BED BATH & Beyond MG00006 User manual

FULL LOFT BED ASSEMBLY
INSTRUCTIONS
SKU MG00006

SAFETY WARNINGS AND GENERAL NOTES：
1. Follow the information on the warnings on the bunk bed
end structure and on the carton. Do not remove the
warning label from the bed.
2. Always use the recommended size mattress on
mattress support, or both, to help prevent the likelihood of
entrapment or falls.
3. Do not allow children under 6 years of age to use the upper bunk.
4. Periodically check and ensure the guardrail, ladder
and other components are in their proper position, free
from damage, and all connectors are tight.
5. Do not allow horseplay on or under beds.
6. Always prohibit jumping on the bed.
7. Prohibit more than one person on upper bunk.
8. Always use the ladder for entering and leaving the upper bunk.
9. Do not use substitute parts.Contact the manufacturer
or dealer for replacement parts.
10. Use of a night-tight may provide added safety
precaution for a child using the upper bunk.
11. Always use guardrails on both long sides of the upper bunk.
12. If the bunk bed will be placed next to a wall, the
guardrail that runs the full length of the bed should be
placed against the wall to prevent entrapment between the
bed and the wall.
The use of water or sleep flotation mattresses is prohibited.
13. STRANGULATION HAZARD-Never attach or hang
items to any part of the bunk bed that is not designed for
use with the bed.
14. Keep these instructions for future reference.
15. We recommend assembling your bunk bed on the
shipping carton to protect your floor or carpet.
16. Be certain all staples are out of the box before
beginning assembly on the shipping carton.
17. USE ONLY MATTRESSES WHICH ARE AS
THE TABLE BELOW ON UPPER AND ON
LOWER BUNKS.
Up bed (bunk bed and tribed included)
Bed type Length Width Thickness
Full Standard 74” – 75” 53 ½ ” 6 ” max
18. SURFACE OF MATTRESS MUST BE AT LEAST
5" (127MM) BELOW THE UPPER EDGE OF
GUARDRAILS.
19. Replacement Parts:
Replacement Parts, including additional guardrails, may
be obtained from any of our dealers.

PART LIST
5 -1PC
1 -1PC
2 -1PC
3 -1PC
4 -1PC
6 -1PC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
16
18
18
19
20

7 -1PC
10 -1PC
8 -1PC
9 -1PC
12 -1PC
13 -1PC
15 -1PC
11 -1PC
16 -1PC
14 -1PC
17 -10PCS
18 -2PCS
19 -1PC
20 -1PC
HARDWARE LIST
A
B
C
D
E
F
6*10 -33pcs
6*30-27pcs
6*60-8pcs
6*40-4pcs
4*10-18pcs
20pcs
G
H
I
J
K
L
4*30-4pcs
4pcs
2pcs
1pc
2pcs
1pc

Step 1: Using hardware A,B,C,K connect #1, #2 and #12 to semi-finish frame 1.
Step 2: Using hardware A,C,D,K connect #5, #7 and #9 attached the frame 1.
A：6*10-1pCs
B：6*30-1pCs
C：6*60-4pCs
K
B*1
C*2
C*2
A*1
A：6*10-4pCs
D：6*40-1pCs
K
1
12
2
5
7
9
A*1
A*1
A*2
D*1

Step 3: Using hardware E & L connect #18 to complete finish frame 1 (Frame 1 is the front part of the bed frame).
Step 4: Using hardware A,B,C,K connect #3, #4, #6 and #14 to complete-finish frame 2(Frame 2 is the back part
of the bed frame).
E：4*10-8pCs
L
E*8
18*2
A：6*10-5pCs
B：6*30-2pCs
C：6*60-4pCs
K
B*1
B*1
C*2
C*2
B*2
B*2
14
4
3
6
Please put frame 1 on
floor to install part 18
more easy

Step 5: Using hardware A,D,K connect Frame 1, Frame 2 and #10, #13, #8.
Step 6: Using hardware D,K connect #15.
A：6*10-18pCs
D：6*40-1pCs
K
13
10
8
A*3
A*3
A*3
A*2
A*1
A*2
A*2
A*2
D：6*40-2pCs
K
D*1
D*1
15

Step 7: Put #17 into the reserved groove.
Step 8: Using hardware B,F,J,K connect with #17.
The middle teeth
hole of these 4 slats
face downwards and
aligned with 4 holes
of #15
J
K
B：6*30-24pcs
F：20pcs
B*10-F*10
B*10-F*10
B*4

Step 9: Using hardware E,L connect with #11 and #16.
Step 10: Using hardware E,L connect with #19 and #20.
A：6*10-4pCs
K
11
16
A*4
E：4*10-12pCs
L
19
20
E*4
E*8

Step 11: Using hardware E& L fix to the wall.
COMPLETED LOFT BED
NOTE: Tighten all step before using. Thank you.
H：4pCs
G：4*30-4pCs
I：2pCs
L
H*2
G*2
I*1
H*2
G*2
I*1
Wall
