INTRODUCTION 1
1. IMPORTANT SAFETY INSTRUCTIONS 1
1.1 INSPECT THE DISHWASHER 2
2. TOOLS WHICH MAY BE NEEDED 3
3. MATERIALS WHICH MAY BE NEEDED 3
4. MATERIALS SUPPLIED 4
4.1 PARTS SUPPLIED 4
4.2 MANUAL BAG 4
4.3 DISHWASHER PARTS BAG 1 4
4.4 DISHWASHER PARTS BAG 2 4
4.5 PARTS ATTACHED TO THE REAR OF THE DISHWASHER 4
5. DISHWASHER SPECIFICATIONS 5
5.1 TECHNICAL FEATURES 5
6. ENCLOSURE PREPARATION 6
6.1 ELECTRICAL PREPARATION 6
6.2 PREPARATION FOR INSTALLING MOUNTING BRACKETS 6
6.3 ADJUSTING HEIGHT 6
6.4 PREPARING THE WATER CONNECTION (A) 9
6.5 DRAIN PREPARATION 10
6.7 STEAM PROTECTION FOIL 11
7. PLACEMENT OF DISHWASHER INTO THE OPENING 12
7.1 DRAIN HOSE CONNECTION, WATER SUPPLY & ELECTRICAL CONNECTIONS 12
7.2 ELECTRICAL CONNECTION 14
7.3 READJUSTING FOOT LEVELS 15
7.4 ADJUSTING THE MOVABLE TOE KICK 15
7.5 INSTALLING THE OUTER DOOR 17
8. INSTALLER CHECKLIST 22
9. FINAL INSTRUCTIONS 22
10. SELF HELP HINTS: 22
To prevent accidents, which could cause serious injury or death, as well as
machine damage read these instructions before installation and / or use.
1USA
INTRODUCTION
Please read ths nstallaton manual
and partcularly the safety nstructons
completely and carefully. They wll save you
tme and effort and help to ensure optmum
dshwasher performance.
Be sure to observe all lsted warnngs and
cautons. Look partcularly for the cons wth
exclamaton marks nsde. The nformaton
con also wll provde mportant references.
WARNING:
Indcates a potentally hazardous stuaton
whch, f not avoded, could result n death
or serous njury.
CAUTION:
Indcates a potentally hazardous stuaton
whch, f not avoded, may result n njury.
It may also be used to alert aganst unsafe
practces.
Notice:
Indcates a potentally hazardous stuaton
whch, f not avoded, may result n damage
to the dshwasher, the table-ware, the
equpment or the envronment.
1. IMPORTANT SAFETY
INSTRUCTIONS
In addton to these nstructons, the
dshwasher shall be nstalled:
•In accordance wth all local codes or, n
absence of a local code,
•In the Unted States, wth the Natonal
Electrc Code,
•In Canada, wth the Canadan Electrc
Code C22.1-latest edton/Provncal
and Muncpal codes and/or local codes.
NOTICE :
Read these nstallaton nstructons
completely before nstallng and follow
them carefully. Save these nstallaton
nstructons and pass them on to any
future user.
WARNING
When installing the dishwasher,
follow basic precautions, including
the following:
•The dshwasher could only be
converted from cord-connected
to permanently connected by an
authorzed servce representatve.
(If needed contact your dealer to
schedule an authorzed servce agent
for converson wth an approprate
converson kt)
•Installaton and repar should be
performed by a qualfed nstaller.
Work by unqualfed persons could be
dangerous and may vod the warranty.
NOTICE :
The dshwasher should be nstalled by an
nsured lcensed plumber, contractor or
traned nstaller. Installaton performed
by persons other than ths could result n
mproper nstallaton and property damage.
•Do not operate the applance f
damaged, malfunctonng, partally
dsassembled or f t has mssng or
broken parts.
•Also follow the safety nstructons of
the user manual.
•To reduce the rsk of electrc shock,
fre, or njury to persons, the nstaller
must ensure that the dshwasher s
completely enclosed at the tme of
nstallaton.
2USA
•Only connect the dshwasher to the
power supply when all nstallaton and
plumbng work s complete.
•If the dshwasher s nstalled n a
locaton that experences freezng
temperatures (e.g. n a vacaton home,
cabn, etc.), you must dran all the
water from the dshwasher’s nteror.
Water system ruptures that occur as
a result of freezng are not covered by
warranty.
•Dshwasher must be secured to
adjacent cabnetry usng the brackets
provded. Falure to do ths may cause
damage to property or bodly njury.
•Connect to a properly rated, protected
and szed power supply crcut to avod
electrcal overload. The dshwasher
s desgned for an electrcal supply
of 120 V (volts), 60 Hz (hertz), AC,
connected to a dshwasher-dedcated,
properly grounded electrcal crcut
wth a fuse or breakers rated for 15
amperes. Electrcal supply conductors
shall be a mnmum of # 16 AWG
copper wre rated at 75 °C (167 °F) or
hgher. These requrements must be
met to prevent njury and machne
damage. Consult a qualfed electrcan
f n doubt.
•Do not use any extenson cord or
portable outlet devce to connect the
dshwasher to a power supply.
•Ensure that any plastc wrappngs,
bags, small peces etc. are dsposed
of safely and kept out of the reach of
chldren. Danger of suffocaton!
•Remove the door to the washng
compartment when removng an old
dshwasher from servce or dscardng
t. Ensure that the applance presents
no danger to chldren whle beng
stored for dsposal.
•Old applances may contan materals
that can be recycled. Please contact
your local recyclng authorty about
the possblty of recyclng these
materals.
NOTICE :
•The dshwasher dran hose must be
nstalled wth a dran loop at least
28” (710mm) off the cabnet floor;
otherwse the dshwasher may not
dran properly.
•Ths dshwasher s ntended for
resdental use only, and should not be
used n commercal establshments.
•New nstallaton - If the dshwasher s
a new nstallaton, most of the work
must be done before the dshwasher
s moved nto place.
•Replacement - If the dshwasher s
replacng another dshwasher, check
the exstng dshwasher connectons
for compatblty wth the new
dshwasher, and replace parts as
necessary.
1.1 INSPECT THE DISHWASHER
After unpackng the dshwasher and pror
to nstallaton, thoroughly nspect the
dshwasher for possble freght or cosmetc
damage. Report any damage mmedately.
NOTICE :
•Cosmetc defects must be reported
wthn 10 days of nstallaton.
•Do not dscard any bags or tems that
come wth the orgnal package untl
after the entre nstallaton has been
completed.
3USA
2. TOOLS WHICH MAY BE NEEDED
3. MATERIALS WHICH MAY BE NEEDED
(Addtonal materals may be requred to comply wth local codes)
Hot Water Supply Lne - Mnmum 3/8” O.D. copper tubng or metal braded
dshwasher supply lne.
UL lsted condut connector or stran relef.
Teflon tape or other ppe thread compound to seal plumbng connectons.
Shut-off valve and fttngs approprate for hot water supply lne (copper
tubng/compresson fttng, or braded hose).
Slcone
Glue
4USA
4. MATERIALS SUPPLIED
4.1 PARTS SUPPLIED
Parts for your dshwasher wll
come n several plastc bags.
Check your parts bags shown
to make sure you have all the
parts as lsted to the left.
4.2 MANUAL BAG
The dshwasher comes wth a
manual bag contanng:
•User manual,
•Installaton manual
4.3 DISHWASHER
PARTS BAG 1
Ths dshwasher bag comes
wth the followng parts:
a.
Sde Trm Strps (Left)
b.
Sde Trm Strps (Rght)
c.
Adjustng Wrench
d.
Screws Ø 1/8” x 5/8” (Ø
3.5mm x 14mm)
e.
Mountng Bracket Left
f.
Mountng Bracket Rght
g.
Sprng Clamp
h.
Screw Clamp
j.
Rubber Connector
k.
Toe Kck Bracket - Left
l.
Toe Kck Bracket – Rght
m.
Edge Protector
n.
Long Legs
o.
Toe Kck (toe kck wthout
slots)
p.
Toe Kck (MODEL
DEPENDING)
r.
Toe Kck
s.
Plastc Caps
t.
Screws Ø 3/16” x 1/4” (Ø
4mm x 6mm)
z.
Steam Protecton Fol
aa.
90° elbow wth 3/8” N.P.T.
male threads on one leg,
and szed to ft your water
supply lne (copper tubng/
compresson fttng, or braded
hose) on the other leg.
4.4 DISHWASHER
PARTS BAG 2
(MODEL DEPENDING)
In addton to the manual bag
and the dshwasher parts bag
(dshwasher models whch can
accept a wooden ktchen door)
also come wth a door panel
nstallaton kt whch contans:
v.
Screws Ø 1/8” x 5/8” (Ø
3.5mm x 14mm)
y.
Screws Ø 3/16” x 13/4” (Ø
4mm x 43mm)
4.5 PARTS ATTACHED
TO THE REAR OF THE
DISHWASHER
a.
Sde Trm Strps (Left)
b.
Sde Trm Strps (Rght)
o.
Toe Kck (toe kck wthout
slots)
p.
Toe Kck (MODEL
DEPENDING)
r.
Toe Kck
5USA
5. DISHWASHER SPECIFICATIONS
5.1 TECHNICAL FEATURES
Load capacity
8 place settngs
Permissible water
pressure
4.35 - 145 ps (0.3 - 10 bars)
Electrical connection
120 V (volts), 12 A (amps),
60 Hz (hertz)
Total power
1400 W (watts)
Heater power
1240 W (watts)
NOTİCE :
Because we contnually strve to mprove our products, we may change our specfcatons
and desgn wthout pror notce. Ths devce corresponds to the followng drectves:
UL 749 Household Dshwasher drectve.
6USA
6. ENCLOSURE PREPARATION
6.1 ELECTRICAL PREPARATION
WARNING
The dshwasher s desgned for an electrcal supply of 120 V, 60 Hz, AC, connected to a
dshwasher-dedcated, properly grounded electrcal crcut wth a fuse or breaker rated for 15
amperes.
6.2 PREPARATION FOR INSTALLING MOUNTING BRACKETS
WARNING
Dishwasher must be secured to
adjacent cabinetry using the mounting
brackets provided. Failure to do this
may cause damage to property or
bodily injury.
Place the two mountng brackets nto the
top corners of the dshwasher.
Bend sdes of mountng brackets (
A
) n
order to fx from sdes (f necessary).
NOTICE :
For these model, DIS25840,
note that
extra bendng should be done on the
brackets as shown.
6.3 ADJUSTING HEIGHT
Measure the heght of the
enclosure.
7USA
6.3.1 INSTALLING THE FOOT SUPPORTS
Suppled (
4
)
If the heght of the enclosure s 337/16” to
341/4” (850mm - 870mm) use short supports
as shown n the fgure.
Suppled (
4
)
If the heght of the enclosure s above
341/4” (870mm) use long supports as
shown n the fgure.
8USA
Adjust the front foot level wth the adjustng
wrench to balance and rase the dshwasher to
the enclosure heght.
Adjust the rear foot level wth a screwdrver
to balance and rase the dshwasher to the
enclosure heght.
NOTICE :
•Make sure the dshwasher s plumb and
notce dshwasher can be placed wth a
small clearance under the counter top.
•Turnng the screwdrver n the drecton of
the black arrows wll brng the dshwasher
back feet up.
•Turnng the screwdrver n the drecton of
the whte arrows wll take the dshwasher
rear feet down.
9USA
6.4 PREPARING THE WATER CONNECTION A
Install an easly accessble shut-off valve (not suppled) n the water supply lne. All solder
connectons must be made before the water lne s connected to the dshwasher’s water
nlet valve. Water can also be suppled to the dshwasher by usng a flexble braded hose
lne.
Check wth your plumbng supply sources for the proper hose and 90° elbow and necessary
fttngs for the water supply lne. Ths materal s not suppled, and must be purchased
separately.
WARNING
Installation should be performed by a qualified installer. Work by unqualified
persons could be dangerous and may void the warranty.
If the dishwasher is installed in a location that experiences freezing
temperatures (e.g. in a vacation home, cabin etc.), you must drain all the water
from the dishwasher’s interior. Water system ruptures that occur as a result of
freezing are not covered by warranty.
6.4.1 INSTALLING THE 90° ELBOW
FITTING (B)
CAUTION
Do not over tighten the 90° elbow. Doing
so may damage the water inlet valve and
cause a water leak.
If the water supply lne s to be copper tubng,
make certan that the elbow has a compresson
fttng. Apply Teflon tape or other ppe sealant
when requred. Orent the water supply
connecton downwards as shown n the fgure so
the water lne can be easly pulled underneath or
on the sde of the dshwasher.
10 USA
6.5 DRAIN PREPARATION
The dshwasher dran hose may be connected to the dran plumbng n one of three ways
(Fgure
A
,
B
,
C
).
NOTICE :
•Ether one of the above methods must be used or the dshwasher wll not operate
properly.
•A hose that attaches to a snk spray can burst f t s nstalled on the same water
lne as the dshwasher. If your snk has one, t s recommended that the hose be
dsconnected and the hole plugged.
•The total length of the dran hose s 763/4” (1950mm). If a hose extenson s requred,
a dranage hose of equal qualty must be used.
•The maxmum length must not exceed 157 ½” (4000mm). Otherwse, the cleanng
process s negatvely nfluenced.
6.5.1 UNDER THE SINK DRAIN
Install a Y-branch tal ppe. (Fgure
A
)
NOTICE :
You must add a loop at least 28” (710mm) above the floor of
the cabnet and above the dran connecton n the dran hose to
prevent waste water from not dranng properly, and causng
ether poor washng results or a bad odor.
6.5.2 INSTALLING AN AIR GAP
If the local ordnance requres an ar gap (Fgure
B
).
NOTICE :
Check wth local ordnance for type of ar gap requred.
6.5.3 DISPOSAL
Remove the dran connecton plug before attachng the dran
hose from the dshwasher.
Every dsposal has a hook up for a dshwasher; consult your
dsposer manual for correct connecton. (Fgure
C
)
11 USA
6.7 STEAM PROTECTION FOIL
Steam wll form nsde the dshwasher durng operaton. At the end of the cycle, when
the dshwasher door s opened, t s requred to use a steam protecton fol to prevent any
steam from collectng on the undersde of the counter top.
6.6.2 FITTING THE PROTECTION FOIL
Before applyng the steam protecton fol to the
undersde of the countertop, clean the area wth
a damp cloth (as shown n Fgure
A
). Once the
area dres, apply the steam protecton fol.
CAUTION
Steam protecton fol must be appled
where the steam escapes when door s frst
opened.
Failure to install the steam
protection foil during installation can
lead to damage to the cabinets and
countertop.
The steam protecton
fol wll be appled at the
locaton where the hot
steam escapes when you
frst open the door (as
shown n Fgure
B
).
12 USA
7. PLACEMENT OF DISHWASHER INTO THE OPENING
Now place the dshwasher nto the openng and get ready to connect all hoses and
electrcal connectons.
CAUTION
Make sure all hoses
are pulled through
the side opening of
the cabinet, no hoses
are kinked and all
slack is taken out as
shown in the above
figure.
7.1 DRAIN HOSE CONNECTION, WATER SUPPLY & ELECTRICAL
CONNECTIONS
7.1.1 DRAIN HOSE CONNECTION
Connect the dran hose to the dran plumbng.
1. Use the suppled rubber connecton hose and dran hose clamps to connect the
dshwasher dran hose to the plumbng dran connecton.
2. Use the sprng clamp to secure the rubber connecton hose to the dshwasher dran
hose. Use the screw clamp to secure the rubber connecton hose to the plumbng
dran connecton.
Note that the marks on the
rubber connecton hose
should be on the dran hose
sde
13 USA
7.1.2 WATER SUPPLY CONNECTION
Water supply may be connected to the dshwasher n
one of two ways:
•Wth metal braded hose.
•Wth copper tubng.
7.1.3 BRAIDED HOSE/COPPER TUBING
After connectons are made turn on the water supply
to check for leaks.
CAUTION
•Hot water supply lne: Use mnmum 3/8” O.D. copper tubng or metal braded
dshwasher supply lne.
•Temperatures requred for solderng and sweatng wll damage the dshwasher’s
water nlet valve so f any such operaton s needed, keep the heat source mn. 77/8”
(200mm) away from the dshwasher’s water nlet valve.
•There should not be any sharp bends n the water lne that may restrct the water
flow.
•Teflon tape or ppe tread compound must be used for sealng the connecton. Before
connectng the copper water supply lne to the dshwasher, flush t wth hot water to
clear any foregn materal.
NOTICE :
After connectons are made turn on the water supply to check for leaks.
14 USA
7.2 ELECTRICAL CONNECTION
WARNING
•
Make sure the voltage and frequency listed on the data plate correspond
with the household electrical supply. This data must correspond to prevent
injury and machine damage. Consult a qualified electrician if in doubt.
•
Only connect the dishwasher to the mains when all installation and
plumbing work is complete.
•
Do not use any extension cord or portable outlet device to connect the
dishwasher to a power supply.
•
The power-supply receptacle for the appliance shall be installed in a
cabinet or on a wall adjacent to the undercounter space in which the
appliance is to be installed.
•
The access hole of the supply cord to the installation compartment must
be smooth and rounded and it must be large enough for the attachment
plug to pass through. The longest dimension of the opening shall not be
more than 1,5” (38 mm).If the partition is metal, it needs to be covered
with the edge protector (m).
•
Care must be taken when the appliance is installed or removed, to reduce
the likelihood of damage to the power-supply cord.
7.2.1 GROUNDING INSTRUCTIONS
Ths applance must be grounded. In the event of a malfuncton or breakdown, groundng
wll reduce the rsk of electrc shock by provdng a path of least resstance for electrc
current. Ths applance s equpped wth a cord havng an equpment-groundng conductor
and a groundng plug. The plug must be plugged nto an approprate outlet that s nstalled
and grounded n accordance wth all local codes and ordnances. Ths applance must be
connected to a grounded metal, permanent wrng system, or an equpment-groundng
conductor must be run wth the crcut conductors and connected to the equpment-
groundng termnal or lead on the applance.
WARNING
Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service representative
if you are in doubt whether the appliance is properly grounded. Do not modify
the plug provided with the appliance, if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.
15 USA
7.3 READJUSTING FOOT
LEVELS
Now that the dshwasher s n the cabnet
you must readjust the feet to brng the
dshwasher up to the requred heght and
attach t underneath the countertop.
1. Readjust the front foot levels wth
adjustng wrench to balance the
dshwasher and rase t up under the
countertop, make sure the unt s level.
2. Readjust the rear foot levels wth a
screwdrver to balance the dshwasher and
rase t to the requred heght usng the
brackets suppled.
3. Attach the dshwasher underneath the
countertop wth the four screws suppled
(Ø 1/8” x 1/8” - Ø 3.5mm x 14mm). Make
sure you do not go through the top of the
countertop or damage grante.
NOTICE :
For model, DIS25840,
note that
you should keep the total
heght of the dshwasher at 321/4” (819mm) max.
7.4 ADJUSTING THE MOVABLE TOE KICK
Now that you have successfully nstalled the dshwasher, you
need to attach the toe kck to the dshwasher. The two pece
toe kck can be adjusted to the heght and depth needed for
your ktchen. Be sure to use the slotted toe kck n the front
and the other behnd t. They slde nto each other.
1. Insert the movable toe kck brackets nto the channel (
A
).
2. Make sure that the plastc tab to the left of the “L”
openng on the dshwasher has not closed the channel
you wll push the bracket through.
16 USA
NOTICE :
Be sure to notce there s a left and a rght bracket.
Adjust the toe kck brackets forward or backwards
so that they wll algn wth the ktchen toe kck (
B
).
Lock the toe kck brackets as shown wth the plastc
tab n the fgure C by pushng the plastc tab on the
dshwasher nto the teeth of the bracket (
C
).
3. Now attach the toe kck to the bracket wth the
two (Ø 3/16” x 1/4” - Ø 4mm x 6mm) screws and the
caps provded as follows.
If the enclosure heght s below 331/16” (840mm)
use only “o” labelled toe kck (toe kck wthout slots).
Installaton should be done followng the steps
llustrated n the Fgures A, B and C respectvely.
1. Bend tabs on toe kck (o) nwards (
A
).
2. Secure toe kck to brackets wth screws (t) as
shown n the supply bags (
B
).
3. Attach caps (s) as shown n the supply bags (
C
).
If the enclosure heght s above 331/16” (840mm)
use “o” and “p” labelled toe kcks together. Make sure
the slotted toe kck “p” s on the outsde so you can
adjust heght of the toe kck. Installaton should be
done followng the steps llustrated n the fgures A,
B and C respectvely.
1. Algn the toe kck (o) and (p) (
A
).
2. Secure toe kcks to brackets wth screws (t) after
adjustng the heght of the slotted toe kck (p) (
B
).
3. Attach caps (s) as shown n the supply bags (
C
).
If the enclosure heght s above 341/4” (870mm)
use “o” and “r” labelled toe kcks together. Make sure
the slotted toe kck “r” s on the outsde so you can
adjust heght of the toe kck. Installaton should be
done followng the steps llustrated n the fgures A,
B and C respectvely.
1. Algn the toe kck (o) and (r) (
A
).
2. Secure toe kcks to brackets wth screws (r) after
adjustng the heght of the slotted toe kck (t) (
B
).
3. Attach caps (s) as shown n the supply bags (
C
).
17 USA
7.5 INSTALLING THE OUTER DOOR
(DIS25840)
Measure the heght and wdth of the enclosure
(Fgure
A
) and the toe kck. Determne how bg the
wooden door can be. For example f the heght
s 337/8” (860mm) and f the toe kck s 315/16”
(100mm) the door can not be taller than 2915/16”
(760mm).
1. Prepare the wooden door wth the mountng
brackets.
Heght : Heght of the wooden door 28” (711mm)
Wdth : 17 ½” to 17 ¾” (442 mm - 448 mm)
Thckness : ¾ “ (19mm)
3. Mark the wooden door as shown n
the drawng (Fgure
C
).
2. To take the plastc bracket out, remove
the screws on t. Screws wll be used n 5th
step agan. (Fgure
B
).
This manual suits for next models
1
Table of contents
Other Beko Dishwasher manuals
Beko
Beko DFN26220W2 User manual
Beko
Beko BDIS38122Q User manual
Beko
Beko DSN39430X User manual
Beko
Beko DE2541FW User manual
Beko
Beko DSN29330X User manual
Beko
Beko SDVN Series User manual
Beko
Beko D2731 User manual
Beko
Beko DIS35023 User manual
Beko
Beko DSN28520X User manual
Beko
Beko DWD 8657 Installation instructions
