Beacon S242P User manual

S242PUser Manual
1

S242PUser Manual
2
TABLE OFCONTENTS
1. SAFETYSYMBOLS &PRECAUTIONS................................................................................................3
1.1 SAFETYSYMBOLS...............................................................................................................3
1.2 PRECAUTIONS......................................................................................................................3
2. INTRODUCTION.....................................................................................................................................7
2.1 CONTROLAND CONNECTOR............................................................................................7
3. QUICKLYSTARTING..............................................................................................................................8
3.1 CONNECTING THECABLES..............................................................................................8
3.2 STARTING UP........................................................................................................................8
4. OSDMENU..............................................................................................................................................9
4.1 OSDMENUINTRODUCTION......................................................................................................10
5. TROUBLESHOOTING..........................................................................................................................11
6. CLEANING.............................................................................................................................................12
7. PRODUCTPACKAGING ANDACCESSORIES.................................................................................13
8. SPECIFICATION....................................................................................................................................14
8.1 SPECIFICATION............................................................................................................................14
8.2 D-SUB 15 PINCONNECTOR........................................................................................................15
8.3 DVI-DCONNECTOR.....................................................................................................................15
8.4 CVBSCONNECTOR.....................................................................................................................15
8.5 S-Video CONNECTOR...................................................................................................................15
8.6 YPbPr/RGBCONNECTOR............................................................................................................16
8.7 PRESETTIMING...........................................................................................................................16
9. DECLARATIONOFCONFORMITY....................................................................................................17

S242PUser Manual
3
lSAFETYSYMBOLS &PRECAUTIONS
lSAFETYSYMBOLS
Medical displaysaremainlyusedtoprovidetrainedmedicalstaffwithprofessional digitalimages,thusfor
theprofessional readingandanalysis.
Thismanual usesthesafetysymbolsbelow. Theydenote critical information. Pleasereadthemcarefully.
WARNING
FailuretoabidebytheinformationinaWARNING mayresult inseriousinjuryandcanbe
lifethreatening.
CAUTION
FailuretoabidebytheinformationinaCAUTION mayresult inmoderate injuryand/or
propertyor product damage.
Alertelectrical hazard.
Indicatesaprohibitedaction.
Indicatestogroundfor safety.
Topreventfireor shockhazard, do notexposethedevice inrainor inwetenvironments. Thismonitor is
completelysafefor thepatients. Thisdevice isnotrecommendedtoconnect householdequipments.
Althougheveryefforttoensurethelatestinformationprovidedinthismanual. pleasenote that monitor
specificationsaresubject tochangewithoutnotice.
lPRECAUTIONS
Toensurepersonal safetyand propermaintenance,pleasereadthissectionandthecautionstatementson
theunit.
WARNING
Ifthe unitbeginsto emitsmoke,smellslike somethingisburning,ormakesstrangenoises,disconnectall
power connectionsimmediatelyand contact your dealer foradvice.
Attemptingtouseamalfunctioningunit mayresultinfire, electric shock, or equipmentdamage.
Donot open the cabinet ormodify the unit.
Openingthecabinet or modifying theunitmayresult infire,electric shock, or burn.
Refer all servicingtoqualified service personnel.
Donotattempttoservice thisproduct yourselfasopeningor removing coversmayresultinfire,electric shock,
or equipmentdamage.
small objectsorliquidsawayfromthe unit.
Small objectsaccidentallyfallingthrough theventilationslotsintothecabinet or spillageinto
thecabinet mayresult infire,electric shock,or equipmentdamage.Ifanobject orliquid
falls/spillsintothecabinet,unplugtheunit immediately.Havetheunit checkedbyaqualified
service engineer beforeusingitagain.
Thismonitorcanbe alongboot, but the lifewill be reduced.

S242PUser Manual
4
Place the device onasolid and stable surface.
Iftheunitisplacedonaninadequate surface mayoccurfallandresult inpersonalinjuryor
equipmentdamage.Iftheunit falls,disconnectthepowerimmediatelyandaskdealerfor
help.Pleasedonotcontinuetousedamagedequipment.Using adamagedunit mayresultin
fireor electric shock.
Set the unit in anappropriatelocation.
Notdoing somayresult infire, electric shock, or equipmentdamage.
lDonotplace outdoors.
lDonotplace inthetransportationsystem(ship,aircraft,trains,automobiles,
etc.
lDonotplace inadustyor humidenvironment.
lDonotplace inalocationwherethesteamcomesdirectlyon thescreen.
lDonotplace near heat generating devicesor ahumidifier.
lDonotplace inaninflammablegasenvironment.
Toavoid danger of suffocation, keep the plastic packingbagsaway frombabiesand children.
Usethe enclosed power cord and connect to the standard power outletof your country.
Besuretoremainwithintheratedvoltageofthepower cord. Notdoing somayresultinfireor electric shock.
Todisconnect the power cord, graspthe plugfirmlyand pull.
Tugging onthecord maydamageandresult infireor electric shock.
The equipmentmust be connected toagrounded main outlet.
Notdoing somayresult infireor electric shock.
Usethe correct voltage.
lTheunitisdesignedfor usewithaspecific voltageonly.Connection toanothervoltagethanspecified
inthisUser sManual maycausefire, electric shock, or equipmentdamage.
lDonotoverloadyour power circuit, asthismayresultinfireor electric shock.
Handle the power cord withcare.
lTheunit isdesignedfor usewithaspecific voltageonly. Connectiontoanother
voltagethanspecifiedinthisUser sManual maycausefire,electric shock, or
equipmentdamage.
lDonotoverloadyour power circuit, asthismayresultinfireor electric shock.
Never touch the plugand power cord if it beginstothunder.
Touching themmayresult inelectric shock.
Donot touch adamaged LCDpanel directlywithbare hands.
Theliquidcrystal that mayleakfromthepanel ispoisonousifit enterstheeyesor mouth.If anypartof the
skinor bodycomesindirect contact withthepanel,pleasewashthoroughly.Ifsomephysical symptomsresult,
pleaseconsult your doctor.
Followlocalregulationorlawsforsafedisposal.
CAUTION

S242PUser Manual
5
Handle withcare when carryingthe unit.
Disconnect thepowercord andsignal cablesandremovetheoptional unit.Movingtheunit withthecord or the
optionattachedisdangerous. Itmayresult ininjury.
When handlingthe unit, grip the bottomof the unitfirmlywithbothhandsensuringthe
panel facesoutward beforelifting.
Dropping theunitmayresult ininjuryor equipmentdamage.
Donot blockthe ventilationslotsonthe cabinet.
lDonotplace anyobjectsontheventilationslots.
lDonotinstall theunit inaclosedspace.
lDonotusetheunit laiddownor upsidedown.
Blockingtheventilationslotspreventsproperairflowand mayresult infire,electric shock,or equipment
damage.
Donot touch the plugwithwet hands.
Doing somayresultinelectricshock.
Periodicallycleanthe areaaround the plug.
Dust,water, or oil ontheplugmayresult infire.
Unplugthe unit before cleaningit.
Cleaningtheunit while it ispluggedintoapower outlet mayresult inelectric shock.
Ifyouplanto leavethe unitunused foranextended period,disconnectthe power cord fromthe wall
socket after turningoff the power switch forthe safety and the power conservation.
LCD PANEL
Whenthemonitor iscoldandbroughtintoaroomor theroomtemperaturegoesupquickly,dewcondensation
mayoccurinsideandoutsidethemonitor.Inthat case,do notturnthemonitor onandwaituntil dew
condensationdisappears, otherwiseit maycausesomedamagestoit.
Inordertosuppress theluminositychangebylong-termuse andtomaintainthestable luminosity,pleaseusethe
monitor withthelower brightness.
Thescreenmayhavedefectivepixels.Thesepixelsmayappearasslightlylightor darkarea onthescreen.This
isduetothecharacteristicsofthepanel itself, andnottheproduct.
ThebacklightoftheLCDpanel hasafixedlifespan.Whenthescreenbecomesdarkor beginstoflicker, please
contact your dealer.
Donotpress onthepanel or edgeoftheframestrongly,asthismayresult indamagetothescreen.Therewill be
printsleftonthescreenifthepressedimageisdark or black.If pressureisrepeatedlyappliedtothescreen,it
maydeteriorate or damageyour LCDpanel.Leavethescreenwhite todecreasetheprints.
Donotscratchor press onthepanel withanysharp objects,suchasapencil or penasthismayresult indamage
tothepanel. DonotattempttobrushwithtissuesasthismayscratchtheLCDpanel.
Whenthescreenimageischangedafterdisplaying thesameimagefor extendedperiodsoftime,anafterimage
mayappear. Usethescreensaver or timer toavoiddisplayingthesameimagefor extendedperiodsoftime.

S242PUser Manual
6
FCCWarning:
Thisdevice complieswithPart 15 ofthe FCC Rules.Operationissubjectto the followingtwo
conditions:(1)thisdevice maynotcause harmfulinterference, and (2)thisdevice mustacceptany
interference received, includinginterferencethatmaycauseundesired operation.
Changesormodificationsnotexpresslyapproved bythe partyresponsible forcompliance
could voidthe user'sauthorityto operatetheequipment.
NOTE:Thisequipmenthasbeen tested and found to complywith the limitsfora
Class Bdigitaldevice, pursuantto Part 15 ofthe FCC Rules.Theselimitsare
designed to provide reasonableprotection againstharmfulinterference in a
residentialinstallation. Thisequipmentgenerates, usesand can radiateradio
frequencyenergy and, if notinstalled and used in accordance withthe
instructions, maycause harmfulinterference toradio communications. However,
there isno guarantee thatinterference will notoccurina particularinstallation.
Ifthisequipmentdoescause harmfulinterference toradio ortelevision reception,
which can be determined by turningthe equipmentoff and on, the useris
encouraged totrytocorrectthe interference byone ormore ofthefollowing
measures:
-- Reorientorrelocatethe receivingantenna.
-- Increase the separation betweenthe equipmentand receiver.
-- Connectthe equipmentinto an outleton a circuitdifferent
fromthatto which the receiverisconnected.
-- Consult the dealeroran experienced radio/TVtechnician forhelp.

S242PUser Manual
7
lINTRODUCTION
S242PisaprofessionalfullHD surgerymedical imagedisplayusedintheoperating roomwiththe
characteristic suchashighdefinitionandhighbrightness.
Thisproduct iswithprecisecalibrationandcompletelycompliantwithstandard ofmedical imaging,it usesthe
latestgenerationofLEDbacklightpanel,supportsresolution1920 x1080,providesHD displayfor theoutputof
surgery,endoscopeandetc.Withbuilt-inbrightnessstabilizationcontrolcircuit and12 bit imageprocessing
technology,makesuretheproduct meet thedemandofhighprecisionmedical imaging.Withavarietyof
interfaces,itissuitable foravarietyofdigital operatingequipmentsignals.Theproductscomplywith
IEC60601-1,IEC60601-1-2safetyandEMCstandardsandCCCsafetycertification
lCONTROL AND CONNECTOR
a.The front side of the monitor
b.The backside of the monitor

S242PUser Manual
8
lQUICKLYSTARTING
Note: Besurethat thepower switchesofboththecomputer andthemonitor areOFF.
lCONNECTINGTHE CABLES
Putthe signalcable intothe backof the monitorconnector,then plugthe otherend into the
computer'sdisplay interface. Asshownin the figurebelow.
After connecting, tightenthescrews.
lSTARTINGUP
Putthe powercordintothe back ofthe monitorpowerconnector,then plug the otherend intoapower
outlet.Turnon the switch ofthe monitor,meanwhile, the powerindicateLEDwillbe light(blue
color).Thenstart the computerorthe device.
Setthe displaymode asbellow: Resolution:1920x1080,Refresh ratio:60Hz.
Ifno image shown in the screen, please referto the"failure analysis"to gethelp.
WARNING
Pleaseusethe enclosed powercord toconnect the standard poweroutlet.
Pleaseensurethat themonitor'spowerplugcanbefullyinsertedintothesocket.Makesurethepowercord used
withintheratedvoltage. Or it mayresult infireor electric shock.
Equipmentmust be connected toaoutletthat grounded good.
Or it mayresult infireor electric shock.
Pleaseturn onthe monitorand then computerpower.
Themonitor'spowerindicator will light(green). Iftheimagedoesnotappear,refertothe"failureanalysis"for
help.After eachuse, turnoffthecomputer andthemonitor.
Note:
Thismonitor canrun for along time, butlifewill bereduced. Recommended10-minute breakeveryhour.

S242PUser Manual
9
lOSDMENU
lSIGNALINDICATOR
Color Display mode
Blue Operating mode
Orange Standbymode
None Power offmode
lSHORTCUTS
Key Function
Left Reduce brightness values
Right Increasebrightness values
Up Reduce contrastvalues
Down Increasecontrastvalues
lKEYFUNCTION
Keys Function
Signal switching Signal switching
Menu/Confirm Enablethemenu andmovedtothenextentry
column/confirmthechoice
EXIT Exit menu/Automatic adjustdisplays
Left Movetotheleftcolumn
Right Movetotherightcolumn
Up Movetothelastcolumn or reduce values
Down Movetothenextcolumnor increasevalues

S242PUser Manual
10
4.1 OSDMENU INTRODUCTION
Main Menu Sub Menu Reference
Input MainInput VGA/DVI /CVBS/S-VIDEO/YPbPr/RGB/SDI
PIPModeLargepip, Side-by-side Off
Brightness Brightnessadjust
Contrast Contrastadjust
Sharpness Sharpness adjust
Aspect Ratio 5:4/4:3/Full/ FullAspect/ Native/ User
ModeSelect Overlappingmodeselection（According todifferentinput
signal toselect differentsuitable overlapping mode.
Setup
Color Temp 5500K/6500K/7500K/8500K/9300K/10000K/User
GammaDICOM/2.4/2.3/2.2/2.1/2.0/1.8
RGB/YPbPr
RGB/YPbPrSEL RGB/YPbPr signal select
OSD Position Center/Top Left/Top Right
BottomLeft/BottomRight
OSD Language English/Chinese
AutoScanInput Onoff
FactoryReset Restorethefactorydefault parameters
VGA
AutoAdjust
Automatic adjustdisplays Detailedtosee 5.2-5.4.
H-position
V-position
Clock
Phase
Lock KeyLock Lockor unlockthetouch-keyshortcutfunctions
Status
FWversion Softwareversioninformation
MainInput Theinputinformationofmainsignal source
MainFormat Theinputsignalformatofmainsingnal source

S242PUser Manual
11
lTROUBLESHOOTING
Ifaproblempersistsevenafter applying thesuggestedremedies, contact adealer.
Problems PointstocheckwithPossibleSolutions
1. Nopicture
Indicator status:Off
Checkthat thepowercord iscorrectlyconnected.Iftheproblempersists,
turnoffthemonitor powerfor afewminutes,thenturnit backonandtry
again.
Indicator status:Green Checkthe<Backlight>shortcutkeysetting.
Indicator status:Orange Trypressingthekeysonthecomputer keyboard or clicking themouse
2.Display positionisincorrect.
Adjusttheimagepositionbyusingthe<H-Position>and<V-Position>.
Iftheproblempersists,usethegraphicsboard'sutilitysoftwaretochange
thedisplaypositionifavailable.
3.Verticalbarsofdistortion
appear.
Decreasethehorizontal barsbyusingthe<Clock>.
4.Horizontalbarsof distortion
appear.
Decreasethehorizontal barsbyusingthe<Phase>.
5.The screen istoo brightortoo
dark.
Adjust<Backlight>shortcutkey(ThebacklightoftheLCDmonitor hasa
fixedlifespan.Whenthescreenbecomesdarkorbeginstoflicker, please
contact your dealer.)
6.After imagephenomena
appear lMakesurethat whetheryouhaveusedthescreensaveror timer
whendisplaying thesameimagefor extendedperiodsoftime
or not.
lAfterimagesareparticulartoLCDmonitors.Avoiddisplaying
thesameimagefor extendedperiodsoftime.
7.The screen hasdefectivepixels
Thisisduetothecharacteristicsofthepanel itself,andnottheLCD
product.
8.Shiatsutracesleft onthe
screen
Keepthescreenbackgroundwhite cansolvethisproblem.

S242PUser Manual
12
lCLEANING
Periodic cleaning isrecommendedtokeeptheoutlookofmonitor cleanandprolong thelifetime.
Note: Neverusethinner,benzene,alcohol(ethanol,methanolor isopropylalcohol), abrasivecleanersor other
solventsbeforethesolubility, astheymaydamagethecabinet or LCDscreen.
Cabinet
Toremovestains, useasoftclothlightlymoistenedwithamilddetergentsolution.
Donotspraywaxor cleaner directlyintothecabinet. (For details, refer tothemanual ofthePC.)
LCD Panel
TheLCDsurface canbecleanedwithasoftcloth, suchascottonor lenspaper.
Ifnecessary,use part ofdamp cloth (to improve itscleaning ability)to remove Stubborn stains.

S242PUser Manual
13
lPRODUCTPACKAGINGAND ACCESSORIES
LCDmonitor
Power cable
DVI signal cable
BNCsignal cable
S-VIDEOsignal cable
Usermanual
Power adapter

S242PUser Manual
14
lSPECIFICATION
8.1 SPECIFICATION
LCDpanel 23.6”,TFTcolor LCD,AG, Hard coating
Brightness(Typ.) 400 cd/m2
Contrast 1000:1
responsespeed 15ms
Viewingangle Horizontal&Vertical:178°atΦ=0°,90°,180°,270°CR >10
Pixel pitch 0.2715mm x0.2715 mm
Horizontal
scanning frequency
31~80 kHz
Vertical
scanning frequency
50~76 Hz
Resolution 1920 x1080
Supportcolor 1.07 Billion
Power supply DC：24V(4.2A)
Power consumption Max：45 W
Inputinterface VGA 15 pinD-sub 0.7Vp-p separate sync
DVI 24pin, DVI-D TDMSsignal
SDI BNC 75Ohmterminated
CVBS BNC,75Ohmterminated （Support:PAL/
NTSC/SECAM）
S-VIDEO DIN-4, 1VppY-signal, +/-300mVC-signal
YPbPr/RG
B BNC, 1Vpp Ysignal, +/-350mVPb,Pr signal
Outputinterface CVBS,YPbPr, S-VIDEO, DVI, SDI
Service interface RS232 D-SUB9PIN
Plug andPlay VESADDC2B
Weight 6.0kg
Temperature Operating：0°C~40°C
Store：-20°C~60°C
Humidity 30%~80%R.H. non-condensing

S242PUser Manual
15
8.2 D-SUB15 PINCONNECTOR
Pin Signal Pin Signal Pin Signal
1 Redvideo 6 Redground 11 GroundShorted
2 Greenvideo 7 Greenground 12 Data (SDA)
3 Bluevideo 8 Blueground 13 H. Sync
4 Ground 9 5V 14 V. Sync
5 GND 10 GroundShorted 15 Clock(SCL)
8.3 DVI-D CONNECTOR
Pin Signal Pin Signal Pin Signal
1 TMDS Data 2- 9 TMDS Data 1- 17 TMDS Data 0-
2 TMDS Data 2+ 10 TMDS Data 1+ 18 TMDS Data 0+
3 TMDS Data 2/4Shield 11 TMDS Data 1/3Shield 19 TMDS Data 0/5Shield
4 TMDS Data 4- 12 TMDS Data 3- 20 TMDS Data 5-
5 TMDS Data 4+ 13 TMDS Data 3+ 21 TMDS Data 5+
6 DDCClock(SCL) 14 +5VPower 22 TMDS Clockshield
7 DDCData (SDA) 15 Ground(For +5V) 23 TMDS Clock+
8 NC 16 HotPlug Detect 24 TMDS Clock-
(*NC：Noconnection)
8.4 CVBS CONNECTOR
Pin signal
1 CVBS
2 GND
8.5 S-Video CONNECTOR
Pin signal
1 GND
2 GND
3 Y
4 C

S242PUser Manual
16
8.6 YPbPr/RGBCONNECTOR
Y/GPb/BPr/R
Pin Signal
1 Y/G Pb/B Pr/R
2 GND GND GND
8.7 PRESET TIMING
lVGA/DVIpresettiming
Video
Formats HorizontalFrequency(kHz) VerticalFrequency(Hz)
PixelClock (MHz)
720 x 400 31.5 70.1 28.3
640 x 480 31.5 59.9 25.2
800 x 600 37.9 60.3 40.0
1024 x 768 48.4 60.0 65.0
1280 x 1024 64.0 60.0 108.0
1600 x 1200 75.0 60.0 162.0
1920 x 108066.6 59.9 138.50
1920 x 108067.0 60.0 172.750
lRGB/YPbPrpresettiming
VideoFormats HorizontalFrequency(kHz)
VerticalFrequency(Hz) PixelClock (MHz)
752 x 582i/50Hz15.625 50.0 14.1875
480i/60Hz 15.734 59.940 13.5
576i/50Hz 15.625 50.0 13.5
480p/60Hz 31.469 59.940 27.0
576p/50Hz 31.25 50.0 27.0
720p/50Hz 37.50 50.0 74.250
720p/60Hz 45.00 60.0 74.250
1080i/50Hz 28.125 50.0 74.250
1080i/60Hz 33.750 60.0 74.250
1080p/50Hz 56.250 50.0 148.50
1080p/60Hz 67.500 60.0 148.50
lCVBS, S-VIDEOpresettiming
VideoFormats HorizontalFrequency(kHz)
VerticalFrequency(Hz)
PixelClock (MHz)
PAL(576i) 15.625 50.0 13.50
NTSC(480i) 15.734 59.940 13.50

S242PUser Manual
17
lSDIinputpresettiming
VideoFormats HorizontalFrequency(kHz) VerticalFrequency(Hz)
PixelClock (MHz)
480i/60Hz 15.734 59.940 13.50
576i/50Hz 15.625 50.0 13.50
720p/50Hz 37.50 50.0 74.250
720p/60Hz 45.00 60.0 74.250
1080i/50Hz 28.125 50.0 74.250
1080i/60Hz 33.750 60.0 74.250
lDECLARATIONOFCONFORMITY
ThisequipmentisinconformitywiththeprovisionsoftheCCC, CE, IEC60601-1standard.
Thisequipmentsatisfiesthefollowingtwoconditions:
lThedevice will notbring dangerousinterference;
lThedevice will notbeinfluencedbyouter interference andcauseunpredictable results.
lToavoidinterference withradioor TVreceiving,pleaseuse thepoweradapterandcable matched;Use
other cable andpower adaptermayinterferetheother electronic equipment;
lThisequipmenthaspassedthe standardsofCCC;thedevice willhaveawireless electromagnetic wave,
incorrect installationandusingwill causeinterference withwireless communicationsystems.
lPleasedo thefollowingstepsifthereisinterference totheother deviceswhenrunningthisequipment:
lAdjusttheangle andpositionoftheradioor thetelevisionreceptionantenna;
lIncreasethedistance betweenthisequipmentandtheradioor thetelevisionreceptionantenna;
lThisequipmentdoesn tsharethesamethepowerinputcircuit withtheradioorthetelevisionreception
antenna;
lPleaseconsult theprofessionalpersonifanyproblem.
