BCB CZ-1L User manual

!
!
!
!
!
!
!
!
!
!
!
!
!
!
Broadcast Camera Batteries,
Inc.
[email protected]
www.broadcastcamerabatteries.com
!!
!
!
!
!
!
BCB
!
!
Multi-function Charger
!
!
User’s Manual
!
!
!
!
!
Broadcast Camera Batteries, Inc.
!
!
!
!
!
!
!
!

Our brand of multi-function chargers ”BCB”, is a series of great
quality chargers for charging professional camcorder batteries.
The charger is controlled by computer-integrated module
during charging, which helps ensure quick charge. Inside of the
charger there is more protection, so the charger is more
powerful, safer, and easier to use. The input voltage is suitable
to charge batteries all over the world. If you are looking for
quality camcorder chargers at an affordable price “BCB” is your
best choice.
!
1. Charging:
First plug the charger into AC, attach a battery onto it till the
battery clicks on the mount (Gold Mount or V-mount) then turn
on when it says “Charge”. You can tell the charger is charging
by seeing that the red indicator light is on. When you detach
the battery from the charger the green indicator light should be
on. When the battery is fully charged the green indicator light
should be on again.
!
2. Adapting:
When the charger is connected to AC, turn on “Supply” in
charging/supplying then the green indicator light should be on.
The adapter can offer DC 15V/70W output. For all chargers in
the series the output polarity is 4 “+”,1“-”.
!
3. Attention:
1) The charger storage temperature: from -20 till 55℃
2) Working temperature: from -10 till 45℃
3) When working with the charger normally, make sure
the fan Is not covered. As soon as the charger is not
connected to AC power take off the battery.
4) If you have any problems or questions please contact
your local distributor.
!
4. Specifications:
Model
Input
power
Chargin
g output
Adaptin
g output
Comp
atible
Size
(mm)
Weigh
t
(g)
!
CZ-1L
AC100V-24
0V,
50-60HZ,
50VA
!
DC16.8V
/2A
!
----
!
AB, V,
NP
!
120x6
8x36
!
380
CZ-2L
AC100V-24
0V,
50-60HZ,
50VA
!
DC16.8V
/2A*2
!
!
------
!
AB, V,
NP
!
120x6
8x36
!
380
CZ-2AL
AC100V-24
0V,
50-60HZ,
80VA
two-
channels
charging
in-phase
16.8V/
1.6A
DC15V/
70W
AB
210x1
42x60
2000
CZ-2BL
AC100V-24
0V,
50-60HZ,
80VA
two-
channels
charging
in-phase
16.8V/
1.6A
DC15V/
70W
V
210x1
42x60
2000
CZ-4AL
AC100V-24
0V,
50-60HZ,
160VA
Four-
channels
charging
in-phase
16.8V/
1.6A
Two-
channels
a d a p t e r
in-phase
DC15V/
70W
AB
252x1
26x16
0
2500
CZ-4BL
AC100V-24
0V,
50-60HZ,
160VA
Four-
channels
charging
in-phase
16.8V/
1.6A
Two-
channels
a d a p t e r
in-phase
DC15V/
70W
V
252x1
26x16
0
2500
