Behringer COMPRESSOR/LIMITER CL9 User manual

COMPRESSOR/LIMITER CL9
Classic Compressor/Limiter Eects Pedal
Thank you for showing your condence in us by purchasing the BEHRINGER COMPRESSOR/LIMITER CL9.
This ultimate eects pedal is specically designed to achieve super-smooth compression and
extended sustain. Thanks to its high-performance features you can compress loud and boost low
signals without degrading the original sound.
A compressor limits the dynamic range of a signal. This means that signal peaks will be attenuated
and the level dierences between loudest and softest playing are reduced. This results in a more
powerful tone.
1. Controls
(1) The ATTACK TIME control determines how fast the compressor responds to input signal peaks.
(2) The LEVEL control adjusts the output level.
(3) The SUSTAIN control determines the amount of compression.
(4) The ON/BATT LED illuminates when the eect is activated. It also serves as a
battery level indicator.
(5) Use the footswitch to activate/deactivate the eect.
(6) Use this ¼" TS IN connector to plug in the instrument cable.
(7) The ¼" TS OUT connector sends the signal to your amp.
Use the DC IN connection to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V battery
(not included), press the hinges with a ballpoint pen and remove the pedal cover. Be careful not to
scratch the unit.
(2)
(7)
(3)
(5)
(6)
(1) (4)

COMPRESSOR/LIMITER CL9
◊ The CL9 has no on/o switch. As soon as you insert the plug into the in connector,
the CL9 is on. When not in use, remove the plug from the in connector. This extends
the life of the battery.
The SERIAL NUMBER is located at the underside.
2. Safety Instructions
Do not use near water, or install near heat sources. Use only authorized attachments/accessories.
Do not service product yourself. Contact our qualied servicing personnel for servicing or repairs,
especially when power supply cord or plug is damaged.
3. Warranty
Please register your new BEHRINGER equipment right after your purchase by visiting
http://behringer.com and read the terms and conditions of our warranty carefully.
4. Specications
In
Connector ¼" TS
Impedance 500 kΩ
Out
Connector ¼" TS
Impedance 1 kΩ
Power Supply
9 V𝌂, 100 mA regulated
BEHRINGER PSU-SB
USA/Canada 120 V~, 60 Hz
Europe/U.K./ 230 V~, 50 Hz
Australia
China 220 V~, 50 Hz
Korea 220 V~, 60 Hz
Japan 100 V~, 50/60 Hz
Power connector 2 mm DC jack,
negative center
Battery 9 V type 6LR61
Power consumption 30 mA
Physical/Weight
Dimensions approx. 2 ⁄ x 2 ¾ x 4 ⁄"
(H x W x D) approx. 54 x 70 x 123 mm
Weight approx. 0.73 lbs / 0.33 kg
BEHRINGER is constantly striving to maintain the
highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing
products without prior notice. Specifications and appearance
may therefore differ from those listed or shown.
