LZR® -MICROSCAN U920
LASER MEASUREMENT DEVICE
WITH BIDIRECTIONAL BUS COMMUNICATION
User’s Guide for product version 0100 and more

3
1
2
3
5
1 2
DESCRIPTION
Other use of the device is outside the permitted purpose and can not be guaranteed by the manufacturer.
The manufacturer cannot be held responsible for incorrect installations or inappropriate adjustments of the device.
LASER MEASUREMENT DEVICE
1. laser sweep emission
2. laser sweep reception
3. LED-signal
4.
5.
6. cable conduit
LED-SIGNAL
Has been switched ON and keep running in measurement mode.
error
In configuration mode
4
6
reset button
take of the cover
and internal shroud
holes for M4 screws

4
1
2
1 2
3 4
MOUNTING
WIRING
INSTALLATION STEPS
Use the adhesive mounting template to
position the sensor correctly. The grey
area indicates the measurement range.
Drill 2 holes as indicated on the
mounting template. Make a hole for
the cable.
Pass the cable through the cable hole. Position the sensor and fasten
the screws firmly.
*
Use M4 screws
For more information see application noteLZR® -MICROSCAN U920 Protocol or contact BEA.
*
Shield
Green
Brown
Yellow
Gray
Violet
Pink
GND
V+
V-
RS485A(RX+)
RS485B(RX-)
RS485Z(TX-)
RS485Y(TX+)

5
SAFETY
Do not look into the laser
emitter directly for long time. The warranty is void if
unauthorized repairs are
made or attempted by
unauthorized personnel.
Only trained and qualified
personnel may install and
adjust the sensor.
INSTALLATION AND MAINTENANCE
Avoid extreme
vibrations.
Do not cover
the front screens.
Avoid moving objects
and light sources in
the measurement
field.
Avoid condensation.
Avoid the presence
of smoke and fog
in the measurement
field.
Avoid exposure to
sudden and extreme
temperature changes.
Keep the sensor
permanently powered
in environments where
the temperature can
descend below -15 °C.
Wipe the front
screens regularly
with a clean and
damp cloth.
Do not use aggressive
products to clean
the front screens.
Avoid direct exposure
to high pressure
cleaning.
CAUTION!
Use of controls, adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
The device contains IR and visible laser diodes.
IR laser: wavelength 905nm; max. output pulse power 75W
(Class 1 according to IEC 60825-1)
For more information see application note LZR®MICROSCAN-U920 Protocol.
°C
-15°C
0°C
°C

6
TECHNICAL SPECIFICATIONS
Specifications are subject to changes without prior notice.
All values measured in specific conditions.
Technology:
Measurement range:
Number of planes:
Number of points/plane:
Angular resolution:
Angular coverage:
Rotating speed:
Scanning frequency:
Remission factor:
Laser emission characteristics:
Supply voltage:
Power consumption:
Peak current at power-on:
Serial communication:
Type
Interface
Communication mode
Transmission speed
Topology
Symbol coding
File type
Cable length:
LED-signal:
Dimensions:
Material:
Colour:
Protection degree:
Temperature range:
Humidity:
Vibrations:
Pollution on front screens:
Expected lifetime:
Norm conformity:
laser scanner, time-of-flight measurement
max 10 m
3 m @ 5% remission factor, 10 m @ 55% remission factor
max. 4*
max. 40*
min. 2.56 °*
max. 100 °*
1500 turns/min
25Hz
>2%
wavelength 905 nm
max. output pulse power 75 W (CLASS 1)
12-24 VDC/AC (±10%)
<4 W
1.5 A (max. 30 ms @ 24 V)
see AN LZR®-MICROSCAN U920 Protocol
asynchronous
RS 422
half-duplex
921600 bit/sec(default)
point to point
1 start bit, 1stop bit, no parity bit
8 bits
3 m
1 bi-coloured LEDs: function status;
118 mm (D) x 80 mm (W) x 54 mm (H)
PC/ABS
black
IP53
-25 °C to +55 °C if powered; -15 °C to +55 °C unpowered
0-95 % non-condensing
< 2 G
max. 30 %; homogenous
8 years
2006/95/EC: LVD; 2011/65/EU: RoHS 2; 2004/108/EC: EMC
IEC 60825-1:2007 Laser Class 1&3R
EN 61000-6-2:2005 EMC - Industrial level
EN 61000-6-3:2006 EMC - Commercial level
*
These parameters can be configured via the RS 422 communication interface.
PARAMETER ADJUSTMENT
For more information on the existing parameters that can be configured, see AN LZR
®MICROSCAN-U920 Protocol.

7
1
1
1
1
1
1
TROUBLESHOOTING
No LED
The orange LED
is on.
There is no power.
The power supply voltage
is exceeding the acceptable
limits.
The sensor exceeds its
temperature limits.
Internal error
Check cable and connections.
Check the power supply voltage.
Verify the outside temperature where the sensor
is installed. Eventually protect the sensor from
sunlight using a cover.
Wait a few seconds.
If the LED remains ON, reset the power supply.
If the LED turns on again, replace the sensor.
Enable LED by command.
The orange LED
flashes 3 times. EEPROM error Open the cover. Keep pushing RESET button for more
than 2 seconds. Repower the sensor.
NOTES
LED is disabled.

8
BEA SA | LIEGE Science Park | ALLÉE DES NOISETIERS 5 - 4031 ANGLEUR [BELGIUM] | T [phone] | F [phone] | [email protected] | WWW.BEA-SENSORS.COM
| Original instructions |69.0958/V2-2019.06
PLEASE KEEP FOR FURTHER USE DESIGNED FOR COLOUR PRINTING
BEA hereby declares that the LZ ®R -MICROSCAN U920 is in conformity with the basic
requirements and the other relevant provisions of the directives 2006/95/EC,
2011/65/EU and 2004/108/EC.
Angleur, June 2013 Pierre Gardier, authorized representative
