BBT BBT-GEN-8000i Quick reference guide

OWNER’S MANUAL
Assembly & Operating Instructions
BBT 8000i Petrol Generator
MODEL NO. BBT-GEN-8000i
All manuals and user guides at all-guides.com
all-guides.com

2
WWW.BBTA.COM.AU BBT-GEN-8000i
To the Owner
Thank you for purchasing our Generator. It was carefully engineered to provide excellent performance when
properly operated and maintained.
Please read this entire manual prior to operating the Generator. It instructs you how to safely and easily set
up, operate and maintain your Generator. Please be sure that you and any other persons who will operate
the Generator carefully follow the recommended safety practices at all times. Failure to do so could result in
personal injury or property damage.
All information in this manual is relative to the most recent product information available at the time of printing.
Review this manual frequently to familiarise yourself with the machine, its features and operation. Please be
aware that this Owner’s Manual may cover a range of product specifications for various models. Characteristics
and features discussed and/or illustrated in this manual may not be applicable to all models. We reserve the right
to change product specifications, designs and equipment without notice and without incurring obligation.
All the power testing information used to establish the power rating of the engine equipped on this Generator
can be found in the engine manufacturer’s manual or website. If you have any problems or questions concerning
the machine, please contact our Customer Support Department.
Throughout this manual, all references to right and left side of the Generator are observed from the operating
position. The engine manufacturer is responsible for all engine-related issues with regards to performance,
power-rating, specifications, warranty and service. Please refer to the engine manufacturer’s Owner’s Manual
packed separately with your Generator for more information.
Customer Support
Please do NOT return the Generator without first contacting the Customer Support Department at
[e-mail].
If you have difficulty assembling this product or have any questions regarding the controls, operation, or
maintenance of this Generator, please contact our Customer Support Department.
SAVE THESE INSTRUCTIONS
All manuals and user guides at all-guides.com

3
WWW.BBTA.COM.AUBBT-GEN-8000i
TABLE OF CONTENTS
Page(s)
To the Owner .........................................................................................................................................................2
Customer Support..................................................................................................................................................2
TABLE OF CONTENTS .............................................................................................................................3
IMPORTANT SAFETY INFORMATION ................................................................................................. 4-5
Additional Information and Potential Changes...................................................................................................4
Safety Information.................................................................................................................................................5
PARTS LOCATION....................................................................................................................................6
PREPARATION BEFORE OPERATING................................................................................................... 6-7
Check Oil ................................................................................................................................................................6
Check Air-filter.......................................................................................................................................................6
Starting Engine ......................................................................................................................................................7
OPERATION......................................................................................................................................... 8-9
Use of circuit ..........................................................................................................................................................9
Stopping The Engine .............................................................................................................................................9
MAINTENANCE............................................................................................................................... 10-11
0il changing..........................................................................................................................................................10
Spark plug ............................................................................................................................................................11
Maintenance of fuel-filter ..................................................................................................................................11
TROUBLESHOOTING.............................................................................................................................12
SPECIFICATIONS....................................................................................................................................13
WARRANTY & SERVICE ........................................................................................................................13
EXPLODED DIAGRAM & PARTS LIST.............................................................................................. 14-19
Fig 00. Cylinder Head System Assy. .....................................................................................................................14
Fig 01. Engine.......................................................................................................................................................14
Fig 02. Cylinder barrel .........................................................................................................................................14
Fig 03. Crankshaft System Assembly...................................................................................................................15
Fig 04. Piston and Connecting Rod System Assembly........................................................................................15
Fig 05. Camshaft System Assy..............................................................................................................................15
Fig 06. Recoil Starter System Assembly...............................................................................................................15
Fig 07. Fan Cover System Assy. ............................................................................................................................16
Fig 08. Carburettor System Assembly .................................................................................................................16
Fig 09. Flywheel System Assy...............................................................................................................................16
Fig 10. Ignition System Assy.................................................................................................................................16
Fig 11. Starter Motor System Assembly ..............................................................................................................16
Fig 12. Control System Assy. ................................................................................................................................17
Fig 13. Muffler System Assy.................................................................................................................................17
Fig 14. Air Cleaner Assy........................................................................................................................................17
Fig 15. Fuel Tank System Assy..............................................................................................................................18
Fig 16. Control Panel ...........................................................................................................................................18
Fig 17. Frame Assy................................................................................................................................................18
Fig 18. Rotor Stator .............................................................................................................................................18
Fig 19. Battery Tray System Assy .........................................................................................................................19
Fig 20. Wheel .......................................................................................................................................................19
YOU MAY ALSO LIKE ...........................................................................................................................20
All manuals and user guides at all-guides.com

4
WWW.BBTA.COM.AU BBT-GEN-8000i
IMPORTANT SAFETY INFORMATION
Additional Information and Potential Changes
We reserve the right to discontinue, change, and improve our products at any time without notice or obligation
to the purchaser. The descriptions and sections contained in this manual were in effect at the time of printing.
Equipment described within this manual may be optional. Some illustrations may not be applicable to your
machine.
WARNING: Read and thoroughly understand all instructions in this manual and on the safety decals
before assembling or operating this Generator. Failure to do so may cause serious injury or death.
Do not allow anyone to operate this Generator who has not read this manual. As with all power
equipment, a Generator can be dangerous if assembled or used improperly. Do not operate this
Generator if you have any questions concerning its safe operation. To get answers to any questions,
call our Customer Support Department.
This SAFETY ALERT SYMBOL identifies important safety messages in this manual. Failure to follow
this important safety information may result in serious injury or death.
DANGER! This Generator was built to be operated according to the safe operation practices in this
manual. As with any type of power equipment, carelessness or error on the part of the operator can
result in serious injury. Failure to observe the following safety instructions could result in serious injury
or death.
The following signals, words and meanings are intended to explain the levels of risk associated with this product.
DANGER indicates a hazardous situation which, if not avoided, will result in serious injury or
death.
WARNING indicates a hazardous situation which, if not avoided, could result in serious injury
or death.
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
NOTICE is important information about the proper use of your Generator. Failure to follow
this instruction could result in damage to your Generator or property.
WARNING! Your Responsibility—Restrict the use of this power machine to persons who have read,
understood and will follow the warnings and instructions in this manual and on the machine.
SAVE THESE INSTRUCTIONS!
All manuals and user guides at all-guides.com

5
WWW.BBTA.COM.AUBBT-GEN-8000i
PLEASE READ AND UNDERSTAND THIS MANUAL COMPLETELY
BEFORE OPERATING THE MACHINE.
Safety Information
NEVER use your BBT 8000i Generator in the home.
NEVER use in wet conditions.
NEVER connect generator to a household circuit.
Keep all flammable products at a safe distance.
Extinguish all cigarettes, cigar, pipes and any other sources of ignition when
refuelling your generator.
When refuelling if fuel is spilled, wipe it off the generator and move machine
to another area and wait 5 minutes before starting the engine.
Always make sure engine is turned off when refuelling.
IMPORTANT SAFETY INFORMATION
All manuals and user guides at all-guides.com

6
WWW.BBTA.COM.AU BBT-GEN-8000i
1. Fuel Tank
2. Fuel On/Off
3. Air Filter
4. Key Ignition Switch
5. Circuit Breaker
6. 24 Volt Plug
7. DC
8. Oil Cap
9. Battery
10. Spark Plug
11. Carburettor
12. Choke
Check Oil
PARTS LOCATION
PREPARATION BEFORE OPERATING
1. Remove clips and remove the outer covering off
the air-filter.
2. Remove sponge filter.
3. Clean air filter by patting several times, this should
remove most of the dust.
4. Replace air filter back on generator.
1. Make sure your generator is on flat, dry solid
ground before operating.
2. Take oil cap off and remove dip stick.
3. Check oil level.
4. Fill to adequate level as required.
5. Replace oil cap.
Check Air-filter
All manuals and user guides at all-guides.com
all-guides.com

7
WWW.BBTA.COM.AUBBT-GEN-8000i
3. Put choke to “ON” position.
1. Remove any load from circuit out
and close circuit breaker.
Starting Engine
PREPARATION BEFORE OPERATING
5. Pull operating handle softly until
you feel a resistance then pull
with greater force.
2. Switch fuel valve to “ON“.
4. Switch the engine switch to “ON”.
6. When engine gets hot, turn the
choke “OFF”
All manuals and user guides at all-guides.com

8
WWW.BBTA.COM.AU BBT-GEN-8000i
2. Electrical equipment, especially the engine produces a strong current when being started. It is recommended
that you use a surge protector at all times on your generator.
3. When more than two loads are connected to generator, ensure connection is from high current to low.
• When connecting generator to your power supply, this must be carried out by a qualified electrician.
• Make sure your connections are wired correctly and you are not using power that is beyond your generators
capacity, this could cause damage to generator or in some cases fire.
To keep your generator in good mechanical condition and electric condition,
please follow the below instructions.
1. Ensure that connection from your generator to the grounding rod grounds the generator for safe operation.
OPERATION
OGood connection XIncorrect connection
OGood connection
All manuals and user guides at all-guides.com

9
WWW.BBTA.COM.AUBBT-GEN-8000i
2. Turn engine switch to “OFF” position.
Stopping The Engine
OPERATION
1. Close the circuit cut-out.
3. Turn Off the fuel valve
If engine must be stopped urgently, pull the
switch to “OFF”
Use of circuit
1. Start the engine. 2. Plug in connection. 3. Connect the circuit cut-out. Push
down the circuit protector.
All manuals and user guides at all-guides.com

10
WWW.BBTA.COM.AU BBT-GEN-8000i
MAINTENANCE
Before each use Every Month or
20 Hrs
Every 3 Months
or 50 Hrs
Every 6 Months
or 300 Hrs
Every Year
or 300 Hrs
Lubricant
Checking
Check oil level 
Replace  
Air-filter
Checking
Check 
Clean /
Replace if necessary 
Fuel Cock Filter Clean fuel cock filter.
Replace if necessary 
Fuel Cock Filter Clean fuel cock filter.
Replace if necessary 
Spark Plug
Check condition adjust
gap and clean / Replace
if necessary 
Valve Gap Check and adjust when
engine is cold. 
Cylinder Cover Cleaning of Cylinder
Cover 
Oil Tank Cleaning of Fuel Tank Every Three Years
0il changing
1. Remove dip stick. 2. Remove drain plug. 3. Replace drain plug.
4. Pour oil till the upper limitation of
engine oil dip stick. 5. Replace the oil engine dip stick.
All manuals and user guides at all-guides.com
