Baxton Studio 0082 S User manual

0082 S Queen Bed
Assembly Instructions
Page 1 of 6
Assembled View
1
Note: Do not assemble
using power tools.
This can cause the bolts
to be overtightened
Use 2 People
WI-0421
Parts List
2
AHeadboard Panel x1
BFootboard Panel x1
CSide Rail
(Left Hand) x2
DSide Rail
(Right Hand) x2
ELong Support x2
F
Post x4
G
Support
Leg x6
H
Support Panel
x4
J
Support Bar
x2
K
Set of Bed Slats x2
Extra holes
on the outside
Extra holes
on the outside

Page 2 of 6
Hardware List
3
1M4 Allen Key
x1
9M8 Flat
Washer
x4
WI-0421
5Metal Plate
x2
2M5 Allen Key
x1
11 Wood Screw
(M4 x 32mm)
x16
3Adjustable
Foot x6 4Barrel Nut x6
6M8 x
50mm JCB
x8
7Spring
Washer
x24
8M6 Flat
Washer
x34
10 M6 JCN
Nut x4
12 M6 x
15mm JCB
x8
13 M6 x
20mm JCB
x8
14 M6 x
40mm JCB
x8
15 M6 x
50mm JCB
x20
16 M6 x
90mm JCB
x2
17 M6 x
100mm JCB
x4
Fit the Adjustable foot to the
bottom of the Support Legs (G).
4Fit the Support Bar (J) to the
Support Leg (G).
5
G
3
x2x6 16
4
J
G
8
x2x2
0082 S Queen Bed
Assembly Instructions

Fit the Post (F) to the
Support Panel (H).
x4 H
F
6
Page 3 of 6
6
WI-0421
Assemble the Side Rail (C & D)
to the Support Panel (H).
Fit the Metal Plate to the
Side Rail (C & D).
x2
C
D
x2
5
12 12
x2x2
15
7
8
7
8
0082 S Queen Bed
Assembly Instructions
C
D
H
H

Assemble the Side Rail (C & D) to the
Headboard / Footboard Panel (A & B).
9
Page 4 of 6
Bolt the Support Panel (H) to the
Headboard / Footboard Panel (A & B).
D
C
C
D
A
B
Extra holes
on the outside
Extra holes
on the outside
8
7
13
C/D
10
15
7
8
H
WI-0421
0082 S Queen Bed
Assembly Instructions
D
C
A
B
C
D

8
17
4
E
G
K
Fit the Slats (K) to the Long Support (E) &
Support Leg (G).
Page 5 of 6
Bolt the Bed Slats (K) to the Side Rail (C & D).
17
K
E
G
4
4
G
8
A
D
C
B
14
14
14
K
14
1414
1414
x2
11
12
WI-0421
0082 S Queen Bed
Assembly Instructions

15
9
10
J
K
K
G
8
Screw the Bed Slats (K) to the Side Rail (C & D).
Page 6 of 6
13
Lastly, fit the Support Bar (J) in place.
A
B
K
14
A
D
C
B
11
11
K
11
1111
WI-0421
0082 S Queen Bed
Assembly Instructions
