 8 –
Proof
• Press the "PROOFER" operation arrow button (Fig. 2).
• Enter the desired temperature (65°F - 115°F) by pressing up or down arrow button (Fig. 3).
• Enter the desired humidity (25% - 95%) by pressing up or down arrow button.
• Enter the desired time for timer. (If it is timed out, beeper is pulsed and timer number ashes.)
PROOFER TIMINGoooo
Press STOP to End.
>
CHANGE MODE
8:42am Friday
After entering desired time and pressing the timer
START/STOP button, the LCD displays message
"PROOF TIMINGoooo" to indicate the proof operation
is now running with timers (Fig. 4).
To stop the proof timer operation, press START/STOP
button. To stop the proof operation, press "CHANGE
MODE" arrow button or ON/OFF button.
NOTE: It is normal to notice that proofer fans in airduct
keep running for 20 minutes to cool down after the
proof operation is canceled.
LED is on indicating the
unit is running.
Fig. 3
Fig. 4
PROOFER MODE:
Enter Settings Above
CHANGE MODE
9:37A.M Friday

– 9 –
Retard
• Press the "RETARDER" operation arrow button (Fig. 2).
• Enter the desired temperature (34°F - 50°F) by pressing up or down arrow button.
• Enter the desired time for timer. (If it is timed out, beeper is pulsed and timer number ashes.)
NOTE: Retard operation does not o󰀨er humidity control. A xed humidity value is used for this
operation.
NOTE: Defrost cycle can be set by entering the Parameter Setup Mode. See chart for default value. During
defrost cycle active, the LCD ashes "DEFR" at the bottom left corner.
Enter the desired timer and press timer START/
STOP button. The LCD displays message
"RETARDER TIMINGoooo" to indicate the retard
operation is running with timer (Fig. 5 and Fig. 6).
To stop the retard timer, press timer START/STOP
button. To stop the retard operation, press "CHANGE
MODE" arrow button or ON/OFF button.
LED is on indicating the
unit is running.
Fig. 6
Fig. 5
RETARDER TIMINGoooo
Press STOP to End.
CHANGE MODE >
10:49am Friday
RETARDER TIMINGoooo
Press STOP to End.
CHANGE MODE >
10:49am Friday

– 10 –
RETARDER/ PROOFER (Auto Mode)
This operation will put Retard and Proof in one operation. The automatic Retard/Proof operation can be
programmed for either a single day or seven days. (See chart for the parameter value setup.) After one
operation cycle (Retard and Proof) is nished, the unit now runs Proofer mode. To resume the next day
program, the operator must go to RETARDER/PROOFER Mode and press "Start/Retard/Proofer" arrow
button.
NOTE: Rest period and Recover time are setup times before the unit enters the proof stage. (See chart
for the default value.)
The operator must select "CHANGE MODE" arrow button, "RETARDER/PROOFER" arrow button, then
press "Start/Retard/Proof" arrow button to resume the program for the next day.
• Follow the steps below to program automatic Retard/Proof operation.
After pressing Review/Edit
Settings, the next screen on the
LCD is shown here (Fig. 8).
Review/Edit Settings>
Start Retard/Proof>
CHANGE MODE>
RETARDER/PROOFER
Today is Friday
Change DAY? >
[NEXT]
7 DAY PROGRAM
In Figure 8, the LCD displays "7 DAY PROGRAM" because the parameter P15 value is set to "1".
NOTE: This step is for service only. If single day program is preferred, see Operating Parameter Setup
to change P15 value to "0".
If day is not correct, then press "Change DAY?" arrow button. The LCD next screen displays the option
to select days as shown below.
DAY
DAY >
[NEXT]
Today is Friday
Use the arrow buttons to change
day. Then select NEXT button
or arrow button to set the clock
(Fig. 9).
To enter the RETARD/PROOF
operation, press "Review/Edit
Settings" arrow button (Fig. 7).
Fig. 7
Fig. 8
Fig. 9
Review or edit new settings.
Press here to change day.

– 11 –
NOTE: Programming is based on Proof cycle completion Time/Day. The program always starts with
Sunday as the rst day for programming. To activate the program, select the arrow button as shown below.
Set CLOCK? >
[NEXT]
Curent Time 8:58 am
If time is correct, then press
NEXT button or arrow button.
If time is not correct, select the
"Set CLOCK?" arrow button to
change time (Fig. 10).
If the program on Sunday is
activated, this screen will display
(Fig. 12).
The next LCD screen displays
time that the program will
be completed for proofing
(Fig. 13).
Press NEXT button or arrow
button.
ACTIVATE Program >
[EXIT] [NEXT]
Sunday Program is
INACTIVE (skipped)
Operator also has the choice to
skip the program on that day by
pressing NEXT button or arrow
button (Fig. 11).
INACTIVATE Program >
[EXIT] [NEXT]
Sunday Program is
ACTIVE (will proof)
Enter the desired time when to
complete Proong by pressing
"Hours" and "Minutes" arrow
buttons. Keep in mind that hour
or minute is changed by one
arrow button. If the desired
hours or minutes is missed, keep
pressing the arrow button until
the desired time is reached.
Press NEXT button or arrow
button.
[EXIT] [NEXT]
Proofing Complete at
7:00 am Hours >
Minutes >
Fig. 10
Fig. 11
Fig. 12
Fig. 13
Press here to edit time.
Press here to activate or
deactivate the program.
Press here to proceed to
next screen.
Change hours.
Change minutes.

– 12 –
Follow the LCD instructions to setup the Retard temperature. Press the Up or Down arrow button to select
desired temperature (Fig. 14 and Fig. 15).
[EXIT] [NEXT]
See ABOVE for
RETARDING SET TEMP
Sunday Program
See ABOVE for
RETARDING SET TEMP
Sunday Program
[EXIT] [NEXT]
After entering the Retard temperature, press NEXT button or arrow button to go to the Proof setup as
shown in Fig. 16 and Fig. 17.
[EXIT] [NEXT]
See ABOVE for
PROOFING SETTINGS
Sunday Program
Operator can enter desired temperature, humidity, and timer
to end proof operation. This is the end of Retard and Proof
cycle (for one day).
See ABOVE for
PROOFING SETTING
Sunday Program
[EXIT] [NEXT]
Fig. 14
Fig. 15
Fig. 17
Fig. 16

– 13 –
The next screen shows the
program for the second day
after the NEXT button is pressed
(Fig. 18).
INACTIVATE Program >
[EXIT] [NEXT]
Monday Program is
ACTIVE (will proof)
Review/Edit Settings>
Start Retard/Proof>
CHANGE MODE>
RETARDER/PROOFER
After a 7-day program is nished, the
LCD displays the nal message as
shown in Fig. 19.
The operator has two options, either
to review/edit new change or go back
to other operation options (manual
Retard or manual Proof) by pressing
"CHANGE MODE" arrow button.
Otherwise, the auto Retard/Proof
operation will start after the arrow
button is pressed as shown in Fig. 19.
Again, the LCD displays a choice of the next day program by activating or deactivating the program button.
To skip the next day, the next day program must be inactive. Then press NEXT button. If next day program
is activated, then proceed with similar steps as shown in screen shot Fig. 11 through Fig. 17.
Fig. 18
Fig. 19
Press here to activate or
deactivate the program.
Press here to activate the auto Retard/Proof.
Press here to go to manual Retard or Proof.

– 14 –
OPERATING PARAMETER SETUP
• Press and hold the TIMER NUMBER arrow button.
• Press ON/OFF button. (Fig. 20).
NOTE: If timer keys are not available the parameter setup
can be accessed pressing simultaneously the HUMIDITY
UP button and the ON/OFF button.
Fig. 20
After entering parameter setup
mode (Fig. 21), the LCD panel
shows function of each parameter
denition. For more information on
parameter value, see the parameter
value chart to understand each
parameter value.
PARAMETER SETUP
Software Version
Fig. 21
Press up or down button
to enter new value.
Press up or down button to
select parameter number.
LCD displays function or
each parameter number.

– 15 –
Denitions and Default Values for Retarder Proofer
/* P0 Software Version Number
/* P1 Fahrenheit or Celsius
/* P2 Temp O󰀨set for Calib. Min. 0 Max. 30, 15 is zero o󰀨set
/* P3 Hum O󰀨set for Calib. Min. 0 Max. 30, 15 is zero o󰀨set
/* P4 Minimum Temp for Proof 65°F
/* P5 Maximum Temp for Proof 115°F
/* P6 Minimum Humid for Proof 25%
/* P7 Maximum Humid for Proof 95%
/* P8 Dummy (undened)
/* P9 Preheat without humidity Preset T=105°F, Time out after 15 min. If Timer Start/Stop button is not pressed
after 30 sec, the unit will go to Proof operation.
/* P10 Minimum Temp for Retard 34°F
/* P11 Maximum Temp for Retard 50°F
/* P12 Rest Time Min. 5 min. Max. 480 min.
/* P13 Recovery Time Min. 30 min. Max. 480 min.
/* P14 1=AM/PM, 0 = Military Time
/* P15 1= 7Day, 0= Single Day
/* P16 Defrost Every xx (hours) Max. 10 hrs.
/* P17 Defrost FOR xx (minutes) Max. 60 min.
NOTE: P0 thru P9 are for Proofer and Retarder Proofer. P10 thru P17 are for Retarder Proofer only.
Default Parameter Values
0001 /* P0 Software Version Number
F /* P1 F=Fahrenheit, C=Celsius
15 /* P2 Temp O󰀨set for Calib.
15 /* P3 Hum O󰀨set for Calib.
65 /* P4 Minimum Temp for Proof
115 /* P5 Maximum Temp for Proof
25 /* P6 Minimum Humid for Proof
95 /* P7 Maximum Humid for Proof
/* P8 Not used
1/* P9 Preheat 1= disabled, 0=enable
34 /* P10 Minimum Temp for Retard
50 /* P11 Maximum Temp for Retard
30 /* P12 Time for Rest Time
60 /* P13 Time for Recovery
1/* P14 1=AM/PM, 0 = Military
0/* P15 1= 7Day, 0= Single Day
6/* P16 Defrost every x hours
10 /* P17 Defrost time x minutes

– 16 –
CUSTOMIZED OPERATION
The Proofer and the Retarder/Proofer controls have the capability of being customized to t your own
personal needs using the setup mode.
NOTE: Before entering the setup mode, read all the instructions to make sure you are completely clear
on what to do. If you need assistance, please call your authorized service o󰀩ce.
Entering Setup Mode
1. Press and hold the TIMER NUMBER arrow button.
While pressing the TIMER NUMBER arrow button,
press the ON/OFF button (Fig. 22).
2. A "0" will appear in the TIMER NUMBER display.
3. Release both buttons.
4. You are now in setup mode.
Changing Items in Setup Mode
1. The number in the TIMER NUMBER display is the setup number. The other display windows will
light up, depending on what item is being changed.
2. To change the setup item being displayed, go to that display and use the arrow buttons to the left of
the display to adjust the setting.
3. To change the setup number, press the UP or DOWN arrow to the left of the TIMERS display.
4. To exit the setup mode, press the ON/OFF and TIMER NUMBER arrow button once to get back to
normal operation.
NOTE: There may be setup numbers in the setup mode that do not pertain to your particular proofer. Do
not attempt to set these. Skip them and go to the next appropriate number.
Setup Guide
Setup Number Setup Item
1Degrees Fahrenheit
2Temperature O󰀨set (0= -15°F/C, 15= 0°F/C, 30= +15°F/C)
3Humidity O󰀨set (0= -15%RH, 15= 0%RH, 30= +15%RH)
4Minimum proof temperature that can be set
5Maximum proof temperature that can be set
6Minimum proof humidity that can be set
7Maximum proof humidity that can be set
9Preheat Disabled (1=Disabled, 0=Enabled) (PW only)
10 Minimum retard temperature that can be set (RPW only)
11 Maximum retard temperature that can be set (RPW only)
12 Rest period (RPW only)
13 Recovery period (RPW only)
14 Military or standard time (RPW only)
15 Daily/Weekly (1= 7 Day Cycle, 0= 1 Day Cycle)
16 Defrost Refrigeration equipment every xx hours (Max. 10 hours)
17 Defrost Refrigeration equipment for xx minutes (Max. 60 minutes)
Fig. 22
TEMP
%HUMIDITY
ON
ON
ON
OFF
TIMER
TIMERS
NUMBER
ON
START
STOP

– 17 –
Setup Hints
• During Rest Period, the unit does not heat, cool or circulate air; this allows the dough to rest.
• During Recovery Time, the unit slowly heats up and adds humidity, bringing the unit to the preset
temperature and humidity and into the proof stage of the automatic retard/proof process.
SELECT PROOFER MODEL VIA BOOTLOADER
The proofer model is set at the factory. However, if the proofer model needs to be changed this procedure
shall be followed.
1. Turn o󰀨 the Proofer with the ON/OFF button.
2. Hold these three buttons, in this order for 5 seconds.
• HUMIDITY DOWN ARROW
• TEMPERATURE UP ARROW
• ON/OFF Button.
3. Keep holding the three buttons until "conF" is shown in the Temperature display (Fig. 23).
Fig. 23
4. The current proofer conguration value will be displayed in the HUMIDITY display. 1, 2 or 3
5. Pressing the HUMIDITY UP ARROW will cycle through the congurations, 1, 2 or 3
• Cong 1: Proofer (PW)
• Cong 2: Retarder/Proofer (RPW)
• Cong 3: Dehumidifying Proofer (DPC1S)
6. The conguration is saved by pressing the ON/OFF button.
7. The TEMP and HUMIDITY display LEDs will ash on and o󰀨 for two seconds to indicate that the
new conguration has been saved.
8. The proofer control board will reboot with the new conguration.
NOTE: If the application rmware is corrupt or missing, the unit will enter the bootloader automatically.
This will happen even if you do select a proofer model, it will still return to the bootloader where you are
required to load the rmware. To correct this error, update the proofer rmware.
MANUAL PROOF ON
SELECT RECIPE >

– 18 –
UPDATE THE PROOFER FIRMWARE VIA BOOTLOADER
1. Load the rmware le named proofer.bin
onto a FAT formatted ash drive.
2. Turn o󰀨 the Proofer with the ON/OFF button.
3. Insert the ash drive into the proofer’s USB
socket (Fig. 24).
4. Hold these three buttons, in this order for
5 seconds.
• HUMIDITY DOWN ARROW
• TEMPERATURE UP ARROW
• ON/OFF button.
5. Keep holding the three buttons until "conF" is
shown in the Temperature display (Fig. 23).
6. Press either TEMP UP or TEMP DOWN
arrow until "LoAd" is displayed in the TEMP
display (Fig. 25).
7. The word "Go" is displayed on the HUMIDITY
display.
8. Press HUMIDITY UP button to start the
update.
9. "UPdt" will be displayed in the TEMP display for 1 second.
10. "Strt" will be displayed in the TEMP display for 1 second.
11. The image le will be validated.
• On a successful update "Succ" will be displayed on the TEMP display for 2 seconds. The control
board will reboot. Remove ash drive and turn on the proofer with the ON/OFF button. Verify
the correct proofer operating mode and parameters.
• On an unsuccessful update "Err" will be displayed on the TEMP display, this will be permanently
displayed and the proofer will need the power cycled to clear this error. Depending on the cause
of the failure either the old application will run if still present or the system will enter into the
bootloader so you can attempt to ash again.
Fig. 24
USB Socket
Flash Drive
Fig. 25
MANUAL PROOF ON
SELECT RECIPE >

– 19 –
CONTROL BOARD POWER UP
Each time power is applied to the control board, the bootloader is launched. The bootloader looks at the
ash conguration to choose which of the three conguration modes to use.
During the boot up process, the conguration mode number 1, 2, or 3 is displayed in the HUMIDITY display
for several seconds.
This function is used to help the technicians verify the proofer control board is congured correctly.
LCD CONTRAST ADJUSTMENT
If the control board includes an LCD, this procedure can be followed to adjust the LCD contrast.
Enter Bootloader:
1. Turn o󰀨 the Proofer with the ON/OFF button.
2. Hold these three buttons, in this order for 5 seconds.
• HUMIDITY DOWN ARROW
• TEMPERATURE UP ARROW
• ON/OFF button.
3. Keep holding the three buttons until "conF" is shown
in the Temperature display (Fig 23).
4. The current proofer conguration value will be
displayed in the HUMIDITY display. 1, 2 or 3.
5. While in the normal bootloader mode, hold down the
HUMIDITY DOWN button and then press the TEMP
UP button. You will see the LED display change and
the LCD will display the instructions (Fig. 26). The
system is now in LCD contrast setting mode.
6. Using the HUMIDITY UP and DOWN buttons set the
LCD contrast as desired.
7. Once satised with the LCD contrast setting, press
the TEMP UP button to save the setting and exit the
LCD contrast mode. You will return to the bootloader
mode.
8. Once back in the bootloader mode, set the desired
conguration and press ON/OFF button to start the application.
Fig. 26
**Set LCD Contrast**
Use Humidity up/down
keys to change the
LCD contrast >

– 20 –
FORM 36756 (Feb. 2019) PRINTED IN U.S.A.
MAINTENANCE
Disconnect the electrical power to the unit and follow lockout / tagout procedures.
Every 6 months have authorized service personnel check air duct, drain, heater plate, spray nozzle and
refrigeration coils (if applicable).
LIGHT BULBS
Replace light bulb(s) with 40-watt incandescent appliance-type bulb(s) ONLY.
SHUT DOWN
1. Remove all remaining product.
2. Turn o󰀨 proofer.
3. Clean the proong chamber. (See Cleaning below.)
CLEANING
1. Using a clean cloth moistened in warm, soapy water, wash the stainless steel interior of the cabinet.
Rinse with clear water and dry with a clean cloth.
2. Clean the outside daily with a clean, damp cloth.
3. Use care when cleaning around sensitive interior parts, such as probes and sensors.
4. Do not use cleaners containing grit, abrasive materials, bleach, harsh chemicals or chlorinated
cleaners. Do not use steel wool on stainless steel surfaces. Never spray down the proofer with water,
steam or power wash.
5. Be cautious with new or improved cleaning formulas; use only after being well tested in an inconspicious
place.
SERVICE AND PARTS INFORMATION
Contact your authorized service o󰀩ce for any repairs or adjustments needed on this equipment.
TROUBLESHOOTING
PROBLEM CORRECTIVE ACTION
Machine will not turn on. 1. Make sure that the power cord is plugged in.
2. Verify that the main power supply is on.
3. Contact your local authorized service office.
Machine will not heat up. 1. Verify that the temperature is set properly.
2. Contact your local authorized service office.
Machine will not humidify
air.
1. Verify that the humidity is set properly.
2. Verify that the water supply is turned on to the equipment.
3. Contact your local authorized service office.
Machine will not cool. 1. Verify that the temperature is set properly.
2. Contact your local authorized service office.
