BEA LZR-I30/S600 User manual

UNIVERSAL REMOTE CONTROL | LZR-I30/S600
LZR-I30/S600 PARAMETERS
A - NO
P - NC
A - NOP - NC P - NC
A - NO
P - NCA - NO
R1
R2
A = active
P = passive
NO = normally open
NC = normally closed
OUTPUT CONFIGURATION
MINIMUM OBJECT SIZE
The distances between the curtains depends on the mounting height and side.
When mounted on the left, the distance between curtain C1 and curtain C4 is approximately 4 in. for every 3 ft (mounting height).
EXAMPLE: At 15 ft. mounting height, the distance between C1 and C4 is 20 in.
LZR TIPS
THE LZR-I30REQUIRES 10-35 V CLEAN DC POWER
(NON-RECTIFIED)
AFTER 30 MINUTES, THE SENSOR LOCKS ACCESS TO
THE REMOTE CONTROL SESSION. POWER CYCLE THE
SENSOR TO RECONFIGURE.
A BEA UNIVERSAL REMOTE IS REQUIRED TO
CONFIGURE THE LZR-I30.
UNIVERSAL REMOTE CONTROL TIPS
TO QUESTION A PARAMETER, PRESS
AFTER UNLOCKING AND CHOOSING A
PARAMETER. COUNT THE LED FLASHES.
CONSIDER USING AN ACCESS CODE
TO SET AN ACCESS CODE:
TO DELETE AN ACCESS CODE:
VIRTUAL PUSH PLATE:
FACTORY DEFAULTS:
ALWAYS FINISH AN ADJUSTMENT SESSION
BY LAUNCHING A SETUP:
TO TURN THE LEDs ON/OFF:
FOR VISIBLE LASER BEAMS:
TO CHANGE OR QUESTION A PARAMETER,
START BY PRESSING THE AND FINISH
THE SESSION BY PRESSING
# OF ACTIVE DETECTION CURTAINS
Increase in case of snow, dead leaves, etc.
UNCOVERED ZONE
2in 4in 6in 8in 10in
MOUNTING SIDE
left right left center
WITH BACKGROUND WITHOUT BACKGROUND
right
indoor outdoor
low
outdoor
med
outdoor
high
Choose between environment or object.
IMMUNITY FILTER
FOR CRITICAL ENVIRONMENTS
(RAIN, SNOW, FOG)
indoor outdoor
low
outdoor
med
outdoor
high
FOR CRITICAL OBJECTS
(BLACK CARS)
OFF 3in 4in 6in 8in
OUTPUT ACTIVATION DELAY
OFF 100ms 200ms 300ms 400ms 500ms 600ms 700ms 800ms 900ms
The relays are triggered when the detection duration ≥ the selected time.
CURTAIN C1 C2 C3 C4
CURTAIN IS INACTIVE ON BOTH FIELDS
CURTAIN IS ACTIVE ON OPTIONAL FIELD
CURTAIN IS ACTIVE ON SAFETY FIELD
CURTAIN IS ACTIVE ON BOTH FIELDS
C1 + C2 ARE ACTIVE ON SAFETY FIELD
C3 + C4 ARE ACTIVE ON OPTIONAL FIELD
C1 IS ACTIVE ON BOTH FIELDS
C2 + C3 ARE ACTIVE ON SAFETY FIELD
C4 IS INACTIVE
ALL CURTAINS ARE ACTIVE ON BOTH FIELDS
EXAMPLE CONFIGURATIONS
OPTIONAL FIELD WIDTH
OPTIONAL FIELD HEIGHT
SAFETY FIELD WIDTH
SAFETY FIELD HEIGHT

UNIVERSAL REMOTE CONTROL | FALCON & IS40 SERIES
79.0216.01 20150217
MICROWAVE PARAMETERS
INFRARED PARAMETERS
LEARN TIME EXPLANATION
UNIVERSAL REMOTE CONTROL TIPS
TO QUESTION A PARAMETER, PRESS
AFTER UNLOCKING AND CHOOSING A
PARAMETER. COUNT THE LED FLASHES.
CONSIDER USING AN ACCESS CODE
TO SET AN ACCESS CODE:
TO DELETE AN ACCESS CODE:
RELAY CONFIGURATION:
FACTORY DEFAULTS:
ALWAYS FINISH AN ADJUSTMENT SESSION
BY LAUNCHING A SETUP:
TO CHANGE OR QUESTION A PARAMETER,
START BY PRESSING THE AND FINISH
THE SESSION BY PRESSING
1- 4
low
SENSITIVITY
XXS XS S > > > > XL XXL
0.5s 1s 2s 3s 4s 5s 6s 8s 9s7s
ACTIVATION RELAY HOLD TIME
bi uni uni
depart
bi = two-way detection
uni = one-way detection towards sensor
uni depart = one-way detection away from sensor
DETECTION MODE
1 2 3 4 5 6
REJECTION MODE
1: DETECTION OF ALL KINDS OF TARGETS IN MOTION
2: DETECTION OF ALL KINDS OF TARGETS IN MOTION + INTERFERENCE IMMUNITY
3: LOW ‘PEDESTRIAN/PARALLEL TRAFFIC’ REJECTION + INTERFERENCE IMMUNITY
4: MEDIUM ‘PEDESTRIAN/PARALLEL TRAFFIC’ REJECTION + INTERFERENCE IMMUNITY
5: HIGH ‘PEDESTRIAN/PARALLEL TRAFFIC’ REJECTION + INTERFERENCE IMMUNITY
6: HIGHEST ‘PEDESTRIAN/PARALLEL TRAFFIC’ REJECTION + INTERFERENCE IMMUNITY
NOTES FACTORY DEFAULTS
DOOR DOOR DOOR DOORDOOR
123 45
DOOR DOOR DOOR DOOR
6 7 8 9
IR PATTERN SIZE
FREQUENCY
IR IMMUNITY
AUTOMATIC LEARN TIME
low
high
medium high
30s 1 min 2 min 5 min 10 min 20 min 1 h 1.5 h 2 h
IR TARGET SIZE
DOOR
3x3
DOOR
4x4
DOOR
3x2
DOOR
1x2 1x1
2x2
IF AN OBJECT IS IN THE PRESENCE DETECTION FIELD AND REMAINS MOTIONLESS FOR LONGER
THAN THE PROGRAMMED LEARN TIME, THE SENSOR WILL ACCEPT THE OBJECT AS PART OF
ITS BACKGROUND/REFERENCE POINT AND WILL DROP THE DETECTION SIGNAL.
**INFINITY (
∞ ) WILL NEVER LEARN A NEW BACKGROUND**
∞
