Becca S700M User manual

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
1 Manual Workstation
INSTRUCTION MANUAL
S700M MANUAL WORKSTATION
° Warranty ° Service Parts
° Safety ° Troubleshooting Guide
° Operation ° Contact Information

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
2 Manual Workstation
TABLE OF CONTENTS
PAGE
WARRANTY INFORMATION ........................................................................................ 3
SPRAY GUN CLEANER SPECIFICATIONS ................................................................. 4
SAFETY AND WARNING .............................................................................................. 5
General Safety ...................................................................................................... 5
Danger and Warning Labels.................................................................................. 5
General Safety Rules ............................................................................................ 6
Personal Safety..................................................................................................... 6
Unit Use and Care................................................................................................. 7
Safety Rules.......................................................................................................... 7-8
INTRODUCTION............................................................................................................ 9
OPERATION GUIDELINES ........................................................................................... 9-12
TROUBLESHOOTING GUIDE....................................................................................... 13-14
MAINTENANCE SCHEDULE ........................................................................................ 15
OPTIONAL SOLVENTWASH FILTER CHANGE INSTRUCTIONS………………………………16
SCHEMATIC OF UNIT................................................................................................... 17-27
Overall Unit ........................................................................................................... 17-18
Control Head......................................................................................................... 19
Control Head Plumbing ......................................................................................... 20
Pump .................................................................................................................... 21
Carbon Exhaust Unit ............................................................................................. 22
PARTS DESCRIPTION.................................................................................................. 23-24
OPTIONAL TURBO700 INFORMATION……………………………………………. ………… 25-26
WARRANTY INFORMATION / TECHNICAL ASSISTANCE ......................................... 27

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
3 Manual Workstation
LIMITED WARRANTY
Solvent Recyclers & Paint Gun Washers
24 MONTH LIMITED WARRANTY
BECCA Solvent Recyclers and Spray Gun Cleaners components are warranted to be free of
defects in material or workmanship for 24 months from established purchase date to the
original user or from original shipment whichever is sooner. During months 1 through12
BECCA will repair or replace any component including labor that is found to be defective in
material or workmanship as determined by BECCA factory certified service technician. For
months 13 through 24 BECCA will furnish parts only (no travel, diagnostic or repair labor is
provided) to replace any component that is found to be defective in material or workmanship
as determined by BECCA factory certified service technician. In all cases defective parts shall
be returned to BECCA for inspection and final approval.
There is no other express warranty, implied warranties, including those of merchantability and fitness
for a particular purpose, are limited to one year from purchase and to the extent permitted by law any
and all implied warranties are excluded. This is the exclusive remedy and liability for consequential
and incidental damages under any and all warranties are excluded to the extent exclusion is permitted
by law.
CONDITIONS OF WARRANTY
BECCA has no control over working conditions, solvents involved in usage and under which
purchaser stores, handles or uses BECCA product. We make no warranty or condition, either
expressed or implied with respects to usage or mistreatment of product. These warranties
apply only to the original purchaser and do not apply if the unit has been misused, subjected to
overloading, neglect, accident, altered or used for any other purpose. BECCA shall not be
liable for loss, damage or delay due to, without limitation, acts of God, transportation delays,
accident, fire, action of civil or military authority, adverse weather or any other causes beyond
BECCA’s control. This warranty does not cover transportation, interior or exterior finishes.
The use of unauthorized chemicals or solvents with acid content in this unit shall render this
warranty null and void. BECCA shall not be responsible or liable for any consequential or
incidental damages, including without limitation, loss of production or faulty production, loss
of use or loss of profit. Attempts at repair or alterations by the owner shall also constitute a
violation of this warranty. Only BECCA certified personnel shall start-up, train, repair or alter
BECCA equipment. Spray Gun Cleaner Brushes, Filters, and Gun Clips & Solvent Recycler
Gaskets/Seals, Oil, and Bags are subject to be replaced due to normal usage, wear and tear
within the warranty period and are excluded from this warranty.
These warranties replace all other warranties expressed or implied by nature or otherwise, and are not
assignable or transferable from original purchaser.
Warranty is in effect after receipt of Registration information & full payment
2010 Cobb International Blvd Ste H Kennesaw, GA 30152 Phone [phone] Fax [phone]
Revision 1/8/05

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
4 Manual Workstation
SPRAY GUN CLEANER SPECIFICATIONS
SPECIFICATION FOR S700M MANUAL POWER CLEAN™ WORKSTATION
SPRAY GUN CLEANER
SPECIFICATIONS
U.S. UNITS
METRIC UNITS
Weight
260 Lbs.
118 Kg
Height
58"
1,450 mm
Width
25"
625 mm
Length
26"
650 mm
Work Table Height
15"
375 mm
Work Table Width
25"
625 mm
Work Table Length
21"
525 mm
Solvent Capacity of Container (2)
2-5 Gal (optional) or
2-10 Gal (optional)
2-5 Gal (optional) or
2-10 Gal (optional)
Weight that can be supported by work surface
18 Lbs.
8 Kg
Diameter of Vapor Chimney
6"
150 mm
Air Consumption by each Suction Nozzle at 90
psi / 8 Bar
8 –10 Nmc
Air Supply Operating Pressure
90 psi
6 –7 Bar
Acoustic Pressure Level LpAm ISO-3746
68.4 dB(A)
68.4 dB(A)
Acoustic Power Level LpAm ISO-3746
79.2 dB(A)
79.2 dB(A)
Ball valve
Brass
Brass
Pump
Single diaphragm
Single diaphragm
Pump Capacity
4 Gal/min
15 Liters/min
Groundable containers
2-5 Gal (optional) or
1-10 Gal (optional)
2-5 Gal (optional) or
1-10 Gal (optional
Outside Frame
Powder paint
Powder Paint
Wash Basin and Work Table
Stainless steel
Stainless steel
Warranty
24 months
24 months

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
5 Manual Workstation
SAFETY AND WARNING
GENERAL SAFETY
1. Carefully inspect the shipping carton for any signs of transport damage. The damage to the carton
often indicates possibility of transport damage to the equipment inside.
2. Carefully remove your Becca Spray Gun Cleaner from the shipping carton.
3. Check your equipment immediately to ensure that it is free of transport damage. Report any
transport damage to the carrier without delay for possible claim procedures. Becca Recycling
Technologies Inc. is not responsible for damage to equipment after it leaves our warehouse.
4. Check the equipment list and compare it with the parts you have received. If any parts are missing,
contact the supplier you purchased the equipment from.
Before operating the BECCA SPRAY GUN CLEANER, read this Instruction Manual completely.
All BECCA products are engineered and manufactured to the highest performance standards
and have been subjected to detail testing before shipment from the factory.
DANGER AND WARNING LABELS
DANGER
1 2 3 4
WARNING
5 6 7 8
1. Presence of flammable vapors and solvents. 5. Observe warnings at all times.
2. No smoking or metal grinding nearby. 6. Read the Instruction Manual carefully.
3. Keep away from open flames. 7. Wear solvent-proof rubber gloves.
4. Wear Breathable Air during use. 8. Wear protective eyewear before use.

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
6 Manual Workstation
SAFETY AND WARNING (cont’d)
WARNING
« READ ALL INSTRUCTIONS » Failure to follow the SAFETY RULES identified by a BULLET (°)
symbol listed BELOW and other safety precautions may result in serious personal injury. « SAVE
THESE INSTRUCTIONS »
GENERAL SAFETY RULES
° KEEP WORK AREA CLEAN.
° KEEP CHILDREN AWAY. Do not let visitors come in contact with the equipment. All visitors should
be kept away from the work area.
PERSONAL SAFETY
° GUARD AGAINST ELECTRIC SHOCK. Prevent body contact with grounded surfaces, for example:
pipes, radiators. Solvent resisting rubber gloves and non-skid footwear is recommended where damp
or wet ground may be encountered. A ground fault circuit interrupter protected power line must be
used for these conditions.
° DRESS PROPERLY. Do not wear loose clothing or jewelry. They can be caught in the moving parts.
Wear protective hair covering to contain long hair.
° USE SAFETY EQUIPMENT. WEAR SAFETY GOGGLES or glasses with side shields.
° STAY ALERT. USE YOUR COMMON SENSE. Concentrate on what you are doing. Do not operate
the unit when you are tired or under the influence of drugs.
° DO NOT OVERREACH. Keep proper footing and balance at all times.
° BEFORE CONNECTING THE UNIT to an air line outlet, be sure the pressure is the same as that
specified on the nameplate of the Spray Gun Cleaner. An air line with pressure greater than that
specified on the Spray Gun Cleaner can seriously injure the user –as well as damage the Spray Gun
Cleaner. If in doubt, DO NOT plug in the unit. Using an air line with pressure less than the pressure
specified on the nameplate is harmful to the pump.

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
7 Manual Workstation
SAFETY AND WARNING (cont’d)
UNIT USE AND CARE
° DO NOT FORCE THE UNIT. It will perform better and safer at the rate for which it was designed.
° THE USE OF ANY OTHER ACCESSORIES not specified in this manual may create a hazard.
° DISCONNECT THE UNIT when not in use, before servicing.
° DO NOT ALTER OR MISUSE THE UNIT. These units are precision built. Any alteration or
modification not specified is misuse and may result in a dangerous situation.
Only trained repairmen should attempt (°) ALL REPAIRS, electrical or mechanical. Contact the
nearest Becca repair service facility. Use only Becca replacement parts, any other parts may create
a hazard.
SAFETY RULES
° THE OPERATOR MUST WEAR protective solvent-proof rubber gloves to prevent contact between
his hands and the products used for washing.
° THE OPERATOR MUST WEAR protective eyewear to prevent spatter from coming in contact with
his eyes.
° THE SPRAY GUN WASHER is designed exclusively to wash spray guns and small objects.
° STAY ALERT at the start of the cleaning cycle. Make sure the solvent is not «corrosive».
Immediately stop washing and replace the solvent whenever you note signs of corrosion on the
worktable.
° IF EYES COME IN CONTACT WITH SOLVENTS rinse thoroughly with water.
° BEFORE USING the Spray Gun Cleaner, make sure that all safety devices are in perfect operating
condition.
° BECOME FAMILIAR WITH THE CONTROLS and their functions before commencing work.
° USE GROUNDABLE CONTAINERS (Containers, solvents are supplied in, are recommended)
for the collection of solvents.
° BE CAREFUL when you load or unload the solvent in the unit. Make sure you do not splash or spill
the contents on the workshop floor.
° THE OPERATOR MUST PERIODICALLY check the level of the dirty solvent contained in the
collection pail to prevent it from overflowing.

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
8 Manual Workstation
SAFETY AND WARNING (cont’d)
° IT IS STRICTLY FORBIDDEN to place unsuitable sized object or objects that weigh more than 18
Lbs. / 8 Kg on the work surface of the Spray Gun Cleaner.
° CLEAN OR REPLACE the mesh filter periodically.
° DO NOT USE ELECTRICAL OR PNEUMATICAL TOOLS WITH THE UNIT. AVOID GASEOUS
AREAS. Do not operate portable electric tools in explosive atmospheres in the presence of
flammable liquids or gases. Motors in these tools normally spark, and do not scrape or scratch the
machine with metal objects; the sparks might ignite fumes.
° DO NOT ALLOW FAMILIARITY GAINED FROM FREQUENT USE OF YOUR SPRAY GUN
WASHER TO BECOME COMMONPLACE. Always remember that a careless fraction of a second is
sufficient to inflict severe injury.
° DO NOT ALTER OR MISUSE THE UNIT. Any alteration or modifications is a misuse and may result
in serious personal injuries.
° FIRE EXTINGUISHING SYSTEMS must be installed in the same room or close to the unit in case of
emergency. These appliances must be kept efficient and inspected every year by a certified person.
° THE INSTALLATION SITE MUST PERMIT PERSONNEL TO EASILY AND QUICKLY MOVE
AWAY FROM DANGER ZONES IN CASE OF AN EMERGENCY.
° DO NOT USE THE UNIT TO wash or degrease objects designed to come in contact with food.
° COMPLY WITH LAWS IN THE COUNTRY where the Spray Gun Cleaner is installed regarding the
use and disposal of the products used to wash clean objects.
THINK SAFETY! SAFETY IS A COMBINATION OF THE OPERATOR’S COMMON SENSE,
KNOWLEDGE OF THE SAFETY AND OPERATING INSTRUCTIONS AND ALERTNESS AT ALL
TIMES WHEN THE UNIT IS BEING USED.

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
9 Manual Workstation
INTRODUCTION
This Instruction Manual provides installation, operation and maintenance instructions for the Manual and
Hands-Free Spray Cleaner unit. These shall be referred to as Spray Gun Cleaners in the following
pages. Spray Gun Cleaners are totally pneumatic units designed for manual washing spray guns and
small parts.
It is very practical, time saving and economic for cleaning. The unit is supplied with a pneumatic pump
that selects the clean solvent from one pail and the used solvent from another pail. Both pails are
located in the base of the unit. The solvent that you will use will depend on the type of paint that you are
using. The manufacturer of the paint will give you the information you need regarding this.
The fumes are exhausted when the operator turns on the “Fume Extractor/Spray Out” dial. The fumes
go through the vapor chimney that you will connect to the outside as per local regulations. You have the
option of placing an active carbon filter (part #824450). This filter can be installed onto the vapor exhaust
duct, which retains contaminating fumes.
This manual is an integral part of the product. It must be properly stored, kept in good condition and
available for consultation at any time during the entire working life of the Spray Gun Cleaner. Proper
washer operation, economy and durability depend on common sense and compliance with the
instructions given in this manual.
OPERATION GUIDELINES
Read the following sections carefully. They will help you use your Spray Gun Cleaner correctly
and help you select the correct function for your task.
Description of the valves
- a: Main air supply on and off air valve
- b: Fume extraction
- c: Manual wash clean and used solvent
- d: Manual wash spray
Description for using the Spray Gun Cleaner unit
The first step in learning to use the Spray Gun Cleaner is to become familiar with the unit. Operations
are carried out via the controls placed on the top front panel which the operator can control the use:
a–The main air supply valve controls the air for the Spray Gun Cleaner. This valve should remain
closed when not using the Spray Gun Cleaner.

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
10 Manual Workstation
OPERATION GUIDELINES (cont’d)
b –The “Fume Extraction/Spray Out” valve has two (2) functions: giving air to the spray gun
through the disconnect for Spray Out purposes and opening up the fume extraction system
air nozzle for vapor exhaust, and to ensure proper extraction of all harmful vapors when
spraying. Solvent vapors are atomized inside the air chamber and conveyed through a
special vent plate, automatically the vapors are sucked by a pair of air nozzles creating a
vacuum inside the duct tube.
c - The “Solvent Selection” valve allows you to select Clean or Used solvent for the Manual
cleaning processes. When set on the used position, it will take the solvent from the used
solvent pail. When set on the clean position, it will take the solvent from the clean solvent pail.
Both pails are located at the bottom of the cleaner.
d -The “Wash Selection” valve allows you to select the Manual Flow Brush or the Manual Wash
Spray. This gives to great methods for cleaning your Spray Gun.
e - The “Manual Wash Spray” valve provides Clean solvent to the shower nozzle allowing you to place
some solvent in the cup for Spray Out or just to rinse the Spray Gun off.
IMPORTANT! : DO NOT POUR LEFTOVER PAINT INTO THE CLEANING AREA.
Manual Cleaning with Clean or Used solvent
To manually wash your spray guns start by removing the cup from the spray gun, empty the cup's
residues into a separate pail. Pour approximately ½ inch of used solvent by turning the “Manual
Brush Wash” valve (d) to the USED SOLVENT position into cup and clean with the brush. Then
rinse cup by turning the “Manual Brush Wash” valve (d) to the CLEAN SOLVENT position and rinse
with the brush.
This solvent is returned into the used solvent pail and added to the existing solvent helping to
regenerate it before being recycled or disposed of.
A brush has been added to the unit to help clean parts and paint guns. The solvent will come out
from the center of the brush.
You can also clean parts or spray guns with “Power Pistol” valve (e). When turning this valve on the
POWERPISTOLTM will be activated helping to clean hard to reach areas.

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
11 Manual Workstation
OPERATION GUIDELINES (cont’d)
In case of inadequate exhaust air movement
Check the air inlet and the compressed air pressure.
Clean the air inlet filter located inside the washer head.
Clean or replace the mesh filter and make sure that it is positioned below the vapor evacuation duct.
Check and clean the evacuation nozzles located at the base of the duct.
Check that the vapors evacuation duct is perfectly vertical for at least 6 feet or 2 meters.
OPTIONAL Filtration System
The unit has an Optional Filtration Recycling System to remove particulate from the solvent. This system
filters out particulate down to 25 micron. There is a 2 stage combination system of 75 micron for gross
residues and a final of 25 micron for the fine residues. Some processes may require the solvent to be
purged periodically due to a build-up of activate type solvents.
The Filters are easily changed by a replacement kit (825244K) that includes one 75 micron filter, one 25
micron filter and two seals (seals are normally useless once the housing is opened).
OPTIONAL Hose Cleaner
If the unit comes with a hose cleaner you will need to place an extra pail in the unit. On the left side
of the unit under the valve system you will find two (2) ¼ inch fittings. Place one (1) safety coupler
attachment on each fitting that will work with our hose systems. Then you will be able to connect
the hose to be cleaned.
How to clean the hose:
- Open valve (f) to the used solvent side and let it clean for a few minutes.
- Turn valve (f) to the clean side for 15 to 30 seconds to let clean solvent drain through the hose
completely.
- Finally, open valve (e). This valve will remove all the solvents left inside the hose. It will take
approximately 60 seconds to dry the hose. The hose is now ready to be re-used.
Solvent Transfer System
When the USED SOLVENT container has been used for several washings, it has to be transferred
into the SOLVENT SAVERRecycler to be recycled. Open the loading valve located on the
recycler. The pump will transfer the used solvent from the gun washer pail to the recycler. Stop when
the solvent level in the boiler is about ½ inch below the bag-retaining ring. Do not overfill.
For instructions pertaining to the recycling of solvent refer to the SOLVENT SAVERRecycler
Instruction Manual.
When the CLEAN SOLVENT container becomes empty, exchange it with the one in the recycler
compartment. Starting the distillation cycle will refill the pail again and again.

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
12 Manual Workstation
OPERATION GUIDELINES (cont’d)
Identification of the Spray Gun Cleaner
Every Spray Gun Cleaner has an identification plate that indicates:
Manufacturer brand
Manufacturer name and address
Spray washer model and serial number
Information on this identification plate must always be specified when asking for service and/or spare
parts.
Periodical check and maintenance
Please follow the rules and regulations listed below to safely maintain the Spray Gun Cleaner:
Periodically make sure that safety devices are complete and efficient.
Periodically replace the mesh filter.
Periodically clean the working surface and the cover from any eventual deposits.
It is strictly forbidden to remove or tamper with safety devices.
According to the instructions given in this manual, only qualified and specialized personnel must
perform maintenance on the Spray Gun Cleaner.
Disconnect the compressed air supply when it is necessary to repair or perform maintenance on the
appliance.
Maintenance must be performed carefully, following the instructions given in this manual for
replacing damaged or worn parts.
The symbolic labels attached to the Spray Gun Cleaner give clear guidelines for preventing
accidents. These labels must always be kept clean and immediately replaced if they are even
partially removed or damaged. It is strictly forbidden to operate the Spray Gun Cleaner when even
only one of these symbolic labels is missing from the point where the Manufacturer placed it.
Always use BECCA GENUINE REPLACEMENT PARTS during repair and maintenance.

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
13 Manual Workstation
TROUBLESHOOTING GUIDE
PROBLEM
CAUSE
SOLUTION
Pump is not operating
- Main Air is not on.
- Air gage shows less than 40 psi.
- No sound coming from pump.
- Pump is pumping but no solvent is
flowing.
- Turn on Main Air
- Make sure air gage is operating
correctly.
Adjust pressure.
- Pump should be replaced –possible
broken actuator spring
- Review solvent lines to assure they
are in the containers
Make sure containers have solvent
Make sure the Control Valves are
operating. Look for solvent flowing
through the lines.
Look for aeration in lines –There is a
leak somewhere
Pump is very slow
- Sluggish or sporadic.
-Make sure air gage is not jumping
Around or below 40 psi.
- Look for aeration in lines –There is a
leak somewhere.
-Assure the Strainer is not clogged
Pump is very fast
- Accelerated pumping sound
- Make sure containers have solvent
- Check for bad connections on the
suction side of the pump
Fume smell coming from
the unit.
- Fume Extractor Valve is in the ON
position and air is not flowing.
- Fume Extractor is ON and air is
flowing but not pulling fumes
- Open the cover to assure the blue
airline is attached.
Check for leaks in the blue air lines
Check to assure valve is operational
- Check exhaust filter. It may need
replaced
Review exhaust path for obstruction
Solvent is not flowing the
valve is operated
- Pump is not operating.
- Pump is operating and nothing is
flowing.
- See “Pump not Operating” section.
- Check to see if flow is working for
either USED or CLEAN –
If both are not and pumps are
pumping review the valve.
If one is working and the other is
not review the Pump not
Operating” section.
Manual Spray Nozzle is not
operating.
- The Pump is not Operating
- Manual Spray Nozzle is clogged.
- See “Pump not Operating” section
- Check the nozzle by removing and
blowing out debris (reverse direction)

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
14 Manual Workstation
Troubleshooting method to isolate the system (Pump) from the Filtration Recycling Systems:
Remove filters from housings, re-attach empty housings and run the gun cleaner (it will take several
minutes for the housings to fill up). If the system runs normally, the problem was caused by the filters.
If the system does not run correctly, the problem was caused by the pump.
Consumable Replacement Parts:
Solvent & Waterborne (ENVIRO) Models:
825159 –Splash Pad for 700 & 800 Models 825165 –Splash Pad (100 Series Models)
825162 –Basin Splash Pad for 50 Models 825163 –Back Splash Pad (50 Series Models)
825258K –Filtration Recycling System Cartridge Replacement Kit (50 & 100 Series Models)
Solvent Models Only:
825244K –Filtration Recycling System Cartridge Replacement Kit (Solvent –Not 50 or 100
Series)
PROBLEM
CAUSE
SOLUTION
Diminished Fluid Flow
Filters are almost loaded
Change filter(s) –either the 75
micron filter or both filters,
depending on the filter change
schedule (see instructions with
Replacement Filter Kit)
Rapid Pump Acceleration
with little to no fluid flow
Filters are loaded
Make sure containers have fluid.
Change filter(s) –either the 75
micron filter or both filters,
depending on the filter change
schedule (see instructions with
Replacement Filter Kit)
Rapid Pump Acceleration
After recent filter change
Air is getting into the fluid lines
Check the filter canisters –make
sure they are screwed on snugly
(hand tightened)
Check the seals in the filter canisters
–make sure they are seated
correctly
Make sure new seals were installed
with the new filters
No fluid flow, loud air noise
coming from pump
Air is by-passing to exhaust in the
pump
Replace the pump
No fluid flow, no pump
noise
The Pump is not Operating
Replace the pump

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
15 Manual Workstation
MAINTENANCE SCHEDULE
Each day
- Wipe-down the unit with solvent. The paint and decals are solvent
resistant.
- Remove any contaminants from the bottom of the Grill
Semi-Annually
-Change out “Used Solvent” Container.
- Replace filter (824588) in back panel.
- Replace Extractor/Dryer Compressed air filters (824016)
- Replace BECCA Protect™ Maintenance Coating (ECP 831004)
- Review Ground Clamp (823079)
Annually
- Replace Manual Flow Brush (824610)
- Review & Replace illegible or damaged Decals

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
16 Manual Workstation
SOLVENTWASH™
Filtration Recycling System (Optional)
Filter Replacement Instructions
1. Important! Before removing the Filter Housing:
Lift the line out of the container
Then allow the pump to continue to run with the Wash Basin or Flow Brush in
the “On” position.
Run the unit to remove some of the solvent from the Housings (3-5”).
2. Turn the Filter Housing with the provided Wrench. If stuck, lightly tap housing
with a rubber mallet to break the seal. Care should be taken so not to crack the
housing.
3. Make sure to replace both filters and place them in the correct position (75
Micron-first to see the solvent and 25 Micron –last to see the solvent before
being used)
4. Make sure to replace both seals in the Filter Housings. (Note: The old seal will
not work after the Filter Housing has been removed)
5. Make sure Filter is located in the Guide located on the threaded top before
spinning housing. Tighten The Filter Housings to a snug position. (Do Not Over
Tighten!!)
6. When Running the Spray Gun Cleaner it will take a few minutes to fill the Filter
Housing before flowing out of the selected function.
7. Used Filters (are Hazardous until proven different) should be allowed to dry and
then dispose per local jurisdiction requirements.
You are ready to use your system!

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
17 Manual Workstation
SCHEMATIC OF UNIT
33
53
51
LIQUIDE
FLAMABLE
A
32
B C
LIQUIDE
FLAMABLE
33
50
52
D
27
17
1
1
8
7
2
3
4
5
10
9
6
4
5
E
6
11
D
6
F
C
6
B
6
A
6

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
18 Manual Workstation
SCHEMATIC OF UNIT (cont’d)
3
47
2
B
A
C
54
36
35
34
D
12
14
13
15

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
19 Manual Workstation
SCHEMATIC OF UNIT (cont’d)
17
16
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
18
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
20
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
19
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
17
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
30
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
29
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
23
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
25
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
26
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
27
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
33
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
20
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
28
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
21
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
24
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
20
6
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
18
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…
…

Sept 2015, Rev. 4.0 BECCA INC. Instruction Manual S700M
20 Manual Workstation
SCHEMATIC OF UNIT (cont’d)
LEGEND
Air - Blue Polyurethane Tube
Solvent - White or Black
Nylon Tube
“USED”
Solvent Hose
(Black Nylon)
“CLEAN”
Solvent Hose
(White Nylon)
