Behringer Warp Distortion WD300 User manual

WARP DISTORTION WD300
Ultimate Warp Distortion Eects Pedal
Thank you for showing your condence in us by purchasing the BEHRINGER WARP DISTORTION WD300.
This high-quality eects pedal enables you to produce super thick, tube-like distortion plus
endless sustain. Thanks to its high-performance features you can achieve the typical hard rock
or heavy metal distortion sounds.
1. Controls
(1) The SUB switch activates a low-frequency boost at around 90 Hz to simulate the resonance
frequency of a 4 x 12" cabinet.
◊ CAUTION: The SUB lter is not suitable for all speakers and combos!
(2) The LEVEL control adjusts the output level.
(3) The WARP control adjusts the mid-frequency range. It boosts the mids from 250 Hz to 1 kHz at
minimum position. In maximum position it cuts mids at 500 Hz with a presence boost at 3 kHz.
(4) The GAIN control adjusts the input sensitivity and the amount of resulting distortion.
(5) The ON/BATT LED illuminates when the eect is activated. It also serves as a battery
level indicator.
(6) Use the footswitch to activate/deactivate the eect.
(7) Use this ¼" TS IN connector to plug in the instrument cable.
(8) The ¼" TS OUT connector sends the signal to your amp.
Use the DC IN connection to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V battery
(not included), press the hinges with a ballpoint pen and remove the pedal cover. Be careful not to
scratch the unit.
(5)
(1)
(7)
(4)
(6)
(3)(2)
(8)

WARP DISTORTION WD300
TECHNICAL SPECIFICATIONS AND APPEARANCES ARE SUBJECT TO CHANGEWITHOUT NOTICE AND ACCURACY IS NOT GUARANTEED. BEHRINGER IS PART OF THE
MUSIC GROUP (MUSIC-GROUP.COM). ALLTRADEMARKS ARE THE PROPERTY OFTHEIR RESPECTIVE OWNERS. MUSICGROUP ACCEPTS NO LIABILITY FOR ANY LOSS
WHICH MAY BE SUFFERED BY ANY PERSONWHO RELIES EITHER WHOLLY OR IN PART UPON ANY DESCRIPTION, PHOTOGRAPH OR STATEMENT CONTAINED HEREIN.
COLORS AND SPECIFICATIONS MAY VARY FROM ACTUAL PRODUCT. MUSIC GROUP PRODUCTS ARE SOLD THROUGH AUTHORIZED FULLFILLERS AND RESELLERS
ONLY. FULLFILLERSAND RESELLERS ARE NOT AGENTS OF MUSICGROUP AND HAVE ABSOLUTELY NO AUTHORITY TO BIND MUSICGROUP BY ANY EXPRESS OR
IMPLIED UNDERTAKING OR REPRESENTATION.THIS MANUAL IS COPYRIGHTED. NO PART OFTHIS MANUAL MAY BE REPRODUCED ORTRANSMITTED IN ANY FORM
OR BY ANY MEANS, ELECTRONIC OR MECHANICAL, INCLUDING PHOTOCOPYING AND RECORDING OF ANY KIND, FOR ANY PURPOSE,WITHOUT THE EXPRESS
WRITTEN PERMISSION OF MUSICGROUPIPLTD. ALL RIGHTS RESERVED. © 2012 MUSICGroupIPLtd.Trident Chambers,Wickhams Cay, P.O. Box 146, RoadTown,
Tortola, British Virgin Islands
◊ The WD300 has no on/o switch. As soon as you insert the plug into the in connector,
the WD300 is on. When not in use, remove the plug from the in connector. This extends
the life of the battery.
The SERIAL NUMBER is located at the underside.
2. Safety Instructions
Do not use near water, or install near heat sources. Use only authorized attachments/accessories.
Do not service product yourself. Contact our qualied servicing personnel for servicing or repairs,
especially when power supply cord or plug is damaged.
3. Warranty
Please register your new BEHRINGER equipment right after your purchase by visiting http://behringer.com
and read the terms and conditions of our warranty carefully.
4. Specications
In
Connector ¼" TS
Impedance 500 kΩ
Out
Connector ¼" TS
Impedance 1 kΩ
Power Supply
9 V𝌂, 100 mA regulated
BEHRINGER PSU-SB
USA/Canada 120 V~, 60 Hz
Europe/U.K./ 230 V~, 50 Hz
Australia
China 220 V~, 50 Hz
Korea 220 V~, 60 Hz
Japan 100 V~, 50/60 Hz
Power connector 2 mm DC jack,
negative center
Battery 9 V type 6LR61
Power consumption 30 mA
Physical/Weight
Dimensions approx. 2 ⁄ x 2 ¾ x 4 ⁄"
(H x W x D) approx. 54 x 70 x 123 mm
Weight approx. 0.73 lbs / 0.33 kg
BEHRINGER is constantly striving to maintain the
highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing
products without prior notice. Specifications and appearance
may therefore differ from those listed or shown.
