BDEUS ERIE Series User manual

Owner’s Manual
ERIE SERIES
Rev 1.0 07/2021
Serial No:
All Rights Reserved.

Parts List ............................................02
Installation Guide................................02
Remote Control Guide........................07
APP Control Guide..............................08
CONTENTS
Safety & Warranty Warning....................01
Troubleshooting..................................09
01
ATTENTION!
Important safety instructions. Please read these instructions thoroughly before using this product.
RADIO FREQUENCY: 2.4 GHz
FCC COMPLIANCE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
To comply with the FCC RF exposure requirements, no change to the antenna or the device is permitted. Any change to
the antenna or the device could result in the device exceeding the RF exposure requirement and void user’s right to
operate the device.
When using an electrical furnishing, basic precautions should
always be followed, including the following:
Read all instructions before using (this furnishing).
DANGER – To reduce the risk of electric shock
1. Always unplug this furnishing from the electrical outlet
before cleaning or servicing
WARNING – To reduce the risk of burns, fire, electric shock,
or injury to persons:
1. Unplug from outlet before putting on or taking off parts.
2. Close supervision is necessary when this furnishing is
used by, or near children, invalids, or disabled persons.
3. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended
by the manufacturer.
4. Never operate this furnishing if it has a damaged cord or
plug, if it is not working properly, if it has been dropped or
damaged, or dropped into water. Return the furnishing to a
service center for examination and repair.
5. Keep the cord away from heated surfaces.
6. Do not use bed outdoors.
7. Do not use bed near explosives.
8. Using bed with oxygen administering equipment other than
the nasal masked type creates a possible fire hazard.
9. Do not operate where aerosol (spray) products are being
used or where oxygen is being administered.
10. To disconnect, turn all controls to the off position, then
remove plug from outlet.
11. Use caution when having liquids in or around the bed to
ensure no spilling occurs. In case of spillage, stand in a dry,
clean area of the floor and unplug the bed immediately. Clean
up spill and allow the area around bed to dry thoroughly
before using the electric controls again. Do not eat or drink hot
liquids while operating the bed.
12. Do not allow any person or pet under the bed at any time.
13. During bed operation, make sure body is positioned
within the confines of the bed. Do not place extremities
over the sides of the bed when operating bed functions.
14. Only for household and similar location use.
PRODUCT RATING:
• The motors are not designed to operate continuously for more
than [2] minutes in an [20] minute time period or approximately
10% duty cycle. Attempting to circumvent or exceed this rating
will shorten the life expectancy of the foundation and may void
the warranty.
OPERATING INFORMATION:
• After power foundation assembly is completed, operate remote
control to ensure proper functions.
• Keep moving parts free of obstruction during bed operation
(including sheets, clothing, tubing, wiring, and products using
electric power cords).
• Distribute body weight evenly over bed surface. Do not place
entire weight on head or foot sections of the bed, during
repositioning and entering or exiting bed.
HOSPITAL DISCLAIMER:
• It is NOT designed for hospital use and is NOT designed to meet
hospital standards.
15. Never operate the furnishing with the air openings blocked.
Keep the air openings free of lint, hair, and the like.
16. Never drop or insert any object into any opening.
SAVE THESE INSTRUCTIONS
WARRANTY WARNINGS:
• Any opening or tampering with the control box, motors, or hand
controls (with the exception of the battery compartment if
equipped) will result in a void of the warranty.
WEIGHT LIMITS:
• Weight Restrictions: The recommended weight limits on our
adjustable beds is 650 pounds. The bed will structurally support
this weight, provided it is evenly distributed across the foundation.
The power foundation is not designed to support or lift this
amount in the head or foot sections alone. Exceeding this weight
restriction could damage the bed and/or cause injury and will
void the warranty.
IMPORTANT SAFETY INSTRUCTIONS

02 03
All electronics and components that need to be installed are placed in boxes under the foundation or
attached to the frame. Before discarding the packing materials, ensure that all the parts are accounted for.
Standard Parts List
Wireless Remote
x1
Power Supply
（29V 2.0A）
x1
AC Power Cord
x1
Leg Assy 8"
8"
x6
Mattress Retainer Bar
x1
Optional Accessories (universal parts)
Not Included
x1
9V 9V
Battery Lock Wire
（Not included）
（Not included）
3"+6"
Bluetooth
x1
Sync Cord
( single bed only)
x1
Adjustable Legs
x6
NOTE: To avoid damage to the foundation,always open the
carton while the foundation is in the flat position.
9V 9V
power supply with battery backup box 3.
Install legs and tighten by hand.
Two people are required to set up the foundation.
1.
Installation Guide
Open the box, take out all the packing components.
Wireless Remote
3xBattery
x1
x1
Power Supply
(29V 2.0A)
x1
AC Power Cord
x1 x6
Mattress Retainer Bar
x1
8"
2.
Remove the foundation from the box. Make sure the floor is clean. Flat the foundation.
Leg Assy 8"
3xBattery
（Not included）
Battery Lock Wire
9V 9V
（Not included）

04 05
Leg Configuration Table（Optional）
Support legs may be needed on some slat/platform foundation, refer to the leg configuration table for height
adjustment.
Add Additional Leg Supports For Slat/Platform Foundation.
3 " 6 "
9 "
Electronics Quick Reference Guide
Wireless Remote
Power Supply
Bluetooth
Foot Motor
Head Motor
Head
Motor Foot
Motor
Power USB LED
APP Sync
DC Power Cord
4.
Carefully rotate the f oundation over so
it is resting on its legs.
AC Power Cord
DC Power Cord
Power Supply
AC Power Source
Connect the DC power cord to the power supply, uncoil the AC power cord
and then connect it to the AC power source .
Connect the connectors as illustrated.
DONE!
+
Insert batteries into the wireless remote.
6.
7.
5. 1
2
Slide the left side of the mattress retainer
bar into the block. Pull the retainer bar to
the opposite bracket and secure the right
side.

06 07
Synchronizing Two Foundations
If simultaneous operation of two foundations is desired, use the sync cord to connect the electronics of both
foundations together.
Sync Cord
Wireless Remote
Head
Motor Foot
Motor
Power USB LED
APP Sync Head
Motor Foot
Motor
Power USB LED
APP Sync
Attention: ( 1) If you want to toggle from "A" or "B" to "P" position (in the middle of "A" and "B") to realize sync control,
please press and hold "Flat" again until to a flat position.
( 2) The quadded cable is in master control when
synchronizing and the bluetooth must be pluged in the master control box. (3) The interval must more than
4s between plug in and plug out the sync cord.
STEP 1：Unplug foundations from the power source.
STEP 2：Connect the male ends of the sync cord to the female sync plugs of the control boxes (Refer to
illustration above).
STEP 3：
Plug foundations back into the power source.
STEP 4：Press and hold and button, a beep sound of the buzzer will be heard and the backlit light
of the wireless remote flashes twice. Open the battery box and toggle the switch to “P” position (in the
middle of "A" and "B") first, next press and hold “FLAT” until you hear a beep sound of each buzzer
on the control box, which means the two foundations can be synchronized with one remote.
STEP 5：Open the battery box and toggle the switch to "A" or "B" position, you can control the two foundations
separately without removing the sync cord.
Remote Pairing
1. Unplug the foundation from the power source then power it on,defaulting to remote pairing within 30s.
2. Next press and hold at the same time.
3. You will hear a beep sound of the buzzer and the backlit light of the wireless remote flashes two times, which
means the pairing is successful.
The original remote that comes in the box is already paired to the foundation. No further action is required.In
the event that the remote is not paired with the foundation, follow the steps below.
Head
Motor Foot Motor
Power USB LED
APP Sync
Quadded Cable
Triplex Cable
Foot lifting
Foot lowering
Head lifting
Head lowering
Zero Gravity
Remote Control Instructions
HEAD UP/DOWN BUTTONS
Press and hold to lift or lower the HEAD section.
FOOT UP/DOWN BUTTONS
Press and hold to lift or lower the FOOT section.
Press to adjust the foundation to the programmed reclined position for optimum weight distribution.
Press to adjust the foundation to the flat position.
Adjustment
Flat

08 09
Battery Lock Wire Installation Guide
Dream Motion APP（Optional）
The Dream Motion APP is applied to control the foundation, available to both IOS and Android users.
IOS
Android
Open the APP store, search the keyword "Dream Motion" to download the application. Dream Motion
Open the Google Play to search the keyword "Dream Motion" and download the application. Dream Motion
When disconnect the power supply,the battery lock wire and two batteries with 9V 2A can be used together to
flat the foundation.
1. 2.
9V 9V
DC power cord
9V 9V
Head
Motor Foot
Motor
Power USB LED
APP Sync
How To Reset
STEP 1：Unplug foundations from the power source.
STEP 2：Plug foundations back into the power source after 60 seconds.
STEP 3：Automatic reset is completed
Please follow the operation guidance in APP!
• Make sure the remote control is paired with the foundation
• Check that the power cord is plugged into a working and grounded
electrical outlet. Unplug the power cord from the outlet. After 30
seconds, plug it back in. Press any button on the remote control
and hold until light on the wireless remote illuminates.
• Make sure the wireless remote is paired with the
foundation .
• Check that the power cord is plugged into a working and grounded
electrical outlet. Unplug the power cord from the outlet. After 30
seconds, plug it back in. Press any button on the wireless remote
and hold until light on the wireless remote illuminates.
• Check that the surge protection device or electrical outlet is not
defective. Test the outlet by plugging in another working appliance.
• Your
foundation may be obstructed preventing smooth operation.
Remove obstructions from around and under the bed.
• Check that the head section is not too close to the wall.
• If a headboard is installed, check that it is not too close to the
edge of the mattress. Make sure there is enough distance between
the headboard bracket and the mattress.
• Check the batteries in the wireless remote. Replace with new
batteries, if necessary.
• Make sure that you are following the duty cycle of the motors.
Do not operate for more than two minutes over a 20-minute period
or approximately 10% duty cycle.
• Press the lift buttons firmly and accurately.
• Wireless remote control may be experiencing common radio
frequency interference from other radio transmitting devices. Wait
several seconds and then try pressing the lift buttons again.
• This is normal. The lift motors click when they are engaged. No
action is required.
• Power off and wait 1 minute and then power on and pairing again.
• Open the battery box and toggle the switch to "A" or "B" position, then
press "Memory 1", next press and hold "Flat" until hearing a beep sound
of each buzzer on the control box.
The adjustable foundation does not
respond when the remote is used.
Remote control led illuminates and
appears to be normal.
No features or function of the
foundation activates.
Head or foot lifts elevate
foundation
but does not return to flat position.
Head or foot lift function has minor
interference during operation.
A clicking noise is heard under the
foundation when raising or lowering
the sections.
Two foundations can't synchronoze.
Troubleshooting
In the event the adjustable foundation fails to operate, investigate the symptoms and possible solutions below.
