BE Power Equipment PIN FD24 User manual

24” & 36” DRUM FAN
OWNER’S MANUAL
Model: FD24 & FD36
AIR COMPRESSOR
OPERATORS MANUAL
Version 5.1
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
24” & 36” DRUM FAN
FD24
FD36
INSTRUCTION MANUAL
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

Page 1
POWER EQUIPMENT
POWER EQUIPMENT
FD24 & FD36 OWNER’S MANUAL
SPECIFICATIONS
Please read and follow the instructions in this user manual even if you feel you are
familiar with the product and nd a place to keep it handy for future reference.
NOTE: The rating of this product (as marked on the product identication plate)
is based on specic loading tests. Normal use or the use of other recommended
attachments may draw signicantly less power.
BEFORE FIRST USE
Before use, remove all packaging and inspect the appliance for any damage. If
there appears to be any damage, please take the unit back to place of purchase
for replacement.
OPERATING INSTRUCTIONS
NOTE:
Before inserting the plug into a power outlet, make sure that the correct volt-
age being used corresponds to what is indicated on the rating label, and that
the socket has an earth facility.
The fan can be manually titled up and down.
MODEL PIN FD24 PIN FD36
Power (Watt) 180W Copper Wound Motor 380W Copper Wound Motor
Air Flow (m3/Min) 200 465
Speeds 3-Speed 3-Speed
Power 240V 10A 240V 10A
Motor (RPM) 1150 1250
Motor Style Tropic Proofed Motor Tropic Proofed Motor
Gross Weight 17KG 25KG

Page 2
POWER EQUIPMENT
POWER EQUIPMENT
FD24 & FD36 OWNER’S MANUAL
CAUTION: Select a suitable location for the fan. Always choose a safe location in
accordance with the safety recommendations outlined.
1. Place the fan on a rm, secure and level surface:
Verify that the feet and wheels are properly positioned.
Verify that the area around the surface is clean, without dust.
2. Plug the fan into a power outlet.
3. Select the desired speed by pressing turning the knob:
O-OFF
1-LOW SPEED
2-MEDIUM SPEED
3-HIGH SPEED
4. Adjust the desired air direction by tilting the fan assembly to the required
position.
CAUTION: The fan should always be switched off when making any adjustments
to the fan head angle.
5. Once the unit is switched off, pull out the plug from the socket.
NOTE: When not in use for prolonged periods of time, the plug must always be
removed from the socket.
Model Description Voltage Frequency Wattage
FD24 600mm drum fan 240V 50Hz 180W
FD36 900mm drum fan 240V 50Hz 380W
SPECIFICATIONS:
Please read and follow the instructions in this user manual even if you feel you are
familiar with the product and find a place to keep it handy for future reference.
NOTE: The rating of this product (as marked on the product identification plate) is
based on specific loading tests. Normal use or the use of other recommended
attachments may draw significantly less power.
BEFORE FIRST USE
Before use, remove all packaging and inspect the appliance for any damage. If there
appears to be any damage, please take the unit back to place of purchase for
replacement.
OPERATING INSTRUCTIONS
NOTE:
• Before inserting the plug into a power outlet, make sure that the correct voltage being
used corresponds to what is indicated on the rating label, and that the socket has an
earth facility.
•The fan can be manually titled up and down.
CAUTION: Select a suitable location for the fan. Always choose a safe location in
accordance with the safety recommendations outlined.
1. Place the fan on a firm, secure and level surface:
-Verify that the feet and wheels are properly positioned.
-Verify that the area around the surface is clean, without dust.
2. Plu
g the
fan
into a
power
outlet.
3. Select the desired speed by pressing turning the knob:
•O-OFF
•1-LOW SPEED
•2-MEDIUM SPEED
•3-HIGH SPEED
4. Adjust the desired air direction by tilting the fan assembly to the required position.
CAUTION: The fan should always be switched off when making any adjustments to the
fan head angle.
5. Once the unit is switched off, pull out the plug from the socket.
NOTE: When not in use for prolonged periods of time, the plug must always be removed
from the socket.
IMPORTANT SAFEGUARDS
When using any electrically powered product, basic safety precautions should always be followed,
including the following:
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT
WARNING: To reduce the risk of fire, electrical shock or injury to persons or property:
• Always operate the product from a power source of the same voltage, frequency and
rating as indicated on the product identification plate.
• Remove the unit from its packaging and check to make sure it is in good condition
before using.
• Do not let children play with parts of the packaging (such as plastic bags).
• Close supervision is necessary when the product is used by or near children. Do not
allow children to use it as a toy.
• Do not operate any product with a damaged cord or plug, after the product
Model Description Voltage Frequency Wattage
FD24 600mm drum fan 240V 50Hz 200W
FD36 900mm drum fan 240V 50Hz 380W

Page 3
POWER EQUIPMENT
POWER EQUIPMENT
FD24 & FD36 OWNER’S MANUAL
IMPORTANT SAFEGUARDS
When using any electrically powered product, basic safety precautions should
always be followed, including the following:
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT
WARNING: To reduce the risk of re, electrical shock or injury to persons or
property:
Always operate the product from a power source of the same voltage,
frequency and rating as indicated on the product identication plate.
Remove the unit from its packaging and check to make sure it is in good
condition before using.
Do not let children play with parts of the packaging (such as plastic bags).
Close supervision is necessary when the product is used by or near children.
Do not allow children to use it as a toy. malfunctions, or is dropped or appears
damaged in any way. Return the complete product to the place of purchase for
inspection, repair, or replacement.
Before unplugging the power cord, be sure to tum the power off. When
touching the unit, be sure your hands are dry to prevent electrical shock.
Do not let children play with parts of the packaging (such as plastic bags).
Close supervision is necessary when the product is used by or near children.
Do not allow children to use it as a toy.
Do not operate any product with a damaged cord or plug, after the product
malfunctions, or is dropped or appears damaged in any way. Return
the complete product to the place of purchase for inspection, repair, or
replacement.
Before unplugging the power cord, be sure to tum the power off. When
touching the unit, be sure your hands are dry to prevent electrical shock.
Never install the unit where it is exposed to direct sunlight, excessive moisture/
rain, dust, and lack of ventilation near any heat sources.
Avoid making contact with moving parts. Never insert ngers, pencils, or any
other objects through the guards whenever the power plug is connected,
especially while the unit is working.
Always place the fan on a stable, level surface when operating to prevent the
fan from overturning. Do not run the power cord under a carpet. Do not cover
the power cord with throw rugs or runners. Route the power cord away from
walking paths so that nobody can trip over it. The cable should be kept away
from heat, sharp edges, and oil.

Page 4
POWER EQUIPMENT
POWER EQUIPMENT
FD24 & FD36 OWNER’S MANUAL
ELECTRIC SCHEMATIC DIAGRAM
RECYCLING
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
malfunctions, or is dropped or appears damaged in any way. Return the complete
product to the place of purchase for inspection, repair, or replacement.
• Before unplugging the power cord, be sure to tum the power off. When touching the
unit, be sure your hands are dry to prevent electrical shock.
•Do not let children play with parts of the packaging (such as plastic bags).
•Close supervision is necessary when the product is used by or near children. Do not
allow children to use it as a toy.
• Do not operate any product with a damaged cord or plug, after the product •
malfunctions, or is dropped or appears damaged in any way. Return the complete
product to the place of purchase for inspection, repair, or replacement.
• Before unplugging the power cord, be sure to tum the power off. When touching the
unit, be sure your hands are dry to prevent electrical shock.
• Never install the unit where it is exposed to direct sunlight, excessive moisture/rain,
dust, and lack of ventilation near any heat sources.
• Avoid making contact with moving parts. Never insert fingers, pencils, or any other
objects through the guards whenever the power plug is connected, especially while the
unit is working.
• Always place the fan on a stable, level surface when operating to prevent the fan from
overturning. Do not run the power cord under a carpet. Do not cover the power cord
with throw rugs or runners. Route the power cord away from walking paths so that
nobody can trip over it. The cable should be kept away from heat, sharp edges, and oil.
ELECTRIC SCHEMATIC DIAGRAM
RECYCLING
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of hazardous
substances.
malfunctions, or is dropped or appears damaged in any way. Return the complete
product to the place of purchase for inspection, repair, or replacement.
• Before unplugging the power cord, be sure to tum the power off. When touching the
unit, be sure your hands are dry to prevent electrical shock.
•Do not let children play with parts of the packaging (such as plastic bags).
•Close supervision is necessary when the product is used by or near children. Do not
allow children to use it as a toy.
• Do not operate any product with a damaged cord or plug, after the product •
malfunctions, or is dropped or appears damaged in any way. Return the complete
product to the place of purchase for inspection, repair, or replacement.
• Before unplugging the power cord, be sure to tum the power off. When touching the
unit, be sure your hands are dry to prevent electrical shock.
• Never install the unit where it is exposed to direct sunlight, excessive moisture/rain,
dust, and lack of ventilation near any heat sources.
• Avoid making contact with moving parts. Never insert fingers, pencils, or any other
objects through the guards whenever the power plug is connected, especially while the
unit is working.
• Always place the fan on a stable, level surface when operating to prevent the fan from
overturning. Do not run the power cord under a carpet. Do not cover the power cord
with throw rugs or runners. Route the power cord away from walking paths so that
nobody can trip over it. The cable should be kept away from heat, sharp edges, and oil.
ELECTRIC SCHEMATIC DIAGRAM
RECYCLING
For further information, please contact your local or regional authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of hazardous
substances.
Do not operate any product with a damaged cord or plug, after the product
malfunctions, or is dropped or appears damaged in any way. Return
the complete product to the place of purchase for inspection, repair, or
replacement.
Before unplugging the power cord, be sure to tum the power off. When
touching the unit, be sure your hands are dry to prevent electrical shock.
Never install the unit where it is exposed to direct sunlight, excessive moisture/
rain, dust, and lack of ventilation near any heat sources.
Avoid making contact with moving parts. Never insert ngers, pencils, or any
other objects through the guards whenever the power plug is connected,
especially while the unit is working.
Always place the fan on a stable, level surface when operating to prevent the
fan from overturning. Do not run the power cord under a carpet. Do not cover
the power cord with throw rugs or runners. Route the power cord away from
walking paths so that nobody can trip over it. The cable should be kept away
from heat, sharp edges, and oil.

Distributed in Australia by
CONTACT DETAILS
B.A.R Group P/L
15 Hudson Place,
Mulgrave, NSW, Australia 2756
Phone: [phone]
www.bargroup.com.au
Distributed in New Zealand by
CONTACT DETAILS
BE Pressure Supply
541D Te Rapa Road, Te Rapa,
Hamilton 3200, New Zealand
Phone: [phone]
www.bepressure.co.nz
Errors and omissions excepted.
Specications and performance may change.
Version 5.1; 2021
AIR COMPRESSOR
OPERATORS MANUAL
Version 5.1
