Dear Customer,
Thank you for prefering a Beko product. We hope that your product which has been
manufactured with high quality and technology will give you the best results. We advise you to
read through this manual and the other accompanying documentation carefully before using
your product and keep it for future reference. If you transfer the product to someone else, give
its manual as well. Pay attention to all details and warnings specified in the user manual and
follow the instructions given therein.
Use this user manual for the model indicated on the cover page.
Read the instructions.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and property.
BWarning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard them
to the dedicated collection points designated by the local authorities.
This product was manufactured using the latest technology in environmentally friendly conditions.

3
Dryer / User Manual
1 Important instructions for safety and
environment
This section contains safety instructions that will help protect from risk of
personal injury or property damage. Failure to follow these instructions shall
void any warranty.
1.1 General safety
•The dryer can be used by children at and above 8 years old and by
persons whose physical, sensory or mental capabilities were not fully
developed or who lack experience and knowledge provided that they
are supervised or trained on the safe usage of the product and the risks
it brings out. Children should not play with the product. Cleaning and
maintenance works should not be performed by children unless they are
supervised by someone.
•Children of less than 3 years should be kept away unless continously
supervised.
•Adjustable feet should not be removed. The gap between the dryer and
the floor should not be reduced with materials such as carpet, wood and
tape. This will cause problems with the dryer.
•Always have the installation and repairing procedures carried out by the
Authorized Service.Manufacturer shall not be held liable for damages
that may arise from procedures carried out by unauthorized persons.
•Never wash the dryer by spraying or pouring water onto it! There is the
risk of electric shock!
For the products with a steam function:
•Use only distilled water or water condensed in the water tank of the
machine in steam programs. Do not use mains water or additives. When
using condensed water in the water tank, it should be filtered and cleared
of fibres.
•Do not open the door when steam programs are running. Hot water may
be expelled.
•Before putting laundry in a steam program, stains on it should be
removed.
•You may only put laundry that is not dirty or stained but permeated with
unpleasant odour in steam (odour removal) program.
•Do not use any dry cleaning sets or additional materials in a steam
program or in any program.
This product was manufactured using the latest technology in environmentally friendly conditions.

4 Dryer / User Manual
Important instructions for safety and
environment
1.1.1 Electrical safety
AElectrical safety instructions should be followed while electrical
connection is made during the installation.
AThe appliance must not be supplied through an external switching
device, such as a timer,or connected to a circuit that is regularly
switched on and off by utility.
•Connect the dryer to a grounded outlet protected by a fuse at the value
specified on the type label. Have the grounding installation performed by
a qualified electrician. Our company shall not be liable for any damages
that will arise when the dryer is used without grounding in accordance
with the local regulations.
•The voltage and allowed fuse protection is stated on the type label plate.
•The voltage specified on the type label must be equal to your mains
voltage.
•Unplug the dryer when it is not in use.
•Unplug the dryer from the mains during installation, maintenance,
cleaning and repair works.
•Do not touch the plug with wet hands! Never unplug by pulling on the
cable, always pull out by grabbing the plug.
•Do not use extension cords, multi-plugs or adaptors to connect the dryer
to power supply in order to decrease the risk of fire and electric shock.
•Power cable plug must be easily accessible after installation.
BDamaged mains cable should be changed notifying the Authorized
Service.
BIf the dryer is faulty, it must not be operated unless it is repaired
by an authorized service agent! There is the risk of electric shock!
1.1.2 Product safety
Superheating of the clothes inside of the dryer can occur if you
cancel the programme or in the event of a power failure whilst
the dryer is running, this concentration of heat can cause self-
combustion and fire so always activate the ventilation programme
to cool down or quickly remove all laundry from the dryer in order
to hang them up and dissipate the heat.

5
Dryer / User Manual
Important instructions for safety and
environment
Points to be taken into consideration for fire hazard:
Below specified laundry or items must not be dried in the dryer
considering fire hazard.
•Unwashed laundry items
•Items soiled with oil, acetone, alcohol, fuel oil, kerosene, stain
removers, turpentine, paraffin or paraffin removers must be
washed in hot water with plenty of detergent before being dried
in the dryer.
For this reason especially the items containing the above specified
stains must be washed very well, to do this use adequate
detergent and choose a high washing temperature.
Below specified laundry or items must not be dried in the
dryer due to the fire hazard:
•Garments or pillows bolstered with rubber foam (latex foam),
shower bonnets, water resistant textiles, materials with rubber
reinforcement and rubber foam pads.
•Clothing cleaned with industrial chemicals.
Items such as lighter, match, coins, metal parts, needle etc.
may damage the drum set or may lead to functional problems.
Therefore check all the laundry that you will load into your dryer.
Never stop your dryer before the programme completes. If you
must do this, remove all laundry quickly and lay them out to
dissipate the heat.
Clothes that are washed inadequately may ignite on their own and
even may ignite after drying ends.
Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The items
become warm, causing an oxidation reaction in the oil. Oxidation
creates heat. If the heat cannot escape, the items can become hot
enough to catch fire. Piling, stacking or storing oil-affected items
can prevent heat from escaping and so create a fire hazard.

6 Dryer / User Manual
Important instructions for safety and
environment
If it is unavoidable that fabrics that contain vegetable or cooking
oil or have been contaminated by hair care products be placed in
a tumble dryer they should first be washed in hot water with extra
detergent - this will reduce, but not eliminate, the hazard.
•You must provide enough ventilation in order to prevent gases exiting
from devices operating with other types of fuels including the naked flame
from accumulating in the room due to the back fire effect.
AUnderwear that contains metal reinforcements should not be dried
in the dryer. Dryer may be damaged if metal reinforcements come
loose and break off during drying.
CUse softeners and similar products in accordance with the
instructions of their manufacturers.
CAlways clean the lint filter before or after each loading. Never
operate the dryer without the lint filter installed.
•Never attempt to repair the dryer by yourself. Do not perform any repair
or replacement procedures on the product even if you know or have the
ability to perform the required procedure unless it is clearly suggested in
the operating instructions or the published service manual. Otherwise,
you will be putting your life and others’ lives in danger.
•There must not be a lockable, sliding or hinged door that may block
the opening of the loading door in the place where your dryer is to be
installed.
•Install your dryer at places suitable for home use. (Bathroom, closed
balcony, garage etc.)
•Make sure that pets do not enter the dryer. Check the inside of the dryer
before operating it.
•Do not lean on the loading door of your dryer when it is open, otherwise it
may fall over.
•The lint must not be allowed to accumulate around the tumble dryer
•The tumble dryer is not to be used if industrial chemicals have been used
for cleaning.
•Fabric softeners, or similar products.should be used as specified by the
fabric softener instructions.

7
Dryer / User Manual
Important instructions for safety and
environment
•Exhaust air must not be discharged into a flue which is used for
exhausting fumes from appliances burning gas or other fuels.
•The final step of the drying cycle (cool-down cycle) occurs without
applying heat to ensure that the items are left at a temperature that will
not damage them.
1.2 Mounting over a washing machine
•A fixing device should be used between the two machines when installing
the dryer above a washing machine. The fitting device must be installed
by the authorized service agent.
•Total weight of the washing machine and the dryer -with full load- when
they are placed on top of each other reaches to approx. 180 kilograms.
Place the products on a solid floor that has sufficient load carrying
capacity!
AWashing machine cannot be placed on the dryer. Pay attention
to the above warnings during the installation on your washing
machine.
Installation Table for Washing Machine and Dryer
Dryer Depth Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm Can be installed Can be
installed Cannot be
installed
60 cm Can be installed Cannot be
installed
1.3 Intended use
•Dryer has been designed for domestic use. It is not suitable for
commercial use and it must not be used out of its intended use.
•Use the dryer only for drying laundry that are marked accordingly.
•The manufacturer waives any responsibility arisen from incorrect usage
or transportation.
•The service life of the dryer that you purchased is 10 years. During this
period, original spare parts will be available to operate the dryer properly.

8 Dryer / User Manual
Important instructions for safety and
environment
1.4 Child safety
•Packaging materials are dangerous for the children. Keep packaging
materials away from children.
•Electrical products are dangerous for the children. Keep children away
from the product when it is operating. Do not let them tamper with the
dryer. Use the child-proof lock in order to prevent the children to tamper
with the dryer.
CChild-proof lock is on the control panel.
(See Child lock)
•Keep loading door closed even when the dryer is not in use.
1.5 Compliance with the WEEE regulation
and disposing of the waste product
This product complies with EU WEEE Directive (2012/19/EU). This
product bears a classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been manufactured with high quality parts and
materials which can be reused and are suitable for recycling. Do
not dispose of the waste product with normal domestic and other
wastes at the end of its service life. Take it to the collection center for the
recycling of electrical and electronic equipment. Please consult your local
authorities to learn about these collection centers.
1.6 Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive
(2011/65/EU). It does not contain harmful and prohibited materials
specified in the Directive.
1.7 Package information
Packaging materials of the product are manufactured from recyclable
materials in accordance with our National Environment Regulations. Do
not dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated
by the local authorities.

9
Dryer / User Manual
Important instructions for safety and
environment
1.8 Technical Specifications
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,5 cm
Depth 53 cm
Capacity (max.) 7 kg**
Net weight (± 4 kg) 32 kg
Width
See type label***Voltage
Rated power input
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
CTechnical specifications of the dryer are subject to specification
without notice to improve the quality of the product.
CFigures in this manual are schematic and may not match the
product exactly.
C
Values stated on markers on the dryer or in the other published
documentation accompanying with the dryer are obtained in
laboratory in accordance with the relevant standards. Depending on
operational and environmental conditions of the dryer, these values
may vary.

10 Dryer / User Manual
2Your Dryer
2.1 Package Contents
12 3 5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.

11
Dryer / User Manual
3 Installation
Refer to the nearest Authorised Service Agent for
installation of your product.
CPreparation of location and electrical
installation for the product is under
customer’s responsibility.
BInstallation and electrical connections must
be carried out by a qualified personnel.
APrior to installation, visually check if the
product has any defects on it. If so, do not
have it installed. Damaged products will
cause risks for your safety.
3.1 Appropriate installation location
• Install the product in an environment which has no
risk of freezing and is in a stable and level position.
• Operate your product in a well ventilated, dust-free
environment.
• Do not block the air ducts in front of and under the
product with materials such as long pile rugs and
wooden bands.
• Do not place your product on a long pile rug or on
similar surfaces.
• Do not install the product behind a door with a
lock, sliding door or a hinged door which can strike
the product.
• Once the product is installed, it should stay at
the same place where its connections have been
made. When installing the product, make sure that
the rear wall of it does not touch anywhere (tap,
socket, etc.) and also pay attention to install the
product at a place where it will stay permanently.
BDo not place the product on top of the
power cable.
• Keep at least 1.5 cm distance to walls of other
furniture.
• The rear surface of the tumble dryer shall be
placed against a wall.
3.2 Under counter installation
• A special part (Part no: 295 970 0100) replacing
the top trim must be provided and installed by
the Authorised Service Agent in order to use the
machine under a counter or in a cupboard. It
should never be operated without the top trim.
• Leave at least 3 cm of space between the side
and rear walls of the product and the walls of the
counter/cupboard when installing your product
under a counter or in a cupboard.
3.3 Ventilation hose and connection
(for products equipped with an outlet
vent)
Ventilation hose allows exhaust air from inside the
machine
Vented dryer has 1 air outlet.
Stainless sheet metal or aluminum pipes can be
used instead of a hose. The pipe diameter should be
minimum 10 cm.
Maximum hose and pipe lengths are given in the table
below.
Hose Pipe
Maximum length 4 m 5 m
1 elbow 45° -1.0 m -0.3 m
1 elbow 90° -1.8 m -0.6 m
1 elbow 90° short -2.7 m
1 wall passage -2.0 m -2.0 m
CEach elbow and other passages should be
subtracted from the maximum length stated
above.
To connect a ventilation hose;
1. Connect the air outlet hose to the hose spacer
piece by turning it counterclockwise.
2. Make the hose passages as shown below.
CExhaust of humid air from the dryer into the
room is inconvenient. It may damage the
walls and furniture in the room.
CThe ventilation hose can be routed outdoors
via a window or it can be connected to the
air outlet in the bathroom.
CAir outlet hose must be routed directly
to the outdoors. There must be a limited
number of elbows as not to hinder
ventilation.
CTo prevent water accumulation in the hose,
make sure that it is not folded on the floor.

12 Dryer / User Manual
Installation
BThe ventilation hose should not be
connected to the chimney of a stove or a
fireplace.
BDo not operate your product at the same
time with heaters such as a coal or gas
stove. Airflow may cause the chimney to
flare up.
3.4 Adjusting feet
In order to ensure that your product operates more
silently and vibration-free, it must stand level and
balanced on its feet. Front feet of your product can be
adjusted. Balance the machine by adjusting the feet.
1. Loosen the feet by hand.
2. Adjust the feet until the product stands level and
firmly on the floor.
CDo not use any tools to loosen the
adjustable feet, otherwise, they can be
damaged.
CNever remove the adjustable feet from their
housings.
CYou may supply 2 plastic pieces from an
Authorized Service with 2951620100 part
number. These parts prevent your machine
from slipping when the machine locates
on wet and slippery surfaces. You may
assemble mentioned parts to the front
adjustable feet by fitting and pressing them
to snap into ground of feet.
3.5 Electrical connection
For specific instructions for electrical connection
required during installation (see 1.1.1 Electrical
Safety)
3.6 Transportation of the machine
1. Unplug the machine from the mains.
2. Remove the water drain (if any) and chimney
connections.
3. Drain water remained in the machine completely
before transportation.
3.7 Changing the illumination lamp
In case an illumination lamp is used in your laundry
dryer.To change the Bulb/LED used for illumination of
your tumble dryer, call your Authorized Service.
The lamp(s) used in this appliance is not suitable for
household room illumination. The intended purpose of
this lamp is to assist the user to place laundry in the
tumble dryer in a comfortable way. The lamps used
in this appliance have to withstand extreme physical
conditions such as vibrations and temperatures above
50 °C

13
Dryer / User Manual
4Preparation
4.1 Laundry suitable for drying in the dryer
Always obey the instructions given on the garment tags. Dry only the laundry having a label stating that they are
suitable for drying in a dryer and make sure that you select the appropriate programme.
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON
Dry or Steam
Iron at high
temperature
Iron at medium
temperature Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature 200 0C150 0C110 0C
LAUNDRY DRYING SYMBOLS
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean
4.2 Laundry not suitable for drying in the dryer
CDelicate embroidered fabrics, woolen, silk
garments, delicate and valuable fabrics,
airtight items and tulle curtains are not
suitable for machine drying.
4.3 Preparing laundry for drying
• Laundry may be tangled with each other after
washing. Separate the laundry items before
placing them into the dryer.
• Dry garments having metal accessories such as
zippers, inside out.
• Fasten the zippers, hooks and buckles and button
sheets.
4.4 Things to be done for energy
saving
Following information will help you use the dryer in an
ecological and energy-efficient manner.
• Spin your laundry at the highest speed possible
when washing them. Thus, the drying time is
shortened and energy consumption is reduced.
• Sort out the laundry depending on their type and
thickness. Dry the same type of laundry together.
For example thin kitchen towels and table clothes
dries earlier than thick bathroom towels.
• Follow the instructions in the user manual for
programme selection.
• Do not open the loading door of the machine
during drying unless necessary. If you must
certainly open the loading door, do not to keep it
open for a long time.
• Do not add wet laundry while the dryer is in
operation
• Clean the lint filter before or after each drying
cycle.
• Clean the condenser regularly at least once every
month or after every 30 drying cycles.
• Ventilate the room, where the dryer is located, well
during drying.

14 Dryer / User Manual
Preparation
4.5 Correct load capacity
Follow the instructions in the “Programme selection and
consumption table”. Do not load more than the capacity
values stated in the table.
CIt is not recommended to load the dryer
with laundry exceeding the level indicated
in the figure. Drying performance will
degrade when the machine is overloaded.
Furthermore, dryer and the laundry can get
damaged.
Following weights are given as examples:
Laundry Approximate weights
(g)*
Cotton quit covers (double) 1500
Cotton quit covers (single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10 pieces) 100
T-Shirts 125
*Dry laundry weight before washing.

15
Dryer / User Manual
5Selecting a Programme and Operating Your Machine
5.1 Control panel
1. Filter cleaning warning light
2. Program follow-up indicator
3. Cancel audio warning
4. On/Off button
5. Programme selection knob
6. Start/Pause/Cancel button
5.2 Preparing the machine
1. Plug in your machine.
2. Place the laundry in the machine.
3. Press the “On/Off” button.
CPressing the “On/Off” button does not
necessarily mean that the programme has
started. Press “Start/Pause/Cancel” button of
the machine to start the programme.
1 2 3 4
56
5.3 Programme selection
Decide the appropriate programme from the table below
which includes drying temperatures in degrees. Select
the desired programme with the programme selection
button.
Extra dry
Dry at high temperature only for
cotton laundry. Thick and multi
layered laundry (E.g.: towels, linens,
jeans) are dried in a way that they do
not require ironing before placing in
the wardrobe.
Cupboard dry
Normal laundry (E.g.: tablecloths,
underwear) are dried in a way that
they do not require ironing before
placing in the drawers.
Cupboard dry +
Normal laundry (E.g.: tablecloths,
underwear) are dried in a way that
they do not require ironing before
placing in the drawers, but more than
those in the ready to wearoption.
Iron Dry Normal laundry (E.g., Shirts, dresses)
are dried ready to be ironed.
CFor further program details, see, “Program
Selection Table”

16 Dryer / User Manual
Operating the product
5.4 Main programmes
Depending on the type of laundry, the following main
programmes are available:
•Cottons
You can dry your durable laundry with this programme.
Dries at high temperature. It is recommended to use
for your cotton items (such as bed sheets, quilt cover,
underclothing, etc.).
•Synthetics
You can dry your less durable laundry with this
programme. It dries at a lower temperature compared
to the cottons programme. It is recommended for your
synthetic laundry (such as shirts, blouses, synthetic/
cotton blended laundry, etc.).
CDo not dry curtains and lace in your
machine.
•Anti-creasing
A 2-hour anti creasing programme to prevent laundry
from creasing will be activated if you do not take
the laundry out after the programme is over. This
programme rotates the laundry in 10-minute intervals to
prevent creasing.
5.5 Special programmes
For special cases, there are also extra programmes
available:
CAdditional programmes may differ
according to the model of your machine.
Mini
You can use this programme to dry the cottons that are
spun at high speeds in your washing machine. It can dry
your 1,2 kg Cotton laundry (3 Shirts / 3 T-Shirts) within
30 minutes.
C
In order to obtain better results from the dryer
programs, your laundry must be washed
with suitable program and spun at the
recommended spin speeds in your washing
machine.
•Shirt
Dries the shirts in a more sensitive way so that they are
less creased and ironed easily.
CShirts may contain little amount of
dampness at the and of the program. It is
advised not to leave the shirts in the dryer.
•Jeans
You can use this program to dry the jeans that are spun
at high speeds in your washing machine.
CReview the relevant part of the program
table.
•Mix
Used to dry synthetic and cotton laundry that do not
release colour. Used for laundry that is suitable for
drying.
•Delicates
You can dry at a lower temperature your very delicate
laundry (silk blouses, fine underwear, etc.) that are
suitable for drying or laundry which is advised to be
hand-washed.
CIt is recommended to use a cloth bag to
avoid certain delicate garments and laundry
from getting creased or damaged. Take your
garments immediately out of the dryer and
hang them after the programme ends in
order to prevent them being creased.
•Freshen up
Only ventilation is performed for 10 minutes without
blowing hot air. You can air your clothes that have been
kept at closed environments for a long time thanks to
this program to deodorize unpleasant odors.
•Timer programs
You can select one of the 10 min., 20 min., 40 min. and
60 min. timer programmes to achieve the desired final
drying level at low temperatures. Programme dries at
the selected time regardless of the drying temperature.

17
Dryer / User Manual
Operating the product
5.6 Program selection and consumption table
„Cotton cupboard dry Programme“ used at full and partial load is the standard drying Programme
to which the information in the label and the fiche relates, that this Programme is suitable for
drying normal wet cotton laundry and that it is the most efficient Programme in terms of energy
consumption for cotton.
Programs Capacity (kg) Spin speed in washing
machine (rpm)
Approximate amount of
remaining humidity Drying time (minutes)
Cottons / Coloreds
ACupboard Dry
71200-1000 % 60 130
900-800 % 70 140
3,5 1200-1000 % 60 75
900-800 % 70 90
ACupboard Dry +
71200-1000 % 60 140
900-800 % 70 150
3,5 1200-1000 % 60 78
900-800 % 70 95
AIron Dry
7
1200-1000 % 60 94
900-800 % 70 110
3,5
1200-1000 % 60 54
900-800 % 70 70
Mini 1,2 1200-1000 %50 30
Shirts 1,5 1000-800 %50 30
Jeans 4 1200-1000 %50 81
Synthetics
BCupboard Dry
3,5
800 % 40 45
600 % 50 60
1,75 800 % 40 28
600 % 50 40
Cottons & Synthetics
Mix 4 1000-800 % 60 82
Delicates
BCupboard Dry 1,5 600 % 50 40
Energy consumption values
Programs Capacity (kg) Spin speed in washing
machine (rpm)
Approximate amount of
remaining humidity
Energy consumption value
kWh
Cottons Cupboard Dry* 7 / 3,5 1000 % 60 4,2 / 2,4
Cottons Iron Dry 7 1000 % 60 3,1
Synthetics Cupboard Dry 3,5 800 % 40 1,6

18 Dryer / User Manual
Operating the product
* : Energy Label standard program (EN 61121:2012)
All values given in the table have been fixed according
to EN 61121:2012 Standard. These values may deviate
from the table according to the laundry type, laundry
spin speed, environmental conditions and voltage
fluctuations.
5.7 Auxiliary function
Cancel audio warning
Your dryer will give an audio warning when the
programme comes to an end. If you do not want to
hear the audio warning, press “Cancel Audio Warning”
button. The relevant light will turn on when this button
is pressed and an audio warning will not be given when
the programme comes to an end.
CYou can select this function either before or
after the programme starts.
5.8 Warning indicators
CWarning indicators may differ according to
the model of your dryer.
Filter cleaning
A warning light will turn on to remind filter cleaning after
the programme finishes.
CIf the filter cleaning warning light lights up
continuously, please refer to, “Suggested
solutions for problems”.
5.9 Starting the programme
1.Press “Start/Pause/Cancel” button to start the
programme.
2.Light of the “Start/Pause/Cancel” button will turn on to
indicate that the programme has started.
5.10 Progress of program
Progress of a running program is shown through the
program follow-up indicator.
At the beginning of every program step, the relevant
indicator LED will light up and light of the completed
step will turn off.
“Drying”:
- Drying level will be illuminated during the whole drying
process until the drying degree reaches “iron dry”.
“Iron Dry”:
- Starts to illuminate when the drying degree reaches
“iron dry” step and remains illuminated until the next
step.
“Ready to wear”:
Starts to illuminate when the drying degree reaches
“Ready to wear” step and remains illuminated until the
next step.
“Final / Anti-creasing”:
- Illuminates when the program comes to an end and
anti-creasing function is activated.
CIf more than one LED light up or
flash concurrently, it means there is
malfunctioning or a failure (please see,
Solution suggestions for problems).
5.11 Changing the programme after it
has started
You can use this feature to dry your clothes under higher
or lower temperatures after your dryer has started.
For example;
1.Press and hold the “Start/Pause/Cancel” button for
about 3 seconds to “Cancel” the programme in order
to select “Extra Dry” programme instead of “Iron Dry”
programme.
2.Select the “Extra Dry” programme by rotating the
programme selection button.
3.Press “Start/Pause/Cancel” button to start the
programme.
CPress “Start/Pause/Cancel” button for 3
seconds to cancel the programme or turn the
programme selection knob in any direction
to end the programme while the machine
is running. Water tank and filter cleaning
warning lights turn on to warn the user when
the programme is cancelled by pressing the
“Start/Pause/Cancel” button for 3 seconds.
However, the warning lights do not turn
on when the programme is cancelled by
turning the programme selection knob. Only
the drying light turns on and the machine
remains in hold until a new programme is
selected and the “Start/Pause/Cancel” button
is pressed. Child-proof lock of the machine
should not be active in order to perform
these two operations. If the child-proof lock is
active, deactivate it before performing these
operations.
Adding/removing laundry in standby mode
In order to add or remove laundry after the programme
starts:
1.Press the “Start/Pause/Cancel” button to switch the
dryer to “Pause” mode. Drying process will stop.
2.Open the door at “Pause” position and close it again
after adding or taking out laundry.
3.Press “Start/Pause/Cancel” button to start the
programme.
CAny laundry added after the drying process
has started may cause the dried clothes in
the machine intermingle with wet clothes
and the result will be wet laundry after the
drying process is over.

19
Dryer / User Manual
Operating the product
AA double beep will be heard if you turn
the programme selection knob when the
machine is running and the child-proof
lock is active. If you deactivate the child-
proof lock without returning the program
selection knob to its previous position, the
programme will be terminated since the
position of the programme selection knob
is changed. The drying light turns on and
the machine remains on hold until a new
programme is selected and the “Start/
Pause/Cancel” button is pressed.
5.13 Finishing by canceling the
programme
To cancel any selected programme:
Press “Start/Pause/Cancel” button for about 3 seconds.
The “Filter cleaning”, “Water tank” and “End/ Anti-
creasing” warning lights will turn on at the end of this
period for reminding purposes.
AAs the inside of the dryer will be
excessively hot when you cancel the
programme while the dryer is running,
activate the ventilation programme to cool
it down.
5.14 End of programme
The “End/Anti-creasing”, “Filter cleaning” and “Water
tank” warning lights on the programme follow up
indicator will turn on when the programme comes to an
end. The door can be opened and the machine becomes
ready for a second cycle.
Press “On/Off” button to turn off the dryer.
CFinal step of the drying cycle (cooling step)
is performed without heat application in
order to keep the items at a temperature that
would not harm them.
CA 2-hour anti creasing programme to prevent
laundry from creasing will be activated if
you do not take the laundry out after the
programme has come to an end.
CIf you will not take the laundry out
immediately, do not stop the dryer before the
drying process is complete.
CClean the filter after each drying (please see,
Filter cleaning).
CDrain the water tank after each drying
(please see, Water tank)
CLaundry may be added or taken out as
much as desired during a drying process,
but this process will extend the programme
duration and increase energy consumption
since the drying will be interrupted
continuously. Therefore, it is recommended
to add laundry before the drying programme
has started.
5.12 Child-proof lock
There is a child-proof lock to prevent any programme
interruption due to the pressing of button while the
programme is running. The loading door and all buttons
except the “On/Off” button on the control panel are
deactivated when the child-proof lock is active.
Press the “Start/Pause/Cancel” and “Cancel audio
warning” buttons simultaneously for 3 seconds to
activate the child-press lock.
To start a new programme after the programme is over
or to interrupt the programme, the child-proof lock
should be deactivated. Press the same buttons for 3
sec. again to deactivate the child-proof lock.
CChild-proof lock is deactivated when the
machine is restarted by pressing the On/
Off button.
CPress the relevant buttons for 3 seconds
to activate the child-proof lock. A long
beep will be heard and the child-proof lock
will be activated. A double beep will be
heard if you press any button or turn the
programme selection knob while the child-
proof lock is active. Press the buttons for 3
seconds to deactivate the child-proof lock.
Single beep will be heard and child-proof
lock will be deactivated.

20 Dryer / User Manual
6Maintenance and cleaning
6.1 Filter Cartridge / Door Inner Surface
Lint and fibres released from the laundry to the air
during the drying cycle are collected in the “Filter
Cartridge”.
CSuch fibre and lint are generally formed
during wearing and washing.
Always clean the filter and the inner
surfaces of the cover after each drying
process.
You can clean the filter and filter area by
vacuum cleaner.
To clean the filter:
1. Open the loading door.
2. Remove the cover filter by pulling it up and open the
filter.
3. Clean lint, fibre, and cotton raveling by hand or with
a soft piece of cloth.
4. Close the filter and place it back into itsseat.
CClogging may arise on the filter surface
after using your machine for some time; if
this occurs, wash the filter with water and
dry it before using again.
Clean the entire inner surface of the cover
and door gasket.
6.2 Sensor (models equipped with a
sensor)
There are humidity sensors in your machine that detect
whether the laundry is dry or not.
For sensor cleaning;
1. Open the door of the machine.
2. Allow the machine to cool off if drying has been
carried out.
3. Wipe the metal sensors with a soft cloth, dampened
with vinegar and dry them.
CClean metal sensors 4 times a year.
ANever use solvents, cleaning agents or
substances alike when cleaning as these
might cause fire and explosion!
