Behringer B-CONTROL DEEJAY BCD2000 User manual

B-CONTROL
DEEJAY
BCD2000
Version 1.0 June 2005
Technical Specifications

2
B-CONTROL DEEJAY BCD2000
BCD2000BCD2000
BCD2000BCD2000
BCD2000
B-CONTROL DEEJAY BCD2000
The Ultimate DJ Machine—Play, Mix and Scratch any MP3 and WAV Files just like
Vinyl Records
VPlay, mix and scratch any MP3 and WAV files just like vinyl records with ultra-low latency
VFull-speed USB 4-channel audio interface plus high-resolution 24-bit A/D and D/A converters
VPerfectly complements the included BEHRINGER B-DJ software or any other DJ software
V2 scratch wheels support creative DJing such as scratching, pitch bending and cue searching
VFull-fledged DJ mixer control panel with premium quality mic preamp, 3-band kill EQ per channel, ultra-
precise faders, super-smooth crossfader and talkover function
V2 state-of-the-art phono preamplifiers—one switchable to CD player
VSophisticated headphone section includes PFL Mix, Split options and direct listening to master output
mix
VPlay, Pause, Cue, Loop and Pitch Bend functions via dedicated controls for intuitive DJing
V4 user-assignable controls and buttons available for integrated FX section
VInnovative Cue logic with multiple storable cue points per song
VHigh-quality components and exceptionally rugged construction ensure long life
VConceived and designed by BEHRINGER Germany

3
B-CONTROL DEEJAY BCD2000
SPECIFICATIONS
BEHRINGER is constantly striving to maintain the highest professional
standards. As a result of these efforts, modifications may be made from
time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
SPECIFICATIONS
AUDIO INPUTS
Microphone input
Type XLR balanced
Gain range -oo- +50 dB
Frequency response 10 Hz - 29 kHz (-3 dB)
Impedance approx. 2 kΩ (balanced)
Max. input level -25 dBu @ 35 dB Gain
(mic level center position)
Signal-to-noise ratio 110 dB (A-weighted)
Distortion (THD+N) 0.01 % (A-weighted)
CMRR typ. -40 dB
Equalizer
EQ low ±12 dB @ 40 Hz
EQ high ±12 dB @ 12 kHz
Line inputs
Phono in 40 dB Gain
Line in 0 dB Gain
Impedance approx. 47 kΩ
Max. input level +12 dBu
AUDIO OUTPUTS
Master Out
Type RCA
Impedance 120 Ω
Signal-to-noise ratio 101 dB
Crosstalk <80 dB @ 1 kHz
Max. output level +18 dBu
Phones Out
Type 1/4" TRS connector
Max. output level +4.7 dBu (+18.2 dBm) @ 30 Ωloading
DIGITAL PROCESSING
Converter 24 Bit
Sample rate 44.1 kHz
Signal-to-noise ratio A/D: 100 dB
D/A: 100 dB
USB INTERFACE
Type Full-Speed 12 MBit/s
SYSTEM SPECIFICATIONS
Signal-to-noise ratio >80 dB
Crosstalk <80 dB
Distortion (THD) 0.01%
Frequency response 15 Hz - 21 kHz, +0/-3 dB
POWER SUPPLY
Voltage 100 - 240 V~, 50/60 Hz
Power consumption max. 7 W
Fuse T 1 A H 250 V
Mains connection Standard IEC receptacle
DIMENSIONS/WEIGHT
Dimensions
(W x H x D) 13" x 3.9" x 11.8"
(330 mm x 100 mm x 300 mm)
Weight approx. 4.41 lbs (2.0 kg)
