Nexcom NISE 108 User manual

NEXCOM International Co., Ltd.
NEXCOM International Co., Ltd.
Published March 2020 www.nexcom.com
IoT Automation Solutions Business Group
Fan-less Computer
NISE 108
User Manual

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. ii NISE 108 User Manual
Content
Contents
Preface
Copyright ............................................................................................. iv
Disclaimer.............................................................................................. iv
Acknowledgements ............................................................................... iv
Regulatory Compliance Statements........................................................ iv
Declaration of Conformity...................................................................... iv
RoHS Compliance ................................................................................... v
Warranty and RMA ................................................................................ vi
Safety Information ................................................................................viii
Installation Recommendations...............................................................viii
Safety Precautions.................................................................................. ix
Technical Support and Assistance............................................................ x
Conventions Used in this Manual............................................................ x
Global Service Contact Information........................................................ xi
Package Contents.................................................................................xiii
Ordering Information ............................................................................xiv
Chapter 1: Product Introduction
NISE 108 Overview..................................................................................1
Key Features........................................................................................1
Hardware Specifications..........................................................................2
Knowing Your NISE 108..........................................................................4
Front Panel ..........................................................................................4
Rear Panel ...........................................................................................4
Mechanical Dimensions...........................................................................5
Chapter 2: Jumpers and Connectors
Before You Begin ....................................................................................6
Precautions ............................................................................................6
Jumper Settings ......................................................................................7
Locations of the Jumpers and Connectors for NISB 108...........................8
NISB 108 .............................................................................................8
Jumpers................................................................................................10
LVDS Panel Power Selection...............................................................10
Backlight Volume Selection................................................................10
Clear CMOS ......................................................................................11
ATX/AT Mode Selection .....................................................................11
COM2 Port Power Setting..............................................................12
Connector Pin Definitions .....................................................................13
External I/O Interfaces........................................................................13
LED Indicators ................................................................................13
DisplayPorts ...................................................................................13
USB 2.0 Ports.................................................................................14
USB 3.0 Ports.................................................................................14
LAN1 Port ......................................................................................15
LAN2 Port ......................................................................................15
24V DC Power Input ......................................................................16
Internal Connectors...........................................................................17
Debug Connector ..........................................................................17
LED Connector...............................................................................17
LVDS Connector.............................................................................18

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. iii NISE 108 User Manual
Content
LVDS Connector.............................................................................18
LVDS Inverter Connector ................................................................19
Front Panel Connector ...................................................................19
Internal USB 2.0 Connector............................................................20
Touch Screen Connector ................................................................20
Remote On/Off Connector .............................................................21
GPIO Connector.............................................................................21
COM3 Connector (RS232/422/485)................................................22
COM1 and COM2 Connectors (RS232) ..........................................22
SATA Connector (7-pin and 15-pin)................................................23
Battery Connector..........................................................................23
Mini-PCIe Connector......................................................................24
M.2 Connector (B-Key)...................................................................25
Chapter 3: System Setup
Removing the Chassis Bottom Cover.....................................................26
Installing a SO-DIMM Memory Module .................................................27
Installing a Wireless LAN Module (Half-size) ..........................................29
Installing an M.2 Storage Module (2242) ..............................................31
Installing a SATA Storage Drive..............................................................33
Wall Mounting Instructions ...................................................................35
Chapter 4: BIOS Setup
About BIOS Setup.................................................................................36
When to Configure the BIOS.................................................................36
Default Configuration...........................................................................37
Entering Setup......................................................................................37
Legends................................................................................................37
BIOS Setup Utility..................................................................................39
Main .................................................................................................39
Advanced..........................................................................................40
Chipset..............................................................................................48
Security .............................................................................................51
Boot..................................................................................................52
Save & Exit ........................................................................................53
Appendix A: Power Consumption ........................54
Appendix B: GPI/O Programming Guide ..............55
Appendix C: LED Programming Guide..................56

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. iv NISE 108 User Manual
Preface
PrefaCe
Copyright
This publication, including all photographs, illustrations and software, is
protected under international copyright laws, with all rights reserved. No
part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written consent from NEXCOM
International Co., Ltd.
Disclaimer
The information in this document is subject to change without prior notice and
does not represent commitment from NEXCOM International Co., Ltd. However,
users may update their knowledge of any product in use by constantly checking
its manual posted on our website: http://www.nexcom.com. NEXCOM shall
not be liable for direct, indirect, special, incidental, or consequential damages
arising out of the use of any product, nor for any infringements upon the rights
of third parties, which may result from such use. Any implied warranties of
merchantability or fitness for any particular purpose is also disclaimed.
Acknowledgements
NISE 108 is a trademark of NEXCOM International Co., Ltd. All other product
names mentioned herein are registered trademarks of their respective
owners.
Regulatory Compliance Statements
This section provides the FCC compliance statement for Class A devices and
describes how to keep the system CE compliant.
Declaration of Conformity
FCC
This equipment has been tested and verified to comply with the limits for
a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area
(domestic environment) is likely to cause harmful interference, in which
case the user will be required to correct the interference (take adequate
measures) at their own expense.
CE
The product(s) described in this manual complies with all applicable
European Union (CE) directives if it has a CE marking. For computer systems
to remain CE compliant, only CE-compliant parts may be used. Maintaining
CE compliance also requires proper cable and cabling techniques.

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. vNISE 108 User Manual
Preface
RoHS Compliance
NEXCOM RoHS Environmental Policy and Status
Update
NEXCOM is a global citizen for building the digital
infrastructure. We are committed to providing green
products and services, which are compliant with
European Union RoHS (Restriction on Use of Hazardous Substance in
Electronic Equipment) directive 2011/65/EU, to be your trusted green
partner and to protect our environment.
RoHS restricts the use of Lead (Pb) < 0.1% or 1,000ppm, Mercury (Hg) < 0.1%
or 1,000ppm, Cadmium (Cd) < 0.01% or 100ppm, Hexavalent Chromium
(Cr6+) < 0.1% or 1,000ppm, Polybrominated biphenyls (PBB) < 0.1% or
1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm.
In order to meet the RoHS compliant directives, NEXCOM has established
an engineering and manufacturing task force to implement the introduction
of green products. The task force will ensure that we follow the standard
NEXCOM development procedure and that all the new RoHS components
and new manufacturing processes maintain the highest industry quality
levels for which NEXCOM are renowned.
The model selection criteria will be based on market demand. Vendors and
suppliers will ensure that all designed components will be RoHS compliant.
How to recognize NEXCOM RoHS Products?
For existing products where there are non-RoHS and RoHS versions, the
suffix “(LF)” will be added to the compliant product name.
All new product models launched after January 2013 will be RoHS compliant.
They will use the usual NEXCOM naming convention.

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. vi NISE 108 User Manual
Preface
Warranty and RMA
NEXCOM Warranty Period
NEXCOM manufactures products that are new or equivalent to new in
accordance with industry standard. NEXCOM warrants that products will be
free from defect in material and workmanship for 2 years, beginning on the
date of invoice by NEXCOM.
NEXCOM Return Merchandise Authorization (RMA)
▪Customers shall enclose the “NEXCOM RMA Service Form” with the
returned packages.
▪Customers must collect all the information about the problems
encountered and note anything abnormal or, print out any on-screen
messages, and describe the problems on the “NEXCOM RMA Service
Form” for the RMA number apply process.
▪Customers can send back the faulty products with or without accessories
(manuals, cable, etc.) and any components from the card, such as CPU
and RAM. If the components were suspected as part of the problems,
please note clearly which components are included. Otherwise, NEXCOM
is not responsible for the devices/parts.
▪Customers are responsible for the safe packaging of defective products,
making sure it is durable enough to be resistant against further damage
and deterioration during transportation. In case of damages occurred
during transportation, the repair is treated as “Out of Warranty.”
▪Any products returned by NEXCOM to other locations besides the
customers’ site will bear an extra charge and will be billed to the customer.
Repair Service Charges for Out-of-Warranty Products
NEXCOM will charge for out-of-warranty products in two categories, one is
basic diagnostic fee and another is component (product) fee.
System Level
▪Component fee: NEXCOM will only charge for main components such as
SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistor, capacitor.
▪Items will be replaced with NEXCOM products if the original one cannot
be repaired. Ex: motherboard, power supply, etc.
▪Replace with 3rd party products if needed.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.
Board Level
▪Component fee: NEXCOM will only charge for main components, such
as SMD chip, BGA chip, etc. Passive components will be repaired for free,
ex: resistors, capacitors.
▪If RMA goods can not be repaired, NEXCOM will return it to the customer
without any charge.

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. vii NISE 108 User Manual
Preface
Warnings
Read and adhere to all warnings, cautions, and notices in this guide and
the documentation supplied with the chassis, power supply, and accessory
modules. If the instructions for the chassis and power supply are inconsistent
with these instructions or the instructions for accessory modules, contact
the supplier to find out how you can ensure that your computer meets
safety and regulatory requirements.
Cautions
Electrostatic discharge (ESD) can damage system components. Do the
described procedures only at an ESD workstation. If no such station is
available, you can provide some ESD protection by wearing an antistatic
wrist strap and attaching it to a metal part of the computer chassis.

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. viii NISE 108 User Manual
Preface
Installation Recommendations
Ensure you have a stable, clean working environment. Dust and dirt can get
into components and cause a malfunction. Use containers to keep small
components separated.
Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
▪A Philips screwdriver
▪A flat-tipped screwdriver
▪A grounding strap
▪An anti-static pad
Using your fingers can disconnect most of the connections. It is recommended
that you do not use needle-nose pliers to disconnect connections as these
can damage the soft metal or plastic parts of the connectors.
Safety Information
Before installing and using the device, note the following precautions:
▪Read all instructions carefully.
▪Do not place the unit on an unstable surface, cart, or stand.
▪Follow all warnings and cautions in this manual.
▪When replacing parts, ensure that your service technician uses parts
specified by the manufacturer.
▪Avoid using the system near water, in direct sunlight, or near a heating
device.
▪The load of the system unit does not solely rely for support from the
rackmounts located on the sides. Firm support from the bottom is highly
necessary in order to provide balance stability.
▪The computer is provided with a battery-powered real-time clock circuit.
There is a danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer’s instructions.
CAUTION!
CAUTION!CAUTION!
Danger of explosion if battery is incorrectly replaced.
Replace with the same or equivalent type recommended by
the manufacturer. Discard used batteries according to the
manufacturer’s instructions.

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. ix NISE 108 User Manual
Preface
Safety Precautions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a
damp cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a stable surface during installation. Dropping it or
letting it fall may cause damage.
7. The openings on the enclosure are for air convection to protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting
the equipment to the power outlet.
9. Place the power cord in a way so that people will not step on it. Do not
place anything on top of the power cord. Use a power cord that has been
approved for use with the product and that it matches the voltage and
current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current
rating marked on the product.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical
shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. The equipment is intended to be supplied by DC mains, it will not
tolerate voltage supplied below 24Vdc, and without PE connection.
15. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b.Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d.The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
16. Do not place heavy objects on the equipment.
17. The unit uses a three-wire ground cable which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the
purpose of this pin. If your outlet does not support this kind of plug,
contact your electrician to replace your obsolete outlet.
18. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER. DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. xNISE 108 User Manual
Preface
Technical Support and Assistance
1. For the most updated information of NEXCOM products, visit NEXCOM’s
website at www.nexcom.com.
2. For technical issues that require contacting our technical support team or
sales representative, please have the following information ready before
calling:
– Product name and serial number
– Detailed information of the peripheral devices
– Detailed information of the installed software (operating system,
version, application software, etc.)
– A complete description of the problem
– The exact wordings of the error messages
Warning!
1. Handling the unit: carry the unit with both hands and handle it with care.
2. Maintenance: to keep the unit clean, use only approved cleaning products
or clean with a dry cloth.
Conventions Used in this Manual
Warning:
Information about certain situations, which if not observed,
can cause personal injury. This will prevent injury to yourself
when performing a task.
CAUTION!
CAUTION!CAUTION! Caution:
Information to avoid damaging components or losing data.
Note:
Provides additional information to complete a task easily.

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. xi NISE 108 User Manual
Preface
Global Service Contact Information
Headquarters
NEXCOM International Co., Ltd.
9F, No. 920, Chung-Cheng Rd.,
ZhongHe District, New Taipei City, 23586,
Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
www.nexcom.com
Asia
Taiwan
NexAIoT Co., Ltd.
Taipei Office
13F, No.920, Chung-Cheng Rd.,
ZhongHe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
NexAIoT Co., Ltd.
Taichung Office
16F, No.250, Sec. 2, Chongde Rd.,
Beitun Dist.,
Taichung City 406, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
NexCOBOT Taiwan Co., Ltd.
13F, No.916, Chung-Cheng Rd.,
ZhongHe District,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com.tw
GreenBase Technology Corp.
13F, No.922,Chung-Cheng Rd.,
Zhonghe Dist.,
New Taipei City, 23586, Taiwan, R.O.C.
Tel: [phone]
Fax: [phone]
Email:[email protected]
www.nexcom.com.tw
China
NEXSEC Incorporated
Floor 5, No.4, No.7 fengxian middle Rd.,
(Beike Industrial Park), Haidian District,
Beijing, 100094, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. xii NISE 108 User Manual
Preface
NEXGOL
1st Floor, Building B4, Electronic 2nd Area,
(Phoenix Lake Industrial Park), Yongchuan Dist.,
Chongqing City, 402160, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexgol.com/NexGoL
Beijing NexGemo Technology Co.,Ltd.
5th Floor, Gemotech Building, No.1, Development Rd.,
Changping International Information Industry Base,
Changping District,
Beijing,102206, China
Tel: [phone]
Fax:[phone]
Japan
NEXCOM Japan
9F, Tamachi Hara Bldg.,
4-11-5, Shiba Minato-ku,
Tokyo, 108-0014, Japan
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom-jp.com
NEXCOM Shanghai
Room 603/604, Huiyinmingzun Plaza Bldg., 1,
No. 609, Yunlin East Rd.,
Shanghai, 200062, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM Surveillance Technology Corp.
Floor 5, Building C, ZhenHan Industrial Zone,
GanKeng Community, Buji Street,
LongGang District,
ShenZhen, 518112, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
NEXCOM United System Service
Room 603/604, Huiyinmingzun Plaza Bldg. 1,
No. 609, Yunlin East Rd.,
Shanghai, 200062, China
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.cn
Europe
United Kingdom
NEXCOM EUROPE
10 Vincent Avenue,
Crownhill Business Centre,
Milton Keynes, Buckinghamshire
MK8 0AB, United Kingdom
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.eu
America
USA
NEXCOM USA
2883 Bayview Drive,
Fremont CA 94538, USA
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.nexcom.com

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. xiii NISE 108 User Manual
Preface
Package Contents
Before continuing, verify that the NISE 108 package that you received is
complete. Your package should have all the items listed in the following table.
Item Part Number Name Description Qty
1 4NCPF00309X00 Terminal Blocks 3P Phoenix Contact:1827716 3.81mm Female DIP Green 1
2 4NCPM00302X00 Terminal Blocks 3P Phoenix Contact:1777992 5.08mm Male DIP Green 1
3 50311F0295X00 Flat Head Screw Long Fei:F2x4 Nylok NIGP F2x4 NIGP Nylok 1
4 50311F0326X00 Flat Head Screw Long Fei:F3x5 Nylok NI+Heat Treatment F3x5 Nylok NI+Heat Treatment 4
5 50311F0330X00 Round Head Screw Long Fei:P2x3 ISO+Nylon P2x3 NI Nylok 2
6 50311F0530X00 I Head Screw Long Fei:I3x6 ISO I3x6 ISO w/Spring+Washer NI 1
7 5060900226X00 Mini PCIe Bracket Chyuan-JYH 29x30x2.1mm SPCC t=1.0mm NI 1
8 5061600107X00 Transistor Washer for VTC 1020 Kang Yang TW-39 A5.46 B3.43 C2.95 D0.81 E1.02 PBT Natural 3
9 6012200052X00 PE Zipper Bag #8 170x240mm, w/China RoHS Symbol 1
10 6012200053X00 PE Zipper Bag #3 100x70mm, w/China RoHS Symbol 2
11 60177A0724X00 NISE 108-J3455 Series Quick Reference Guide VER:A KRAMER Size: A4 1
12 602DCD1614X00 NISE 108-J3455 DVD Driver VER:1.0 JCL 1

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. xiv NISE 108 User Manual
Preface
Ordering Information
The following information below provides ordering information for NISE 108.
NISE 108 (P/N: 10J00010800X0)
Intel®Celeron®processor J3455 quad core, 1.50GHz fanless system
• 24V, 60W AC/DC power adapter w/o power cord (P/N: 7400060032X00)

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. 1NISE 108 User Manual
Chapter 1: Product Introduction
ChaPter 1: ProduCt IntroduCtIon
Key Features
▪Onboard Intel®Celeron®processor J3455 quad core, 1.50GHz
▪Dual independent display from DP1 & DP2
▪2 x Intel®I210-IT GbE LAN ports; support WoL, teaming and PXE
▪2 x USB 2.0 & 2 x USB 3.0
▪3 x COM ports (COM3 with RS232/422/485, jumper-free setting)
▪Support both 2.5” HDD and M.2
▪Support -5~55 degree C operating temperature
▪Support 24 VDC input
NISE 108 Overview

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. 2NISE 108 User Manual
Chapter 1: Product Introduction
Hardware Specifications
CPU Support
▪Onboard Intel®Celeron®processor J3455 quad core, 1.50GHz
Main Memory
▪1 x DDR3L SO-DIMM socket, support DDR3L1866 8GB RAM max.,
un-buffered and non-ECC
Display Option
▪Dual independent display: DP1 & DP2
I/O Interface - Front
▪ATX power on/off switch
▪1 x Power status/1 x HDD access/1x programming LEDs
▪2 x USB 3.0 (900mA per each)
▪2 x USB 2.0 (500mA per each)
▪2 x Intel®I210-IT GbE LAN ports; support WoL,teaming and PXE
▪1 x DB9 for COM3, it supports RS232/422/485 with auto flow control
– Jumper-free setting on RS232/422/485 by BIOS
▪2 x DB9 for COM1 & COM2, support RS232 only
– COM1 supports ring function
– COM2 supports 5V/12V/ring function via jumper setting, default
setting is ring.
▪1 x 3-pin DC input, support 24 VDC input
▪1 x Antenna hole for optional Wi-Fi/3.5G antenna
▪1 x 3-pin remote power on/off switch
I/O Interface - Rear
▪1 x Antenna hole for optional Wi-Fi/3.5G antenna
Storage Device
▪1 x M.2 (SATA 2.0)
▪1 x 2.5” HDD (SATA 2.0)
Expansion Slot
▪1 x mini-PCIe socket for optional Wi-Fi/3.5G/4G module
(For 3.5G/4G function, mini-PCIe module must have a SIM card holder)
Power Requirements
▪Power input: DC input: 24V
▪1 x Optional 24V, 60W power adapter
Dimensions
▪185 mm (W) x 131mm (D) x 54 mm (H) without wall-mount bracket
Construction
▪Aluminum and metal chassis with fanless design
Environment
▪Operating temperature:
Ambient with air flow: -5°C to 55°C with industrial grade device
(according to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)
▪Storage temperature: -20°C to 80°C
▪Relative humidity: 10% to 95% (non-condensing)
▪Shock protection:
– HDD: 20G, half sine, 11ms, IEC60068-2-27
– CFast: 50G, half sine, 11ms, IEC60068-2-27

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. 3NISE 108 User Manual
Chapter 1: Product Introduction
▪Vibration protection w/ HDD condition:
– Random: 0.5Grms @ 5~500 Hz, IEC60068-2-64
– Sinusoidal: 0.5Grms @ 5~500 Hz, IEC60068-2-6
▪Vibration protection w/ SSD condition:
– Random: 2Grms @ 5~500 Hz, IEC60068-2-64
– Sinusoidal: 2Grms @ 5~500 Hz, IEC60068-2-6
Certifications
▪CE
▪FCC Class A
OS Support List
▪Windows 10 IoT Enterprise, 64-bit
▪Linux kernel version 4.1

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. 4NISE 108 User Manual
Chapter 1: Product Introduction
Knowing Your NISE 108
Front Panel
LED
Indicators
DisplayPort2 & DisplayPort1
Power
Switch
COM1COM2COM3
Antenna Hole
Antenna Hole
24V DC Input
Used to plug a DC power cord.
LAN1 & LAN2
Used to connect the system to a local area network.
USB 3.0
Used to connect USB 3.0/2.0 devices.
USB 2.0
Used to connect USB 2.0/1.1 devices.
DisplayPort1 & DisplayPort2
Used to connect a DisplayPort interface monitor.
LED Indicators
Two LEDs used to indicate the power status and storage activity of the
system. The third LED is user programmable.
Power Switch
Press to power-on or power-off the system.
COM1 to COM3
Three DB9 ports used to connect RS232 compatible devices. COM3 supports
RS232/422/485 connection.
Remote On/Off Switch
Used to connect a remote to power on/off the system.
Antenna Hole
The external antenna mounting holes are used to mount and connect
optional Wi-Fi antennas.
Rear Panel
Remote
On/Off
24V
DC Input
USB 3.0 USB 2.0
LAN1 & LAN2

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. 5NISE 108 User Manual
Chapter 1: Product Introduction
Mechanical Dimensions
206.00
184.85
131.00 115.00
60.00
54.00

Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved. 6NISE 108 User Manual
Chapter 2: Jumpers and Connectors
ChaPter 2: JumPers and ConneCtors
This chapter describes how to set the jumpers and connectors on the
NISE 108 motherboard.
Before You Begin
▪Ensure you have a stable, clean working environment. Dust and dirt can
get into components and cause a malfunction. Use containers to keep
small components separated.
▪Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
– A Philips screwdriver
– A flat-tipped screwdriver
– A set of jewelers screwdrivers
– A grounding strap
– An anti-static pad
▪Using your fingers can disconnect most of the connections. It is
recommended that you do not use needle-nosed pliers to disconnect
connections as these can damage the soft metal or plastic parts of the
connectors.
▪Before working on internal components, make sure that the power is off.
Ground yourself before touching any internal components, by touching
a metal object. Static electricity can damage many of the electronic
components. Humid environments tend to have less static electricity than
dry environments. A grounding strap is warranted whenever danger of
static electricity exists.
Precautions
Computer components and electronic circuit boards can be damaged by
discharges of static electricity. Working on computers that are still connected
to a power supply can be extremely dangerous.
Follow the guidelines below to avoid damage to your computer or yourself:
▪Always disconnect the unit from the power outlet whenever you are
working inside the case.
▪If possible, wear a grounded wrist strap when you are working inside the
computer case. Alternatively, discharge any static electricity by touching
the bare metal chassis of the unit case, or the bare metal body of any
other grounded appliance.
▪Hold electronic circuit boards by the edges only. Do not touch the
components on the board unless it is necessary to do so. Don’t flex or
stress the circuit board.
▪Leave all components inside the static-proof packaging that they shipped
with until they are ready for installation.
▪Use correct screws and do not over tighten screws.
