BBT BBT-BC-36CCBH User manual

OWNER’S MANUAL
Assembly & Operating Instructions
BBT Brush Cutter
MODEL NO. BBT-BC-36CCBH
BBT-BC-36CCDH

2
WWW.BBTA.COM.AU BBT-BC-36CCBH, BBT-BC-36CCDH
To The Owner
Thank you for purchasing our Brush Cutter. It was carefully engineered to provide excellent performance when
properly operated and maintained.
Please read this entire manual prior to operating the Brush Cutter. It instructs you how to safely and easily set
up, operate and maintain your Brush Cutter. Please be sure that you and any other persons who will operate
the Brush Cutter carefully follow the recommended safety practices at all times. Failure to do so could result in
personal injury or property damage.
All information in this manual is relative to the most recent product information available at the time of printing.
Review this manual frequently to familiarise yourself with the machine, its features and operation. Please be
aware that this Owner’s Manual may cover a range of product specifications for various models. Characteristics
and features discussed and/or illustrated in this manual may not be applicable to all models. We reserve the right
to change product specifications, designs and equipment without notice and without incurring obligation.
All the power testing information used to establish the power rating of the engine equipped on this Brush
Cutter can be found in the engine manufacturer’s manual or website. If you have any problems or questions
concerning the machine, please contact our Customer Support Department.
Throughout this manual, all references to right and left side of the Brush Cutter are observed from the operating
position. The engine manufacturer is responsible for all engine-related issues with regards to performance,
power-rating, specifications, warranty and service. Please refer to the engine manufacturer’s Owner’s Manual
packed separately with your Brush Cutter for more information.
Customer Support
Please do NOT return the Brush Cutter without first contacting the Customer Support Department at
[e-mail].
If you have difficulty assembling this product or have any questions regarding the controls, operation, or
maintenance of this Brush Cutter, please contact our Customer Support Department.
SAVE THESE INSTRUCTIONS

3
WWW.BBTA.COM.AUBBT-BC-36CCBH, BBT-BC-36CCDH
TABLE OF CONTENTS
Page(s)
To The Owner.........................................................................................................................................................2
Customer Support..................................................................................................................................................2
TABLE OF CONTENTS .............................................................................................................................3
IMPORTANT SAFETY INFORMATION ................................................................................................. 4-5
Additional Information and Potential Changes...................................................................................................4
Key to Symbols.......................................................................................................................................................5
GENERAL SAFETY RULES ................................................................................................................... 6-7
PARTS LOCATION....................................................................................................................................8
ASSEMBLING .................................................................................................................................... 9-10
Installing Plastic Shield ..........................................................................................................................................9
Blade Installation ...................................................................................................................................................9
Installing Bull Horn Handle ................................................................................................................................10
Installing D–Handle .............................................................................................................................................10
RULES OF SAFE OPERATION .......................................................................................................... 11-15
Danger Zone - An Area 15 Metres in Radius......................................................................................................11
Cutting with a Nylon Head..................................................................................................................................12
Cutting with a Blade............................................................................................................................................14
PREPARING FOR OPERATIONS ....................................................................................................... 16-17
Engine Safety Precautions...................................................................................................................................16
Burns and Fires.....................................................................................................................................................16
Fuel .......................................................................................................................................................................17
Engine Oil.............................................................................................................................................................17
OPERATIONS.........................................................................................................................................18
Engine Starting and Stopping Procedures .........................................................................................................18
Hot Restart ...........................................................................................................................................................18
Emergency Stop ...................................................................................................................................................18
MAINTENANCE CARE...........................................................................................................................19
TROUBLESHOOTING ...................................................................................................................... 19-20
SPECIFICATIONS....................................................................................................................................21
WARRANTY & SERVICE ........................................................................................................................22
EXPLODED DIAGRAM & PARTS LIST.............................................................................................. 23-25
YOU MAY ALSO LIKE ...........................................................................................................................26

4
WWW.BBTA.COM.AU BBT-BC-36CCBH, BBT-BC-36CCDH
IMPORTANT SAFETY INFORMATION
Additional Information and Potential Changes
We reserve the right to discontinue, change, and improve our products at any time without notice or obligation
to the purchaser. The descriptions and sections contained in this manual were in effect at the time of printing.
Equipment described within this manual may be optional. Some illustrations may not be applicable to your
machine.
WARNING: Read and thoroughly understand all instructions in this manual and on the safety decals
before assembling or operating this Brush Cutter. Failure to do so may cause serious injury or death.
Do not allow anyone to operate this Brush Cutter who has not read this manual. As with all power
equipment, a Brush Cutter can be dangerous if assembled or used improperly. Do not operate this
Brush Cutter if you have any questions concerning its safe operation. To get answers to any questions,
call our Customer Support Department.
This SAFETY ALERT SYMBOL identifies important safety messages in this manual. Failure to follow
this important safety information may result in serious injury or death.
DANGER! This Brush Cutter was built to be operated according to the safe operation practices in
this manual. As with any type of power equipment, carelessness or error on the part of the operator
can result in serious injury. This Brush Cutter is capable of amputating hands and feet and throwing
debris. Failure to observe the following safety instructions could result in serious injury or death.
The following signals, words and meanings are intended to explain the levels of risk associated with this product.
DANGER indicates a hazardous situation which, if not avoided, will result in serious injury or
death.
WARNING indicates a hazardous situation which, if not avoided, could result in serious injury
or death.
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
NOTICE is important information about the proper use of your Brush Cutter. Failure to follow
this instruction could result in damage to your Brush Cutter or property.
Because a trimmer/cutter is a high-speed, fast cutting power tool, special safety precaution must
be observed to reduce the risk of personal injury. Read this manual carefully. Be familiar with
the controls and the proper use of the unit. Know how to shut off your Brush Cutter and how to
unhook a harnessed unit quickly

5
WWW.BBTA.COM.AUBBT-BC-36CCBH, BBT-BC-36CCDH
IMPORTANT SAFETY INFORMATION
Key to Symbols
Symbol Description
READ THE OWNER’S MANUAL(S)
Read, understand and follow all instructions in the manual(s) before attempting to
assemble and operate.
FACE PROTECTION
Always wear safety goggles or safety glasses with side shields or a face shield when
operating this product as well as ear protection.
WEAR GLOVES
Always wear non-slip, heavy-duty protective gloves when operating this product.
WEAR SAFETY FOOTWEAR
Always wear non-slip steel-toed safety footwear when operating this product.
BEWARE OF FLYING OBJECTS
Danger of eye injury. Wear safety glasses.
BYSTANDERS
Keep bystanders, helpers and children at least 15 metres away.
BEWARE OF SHARP BLADES
Serious injury is possible.
BEWARE OF FALLING
OBJECTS
Serious injury is possible.
TURN OFF ENGINE
Make sure the cutting tool has stopped before cleaning, removing or adjusting
blade.
NEVER MODIFY A TRIMMER OR CUTTER IN ANY WAY
Improper use of any trimmer can cause serious or fatal personal injury.
BEWARE OF HAZARDOUS GASES
The engine exhaust from this product contains chemicals known to cause cancer,
birth defects, or other reproductive harm.
NO FIRE
No fire, no unprotected source of flame, no smoking.
WARNING! Your Responsibility—Restrict the use of this power machine to persons who have read,
understood and will follow the warnings and instructions in this manual and on the machine.
SAVE THESE INSTRUCTIONS!
15M
STOP
