Behringer Tube Ultragain MIC100 User manual

TUBE ULTRAGAIN MIC100
Version 1.1 September 2003
Users Manual
ENGLISH

This symbol, wherever it appears, alerts you to the presence of uninsulated
dangerous voltage inside the enclosurevoltage that may be sufficient to
constitute a risk of shock.
This symbol, wherever it appears, alerts you to important operating and
maintenance instructions in the accompanying literature. Please read the
manual.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: To reduce the risk of electric shock, do not remove the top cover (or the
rear section). No user serviceable parts inside refer servicing to
qualified personnel.
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance
to rain and moisture.
DETAILED SAFETY INSTRUCTIONS:
1) Read these instructi ns.
2) Keep these instructi ns.
3) Heed all warnings.
4) F ll w all instructi ns.
5) D n t use this device near water.
6) Clean nly with a dry cl th.
7) D n t bl ck any ventilati n penings. Install in acc rdance with the manufacturers
instructi ns.
8) D n t install near any heat s urces such as radiat rs, heat registers, st ves, r ther
apparatus (including amplifiers) that pr duce heat.
9) D n t defeat the safety purp se f the p larized r gr unding-type plug. A p larized
plug has tw blades with ne wider than the ther. A gr unding type plug has tw blades
and a third gr unding pr ng. The wide blade r the third pr ng are pr vided f r y ur safety.
If the pr vided plug d es n t fit int y ur utlet, c nsult an electrician f r replacement f
the bs lete utlet.
10) Pr tect the p wer c rd fr m being walked n r pinched particularly at plugs, extensi n
c rds, and the p int at which they exit the unit.
11) Only use attachments/access ries specified by the manufacturer.
12) Use nly with the cart, stand, trip d, bracket, r table specified by the manufacturer,
r s ld with the device. When a cart is used, use cauti n when m ving the cart/device
c mbinati n t av id injury fr m stumbling ver it.
13) Unplug this device during lightning st rms r when n t used f r l ng peri ds f time.
14) Refer all servicing t qualified service pers nnel. Servicing is required when the unit
has been damaged in any way, such as p wer supply c rd r plug is damaged, liquid has
been spilled r bjects have fallen int the device, the unit has been exp sed t rain r
m isture, d es n t perate n rmally, r has been dr pped.

3
TUBE ULTRAGAIN MIC100
Welcome to the BEHRINGER family!
Thank you for the confidence you have placed in us by purchasing
the MIC100.
Your MIC100 is a professional mic preamp that can be used in a
variety of applications. Due to its incredible functionality and the
broad range of connection options the MIC100 ensures outstanding
performance. You will soon appreciate the MIC100s flexibility be it
live on stage or in the home/professional recording studio.
1. INTRODUCTION
With the MIC100 you have purchased an extremely musical mic
preamp that is equipped with a 12AX7 vacuum tube. An integrated
limiter a phase reverse function phantom power supply a highly
accurate LED meter and a switchable pad function complement this
powerful device.
1.1 The design concept
The heart of the TUBEULTRAGAIN is an extremely low-noise
microphone preamp circuitry that uses discrete components and
produces a highly trans-parent sound. In combination with our
BEHRINGER tube technology the operational amplifiers 4580 and a
sophisticated circuit topology the TUBEULTRAGAIN yields excellent
noise and distortion properties. The innovative UTC circuitry that has
been developed by our engineering team offers an abundance of
sound-shaping possibilities. Absolute musicality was our major goal
when we designed the TUBE ULTRAGAIN. The result is a device that
thanks to our tube circuitry lends an incredible punch to percussion
instruments. On the other hand instruments that are rich in upper
harmonics will receive more transparency. The sound will be warm
detailed and brilliant.
Surely you know the recording problem that single instruments or
vocals sometimes dont cut through. Thanks to the TUBEULTRAGAIN
vocals gain in presence and volume without masking other instruments.
As a result your voice will be perfectly integrated in the mix.
1. INTRODUCTION

4
TUBE ULTRAGAIN MIC100
2. CONTROL ELEMENTS
Fig. 2.1: Side panel of the MIC100
2.1 Connections (side pane )
Use the POWER SUPPLY CO ECTOR to hook up the enclosed
power supply unit. Next to this connector youll find the strain
relief clamp which prevents accidental release of the power
supply.
This is the balanced XLR OUTPUT of your MIC100. Use this
connector to feed the XLR input of your mixing console
multitrack recorder or power amp.
The balanced 1/4" TRS OUTPUT of your MIC100 can also be
connected to either mixer recording system or power amp.
+P ease note that you can use the XLR and TRS outputs of
your MIC100 at the same time! Thus, it is possib e to
connect the MIC100s output signa to two different devices
simu taneous y.
The balanced 1/4" TRS I PUT of your MIC100 can be used to
connect your electric guitar for example. This input is wired
parallelly to the XLR input.
2. CONTROL ELEMENTS

5
TUBE ULTRAGAIN MIC100
Use the balanced XLR I PUT to connect your microphone.
+In contrast to its outputs, the MIC100s inputs shou d
never be used simu taneous y!
2.2 User interface
Fig. 2.2: User interface of the MIC100
The GAI control allows applying gain from +26 to +60 dB to the
input signal. This control should be set fully counterclockwise
when (dis)connecting a sound source to the MIC100. When all
connections are made slowly start raising gain.
We recommend using the LED meter to adjust gain. The
LED chain displays the output signal level in dB. Please make
sure that the clip LED never lights up permanently. It should
light up only at peak signals but never all the time.
2. CONTROL ELEMENTS

6
TUBE ULTRAGAIN MIC100
If your MIC100 is connected to the mains via the enclosed
power supply unit the POWER LED lights up to indicate that
your MIC100 is running.
The 20 dB PAD button reduces the input sensitivity by 20 dB.
The appropriate setting depends on the equipment connected.
No matter what your application is the clip LED warns you to
reduce the gain setting so as to avoid distortion.
This +48 V switch activates the phantom power supply for the
XLR input. Phantom power supply is required for operating
condenser microphones.
With the PHASE REVERSE switch the input signal is reversed
by 180°. This function is available for both mic and line signals.
Use this function in a multi-microphone setup if you detect
phase cancellations in specific frequency bands.
Use the LIMITER switch to limit the signal and to prevent
distortion.
The OUTPUT control governs the output level of the device
within a range from -oo to +10 dB. If the control is set fully
counter-clockwise there is no output signal at all. The more the
control is set clockwise the higher the output level.
2.3 Seria number
The MIC100s serial number is located on the bottom cover. Please
take time to fill in and return the warranty card within 14 days after the
date of purchase so as to benefit from our extended warranty. Or
use our online registration option available on the World Wide Web at
www.behringer.com.
3. WIRING EXAMPLES
Youll be surprised how flexibly you can set up your MIC100. The
following chapter describes some typical wiring examples.
3. WIRING EXAMPLES

7
TUBE ULTRAGAIN MIC100
3.1 Enhancing voca s and instruments in ive app ications
Here the MIC100 is wired before the mixers channel input. Thus
the sound gains in warmth and transparency. Due to the integrated
limiter distortion is eliminated effectively.
Fig. 3.1: Standard live application
3.2 Direct to disk app ication in studio or home recording
environments
If you are looking for a device that considerably enhances the sound
of your digital workstation this is where the MIC100 comes in. Many
hard disk recorders lack a certain liveliness. In addition they are
often equipped with lousy microphone preamps. Such problems can
be solved perfectly with the MIC100.
Fig. 3.2: Connection of the MIC100 and the soundcard of your PC
3. WIRING EXAMPLES

8
TUBE ULTRAGAIN MIC100
3.3 The MIC100 as DI-box
Your MIC100 is excellently suited for this application. For example
you can connect an unbalanced acoustic guitar signal to the MIC100
to prevent hum or interference noise. What you get is a balanced
noise-free signal.
Fig. 3.3: The MIC100 as DI-box
4. AUDIO CONNECTIONS
Fig. 4.1: XLR connectors
4. AUDIO CONNECTIONS

9
TUBE ULTRAGAIN MIC100
Fig. 4.2: 1/4" TS connector
Fig. 4.3: 1/4" TRS connector
5. WARRANTY
For our current warranty terms please refer to our website at http:/
/www.behringer.com or send us a request via e-mail at
[email protected] fax at [phone] or call
[phone].
5. WARRANTY

10
TUBE ULTRAGAIN MIC100
6. SPECIFICATIONS
XLR input
Co ector Bala ced/u bala ced
Type Tra sformerless, DC-decoupled i put
Impeda ce approx. 2 kΩ
Max. i put level +7 dBu / 20 dB with pad
1/4" TRS input
Co ector Bala ced/u bala ced
Type Tra sformerless, DC-decoupled i put
Impeda ce approx. 1 MΩ
Max. i put level +16 dBu / 20 dB with pad
Audio outputs
Co ectors XLR a d 1/4" TRS co ector bala ced/u bala ced
Type Tra sformerless, DC-decoupled output
Impeda ce approx. 700 Ω bala ced / approx. 350 Ω u bala ced
Max. output level approx. +26 dBu @ 100 kΩ
System specifications
Freque cy respo se Mic i put <10 Hz - 43 kHz (+/-3 dB)
Li e i put <10 Hz - 40 kHz (+/-3 dB)
Function controls
Gai variable (+26 to +60 dB)
Output variable (-oo to +10 dB)
Function switches
20 dB pad Level atte uatio (20 dB)
+48 V Activates the pha tom power
Phase reverse Phase reverse (180°)
Limiter Limits the output sig al
Indicators
I put level 8-segme t LED meter: -24, -18, -12, -6, 0, +6, +12,
clip
Power-LED I dicates operatio
ower supply
Mai s voltages USA/Ca ada 120 V~, 60 Hz, PSU
U.K./Australia 240 V~, 50 Hz, PSU
Europe 230 V~, 50 Hz, PSU
Japa 100 V~, 50 - 60 Hz, PSU
hysical
Dime sio s (H x W x D) approx. 2 1/2" (64 mm) x 5 1/4" (135 mm) x
5 1/4" (135 mm)
Weight (without power supply) approx. 0.5 kg (1.1 lbs)
BEHRINGER is constantly striving to maintain the highest professional standards. As a
result of these efforts, modifications may be made from time to time to existing products
without prior notice. Specifications and appearance may differ from those listed or illustrated.
6. SPECIFICATIONS

11
TUBE ULTRAGAIN MIC100
The information contained in this manual is subject to change without notice. No part of
this manual may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying and recording of any kind, for any purpose, without
the express written permission of BEHRINGER Spezielle Studiotechnik GmbH.
BEHRINGER is a registered trademark. ALL RIGHTS RESERVED.
© 2003 BEHRINGER Spezielle Studiotechnik GmbH.
