Hahn Hyde Park Bench with Back User manual

Necessary Tools
Hyde Park Bench with Back Hyde Park Bench without Back
®
hanit Installation Guide
- Hyde Park Bench -
HAHN
Screwdriver / cordless screwdriver, knife
Mallet
The strapping allows for easier installation of the bench panel as it holds the planks tight.
Carefully remove the strapping after the last step has been completed.
2
1
1
Seat element
Seat end
1
Quantity Sketch
Pan head s
6 x 60 mm
crews 16
12
Bit
Back element
2
1
Seat element
Seat end
1
16
Bit
Parts List
Countersunk screws
6 x 60 mm
Stückliste
Parts List
Quantity Sketch
Pan head
6 x 60 mm
screws
HAHN Kunststoffe GmbH - Gebäude 1027 - DE 55483 Hahn-Flughafen
Phone: +49 65 43 / 98 86 - 0 Mail: [e-mail]
Fax: +49 65 43 / 98 86 - 99 Online: www.hahnkunststoffe.de

Schritt 1 Step 1 Schritt 1 Schritt 1 Step 1
Schritt 1 Schritt 1 Schritt 1 Step 2 Step 2
Schritt 1 Schritt 1 Schritt 1 Step 3
Schritt 1 Schritt 1 Schritt 1 Step 4
HAHN
Place the seat element on a high, clean and solid work
surface. Push the seat element into the recess of the seat
ends. Gently use the mallet to ensure the seat element is
pushed all the way into the seat ends.
Take the seat end partially off one side of the seat element.
Then place the back element into the recess of the seat end.
Push all the elements into the seat ends. If necessary,
use the mallet to ensure the seat and back elements
are evenly in the recesses of the seat ends. When the
elements are correctly in place, use the pan head screws
to fix the seat element with the pre-drilled holes. Use
the countersunk scews to do the same with the back
element.
Carefully cut the strapping (strapping is under tension)
and take out the washers. The seat ends must be
anchored to the ground.
For safety reasons, the Hyde Park Bench with
back must be secured to the ground. This can
®
be done by using the hanit - Ground Anchor
item number BOA48028.
Please remove the security hint label only after
this step has been completed.
®
hanit Installation Guide
- Hyde Park Bench -
Hyde Park Bench with Back Hyde Park Bench without Back
Place the seat element on a clean work surface. Insert
the seat element into the recess of the seat ends. When
the seat element is correctly in place, use the screws to
fix the seat element with the pre-drilled holes.
Carefully cut the strapping (strapping is under tension)
and take out the washers.
HAHN Kunststoffe GmbH - Gebäude 1027 - DE 55483 Hahn-Flughafen
Phone: +49 65 43 / 98 86 - 0 Mail: [e-mail]
Fax: +49 65 43 / 98 86 - 99 Online: www.hahnkunststoffe.de
