Bayan Audio Mixx In Car DASHCHARGE User manual

DASHCHARGE
WIRELESS CHARGER
QUICK START GUIDE

CHECK
1
2
3
4
5
6
Suction Cup
Suction Cup Lock
Angle Lock
Windshield Arm
Extendible Arm
Rotation Ball Joint
What’s in the box:
• DashCharge cradle
• USB to USB Type C power cable
• QC 3.0 car charger
• DashCharger quick start guide
• Vent mount
Or
• Windshield mount
1
23456

Rotation Ball Joint
Wireless Charging Pad
Cradle Arms
Joint Connector
Vent Lock
Vent Clips
Vent Stabilising Feet
Release Button
USB Type C Port
Base Support
LED Light
12
13
14
15
16
6
7
8
9
10
11
7
8
9
6
10
11
12
13
14
15
16
9

LET’S INSTALL
Avoid installing on the vehicle’s airbag
or areas the airbag can reach when
inflated.
Install in 3 easy steps.
1. Loosen the Joint Connector from
the back of your DashCharge Cradle
and place onto the Rotation Ball
Joint of your Vent/Windshield
Mount. Press the DashCharge Cradle
onto the Rotation Ball Joint until
it clicks. Tighten the Joint Connector
clockwise to secure the cradle into
place.
2. Position your car mount on the
windshield or air vent.
DashCharge Vent Mount
Position the Vent Clips on the
desired vane and ensure the Vent
Stabilising Feet are in contact
against the dashboard. Push down the
Vent Lock towards you to secure
the Vent Clips into place. To release
the vent mount, pull the Vent Lock
upwards and the clips will open.
9
6
6
9
12
11
10
10
11

DashCharge Windshield Mount
Remove the adhesive peel back label
from the Suction Cup , position on
the windshield (ensure the area is
clean) and push down on the Suction
Cup Lock to secure the mount. To
remove, pull the Suction Cup
Lock towards you to release the
mount.
Adjust the windshield arm
Loosen the Angle Lock then adjust
the angle of the windshield arm to
the desired level and then tighten the
Angle Lock .
Extend the windshield arm
Hold the Fixed Windshield Arm and
then pull the back of DashCharge
Cradle towards you to set the desired
length.
3. Adjust the knobs and ball joint of the
DashCharge Cradle to reposition for
an optimal viewing angle.
1
2
2
3
3
4

LET’S POWER YOUR
DASHCHARGE
Insert the Type C USB connector of the
charging cable into the Type C USB
Port at bottom of your DashCharge
Cradle. Then place the USB connector
of your cable into the QC 3.0 car charger
provided.
While your car engine is running, plug
the QC 3.0 car charger into your car
lighter socket. The car charger LED light
will turn RED when powered on and the
DashCharge LED Light will be BLUE.
You are now ready to use your
DashCharge car mount.
14
16

LET’S CHARGE YOUR
SMARTPHONE
Press and hold the Release Button to
extend the Cradle Arms . Place your
Qi-enabled smartphone against the
Wireless Charging Pad , your phone
will be supported by the cradle Base
Support . Press the two Cradle Arms
together to secure your phone in place.
When the DashCharge LED Light turns
GREEN your smartphone is successfully
charging. When your phone is removed
the DashCharge will enter standby mode
and the LED Light will change back to
BLUE.
Warning Light
The DashCharge LED Light will
flash BLUE to let you know either the Qi
wireless charging signal is blocked, the
phone is not Qi-enabled or the Wireless
Charging Pad
13
8
7
15 8
16
16
16

Qi Wireless Charging Technology
The MIXX DashCharge car mount uses
the latest Qi technology to wirelessly
charge your smartphone. The
DashCharge can also charge a phone
with a compatible Qi phone case. Please
note, metallic or magnetic items or cases
should be removed prior to charging.
LET’S FAST CHARGE
The MIXX DashCharge comes with a
car charger with a QC 3.0 for super fast
charging of compatible phones. Together
with your QC 3.0 enabled smartphone it
will wirelessly charge at the maximum
capable speed.

Overcurrent protection:
The QC 3.0 car charger will stop charging
when it reaches its maximum current lev-
el to prevent product damage and the car
charger LED light will not be lit. In this
event, remove from the car lighter socket
and plug in again.
Your DashCharge will intelligently detect
if your smartphone supports fast charging
and will supply the optimum power.
For best results use the QC 3.0 car
charger supplied.
SAFETY PRECAUTION
• Do not operate the car charger while
driving. Failure to pay full attention
to the operation of your vehicle could
result in serious injury or damage
to your property. Always use your
own judgement and obey traffic laws
while driving.

LET’S BE SAFE
Do not disassemble, expose to water or
intense heat.
Do not place in close proximity to strong
magnetic fields or strips such as ID cards,
bank cards etc.
Keep at least 20cm away from implanted
medical devices (such as pacemakers and
cochlear implants) to prevent potential
magnetic interference.
Please keep away from children and pets.
Do not continue to use your Dash Charge
if damaged.
LET’S RECYCLE
This product can be recycled. Products
bearing this symbol must NOT be
thrown away with normal household
waste.
Take the product to a collection point
designated for recycling of electronic
devices.
Find out more about return and collection
points through your local authority.

For technical support or to download the user guide
visit www.mixxcharge.com
Mixx In CarTM is a registered trademark of Bayan Audio
Ltd. Registration number 016983141
MQSV-QSG01
