Beko B3T4911DW User manual

Dryer
User Manual
B3T4911DW
B3T4911DG
EN
2960313094_EN/29-09-21.(8:55)

14 Dryer / User manual
3 Your drying machine
3.1 Technical specifications
* Min. height: Height with the adjustable stand closed.
Max. height: Height with the adjustable stand opened at maximum height.
** Weight of dry laundry before washing.
*** Data plate is under the door on the drying machine.
In order to increase the drying machine’s quality, the technical specifications may be
changed without prior notice.
Figures in this manual are schematic and may not exactly match the product.
The values provided with the drying machine or its accompanying documents are
laboratory readings in accordance with the respective standards. These values may
differ depending on the use and ambient conditions.
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,8 cm
Depth 60,9 cm
Capacity (max.) 9 kg**
Net weight (± %10) 35 kg
Voltage
See type label***Rated power input
Model code

15
Dryer / User manual
3.2 General appearance
1. Top panel
2. Control panel
3. Loading door
4. Toe board handle
5. Ventilation grids
6. Adjustable feet
7. Toe board
8. Rating plate
9. Lint filter
10. Water tank drawer
11. Power cord
3.3 Scope of delivery
1. Water
discharge
hose*
6. Water
filling cap*
2. Filter
drawer
spare
sponge*
7. Pure
Water*
3. User
Manual
8. Odour
Capsule
Group*
4. Drying
basket* 9. Brush*
5. Drying
basket user
manual*
10. Filter
cloth*
*Optional - may not be included, depends on
model.
11
10
1
2
3
4
5
6
7
8
9

16 Dryer / User manual
4 Installation
Read the “Safety Instructions” first!
Before consulting the nearest Authorized
Service for installing the drying machine, see
the information in the user guide and make sure
the electric and water utilities are as required. If
not, call an electrician and plumber to arrange
the utilities as necessary.
It is customer's responsibility to
prepare the location the drying
machine shall be placed on and
also have power and waste water
installation prepared.
4.1 Right place for installation
• Install the drying machine on a flat and
stable surface.
• Dryer machine is heavy. Do not move it by
yourself.
• Operate the drying machine in an
environment free of dust with good
ventilation.
• The gap between the drying machine and
the floor shall not be reduced via materials
such as rugs, pieces of wood and bands.
• Do not block the ventilation grilles of the
drying machine.
• There shall not be doors that can be
locked, sliding doors or hinged doors near
the installation environment of the drying
machine that may block the loading door
to be opened.
• Once the drying machine is installed,
the connections must stay stable. After
placing the drying machine, ensure that
the back wall does not come in contact
with any extrusion (a water tap, electrical
outlet etc.).
• Place the drying machine with at least 1
cm space between the product and the
furniture edges.
• Your drying machine is suitable to be
operated between +5°C to +35°C. If
operated outside this temperature range,
your drying machine’s operation may be
compromised and get damaged.
• The drying machine shall not be placed
with the back side against a wall.
BDo not place the drying machine on
its power cord.
4.2 Removing the
shipping safety group
Remove the shipping
safety group prior to
first use the product.
NOTICE
Do not leave an accessory or any
parts of the shipping safety group
inside the drum.
4.3 Water connection
Instead of periodically draining the water
accumulated in the water tank, you can
discharge via the water discharge hose
supplied with the drying machine.
Connecting the water
drainage hose
1
3 4
21-2 Remove the
hose behind the
drying machine
by pulling it
manually from
where it is
attached. Do
not use a tool
to remove the
hose.
3 Insert one end of the water discharge hose
supplied with the drying machine to where
you have removed the hose on the drying
machine.
4 Fix the other end of the water discharge
hose to directly waste water drainage or a
sink.

17
Dryer / User manual
NOTICE
The water discharge hose shall be
fixed at maximum 80 cm height.
Ensure that the water discharge
hose do not get kinked, collapsed
or pressed on between the
discharge and the drying machine.
Hose shall be connected not to
be disconnected from its location.
Leaked water may cause damage.
Do not extend the water drainage
hose.
Check whether the water runs at an
appropriate flow. The drainage line
shall not be closed or clogged.
If an accessory package is provided
with your product, check the
detailed instructions.
4.4 Adjusting the stands
Until the drying
machine stands level
and sturdy, adjust
the stands by turning
them left and right.
4.5 Moving the drying machine
• Drain the water in the drying machine
completely.
• If the product is connected via direct
discharge, remove the hose connections.
The drying machine is
recommended to be moved in
upright position. Otherwise, tilt it to
the right side when viewed from the
front and move the drying machine.
4.7 Replacing the lighting bulb
If your drying machine has drum lighting lamp;
Consult the authorized service to replace the
bulb/LED used in lighting your drying machine.
The bulb in this product is not suitable for home
lighting. The intended use of this lamp is to
ensure safely loading the laundry to the drying
machine. The lamps used in this appliance is
resistant to heavy physical conditions such as
temperatures over 50°C.

18 Dryer / User manual
Read the “Safety Instructions” first!
5.1 Laundry suitable for
drying in drying machine
NOTICE
Laundry that are not drying machine
safe may damage the appliance and
the laundry during drying. Follow
the instructions on the labels on the
laundry to be dried. Only dry the
laundry with “drying machine safe”
written on their labels.
Do not dry
with dryer
5.2 Laundry not suitable for
drying in drying machine
NOTICE
Undergarments with metal supports
shall not be dried in drying machine.
If these metal supports get loose
and ripped from the garment, it may
damage the machine.
Delicate embroidery textiles, cotton
and silk garments, garments
manufactured from delicate and
valuable textiles, non breathing
garments and tulle curtains shall not
be dried in drying machine.
5.3 Preparing the
laundry to be dried
NOTICE
Items such as coins, metal parts,
needles, nails, screws, stones etc.
may damage the drum group of the
product or may cause functional
operation issues. Therefore check
all laundry that will be loaded to the
product.
Dry the laundry with metal
accessories such as zippers by
turning them inside out.
Close the zippers, hooks and
clasps, button up the covers’
buttons, tie textile belts and apron
belts.
5.4 What to do for energy saving
• Use the highest possible wringing option
as you wash the laundry. Therefore you
can reduce the drying period and reduce
energy consumption. Sort the laundry
based on their types and thickness.
Dry same types of laundry together. For
instance kitchen towels and table cloths
dry faster than bathroom towels.
• Follow the recommendations in the user
manual for program selection.
• During drying do not open the loading
door unless necessary. If you are required
to open the loading door, do not keep it
open for too long.
• Do not add wet laundry as the drying
machine operates.
• Clean the Fibre Filter before and after
each drying session.
• For condensation models, be sure to
clean the condenser at least once a
month or after each 30 drying sessions.
• Make sure the filters are clean. Refer to
maintenance and cleaning for details.
• For models with flue, follow the flue
connection rules specified in the guides
and clean the flue.
• During drying session, properly ventilate
the environment in which the drying
machine is in.
• On models with heat pump, check the
condenser at least every six months and
clean it if it is dirty.
5 Preparation

19
Dryer / User manual
• If you are using environment friendly filter,
you are not required to clean the filter
after every cycle. When the environment
friendly icon is lit on the screen, change
the filter cloth.
5.5 Correct load capacity
NOTICE
If the laundry in the
product exceed
maximum load
capacity, it may not
operate as intended
and may cause
material damage or
damage the product.
For each program,
follow the maximum
load capacity.
The weights below are provided as examples.
Laundry
Approx.
weight
(g)*
Laundry Approx.
weight (g)*
Cotton
bedding
(double size)
1500 Cotton dress 500
Bedding
(single size) 1000 Dress 350
Bed sheet
(double size) 500 Denim 700
Bed sheet
(single size) 350 Handkerchief (10 pcs) 100
Large table
cloth 700 T-Shirt 125
Small table
cloth 250 Blouse 150
Tea napkin 100 Cotton shirt 300
Bath towel 700 Shirt 200
Hand towel 350
*Weight of dry laundry before washing.

20 Dryer / User manual
6.1 Control Panel
6 Running the product
3
4 5
2
6
7
8
1
1. On/Off/Program Selection button.
2. Start / Stand-by button.
3. End time selection button.
4. Time program selection button.
5. Low temperature selection button.
6. Audible warning and child lock selection
button.
7. Wrinkle prevention selection button/ Drum
light button.
8. Dryness level selection button.
6.2 Symbols
6.3. Preparation of
drying machine
• Plug the drying machine.
• Open the loading door.
• Place the laundry to the drying machine
without jamming them.
• Push and close the loading door.
NOTICE
Ensure that no
laundry is jammed to
the loading door.
Do not close the
loading door with
force.
• Select the desired program by using
On/Off/Program Selection button, the
machine will turn on.
Selecting the program with the On/
Off/Program Selection button does
not mean that the program started.
Press Start / Stand-by button to
start the program.
Filter
cleaning
Tank
full
Filter drawer /
Heat exchanger
cleaning
Start
pause
cancel
Iron Dry
Drying Buzzer Cupboard
Dry
Cupboard
Dry +
Extra dry End Anti-
creasing
Child-proof
lock
Low
temperature
TimeDry Ending In RapiDry
Drum
Light
Dryness
Level
Daily Delicates Synthetics
Towels Mix Cottons
Eco
Cottons Jeans Sport Bedding/
Duvet
Shirts Express Hygienic
Drying
Hygienic
Refresh
Steam Steam
Level1
Steam
Level2
On / O Wool Protect
Night
Freshen
Up
Outdoor
Hygiene
(Baby Protect+)
Environmentally
friendly lter full
Environmentally
friendly lter
Downwear Wi Remote
Control
Bluetooth Gentle
Dry

21
Dryer / User manual
6.4 Program selection and consumption chart
EN
Programmes Programme Description
Capacity (kg)
Spin speed in
washing machine
(rpm)
Drying Time
(minutes)
Cottons
You can dry your heat-resistant cotton textiles
with this programme. A drying setting suitable for
the thickness of the products to be dried and the
desired level of dryness should be selected.
9 1000 159
Cottons Eco It dries single layer, casual cotton textiles in the
most economical way. 9 1000 149
Cottons Iron dry
You may dry your cotton laundry to be ironed in
this program to have them slightly damp for ease
of ironing. (Shirt, T-shirt, tablecloth, etc.)
9 1000 120
Synthetics
You can dry all your synthetic textiles with this
programme. A drying setting suitable for the level
of dryness you desire should be selected.
4 800 50
Mix
Use this programme to dry non-pigmenting
synthetic and cotton laundry items together.
Sports and fitness clothes may be dried with this
program.
4 1000 83
Towels Drying towels such as kitchen towel, bath towel
and hand towel. 5 1000 110
GentleCare
You may dry your delicate laundry or laundry
with hand wash symbol (silk blouses, thin
underwear, etc.) at low temperature in this
program.
2 1200 35
Sports
You can dry your single-layer sportswear for daily
use made of synthetic, cotton or mixed fabrics
with this program.
4 1000 60
Freshen up
It just provides airing for 10 minutes without
any hot air. You can air the cotton and linen
laundry that are kept closed for a long time , and
eliminate the odour in them.
- - 10
Timer Programme
You may select from time programmes
between 10 and 160 minutes to achieve the
desired drying level at low temperature. In this
programme, tumble drier’s operation lasts for
the set time independently from the dryness of
laundry.
- - -
Jeans You may dry denim pants, skirts, shirts or jackets
in this program. 4 1200 80

22 Dryer / User manual
* : Energy Label standard program EN 61121The values in the table are determined according to
the EN 61121 standard. Consumption values may vary from the valued in the chart depending on
laundry type, wringing speed, ambient conditions and voltage levels.
Outdoor
You can dry your multi-layer textile products
made of synthetic, cotton or mixed fabrics used
for outdoor activities and outdoor sports with this
program.
2 1000 60
Daily
You can dry both cotton and synthetic laundry
with this programme.Sports and fitness clothes
may be dried with this program.
4 1000 83
Shirts It dries the shirts in a more sensitive manner, and
causes less creasing and easier ironing. 1,5 1200 35
Super Short 0.5kg Use this program to have 2 shirts ready for
ironing. 0,5 1200 15
Hygiene
It is a long-term program that you can use for the
clothes (baby clothes, towels, underwear, etc.
cotton) you require hygeine. Hygiene is provided
with high temperature. It is especially suitable for
durable fabrics. ((This program is identified and
approved by England’s “The British Foundation”
(Allergy UK).))
5 800 105
Energy consumption values
Programmes Capacity (kg)
Spin speed in
washing machine
(rpm)
Approximate
amount of remaining
humidity
Energy consumption
value kWh
Cottons Eco * 9 1000 60% 5,21
Cottons Iron dry 9 1000 60% 4,10
Synthetics cupboard dry 4 800 40% 1,90
“Cottons Eco programme” used at full and partial load is the standard drying programme to which
the information in the label and the fiche relates, that this programme is suitable for drying normal
wet Cottons laundry and that it is the most efficient programme in terms of energy consumption for
Cottons.
“If you regularly dry the 9 Kg maximum load of Cottons we suggest to connect the drain hose to
prevent the dryer stopping mid-cycle in order to empty the tank” (see Section “Connection to the
drain”)

23
Dryer / User manual
Allergy UK is the trademark of
the British Allergy Foundation.
The Seal of Approval has been
created to guide people
requesting an advice that the
product significantly reduces
the amount of the allergens in an
environment where allergic people are
present or the product restricts/reduces/
eliminates the allergens. The purpose is to
provide evidence that the products have
been scientifically tested or analysed to yield
measurable results.
6.5 Auxiliary functions
Dryness level
Dryness level button is used for adjusting to
desired dryness. Program time may change
depending on the selection.
You can activate this function only
prior to start of program.
Wrinkle prevention
You can turn on and off the wrinkle prevention
function by pressing the wrinkle prevention
selection button. If you will not take the
laundry out immediately after the program has
completed, you may use Wrinkle prevention
function to prevent wrinkling of your laundry.
Audible warning
Drying machine makes an audible warning
when the program is completed. Press the
“Audible Warning” button if you do not want
audible warning. When you press the audible
warning button, the light goes off and it does
not sound when the program is completed.
You can select this function before
the program starts or after the
program starts.
Low temperature
You can activate this function only prior to start
of a program. You can activate this function
if you want to dry your laundry at a lower
temperature. The program duration will be
longer after it becomes activated.
End time
You can delay the end time of the program up
to 24 hours with end time function.
1. Open the loading door and place the
laundry.
2. Select the drying program.
3. Press the End Time selection button and
set the delay time you wish. End time LED
turns on. (When pressed and hold the
button, End Time proceeds non-stop).
4. Press the Start / Stand-by button. End
Time countdown begins. The “:” sign in the
middle of displayed delay time flashes.
You can add or remove laundry
within end time. Displayed time is
the sum of normal drying time and
end time. End Time LED turns off at
the end of countdown, the drying
starts and the drying LED turns on.
Changing the end time
If you want to change the duration during the
countdown:
Pause the program and Turn the On/Off/
Program Selection button and cancel the
program. Select the desired program and
repeat the End Time selection.
Cancelling the end time function
If you want to cancel the end time countdown
and start the program immediately:
Pause the program and Turn the On/Off/
Program Selection button and cancel the
program. Select the desired program and press
the “Start/Pause” button.
Drum Light
You can turn on and off the drum light by
pressing this button. The light turns on when
the button is pressed and turns off after certain
time.

24 Dryer / User manual
6.6 Warning indicators
Warning indicators may vary
depending on the model of your
drying machine.
Filter cleaning
When the program is completed, the warning
indicator for filter cleaning turns on.
Water tank
If the water tank fills up while the program
continues, the warning indicator starts flashing
and the machine goes into stand-by. In this
case, empty the water tank and start the
program by pressing the Start / Stand-by
button. Warning indicator turns off and program
resumes.
Cleaning of filter drawer/
heat exchanger
Warning symbol flashes periodically to remind
that filter drawer must be cleaned.
6.7 Starting the program
Press the Start/Stand-by button to start the
program.
Start/Stand-by and Drying indicators turn on to
show that program started.
6.8 Child Lock
The drying machine has a child lock which
prevents the program flow from being
interrupted when the buttons are pressed
during a program. When the Child Lock is
activated, all buttons on the panel except
the On/Off/Program Selection button are
deactivated.
Press the Audible Warning button for 3
seconds in order to activate the child lock.
The child lock has to be deactivated to be
able to start a new program after the current
program is finished or to be able to interfere
with the program. To deactivate the child lock,
keep the same buttons pressed for 3 seconds.
When the child lock is activated,
the child lock warning indicator on
the screen turns on.
When the child lock is active:
The drying machine runs, or in stand-by state
the indicator symbols will not change upon
changing the position of the program selection
button.
When the drying machine is
operated and the child lock is
active, if the program selection
button is turned, a double beeping
noise will be heard. If the child lock
is deactivated before the program
selection button is turned to its
original place, the program will
be terminated since the program
selection button is displaced.
6.9 Changing the program
after it is started
You can change the program you selected to
dry your laundry with a different program after
the drying machine starts running.
• For example, Pause the program and turn
the On/Off/Program Selection button to
select the Extra Dry program in order to
select the Extra Dry program instead of
Ironing Dryness.
• Press the Start/Stand-by button to start
the program.
Adding and removing
clothes during stand-by
If you want to add or remove clothes to/from
the drying machine after the drying program
starts:
• Press the Start/Stand-by button to put
the drying machine in Stand-by state. The
drying operation stops.
• Open the loading door while in Stand-
by state, and close the door after you
remove or add laundry.
• Press the Start/Stand-by button to start
the program.

25
Dryer / User manual
Adding laundry after the drying
operation starts may cause the
dried laundry inside the drying
machine to mix with wet laundry
and leave the laundry damp at the
end of operation.
Adding or removing laundry
during drying may be repeated as
many times as you wish. But this
operation continuously interrupts
the drying operation, and thus
increases program duration and
energy consumption. So, it is
recommended to add laundry
before the program starts.
If a new program is selected by
turning the program selection
button while the drying machine is
in stand-by, the running program
terminates.
Do not touch the inner surface of
the drum while adding or removing
clothes during a continuing
program. The drum surface is hot.
6.10 Cancelling the program
If you want to cancel the program and
terminate the drying operation for any reason
after the drying machine starts running, Pause
the program and turn the On/Off/Program
Selection button; the program terminates.
The inside of the drying machine
shall be extremely hot when you
cancel the program during machine
operation, so run the refreshing
program to allow it to cool down.
6.11 End of program
When the program ends, the LED’s of End/
Wrinkle Prevention and Fibre Filter Cleaning
Warning on the program follow-up indicator
turn on. Loading door can be opened and
drying machine is ready for another operation.
Turn the On/Off/Program Selection button to
On/Off position in order to turn off the drying
machine.
If the Wrinkle Prevention mode
is active and the laundry is not
removed after the program is
completed, the wrinkle prevention
function activates for 2 hours to
prevent the laundry inside the
machine to get wrinkled. The
program tumbles the laundry with
10-minute intervals to prevent them
from wrinkling.
6.12 Odour feature
If your drying machine has odour feature, read
the ProScent manual to use this feature.

26 Dryer / User manual
7 Maintenance and cleaning
Service life of the product extends and
frequently faced problems decrease if cleaned
at regular intervals.
BThis product must be unplugged
during maintenance and cleaning
works (control panel, body, etc.).
7.1 Lint Filter / Loading
Door Inner Surface
Lint and fiber released from the laundry to the
air during the drying cycle are collected in the
Lint Filter.
Always clean the lint filter and the
inner surfaces of the loading door
after each drying process.
You can clean the lint filter housing
with a vacuum cleaner.
To clean the lint filter:
• Open the
loading door.
• Remove the
lint filter by
pulling it up
and open the
lint filter.
• Clean lint, fiber, and cotton raveling by
hand or with a soft piece of cloth.
• Close the lint filter and place it back into
its housing.
A layer can build up
on the filter pores that
can cause clogging
of the filter after using
the dryer for a while.
Wash the lint filter with
warm water to remove
the layer that builds
up on the lint filter
surface. Dry the lint
filter completely before
reinstalling it.
• Clean the entire inner surface of the
loading door and loading door gasket
with a soft damp cloth.
7.2 Cleaning the sensors
There are
dampness
sensors in the
dryer that detect
whether the
laundry is dry or
not.
To clean the
sensors:
• Open the loading door of the dryer.
• Allow the machine to cool down if it is
still hot due to the drying process.
• Wipe the metal surfaces of the sensor
with a soft cloth, dampened with
vinegar and dry them.
Clean metal surfaces of the sensors
4 times a year.
Do not use metal tools when
cleaning metal surfaces of the
sensors.
Never use solvents, cleaning agents
or similar substances for cleaning
due to the risk of fire and explosion!

27
Dryer / User manual
7.3 Draining the water tank
Dampness of the laundry is removed and
condensed during drying process and the water
that arise accumulates in the water tank. Drain
the water tank after each drying cycle.
AWARNING!
• Condensed water is not drinkable!
• Never remove the water tank when the
program is running!
If you forget to drain the water tank, the
machine will stop during the subsequent drying
cycles when the water tank is full and the Water
Tank warning symbol will flash. If this is the
case, drain the water tank and press Start /
Pause button to resume the drying cycle.
To drain the water tank:
1. Remove the water tank in the drawer
or container carefully.
• If there is lint accumulation in the funnel
of the water tank, clean it under running
water.
• Place the water tank into its seat.
If the direct water draining is used as
an option, there is no need to empty
the water tank.
7.4 For the condenser;
Clean the condenser after every 30
drying cycles or once a month.
o clean the condenser:
• If a drying
process has been
carried out, open
the door of the
machine and wait
until it cools down
• Unlock the 2 condenser locks after
opening the kick plate
• Pull out the condenser.
Clean the condenser
by applying
pressurized water with
a shower armature
and wait until the water
drains.
Place the condenser in
its housing. Fasten the
2 locks and make sure
that they are seated
securely.
Close the kick plate
cover.

28 Dryer / User manual
8 Troubleshooting
Drying operation takes too long.
Fibre filter (interior and exterior filter) pores may be clogged. >>> Wash the fibre filters with warm water
and dry.
Condenser front side may be clogged. >>> Clean the front side of the condenser.
The ventilation grills in front of the machine may be closed. >>> Remove any object in front of the
ventilation grills that blocks air.
Ventilation may be inadequate because the are the machine is installed in is too small. >>> Open the
door or windows to prevent the room temperature from rising very high.
If there is a humidity sensor.
A lime layer may have accumulated on the humidity sensor. >>> Clean the humidity sensor.
Excessive amount of laundry might be loaded. >>> Do not load the drying machine excessively.
Laundry might not have been wrung adequately. >>> Perform a higher speed wringing on the washing
machine.
Clothes come out damp after drying.
A program not suitable for the laundry type may have been used.>>> Check the maintenance labels on
the clothes and select a program suitable for the clothes' type or use time programs as extra.
Fibre filter (interior and exterior filter) pores may be clogged. >>> Wash the filters with warm water and
dry.
Condenser front side may be clogged. >>> Clean the front side of the condenser.
Excessive amount of laundry might be loaded. >>> Do not load the drying machine excessively.
Laundry might not have been wrung adequately. >>> Perform a higher speed wringing on the washing
machine.
Drying machine does not turn on or program cannot be started. Drying machine does not run after it is
configured.
Power plug might be unplugged. >>> Make sure the power cord is plugged in.
Loading door might be open. >>> Ensure that the loading door is properly closed.
A program might not be set or Start / Pause button might not be pressed. >>> Check that the program
is set and it is not in Pause position..
Child lock may be activated. >>> Turn off the child lock.
Program terminated prematurely for no reason.
Loading door might be closed completely. >>> Ensure that the loading door is properly closed.
There might be a power outage. >>> Press the Start / Pause / Cancel button to start the program.
Water tank may be full. >>> Empty the water tank.
Clothes have shrunk, hardened or spoiled.
A program not suitable with the laundry type might have been used. >>> Check the maintenance labels
on the clothes and select a program suitable for the clothes.
Water drips from the loading door.
Fibres might have gathered on the inner sides of the loading door and the loading door gasket. >>>
Clean the inner surfaces of the loading door and the loading door gasket surfaces.
Loading door opens by itself.
Loading door might be closed completely. >>> Push the loading door until the closing sound is heard.
Water tank warning symbol is on/flashing.
Water tank may be full. >>> Empty the water tank.
Water discharge hose might have collapsed. >>> If the product is connected directly to the water drain
check the water discharge hose.

29
Dryer / User manual
The lighting inside the drying machine does not turn on. (In models with lamp)
The drying machine might not have been turned on using On/Off button. >>> Check that the drying
machine is turned on.
Lamp might be malfunctioning. >>> Contact Authorized Service to replace the lamp.
Wrinkle prevention icon or light is lit.
Anti-Crease mode that prevents the laundry in the drier to crease may be activated. >>> Turn the drier off
and remove the laundry.
Fibre filter cleaning icon is lit.
Fibre filter (interior and exterior filter) may be unclean. >>> Wash the filters with warm water and dry..
A layer may be formed on the fibre filter pores that leads to clogging. >>> Wash the filters with warm
water and dry.
A layer that may cause clogging of the pores of the fibre filters (internal and external filters) may have
occurred.<<Wash and dry the filters with lukewarm water>>
Fibre filters may not be inserted. >>> Insert the interior and exterior filters to their places.
Environmentally-friendly filter cloth may not be installed on the plastic part and the front of the condenser
may have clogged.>>>Install the environmentally-friendly filter to the plastic part and place it on the filter
housing.
Environmentally-friendly filter may have not been replaced although the warning
symbol is illuminated. “Replace your filter.”
An audible warning is heard from the machine
Fibre filters may not be inserted. >>> Insert the interior and exterior filters to their places.
Filters of the machine may not have been installed.>>> Install the fibre filters (internal and external) or the
environmentally-friendly filter to their housing.
Condenser warning icon is flashing.
Condenser front side may be clogged with fibres. >>> Clean the front side of the condenser.
Fibre filters may not be inserted. >>> Insert the interior and exterior filters to their places.
The lighting inside the drying machine turns on. (In models with lamp)
If the drying machine is plugged to the power outlet, the On/Off button is pressed and the door is open;
the light turns on. >>> Unplug the drying machine or bring the On/Off button to Off position.
Wifi icon flashes continuously. (for models featuringHomeWhiz Function)
>>> The product may not be connected to the wireless network. Follow the instructions to connect
to the network. The device which the product utilize to connect to network may be faulty. Check it.The
product may not be connecting to the network due to proximity.
If you see the “F L t” message on the screen, please follow the steps below.
Filters may be dirty. Clean internal and external filters or replace the eco-friendly filter.
If you use double filter, as an internal and external filter, on the cover area, ensure that both filters are
installed.
If you use the eco-friendly filter feature, ensure that the filter cloth is installed to the plastic part. Install the
filter cloth to the plastic part if it is not installed.
The are in front of the condenser may be dirty. Open and inspect the toe board area and ensure that it is
clean. Refer to the Maintenance and Cleaning section.
If the problem persists after following the instructions in this section, contact your vendor or an
Authorized Service. Never try to repair your product yourself.
If you experience any issue with your device, you can request a replacement by consulting to
the nearest authorised service with the device model number.

30 Dryer / User manual
9. Electrical Connection In order to avoid hazards, damaged
supply cord should be replaced by the
manufacturer, its service agent or similarly
qualified people.
Do not operate without the top
cover fitted. Risk of injury.
Important
9.3 Fitting a different plug
As the colours of the wires in the mains
lead of this appliance may not correspond
with the coloured markings identifying the
terminals on your plug, proceed as follows:
1 Connect the green - yellow or green (earth)
wire to the terminal in the plug marked ‘E’
or with the symbol or coloured green and
yellow or green.
2 Connect the blue (neutral) wire to the
terminal in the plug marked ‘N’ or coloured
black.
3 Connect the brown (live) wire to the
terminal in the plug marked ‘L’ or coloured
red.
With the alternative plugs a 13 A fuse must
be fitted either in the plug or adaptor or in
the main fuse box. If in doubt contact a
qualified electrician.
Green and yellow
or green
N
Blue or black L
Brown or red
9.4 Washer/dryer combination
Do not stack washing machine on top of
the tumble dryer. This would damage both
appliances and guarantees would become
void. It is also unsafe to stack an appliance
on top of another without using a suitable
and approved stacking kit obtained from
specialist retailers.
Make sure that you have an earthed power
outlet socket rated at 13 amps (minimum).
9.1 Attention!
When installed, the socket must be
reachable after installation, or a separate
switch (which can disconnect the two poles)
must be used in the installation. Check for
suitability.
For a permanent connection, a master
switch with at least 3mm contact clearance
and minimum 13 A rating must be used.
9.2 Electrical requirements
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown in the rating label
corresponds to your electricity supply.
We recommend that this appliance be
connected to the mains supply via a suitable
switched and fused socket in a readily
accessible position.
Should the mains lead of the appliance
become damaged or need replacing at
any time, it must be replaced by a special
purpose made mains lead which can only be
obtained from an Authorised Service Agent.
Warning
This appliance must be earthed
If the fitted moulded plug is not suitable for
your socket, then the plug should be cut off
and an appropriate plug fitted.
The moulded plug on this appliance
incorporates a 13A fuse. Should the fuse
need to be replaced an ASTA approved
BS1362 fuse of the same rating must be
used. Do not forget to refit the fuse cover.
In the event of losing the fuse cover, the
plug must not be used until a replacement
fuse cover has been fitted. Colour of the
replacement fuse cover must be the same
colour as that visible on the pin face of the
plug. Fuse covers are available from any
good electrical store.
