ASSEMBLY INSTRUCTIONS
Item No : WF306306AAA
Description : QUEEN BED
MADE IN MALAYSIA
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part
that may have come loose inside carton during shipment.
WF306306AAA

Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part
that may have come loose inside carton during shipment.
Hardware List
No. Description Sketch Quantity
AWood Dowel M8x50mm 26PCS
BJRN Nut 12PCS
C JCBC M6 x 90mm 12PCS
DAllen Key M4 1PC
E JCBCW M7 x 40mm 4PCS
F Screw M4 x 32mm 32PCS
TOOLS REQUIRED (Not provided)
Screwdriver
Part List
No. Description Sketch Quantity
1Headboard 1PC
2 Headboard Posters L/R 2PCS
3Footboard 1PC
4 Footboard Posters L/R 2PCS
5Side Rails 1 2PCS
6Side Rails 2 2PCS
7Side Rails Support 2PCS
8Center Rail 2PCS
9Center Rail Support 4PCS
10 Slats 2SETS
ASSEMBLY INSTRUCTIONS
Item No : WF306306AAA
Description : QUEEN BED
3
1
MADE IN MALAYSIAPAGE 2 OF 5
4L
4R
2L
2R
5
5
6
6
7
7
9
10
8

MADE IN MALAYSIA
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part
that may have come loose inside carton during shipment.
PAGE 3 OF 5
Step 2 : Connect Posters (2,4) to Headboard (1) and Footboard (3) with JCBC (C) using Allen Key (D).
AWood Dowel M8x50mm 26PCS
BJRN Nut 12PCS
ASSEMBLY INSTRUCTIONS
Item No : WF306306AAA
Description : QUEEN BED
Step 1 : Attach Wood Dowel (A) and JRN Nut (B) to parts (1,3,5,6) accordingly. Put Side Rails (5,6) together.
AA
AA
AAA
AAA
AAA
AAA
AA
AA
A x 3
A x 3
BB
BB
BB
BB
B
B
B
B
1
355
6
6
B
A
A
C JCBC M6 x 90mm 8PCS
DAllen Key M4 1PC
CC
CC
C
C
CC
D
C
D
1
3
2L
2R
4L
4R

MADE IN MALAYSIA
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part
that may have come loose inside carton during shipment.
PAGE 4 OF 5
Step 4 : Connect Side Rails (5,6,7) to Headboard (1,2) with JCBC (C) using Allen Key (D).
DAllen Key M4 1PC
E JCBCW M7 x 40mm 4PCS
F Screw M4 x 32mm 12PCS
ASSEMBLY INSTRUCTIONS
Item No : WF306306AAA
Description : QUEEN BED
Step 3 : Attach Side Rails Support (7) to Side Rails (5,6) using Screw (F). Connect Center Rail Support (9) to Center Rail (8)
with JCBCW (E) using Allen Key (D). Attach Slats (10) onto Center Rail (8,9) with Screw (F).
C JCBC M6 x 90mm 2PCS
DAllen Key M4 1PC
5,6
5,6
7
8
9
10
7
F x 4
F x 4
F
F
E
E
D
C
C
D
5,6,7
5,6,7
1,2
x 2

MADE IN MALAYSIA
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small part
that may have come loose inside carton during shipment.
PAGE 5 OF 5
Step 6 : Attach Center Rail and Slats (8,9,10) to the bed using Screw (F). Completed Assembly.
ASSEMBLY INSTRUCTIONS
Item No : WF306306AAA
Description : QUEEN BED
Step 5 : Attach Footboard (3,4) to the assembled parts with JCBC (C) using Allen Key (D).
F Screw M4 x 32mm 20PCS
C JCBC M6 x 90mm 2PCS
DAllen Key M4 1PC
3,4
C
C
D
8,9,10
F
