Beko DDT28410X User manual

www.beko.com.tr
DDT28410X
USA
Document Number :
Dishwasher
User manual
15 0619 01 00_AA_BEKO_E5_USA/ 10-03-16.(9:53)

To prevent accidents, which could cause serious injury or death, as well
as machine damage read these instructions before installation and / or
use.
CONTENTS
1. IMPORTANT SAFETY INSTRUCTIONS 1
2. INSTALLATION 4
3. GETTING TO KNOW YOUR DISHWASHER 5
4. LOADING THE DISHWASHER 6
4.1 UPPER RACK 8
4.2 LOWER RACK 11
4.3 PROPER AND IMPROPER LOADING OF DISHWARE 15
5. WHAT SHOULD NOT BE WASHED IN YOUR DISHWASHER 16
6. OPERATING THE PRODUCT 17
6.1 KEYS 17
6.2 PREPARING THE MACHINE 18
6.3 PROGRAMME SELECTION 18
6.4 AUXILIARY FUNCTIONS 20
6.5 PROGRAMMING THE WASHING TIME 22
6.7 CHILD (KEY) LOCK 23
6.8 CANCELLING THE PROGRAMME 23
6.11 END OF PROGRAMME 24
6.12 WATER CUT-OFF WARNING 24
6.13 OVERFLOWING WARNING 24
7. DETERGENT & RINSE AID DISPENSER 25
7.1 FILLING THE DETERGENT DISPENSER 25
7.2 FILLING RINSE AID DISPENSER 26
7.3 SET THE DOSE OF RINSE AID 27
8. SETTING THE WATER SOFTENER 28
WATER HARDNESS & REGENERATION SETTINGS 28
9. FILLING THE DISHWASHER SALT DISPENSER 29
10. CARE AND MAINTENANCE 30
10.1 CARING FOR YOUR DISHWASHER EXTERIOR 31
10.2 CARING FOR YOUR DISHWASHER INTERIOR 31
10.3 CLEANING THE FILTERS 32
10.4 CLEANING THE HOSE FILTER 33
10.5 CLEANING THE IMPELLERS 33
11. TROUBLESHOOTING 35
12. TECHNICAL FEATURES 40
13. WARRANTY STATEMENT FOR THE BEKO DISHWASHERS 41

1USA
INTRODUCTION
Please read this user manual and
particularly the safety instructions
completely and carefully. They will save
you time and effort and help to ensure
optimum dishwasher performance.
Be sure to observe all listed warnings
and cautions. Look particularly for the
icons with exclamation marks inside. The
information icon will also provide important
references.
AWARNING:
Indicates a
potentially hazardous situation
which, if not avoided, could
result in death or serious injury.
ACAUTION:
Indicates a
potentially hazardous situation
which, if not avoided, may result
in injury. It may also be used to
alert against unsafe practices.
CNOTICE:
Indicates a
potentially hazardous situation
which, if not avoided, may result
in damage to the dishwasher,
the table-ware, the equipment
or the environment.
1. IMPORTANT SAFETY
INSTRUCTIONS
AWARNING:
When using
the dishwasher, follow basic
precautions, including the
following:
Read all instructions before
using the dishwasher! Save
these operating instructions
and pass them on to any future
user.
•Use the dishwasher only for its
intended purpose as described in
this user manual. This appliance is
intended for normal household use
only.
• The manufacturer disclaims
responsibility for damage or
injury caused by improper use
of this appliance.
•The information in this user manual
must be followed to minimize the risk
of fire or explosion and to prevent
property damage, personal injury or
loss of life.
•Do not operate your dishwasher
unless all the enclosure panels are
properly in place.
•Do not tamper with the controls.
•Do not abuse, sit on, stand in or on the
door or dish rack of the dishwasher.
•The cup racks are designed to support
cups, glasses and kitchen utensils.
When the cup racks are in the
dishwasher do not lean on or use the
cup racks to support your body weight.
•To reduce the risk of injury, do not
allow children to play in, on or near the
dishwasher.

2USA
•Use only detergents or rinse aids
recommended for use in a household
dishwasher and keep them in a dry
place out of the reach of children.
Check that the detergent dispenser
is empty after the completion of each
wash program.
•Dishwasher detergents are alkaline.
They can be dangerous if inhaled or
swallowed. Avoid contact with skin
and eyes and keep children and infirm
persons away from the dishwasher
when the door is opened. Consult a
doctor immediately if detergent has
been swallowed or inhaled.
•Do not drink water from the
dishwasher! Harmful residues could be
present.
•Under certain conditions hydrogen gas
may be produced in a hot water heater
system that has not been used for
two weeks or more. Hydrogen gas is
explosive. If the hot water system has
not been used for such period, before
using the dishwasher turn on all hot
water taps and let the water flow from
each for several minutes. This will
release any accumulated hydrogen
gas. As gas is flammable, do not smoke
or use an open flame during this time.
•Do not store or use flammable
liquids or vapors in the area of the
dishwasher.
•When loading items to be washed,
position sharp items so that they are
not likely to damage the door seal and
load sharp knives with the handles up
to reduce the risk of cut-type injuries.
•Do not wash plastic items unless they
are marked “dishwasher safe” or the
equivalent. For plastic items not so
marked, check the manufacturer’s
recommendations.
•If a malfunction occurs, switch off
the appliance and turn off the water
supply to the dishwasher.
•Please do not attempt to carry the
dishwasher by yourself in order
to avoid potential injuries. Two or
more people are needed to move a
dishwasher.
•Before cleaning or carrying out
maintenance, switch off the
appliance, disconnect the power plug
and turn off the water supply.
•Repairs and technical modifications
must be carried out exclusively by a
qualified technician.
•If the dishwasher is not in use for an
extended period of time (i.e. vacation
home), we recommend you check
that the baskets are empty, leave the
inside of the dishwasher clean, leave
the door cracked open to allow air to
circulate and turn off both the power
and water supply to the dishwasher.
•This appliance must be grounded.
In the event of a malfunction or
breakdown, grounding will reduce
the risk of electric shock by providing
a path of least resistance for electric
current. This appliance is equipped
with a cord having an equipment-
grounding conductor and a grounding
plug. The plug must be plugged into an
appropriate outlet that is installed and
grounded in accordance with all local
codes and ordinances.
•Potential hazards exist if any
equipment uses electricity, water and
moving parts.
•This appliance must be connected to
a grounded metal, permanent wiring
system, or an equipment-grounding
conductor must be run with the circuit
conductors and connected to the
equipment-grounding terminal or lead
on the appliance.
•This appliance produces ozone
within the washing compartment

3USA
during normal operation. Long-term
exposure to ozone or exposure
at elevated levels may result in
respiratory problems, especially for
the infirmed, elderly and children.
•It is the legal responsibility of parents/
legal guardians to supervise or instruct
concerning use of the machine when
the children become old enough to
operate.
•Do not leave the door open in order
not to cause a tripping hazard.
•Remove the door to the washing
compartment when removing an old
dishwasher from service or discarding
it. Ensure that the appliance presents
no danger to children while being
stored for disposal.
•Remove the door lock or door of
the washing compartment before
disposing dishwasher so that children
or small animals can not trapped
inside.
•Old appliances may contain materials
that can be recycled. Please contact
your local recycling authority about
the possibility of recycling these
materials.
•Please check the water supply line
periodically. It is susceptible to
breakage. It becomes less flexible as
time goes by.Replace it immediately
when it is torn, cut, swollen or there is
water leakage.
•Please keep the dishwasher package
out of the reach of children after
unpacking it.
AWARNING:
If your dishwasher
is equipped with internal
illumination, lamp should only
be replaced by the Authorised
Service Agent in case of failures
that may occur on the lamp.
AWARNING:
Improper
connection of the equipment-
grounding conductor can result
in a risk of electric shock. Check
with a qualified electrician
or service representative if
you are in doubt whether the
appliance is properly grounded.
Do not modify the plug provided
with the appliance, if it will not
fit the outlet, have a proper
outlet installed by a qualified
electrician.
AWARNING:
Warning: This
product may contain chemicals
known to the state of California
to cause cancer or birth defects
or other reproductive harm.
SAVE THESE INSTRUCTIONS

4USA
2. INSTALLATION
AWARNING:
When installing
the dishwasher, follow basic
precautions, including the
following:
•Please check the standarts and local
codes for placement of machine.
•Installation, maintenance and repair
should be performed by a qualified
installer. Work by unqualified persons
could be dangerous and may void the
warranty.
•Do not operate the appliance if
damaged, malfunctioning, partially
disassembled or if it has missing or
broken parts.
•Before installation or service,
disconnect the power supply to
the work area by unplugging the
unit, “tripping” the circuit breaker or
removing the fuse.
•Only connect the dishwasher to the
power supply when all installation and
plumbing work is complete.
•Never connect the ground wire to gas
lines, or hot water pipes, plumbing
lines.
•Do not install or store the dishwasher
where it can be exposed to below
freezing temperatures or exposed to
weather.
•Dishwasher must be secured to
adjacent cabinetry using the brackets
provided. Failure to do this may cause
damage to property or bodily injury.
•Connect to a properly rated, protected
and sized power supply circuit to avoid
electrical overload. The dishwasher
is designed for an electrical supply
of 120 V (volts), 60 Hz (hertz), AC,
connected to a dishwasher-dedicated,
properly grounded electrical circuit
with a fuse or breakers rated for 15
amperes. Electrical supply conductors
shall be a minimum of # 16 AWG
copper wire rated at 75 °C (167 °F) or
higher. These requirements must be
met to prevent injury and machine
damage. Consult a qualified electrician
if in doubt.
•Do not use any extension cord or
portable outlet device to connect the
dishwasher to a power supply.
AWARNING:
Danger of
suffocation! Ensure that any
plastic wrappings, bags, small
pieces etc. are disposed of
safely and kept out of the reach
of children.

5USA
1. Upper rack
2. Upper spray arm
3. Salt container (MODEL DEPENDING)
4. Cutlery basket
5. Detergent dispenser
6. Door
7. Control panel
8. Guiding track for the upper rack
9. Lower spray arm
10. Filters
11. Lower rack
12. Model and Serial Tag
13. Turbo fan heat drying system (MODEL DEPENDING)
14. Removable 3rd basket (MODEL DEPENDING)
15. Additional upper spray arm (MODEL DEPENDING)
3. GETTING TO KNOW YOUR DISHWASHER
13

6USA
4. LOADING THE
DISHWASHER
1. Pull the handle to open the door. If the
door is opened during operation, the
dishwasher will stop running. Once
the door is closed the program will
continue.
Upper rack (MODEL DEPENDING)
Top rack load pattern for 12 place settings
according to the AHAM DW-1 Standards
ACAUTION:
Hot steam can
escape! Danger of serious burns
or other injury.
2. Remove coarse food leftovers from
tableware.
3. Now you can load the dishwasher.
Lower rack (MODEL DEPENDING)
Bottom rack load pattern for 12 place
settings according to the AHAM DW-1
Standards
Upper rack (MODEL DEPENDING)
International Loading Pattern – Top rack
(14 place settings)
ACAUTION:
Hot steam can
escape! Danger of serious burns
or other injury.
2. Remove coarse food leftovers from
tableware.
3. Now you can load the dishwasher.

7USA
Lower rack (MODEL DEPENDING)
International Loading Pattern – Bottom
rack (14 place settings)
Upper rack (MODEL DEPENDING)
Additional Loading Pattern – Top rack (10
place settings)
ACAUTION:
Hot steam can
escape! Danger of serious burns
or other injury.
2. Remove coarse food leftovers from
tableware.
3. Now you can load the dishwasher.
Lower rack (MODEL DEPENDING)
Additional Loading Pattern – Bottom rack
(10 place settings)
ACAUTION:
Large knives and
other utensils with sharp tips
and edges must be placed
horizontally into the upper
rack due to risk of injury. Other
smaller knives and sharp
utensils should be placed with
sharp side down in the cutlery
basket.
ACAUTION:
Use extreme
caution when removing knives
and other sharp utensils from
the dishwasher. These items
may have shifted position
during the wash program, and
may be wet or slippery.

8USA
ACAUTION:
The cup racks
are designed to support cups,
glasses and kitchen utensils.
When the cup racks are in the
dishwasher do not lean on or
use the cup racks to support
your body weight.
CNOTICE:
3rd basket should be
removed out of the dishwasher
during the tests according to
AHAM DW-1.
•Your dishwasher holds a maximum of 12
place settings.
•Place all containers such as cups, glasses
and pots into the dishwasher with the
opening facing downwards (so that no
water can collect).
•Small and light items can go into the
upper rack.
•Long and narrow items are placed in the
middle of the racks.
•Place all large and very dirty items in the
lower rack.
•Dishes and cutlery should not be placed
above each other.
•Glasses should not touch each other.
•The movement of the spray arms must
not be hindered.
•Do not overload your dishwasher and pay
attention to manufacturer instructions
regarding dishes which are appropriate
for use in for a dishwasher. Only with
suitable dishes (mentioned in section 5)
will you obtain optimal washing results
with a sensible use of energy.
4.1 UPPER RACK
Load the upper rack with dessert plates,
cups, glasses etc.
ADJUSTABLE SHELVES (MODEL
DEPENDING)
Depending on the size of the glasses and
cups, the shelf height setting may be
adjusted.
1. Fold the shelf upwards A .
2. Positioning at the desired height B .
3. Fold the shelf again downwards C .

9USA
COLLAPSABLE UPPER BASKET
TINES
(MODEL DEPENDING)
Upper basket of the machine is equipped
with wires with gradual folding system (A)
that you can lay down when you need a
larger space for large dishes.
To bring the collapsible wires into
horizontal position, grab the wire from mid
position and push them in the directions
of arrows. Place your larger dishes into
the area created. To bring the wires back
to vertical position, just lift them up.
Collapsible wires will click into the latch
again.
CNOTICE:
Bringing the wires
to the horizontal position by
holding them from the tips may
cause them to bend. Therefore,
it will be appropriate to bring
the wires in the middle to
horizontal or vertical position by
holding them from their stems
and pushing in the direction of
arrow.
COLLAPSIBLE UPPER BASKET
TINES
(MODEL DEPENDING)
There are foldable tines on the upper
basket of the machine that you can lay
down when you need larger space for big
dishes. On your upper basket there are
two types of laying tines namely, fully laid
system (A) and gradually laid system (B).
To bring the foldable tines into horizontal
position, push the tines in the direction of
the arrow by holding from the middle. Place
your larger dishes into the area created. To
bring the tines back to vertical position, just
lift them up. Foldable tines will then snap in
the latch again.
CNOTICE:
Bringing the wires
to the horizontal position by
holding them from the tips may
cause them to bend. Therefore,
it will be appropriate to bring
the wires in the middle to
horizontal or vertical position by
holding them from their stems
and pushing in the direction of
arrow.

10 USA
FOLDING TINES
(MODEL DEPENDING)
There are “folding tines” in the upper rack
to allow you more space to accommodate
glasses or cups.
Simply pull in the first front folding tine,
move it to left A and right B to place in
another positon. When you need, take the
tines down until the tines fall down.




LOWER UPPER RACK
1. To lower the upper rack, hold and
press in the rack lever on one side
and carefully lower the rack without
releasing the lever B .


2. Repeat the procedure with the lever
on the opposite side of the rack.
CNOTICE:
Make sure that both
levers catch in the same height
position.
VARIABLE HEIGHT SETTING
(MODEL DEPENDING)
The upper rack is equipped with a lifting
mechanism which enables you to change
the height of the rack even if it is fully
loaded, and without having to remove it
from the dishwasher.
LIFT UPPER RACK
1. To lift the upper rack to a higher
position, hold it on one side and
carefully pull it upwards A .
2. To lift the opposite side of the rack,
hold it and pull it upwards in the same
manner.

11 USA
HEIGHT SETTING
(MODEL DEPENDING)
In certain models, the height setting of
the upper rack may be changed using the
wheels which are present at two height
levels.
ACAUTION:
Make sure that
the rack is empty. Changing
the height setting while the
rack contains tableware could
cause the contents to dislodge,
causing personal injury or
damage to the tableware.
1. Release the latches on both the right
and left tracks of the upper rack by
turning them to the outside A.
2. Pull out the rack completely B .
3. Place the rack into the tracks again at
the desired height C .
4. Push the latches back into the correct
position.
4.2 LOWER RACK
Use the lower rack for plates, bowls, pots
etc.

12 USA
FOUR FOLDING PLATE SUPPORT
TINES (MODEL DEPENDING)
There are 4 separate “folding plate support
tines” in the lower rack of your dishwasher
designed to allow you more space to
accommodate saucepans, pots and large
bowls in the lower rack. You can either fold
each section ( 1 , 2 , 3 , 4 ). individually or, all
at once, to create a large empty space.
Simply press the handgrips A and fold them
down. Pull tines up to fold them up again.
COLLAPSABLE LOWER BASKET
WIRES 4 PIECES-(MODEL
DEPENDING)
The four piece foldable wires located at the
lower basket of the machine are designed
for an easier placement of large pieces
such as pans, bowls, etc. (1, 2, 3, 4) . You
can create larger spaces by folding each
wire individually or all of them at once. Lay
the foldable wires down by pressing on the
latch (A) .

13 USA
SILVERWARE BASKET
(MODEL DEPENDING)
Silverware basket is designed to wash your
dishes such as knife, fork, spoon, etc. in a
cleaner manner.
Since the cutlery basket can be moved
(A, B), you can create a wider space while
placing your dishes to the lower basket and
free up space for your dishes in different
sizes.
CNOTICE:
When finished, test
to ensure that the spray arm can
still move freely.
To bring the collapsible wires into
horizontal position, grab the wire from mid
position and push them in the directions
of arrows (B) To bring the wires back
to vertical position, just lift them up.
Collapsible wires will click into the latch
again.
CNOTICE:
Bringing the wires
to the horizontal position
byholding them from the tips
may cause them to bend.
Therefore, it will be appropriate
to bring the wires in the
middle to horizontal or vertical
position by holding them from
their stems and pushing in the
direction of arrow..
COLLAPSABLE LOWER BASKET
WIRES 6 PIECES-(MODEL
DEPENDING)
The foldable wires (A) located at the lower
basket of the machine are designed for
an easier placement of large pieces such
as pans, bowls, etc. You can create larger
spaces by folding each wire individually or
all them at once.

14 USA
UPPER CUTLERY BASKET
(MODEL DEPENDING)
The upper cutlery basket is designed for
small dishes, or long items that cannot fit
into the lower cutlery basket.
Thanks to the easy take-out-from-the-
machine feature, it allows taking out the
dishes from the machine together with the
basket after they are washed (A). Since
it can fit into all standard size drawers, it
does not require the dishes to be removed
from the basket and placed into the kitchen
drawers or shelves.

If you don’t want to use the upper cutlery
basket, pull it back to yourself to remove
it from the machine, rotate the rail lids
towards outside and pull them towards
yourself to take them out (B).



After taking out the basket by lifting it up,
remove the carrier part from the rails by
pulling it towards yourself (C).

Replace the rail lids and push them back to
seat them into their places. Turn the rails
inside the machine sideways to seat them
properly in their places (D).



In order to replace the upper cutlery basket
into its place again, repeat the same
process in reverse order.

15 USA
6
5
5
4
44444
33
3
33
3
222
2
2
2
2
2
2 2
2
2
2
2
2
2
2
2
2
2
22
1
1
1
1
1
111
1
1
1
1
44 44 4
32 432
3333
4.3 PROPER AND IMPROPER LOADING OF DISHWARE
1: Salad Fork
2: Teaspoon
3: Dinner fork
4: Knife-solid handle
5: Serving spoon
6: Serving fork
Sliding Cutlery Basket load pattern for 12 place
settings according to the AHAM DW-1 Standards
•Place all large and very dirty items in the lower
rack.
•Place all containers such as cups, glasses and pots into the dishwasher with the opening
facing downwards (so that no water can collect).
•The movement of the spray arms must not be hindered.
•Do not overload your dishwasher. Dishes and cutlery should not be placed above each
other. Glasses should not touch.
•Only with suitable dishes (mentioned in section 5) will you obtain optimal washing
results with a sensible use of energy.
incorrect incorrect
incorrect incorrect

16 USA
5. WHAT SHOULD NOT
BE WASHED IN YOUR
DISHWASHER
•Rust-sensitive steel parts like iron
and cast iron that can rust and stain
other utensils and damage the interior
stainless steel liner of the dishwasher
and void the warranty. Do not wash
copper, brass, pewter, bronze or tin.
•Cutlery with wooden or horn handles
and cutlery with mother-of-pearl or
porcelain handles will deteriorate over
time if put in the dishwasher.
•Plastics may lose their shape or color
with hot water, please follow the
instructions of plastic manufacturers.
Be sure that plastic items are marked
“dishwasher safe”.
•Glued dishes or cutlery are not
suitable for machine washing since
certain adhesives may get soft or
dissolve with hot water.
•Aluminum may fade over time.
Minerals in water and detergent may
cause the aluminum to darken or spot.
•Sterling silver articles should not be
washed in the dishwasher because
they tend to discolor and become dull
by dishwasher detergent.
•Silverware and stainless steel items
should not be in contact with each
other. Mixing these items can cause
staining. Remove and hand dry these
items immediately when the program
ends.
•Decorated glasses, porcelain, fine
china and china with gold rims are
sensitive to machine washing. They
may lose their patterns and colors
over time.
•Crystal and very fine glassware may
become opaque (etch) losing their
shine over time. You may prefer to
wash them by hand.
•Do not wash sponges or dish cloths in
dishwasher.
•Do not wash art and craft articles in
dishwasher.
•Disposable plastics and disposable
aluminum cannot withstand high
temperatures; do not wash them in
the dishwasher.
ACAUTION :
If in doubt, wash by
hand or follow the instructions
from the manufacturer of
utensils, dishes, glasses or pots
and pans.
Do not wash items soiled with
cigarette ash, candle wax,
varnish, paints or chemicals
since they can damage your
dishwasher.
CNOTICE:
We recommend
when buying new dishware, try
to choose ones that are suitable
for machine washing (marked as
dishwasher safe).
CARING FOR YOUR TABLE-WARE
The combination of high temperatures and
dishwasher detergent may cause damage
to some items if they are washed in the
dishwasher. Remember, if there is any
doubt about any aspect concerning items
to be washed in the dishwasher, follow the
instructions from the manufacturer of the
items, or wash the items by hand.

17 USA
6. OPERATİNG THE PRODUCT
CNOTICE:
If you do not perform any operation after switching on the machine,
it will be automatically switched off within 5 seconds.
F1
F2
F3
F4
Cancel 3”
1
10
2 4 5 6 7 8
111213
3 3 9
1. On/Off key
2. Programme Selection / Programme
Cancel (3 seconds) key
3. Function keys & indicators
F1
F2
F3
F4
4. Programme indicator
5. Salt indicator (MODEL DEPENDING)
6.
7. Start / Cancel indicator
8. Time Delay / Programme Time indicator
9. Time Delay key
10. Time Delay indicator
11. End of Programme indicator
12.
13. Rinse Aid indicator
6.1 KEYS
On/Off key
When you press On / Off key, indicator lights illuminate on the display for ON position. The
lights turn off in OFF position.
Programme Selecton / Programme Cancel key
Press this key until the desired programme appears in the programme indicator.
To cancel the running programme open the door of the product. Press and hold the
Programme Selection / Programme Cancel keys for 3 seconds. After the 3 - 2 - 1
countdown, 0:01 is displayed, close the door of the product and wait for the draining
process complete. Draining is completed in 2 minutes and the machine gives an audible
warning when it is completed.
Half Load Function
SteamGloss Function
Sanitize Function
Sanitized indicator
AquaIntense Function
(Not in use)

18 USA
Functon keys
If you press any of the Function keys
during programme selection or time delay
selection, an affirmative key signal will be
heard provided that the relevant function
is supported by the selected programme.
Function will be deemed selected when the
indicator of the selected function is lit.
To cancel the selected function, keep the
function key pressed until the function
indicator disappears.
6.2 PREPARİNG THE
MACHİNE
1. Open the door of the dishwasher.
2. Place the dishes in accordance with the
instructions in the user manual.
3. Make sure that the upper and lower
impellers rotate freely.
4. Put adequate amount of detergent
into the detergent dispenser.
6.3 PROGRAMME
SELECTİON
1. Press the On/Off button to turn on
your machine.
2. Check the Salt and Rinse Aid indicators
and add salt and/or rinse aid if needed.
3. Refer to the table of “Programme data
and average consumption values”
to determine a washing programme
suitable for your dishes.
4. Selected programme will start when
you close the door of your machine.
