BEAVIIOO HW01 User manual

Wireless Headset for Chapter Flight Simulator
This 2.4G Wireless gaming headset is used to support remote orientations on the flight
simulator. The USB dongle is connected to a USB port on the chapter’s pro ection PC
(located on the counter to the right of the flight simulator). The headset is used to
communicate with the orientation trainer via a Zoom session on the pro ection PC.
In the future we may also be providing this for normal use on the Flight Simulator but for now,
it’s ust for remote training and orientations.
NOTE: The user must take care when moving the position the microphone on the headset.
Do not grab the end of the boom mic to move it up or down – you may damage it. If the
boom microphone is in the folded/up position, then do the following (before putting the
headset on your head). While holding the left side earcup with one hand, use the index finger
and thumb of the other hand to grab the mounting base of the microphone (where it attaches
to the earcup) and carefully rotate the microphone boom from it’s upright position (in a
counter-clockwise direction) to about 120 degrees. In other words, turn it to the left like a
knob. Do not rotate more than 120 degrees as it has a ‘hard stop’ at that position. It should
look like the photo above after you have correctly position the microphone for use. In a
similar manner, when finished using the headset, carefully rotate the microphone boom
(clockwise) back to the vertical/closed position for storage.

The headset controls are located on the rear side of the left side earcup as shown in the
picture above.
Before putting the headset on your head, turn on the power by holding down the power
ON/OFF button for at least two seconds (listen carefully for the aural message “power on”
coming from the headset speakers).
There is an indicator LED ust below the power button to indicate that it has connected with
the USB dongle in the PC. Flashing red and blue indicates attempting to connect. When
connection is established the flashing LED lights will go off and the aural message
“connected” will be heard. The blue LED will blink about once every 10 seconds to indicate
power is on and the headset is connected.
The volume ad ustment is an ‘up/down’ style thumb wheel located above the power button.
Position it to full volume to start with and ad ust lower (downward) later if necessary.
The top button is the microphone ON/OFF (mute) button. You will hear the aural message
“microphone on” or “microphone off” when pressing the button.
The USB Type-C port at the bottom is for recharging the internal battery using the supplied
USB adapter cord. Do so only when advised by a trainer.
When you are finished using the headset, press and hold the power ON/OFF button for at
least two seconds until you hear the aural message “power off”.

The following pages are from the manual that came with the headset.
