BBQ'S AUSTRALIA IFC 900C User manual

Phone: [phone]
[email protected]
www.bbqsaustralia.com.au
INSTRUCTION MANUAL
Commercial Kitchen Barbecues

2
PLEASE READ THESE IMPORTANT
SAFETY INSTRUCTIONS WHICH APPLY
TO ALL OUR GAS APPLIANCES!
•Do not operate this appliance before reading the
instruction manual
•Do not place articles on or against this appliance
•Do not store chemicals on or against this appliance
•Do not spray aerosols near this appliance when in
operation
•Do not leave this appliance unattended when in use
•Do not leave covers on this appliance when in use
•When installed in a commercial kitchen a suitable
extraction hood must be installed
•Caution this appliance has hot surfaces

3
THANK YOU
For purchasing a product from BBQ’s Australia.
We place an immense importance on quality and performance
when designing and manufacturing appliances you use.
With minimal care, as outlined in this guide, our product is
designed to provide you with years of dependable service.
Please take the few minutes necessary to learn the proper and
efficient use and care of our quality products.
We appreciate your choosing an Infresco product, and hope that
you will again select our products for your other requirement in the
future.

4
Models: IFC 900C, IFC985C, IFC1185C and IFC1360C
Nominal Hourly Gas Consumption:
Gas Type: Natural
MJ/h Rating: Solid Plate Griddle Boiling Top
12 15 20
Injector Orifice: 1.6mm 1.8mm 2.1mm
Test Point Pressure: 1.0 kPa
Gas Type: Propane
MJ/h Rating: Solid Plate Griddle Boiling Top
Per Burner: 10 10 16
Injector Orifice: 0.9 mm 0.9 mm 1.1 mm
Test Point Pressure: 2.5 kPa
Overall Dimensions:
Height: 227 mm (not including lid handles or hood)
565 mm (including hood)
Width: 980, 1065, 1265 & 1440 mm
Depth: 635 mm
WARRANTY
For barbecues manufactured by BBQ’s Australia, all of their component parts and accessories
are warranted to be free from defective materials or workmanship in normal household use for
a period of twelve (12) months from the date of purchase. BBQ’s Australia, warrantor, agrees to
repair or replace, at its option, any part which fails or is found to be defective during the
warranty period. Owner shall be responsible for proper installation, providing normal care and
maintenance, providing proof of purchase upon request, and making the appliance reasonably
accessible for service. ANY DEFECTS MUST BE REPORTED TO THE SELLING DEALER WITHIN
FOURTEEN (14) DAYS FROM DATE OF ORIGINAL RETAIL PURCHASE. BBQ’s Australia uses the
most up-to-date processes and best materials available to produce all finishes. However, slight
variation may be noticed because of the inherent differences in stainless steel parts, and other
factors. Under the terms of this warranty, service must be performed by a factory authorised
Infresco agent or representative. Service will be provided during normal business hours, and
labour performed at overtime or premium rates shall not be covered by this warranty.
Specifications are subject to change without notice.

5
BARBECUE INSTRUCTIONS
INSTALLATION INSTRUCTIONS
1. This appliance must be installed by an authorized person to the requirements of the local gas
authority. The installation must comply with installation code AS/NZ 5601 or with local installation
codes and any other relevant statutory regulations
2. Remove all transit packaging before installing this appliance
3. Models are available in natural and propane gas. Check the appliance data plate located in the
grease tray to ensure correct gas type
4. The gas connection is 45 mm from the right-hand side and 70 mm from the base of the appliance
5. Clearance from combustible surfaces of 10mm at the sides, 100mm at the rear, 30mm underneath
and 1000mm vertically must be provided. The appliance is fitted with side, rear and underneath
spacers to guarantee these clearances
6. The gas regulator supplied must be fitted. Installers must supply and fit an isolation valve to the
appliance to allow the regulator to be removed or serviced without shutting down the main gas
supply
7. This appliance may be connected by solid piping, or a certified hose assembly may be used. If
connected with a hose assembly an anchor point complying with the requirements of AS/NZ 5601
must be provided. Refer to AS/NZ 5601 for pipe sizing details
8. The installer must purge all lines. Light and test burners on high and low operation and make any
adjustment required and then instruct the consumer on the correct and safe operation of the
appliance
9. The gas pressure must be checked by using a manometer or some other suitable means. The burner
pressure can be adjusted by turning the adjustment screw on the pressure regulator. When setting
the gas pressure ensure that at least 50% of the burners are turned to high setting. Gas pressure
details are on the data plate
10. When the installation is complete check all gas joints for soundness
11. Before leaving instruct the user regarding the correct operation of this appliance
12. If this appliance cannot be adjusted to perform correctly contact the manufacturer or the
manufacturers agent
OPERATING INSTRUCTIONS FOR HOT PLATE AND OPEN GRILL
1. For models fitted with a Roasting Hood the hood must be open when lighting the appliance. If the
Roasting Hood is closed during cooking, then use only 2 burners and they must be turned to the low
position
2. Push and turn gas control to high position
3. Push silver peizo ignitor button and continue to push in control knob for 30 seconds
4. Release control knob and burner should stay alight (use viewing hole in front panel). If burner goes
out wait 5 minutes before re-lighting.

6
5. You are now able to turn control between high and low as desired
6. If you turn burner to the off position, you must start again from step 1
7. The burner energises a flame failure/ safeguard device. If the burner is turned off or goes out, then
the gas supply to that burner will shut off within 60 seconds
8. To shut down, turn all gas controls to the off position
OPERATING INSTRUCTIONS FOR BOILING TOP BURNER
1. For models fitted with a Roasting Hood the hood must be open when lighting and remain open
when the boiling top burner is being used
2. Push and turn gas control to elevated position
3. Push silver piezo igniter button and continue to push in gas control knob for 30 seconds after
burner has ignited
4. Release knob and burners should stay alight. If burners go out wait 5 minutes before re-lighting
5. To shut downturn all gas controls to the off position
6. This appliance should burn with a blue flame. If the flame becomes yellow or soot appears contact
the manufacturer to arrange servicing of the appliance
SERVICING INSTRUCTIONS
To be carried by authorised servicemen at least once every 12 months:
1. Check gas pressure at test point should be 1.00 KPa for natural gas and 2.5 kPa for LPG Propane.
Adjust if required.
2. Lubricate gas cocks with approved lubricant. Isolate gas supply, remove gas cock knobs, remove
screws from front cover and remove cover, undo gas cock latching plate to gain entry to gas plug.
3. Remove and clean burners clean dust from venturi and burner surface. To remove burners for
griddle, lift the griddle plate off then remove the rock tray. Then loosen the nuts holding the
thermocouple in position and remove the electrode lead from the igniter and the burner can then
be lifted out. Burner removal for the solid plate burners is by removing the fat tray then loosen the
nuts holding the thermocouple and remove the electrode lead from the igniter.
4. Pressurise the appliance and leak test. If okay reinstate gas supply and test operation of each
burner and gas cock
5. To replace the thermocouple, follow step 2 for removing front cover then undo the thermocouple
nut at the rear of the gas cock, undo the nuts holding the thermocouple head into the bracket on
the burner and then remove the thermocouple.
6. Contact the manufacturer for service and spare parts.

7
FAULT FINDING SERVICE CHART
*Any works must be conducted by an Authorized Service person only
FAULT
CAUSE
REMEDY
No gas to burner
Supply turned off or
depleted. Orifice
blocked.
Check supply, service pipe under size. Clean
orifice with drill or wire smaller than orifice
diameter.
Sluggish flame
Yellow tips
Burner over gassed.
Insufficient primary air.
Check gas pressure.
Clean burner ports.
Check orifice firing centre of burner.
Noisy flame
Too much primary air
Check pressure
No gas to burners
Regulator faulty on gas
supply
Check supply
Check orifice with drill
Check flame failure control
Check thermocouple
Replace regulator
Burner goes out
Check flame failure control
Burner
Loose thermocouple
connection
Defective
thermocouple
Defective control
Tighten connection nut to flame failure control.
Replace
Replace
Important:
Ensure gas pipeline to appliance is sufficient to maintain total MJ/h requirement, when
additional appliances are operating or have been added, service charges may be
incurred if insufficient pipe size found.

8
PREPARING AND SEASONING YOUR
MILD STEEL BBQ PLATE
Step 1: Clean the plate with soap and water. When clean, wipe off
soapy water and re-clean with plain water.
Step 2: Heavily apply an animal fat/oil (lard) to hotplate and cover
with salt generously.
Step 3: Light the barbecue and heat it upon high for 7-10 minutes.
With a heat proof oven glove, work the oil into the plate.
Step 4: Turn the barbecue off and allow it to cool. Once the
hotplate is cool, remove all excess oil and salt with a dry rag (no
scraping with a metal implement).
Step 5: Now the BBQ plate has been seasoned. Treat it like a non-
stick surface.

9
CLEANING YOUR STAINLESS STEEL
Retaining a sparkling finish on stainless steel surfaces is just a matter of a few simple steps. We
can supply all your cleaning requirements.
WHAT DO I USE TO CLEAN MY STAINLESS STEEL?
Simply wiping stainless steel with a damp cloth is not as effective as it can smear dirt without
removing it. We supply a stainless-steel cleaner which is very effective in removing dirt from
stainless steel and it leaves a highly polished finish. We also have a range of excellent cloths and
soft scourer sponges.
REMEMBER- STAINLESS STEEL IS EASILY SCRATCHED
Stainless steel can be scratched by careless handling or aggressive scrubbing. Just like you
would take care of a polished timber finish, avoid dragging rough items across the surface and
be aware that grit trapped under other objects can be the culprit.
DISCOLOURATION
Stainless steel may discolour if left in contact with salts or acids for extended periods. Also
avoid leaving carbon steel items in contact with stainless steel, particularly if wet. But if you
observe ordinary hygiene measures, like timely cleaning-up in food preparation areas, you
won't have any problems.
FOLLOW THE GRAIN
Always rub stainless steel in the same direction as the grain. Rubbing against the grain will spoil
the finish and the stainless steel will lose its shine. Rubbing against the grain can also damage
the surface by creating microscopic crevices where dirt can collect. This can lead to corrosion
spots. Fortunately, it's usually easy to tell which is the right direction.
USE SOFT CLOTHS
NEVER EVER use steel wool (wire wool) to clean stainless steel. It is usually made of carbon
steel and any fragments left behind will rust onto the stainless-steel surface. Using any kind of
scourer sponges which have previously been used on ordinary (carbon) steel is also a no-no for
the same reason. We also have a range of scouring pads that can carry out the heavy-duty
work, like removing burnt food from stainless steel. These will scratch but if you follow the
grain the small scratches will be hard to spot on the stainless-steel surface. These special
scourers won’t leave fragments to go rusty.
DO NOT rub with steel wool (wire wool)
DO NOT scrape with steel tools
DO NOT use scourers or cleaning cloths that have been used on ordinary steel
DO NOT rub plastic scourers across the grain of brushed surfaces
DO NOT use concentrated bleach or hydrochloric acid-based cleaning products
