Beko DPU 7360 X User manual

Dryer
User manual
DPU 7360 X
2960310618_EN/251215.1757
EN FR

2 / EN Dryer / User Manual
Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that your product which has been manufac-
tured with high quality and technology will give you the best results. We advise you to read
through this manual and the other accompanying documentation carefully before using your
product and keep it for future reference. If you transfer the product to someone else, give its
manual as well. Pay attention to all details and warnings specied in the user manual and fol-
low the instructions given therein.
Use this user manual for the model indicated on the cover page.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful
hints about usage.
AWarning for hazardous situations
with regard to life and property.
BWarning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the
product are manufactured from
recyclable materials in accordance
with our National Environment
Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard
them to the dedicated collection points designated by the local authorities.
This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN
Dryer / User Manual
1Important instructions for safety and
environment
Ths secton contans safety nstructons that wll help
protect from rsk of personal njury or property damage.
Falure to follow these nstructons shall vod any warranty.
1.1 General safety
•The dryer can be used by chldren at and above 8
years old and by persons whose physcal, sensory or
mental capabltes were not fully developed or who
lack experence and knowledge provded that they are
supervsed or traned on the safe usage of the product
and the rsks t brngs out. Chldren should not play wth
the product. Cleanng and mantenance works should not
be performed by chldren unless they are supervsed by
someone.
•Chldren of less than 3 years should be kept away unless
contnously supervsed.
•Adjustable feet should not be removed. The gap between
the dryer and the floor should not be reduced wth
materals such as carpet, wood and tape. Ths wll cause
problems wth the dryer.
•Always have the nstallaton and reparng procedures
carred out by the Authorzed Servce.Manufacturer
shall not be held lable for damages that may arse from
procedures carred out by unauthorzed persons.
•Never wash the dryer by sprayng or pourng water onto t!
There s the rsk of electrc shock!

4 / EN Dryer / User Manual
1.1.1 Electrcal safety
AElectrcal safety nstructons should be followed
whle electrcal connecton s made durng the
nstallaton.
•Connect the dryer to a grounded outlet protected by a
fuse at the value specfed on the type label. Have the
groundng nstallaton performed by a qualfed electrcan.
Our company shall not be lable for any damages that
wll arse when the dryer s used wthout groundng n
accordance wth the local regulatons.
•The voltage and allowed fuse protecton s stated on the
type label plate.
•The voltage specfed on the type label must be equal to
your mans voltage.
•Unplug the dryer when t s not n use.
•Unplug the dryer from the mans durng nstallaton,
mantenance, cleanng and repar works.
•Do not touch the plug wth wet hands! Never unplug by
pullng on the cable, always pull out by grabbng the plug.
•Do not use extenson cords, mult-plugs or adaptors to
connect the dryer to power supply n order to decrease the
rsk of fre and electrc shock.
•Power cable plug must be easly accessble after
nstallaton.
BDamaged mans cable should be changed notfyng
the Authorzed Servce.
BIf the dryer s faulty, t must not be operated unless
t s repared by an authorzed servce agent! There s
the rsk of electrc shock!

5 / EN
Dryer / User Manual
1.1.2 Product safety
Ponts to be taken nto consderaton for fre
hazard:
Below specfed laundry or tems must not be dred
n the dryer consderng fre hazard.
•Unwashed laundry tems
•Items soled wth ol, acetone, alcohol, fuel ol,
kerosene, stan removers, turpentne, paraffn or
paraffn removers must be washed n hot water
wth plenty of detergent before beng dred n the
dryer.
For ths reason especally the tems contanng the
above specfed
stans must be washed very well, to do ths
use adequate detergent and choose a hgh washng
temperature.
Below specfed laundry or tems must not be
dred n the dryer due to the fre hazard:
•Garments or pllows bolstered wth rubber foam
(latex foam), shower bonnets, water resstant
textles, materals wth rubber renforcement and
rubber foam pads.
•Clothng cleaned wth ndustral chemcals.
Items such as lghter, match, cons, metal parts,
needle etc. may damage the drum set or may lead to
functonal problems. Therefore check all the laundry
that you wll load nto your dryer.
Never stop your dryer before the programme
completes. If you must do ths, remove all laundry
quckly and lay them out to dsspate the heat.
Clothes that are washed nadequately may gnte on
ther own and even may gnte after dryng ends.

6 / EN Dryer / User Manual
•You must provde enough ventlaton n order to prevent
gases extng from devces operatng wth other types of
fuels ncludng the naked flame from accumulatng n the
room due to the back fre effect.
AUnderwear that contans metal renforcements
should not be dred
n the dryer. Dryer may be damaged f metal
renforcements come loose and break off durng
dryng.
CUse softeners and smlar products n accordance
wth the nstructons of ther manufacturers.
CAlways clean the lnt flter before or after each
loadng. Never operate the dryer wthout the lnt
flter nstalled.
•Never attempt to repar the dryer by yourself. Do not
perform any repar or replacement procedures on the
product even f you know or have the ablty to perform
the requred procedure unless t s clearly suggested n the
operatng nstructons or the publshed servce manual.
Otherwse, you wll be puttng your lfe and others’ lves n
danger.
•There must not be a lockable, sldng or hnged door that
may block the openng of the loadng door n the place
where your dryer s to be nstalled.
•Install your dryer at places sutable for home use.
(Bathroom, closed balcony, garage etc.)
•Make sure that pets do not enter the dryer. Check the
nsde of the dryer before operatng t.
•Do not lean on the loadng door of your dryer when t s
open, otherwse t may fall over.
•The lnt must not be allowed to accumulate around the
tumble dryer

7 / EN
Dryer / User Manual
1.2 Mountng over a washng machne
•A fxng devce should be used between the two machnes
when nstallng the dryer above a washng machne. The
fttng devce must be nstalled by the authorzed servce
agent.
•Total weght of the washng machne and the dryer -wth
full load- when they are placed on top of each other
reaches to approx. 180 klograms. Place the products on a
sold floor that has suffcent load carryng capacty!
AWashng machne cannot be placed on the dryer.
Pay attenton to the above warnngs durng the
nstallaton on your washng machne.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm Can be installed Can be
installed Cannot be
installed
60 cm Can be installed Cannot be
installed

8 / EN Dryer / User Manual
1.3 Intended use
•Dryer has been desgned for domestc use. It s not sutable
for commercal use and t must not be used out of ts
ntended use.
•Use the dryer only for dryng laundry that are marked
accordngly.
•The manufacturer waves any responsblty arsen from
ncorrect usage or transportaton.
•The servce lfe of the dryer that you purchased s 10 years.
Durng ths perod, orgnal spare parts wll be avalable to
operate the dryer properly.
1.4 Chld safety
•Packagng materals are dangerous for the chldren. Keep
packagng materals away from chldren.
•Electrcal products are dangerous for the chldren. Keep
chldren away from the product when t s operatng. Do
not let them tamper wth the dryer. Use the chld-proof
lock n order to prevent the chldren to tamper wth the
dryer.
CChld-proof lock s on the control panel.
(See Chld lock)
•Keep loadng door closed even when the dryer s not n
use.

9 / EN
Dryer / User Manual
1.5 Compliance with the WEEE regulation and disposing of the
waste product
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classication symbol for waste electrical and electronic equipment (WEEE).
This product has been manufactured with high quality parts and materials which
can be reused and are suitable for recycling. Do not dispose of the waste product
with normal domestic and other wastes at the end of its service life. Take it to the
collection center for the recycling of electrical and electronic equipment. Please
consult your local authorities to learn about these collection centers.
1.6 Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not
contain harmful and prohibited materials specied in the Directive.
1.7 Package information
Packaging materials of the product are manufactured from recyclable materials in accordance
with our National Environment Regulations. Do not dispose of the packaging materials togeth-
er with the domestic or other wastes. Take them to the packaging material collection points
designated by the local authorities.
1.8 Technical Specifications
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,5 cm
Depth 59,8 cm
Capacity (max.) 7 kg**
Net weight (plastic front door usage) 49 kg
Net weight (glass front door usage) 51 kg
Voltage
See type label***Rated power input
Model code
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
CTechnical specications of the dryer are subject to specication without notice to
improve the quality of the product.
CFigures in this manual are schematic and may not match the product exactly.
CValues stated on markers on the dryer or in the other published documentation
accompanying with the dryer are obtained in laboratory in accordance with the
relevant standards. Depending on operational and environmental conditions of the
dryer, these values may vary.

10 / EN Dryer / User Manual
2Your Dryer
2.1 Package Contents
12 3 5
4
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
*It can be supplied with your machine depending on its model.

11 / EN
Dryer / User Manual
3Installation
Refer to the nearest Authorized Service
Agent for installation of the product. To
make the product ready for use, make sure
that the electricity and water drainage
system are appropriate before calling the
Authorized Service Agent. If they are not, call
a qualified technician and plumber to have
any necessary arrangements carried out.
CPreparation of the product’s
location as well as the electrical
and waste water installations is
under customer’s responsibility.
BInstallation and electrical
connections of the product must
be carried out by the Authorized
Service Agent. Manufacturer shall
not be held liable for damages that
may arise from procedures carried
out by unauthorized persons.
A
Prior to installation, visually check
if the product has any defects on
it. If so, do not have it installed.
Damaged products cause risks for
your safety.
ALet your dryer wait for 12 hours
before starting to use it.
3.1 Appropriate installation
location
• Install the product on a stable and level
surface.
• Dryer is heavy. Do not move it by
yourself.
• Operate your product in a well ventilated,
dust-free environment.
• Do not block the air ducts in front of and
under the product with materials such as
long pile rugs, wooden blocks and bands.
• Do not install the product behind a door
with a lock, sliding door or a hinged door
which can strike the product.
• Once the product is installed, it should
stay at the same place where its
connections have been made. When
installing the product, make sure
that the rear wall of it does not touch
anywhere (tap, socket, etc.). Also
pay attention to select an installation
location which you will not be required to
change afterwards.
• Place the product at least 1.5 cm away
from the edges of other furniture.
• The rear surface of the tumble dryer
shall be placed against a wall
BDo not place the product on the
power cable.
3.2 Removing the
transportation safety
assembly
ARemove the transportation safety
assembly before using the product
for the first time.
1. Open the loadng door.
2. There s a nylon bag nsde the drum that
contans a pece of styrofoam. Hold t
from ts secton marked wth XX XX.
3. Pull the nylon towards yourself and
remove the transportaton safety
assembly.
AMake sure that no part of the
transportation safety assembly
remains inside the drum.

12 / EN Dryer / User Manual
3.3 Under counter installation
This product can be installed under a counter
if the height of the counter is sucient.
AWhile using undercounter dryer,
it should never be operated
without undercounter installation
part.
Dryer Depth 60 cm 54 cm
Stock number
of
under-bench
installation
part
2979700100 2973600100
Leave at least 3 cm of space around the sides
and the rear wall of the product when
installing it under a counter or in a cup-
board.
3.4 Connecting to the drain
In products equipped with condenser
unit, water accumulates in the water tank
during the drying cycle. You should drain
accumulated water after each drying cycle.
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining
the water collected in the water tank.
Connecting the water drain hose
1. Pull hose n the product by hand n
order to dsconnect t from where t
s connected. Do not use any tools to
remove the hose.
2. Connect one end of the dran hose
suppled separately wth the product
to the connecton pont from where
you removed the hose of the product n
prevous step.
3. Connect the other end of the dran hose
drectly to the wastewater dran or to
the washbasn.
AHose must be fixed in every type
of connection. Your house will be
flooded if the hose comes loose
during water discharge.
CWater drain hose should be attached
to a height of maximum 80 cm.
CMake sure that the water drain hose
is not stepped on and it is not folded
between the drain and the machine.
3.5 Adjusting the feet
In order to ensure that the product operates
more silently and vibration-free, it must
stand level and balanced on its feet. Balance
the machine by adjusting the feet.
Turn the feet to left or right until the
machine stands level and firmly.
CNever remove the adjustable feet
from their housings.
3.6 Electrical connection
For specific instructions for electrical
connection required during installation
(see 1.1.1 Electrical Safety)

13 / EN
Dryer / User Manual
3.7 Transportation of the dryer
Unplug the dryer before transporting it.
Drain all water that has remained in the
dryer.
If direct water drain connection is made, then
remove the hose connections.
A
We recommend carrying the
dryer in upright position. If it is
not possible to carry the machine
in the upright position, we
recommend carrying it by tilting
towards the right side when
looked from the front.
3.8 Warnings about sounds
CIt is normal to hear a metallic noise
from the compressor sometimes
during operation.
CWater collected during operation is
pumped to water tank. It is normal
to hear pumping noise during this
process.
3.9 Changing the illumination
lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.
The lamp(s) used in this appliance is not
suitable for household room illumination.
The intended purpose of this lamp is to
assist the user to place laundry in the tumble
dryer in a comfortable way. The lamps used
in this appliance have to withstand extreme
physical conditions such as vibrations and
temperatures above 50 °C

14 / EN Dryer / User Manual
4Preparation
4.1 Laundry suitable for drying in the dryer
Always obey the instructions given on the garment tags. Dry only the laundry having a label
stating that they are suitable for drying in a dryer and make sure that you select the ap-
propriate programme.
4.2 Laundry not suitable for
drying in the dryer
CDelicate embroidered fabrics,
woollen, silk garments, delicate
and valuable fabrics, airtight
items and tulle curtains are not
suitable for machine drying.
4.3 Preparing laundry for
drying
• Laundry may be tangled with each other
after washing. Separate the laundry
items before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for
energy saving
Following information will help you use the
dryer in an ecological and energy-ecient
manner.
• Spin your laundry at the highest speed
possible when washing them. Thus, the
drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type
of laundry together. For example thin
kitchen towels and table clothes dries
earlier than thick bathroom towels.
• Follow the instructions in the user
manual for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must certainly open the loading
door, do not to keep it open for a long
time.
Drying
Settings
At any temperature At high temperature At medium temperature At low temperature Without heating Hang to dry Lay to dry Hang wet to dry Lay in shadow to dry Dry-cleanable
Iron -
IRON
Dry or Steam
Iron at high
temperature
Iron at medium
temperature Iron at low
temperature
Do not iron
Iron without
steam
Maximum temperature 200 0C150 0C110 0C
LAUNDRY DRYING SYMBOLS
Drying
Symbols Suitable for
dryer No Iron Sensitive /
Delicate dry
Do not dry
with dryer
Do not dry Do not dry-
clean

15 / EN
Dryer / User Manual
• Do not add wet laundry while the dryer is
in operation
• Clean the lint filter before or after each
drying cycle. (See 6.1 Cleaning Lint
Filter / Loading Door Inner Surface)
• Clean the filter periodically when there
is visible air collection on it or when
the symbol lights up, if there is a filter
drawer cleaning warning symbol «
»available. (See 6. 4 Cleaning the filter
drawer)
• Ventilate the room, where the dryer is
located, well during drying.
4.5 Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated in
the table.
CIt is not recommended to load
the dryer with laundry exceeding
the level indicated in the gure.
Drying performance will degrade
when the machine is overloaded.
Furthermore, dryer and the laundry
can get damaged.
Following weights are given as examples.
Laundry Approximate
weights (g)*
Cotton quit covers
(double) 1500
Cotton quit covers
(single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea napkins 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces) 100
T-Shirts 125
*Dry laundry weight before washing.

16 / EN Dryer / User Manual
Spin speed / Timer programs*
Operation symbol
Pause symbol
Water Tank warning symbol
Filter cleaning warning symbol
Filter Drawer Cleaning warning symbol
Remaining Time indicator**
Child-proof Lock warning symbol
Time Delay mode
Loading door open warning symbol
Anti-creasing mode
Audio Warning Level / Cancel Audio Warning
Dryness Level
Anti-creasing is activated
* Spin speed is used to show the remaining time more accurately. It does not
affect the performance of your machine.
** Time that appears on display indicates the remaining time until the end of the
programme and changes according to the dampness level of the laundry.
5Selecting a Programme and Operating Your Machine
5.1 Control panel
1. Washing Machine Spin Speed / Timer
Programme Selection button
2. Display
3. Start / Pause / Cancel button
4. Programme Selection knob
5. On / O button
6. Anti-creasing button
7. Dryness Level button
8. Cancel Audio Warning button
9. Time Delay buttons
1 2 3 4 5
6789

17 / EN
Dryer / User Manual
5Selecting a Programme and Operating Your Machine
5.2 Preparing the machine
1. Plug in the machine.
2. Place the laundry in the machine.
3. Press the On / O button.
CPressing the On / O button does
not necessarily mean that the
programme has started. Press
Start / Pause / Cancel button to
start the programme.
5.3 Programme selection
1. Decide the appropriate programme from
the table below which includes drying
levels.
2. Select the desired programme with the
Programme Selection knob.
Extra Dry
Only the cotton laundry is
dried at normal temperature.
Thick and multi layered laun-
dry (towels, linens, jeans and
etc.) are dried in a way that
they do not require ironing
before being placed in the
wardrobe.
Cupboard
dry
Normal laundry (tablecloths,
underwear and etc.) are dried
in a way that they do not
require ironing before being
placed in the wardrobe.
Iron Dry Normal laundry (shirts, dress- es and etc.) are dried ready to
be ironed.
CFor further programme details,
see “Programme selection and
consumption table”.
5.4 Main programmes
Depending on the fabric type, the following
main programmes are available:
• Cottons
Dry durable laundry with this programme.
Dries at normal temperature. It is recom-
mended to use for your cotton items (bed
sheets, quilt covers, towels, bathrobes, etc.).
• Synthetics
Dry less durable laundry with this pro-
gramme. Recommended for synthetics.
5.5 Additional programmes
For special cases, following additional pro-
grammes are available in the machine.
CAdditional programs may dier
according to the features of your
machine.
• Express
You can use this program to dry your cotton
laundry that you have spun at high speeds in
your washing machine. This program dries 1
kg cotton laundry (3 Shirts/3T-shirts) in 45
minutes.
CTo obtain better results from
your dryer, your laundry must be
washed at suitable programs and
spun at the recommended speed
in the washing machine.
Daily
Timer
program
mes
Cottons Synthetics Freshen Up Anti
Creasing
Iron Dry Extra dry Cupboard
Dry
Dryness
Level
Buzzer/
cancel
On/Off Start
pause
cancel
Filter
cleaning
Child-proof
lock
Tank
full
Xpress
Jeans Shirts
BabyProtect Sport Spin Mix Delicates
Wool
Refresh Drying
Rack
Timer
Delay

18 / EN Dryer / User Manual
• Shirt
This programme dries the shirts more sensi-
tively and creases them less and thus, helps
to iron them more easily.
CThere may be a little moisture on
the shirts at the end of the pro-
gramme. We recommend you not
to leave the shirts in the dryer.
• Jeans
Use this programme to dry your jeans that
are spun at high speeds in the washing ma-
chine.
• Mixed
Use this programme to dry non-pigmenting
synthetic and cotton laundry items together.
• Sport
Use this programme to dry together the
synthetic and cotton laundry items and the
laundry items made of mixed fabrics.
• Wool Refresh
You can use this program to ventilate and
soften your woolen laundry that can be
washed in the washing machine. Do not use
this program to dry your laundry completely.
Take out your laundry and ventilate them im-
mediately after the program is over.
• Daily
This program is used to dry cottons and syn-
thetics daily, and lasts for 1.5 hour.
• BabyProtect
This program is used for baby clothes that
bear machine dryable approval on its label.
• Delicates
You can dry your highly delicate laundry that
are suitable for drying or laundry which is
advised to be hand-washed at a lower tem-
perature.
CIt is recommended to use a cloth
bag to prevent certain delicate
laundry from getting creased or
damaged. Take your laundry im-
mediately out of the dryer and
hang them after the program
is over in order to prevent them
from getting creased.
• Ventilation
Only ventilation is performed for 10 minutes
without blowing hot air. You can air the
clothes that have been kept at closed envi-
ronments for a long time and deodourise un-
pleasant odours thanks to this programme.
• Timer programmes
You can select one of the 10 min., 20 min., 30
min., 40 min., 50 min., 60 min., 80 min., 100
min., 120 min., 140 min. and 160 min. timer
programmes to achieve the desired nal dry-
ing level at low temperatures.
CWith this programme, the ma-
chine dries for the time selected
regardless of the dryness level.

19 / EN
Dryer / User Manual
5.6 Programme selection and consumption table
* : Energy Label standard programme (EN 61121:2012) “All the lters must be cleaned prior to
test series.”All values given in the table have been xed according to EN 61121:2012 Standard.
These values may deviate from the values in the table according to the laundry type, laundry
spin speed, environmental conditions and voltage uctuations.
EN
Programs Capacity (kg) Spin speed in washing ma-
chine (rpm)
Approximate
amount of re-
maining humidity
Drying time
(minutes)
Cottons / Coloreds
AExtra dry 7 1000 % 60 175
ACupboard dry 7 1000 % 60 156
AIron dry 7 1000 % 60 125
BabyProtect 31000 % 60 80
Shirt 1.5 1200 % 50 50
Jeans 41200 % 50 120
Daily 41200 % 50 90
Mixed 41000 % 60 115
Sport 41000 % 60 105
Express 11200 % 50 45
Delicates 2600 % 40 55
Wool Refresh 1.5 600 % 50 8
Synthetics
BCupboard dry 3.5 800 % 40 62
BIron dry 3.5 800 % 40 50
Energy consumption values
Programs Capacity (kg) Spin speed in washing ma-
chine (rpm)
Approximate
amount of re-
maining humidity
Energy con-
sumption value
kWh
Cupboard dry for cottons* 7 1000 % 60 2,15
Iron dry for cottons 7 1000 % 60 1,8
Cupboard dry for synthetics 3.5 800 % 40 0,8
Power consumption of the o-mode for the standart cotton programme at full load, PO (W) 0,5
Power consumption of the left-on mode for the standart cotton programme at full load, PL (W 1,0
Contains uorinated greenhouse gases covered by the Kyoto Protocol. Hermetically sealed. R134a/ 0,30 kg
„Cotton cupboard dry programme“ used at full and partial load is the standard
drying programme to which the information in the label and the fiche relates, that
this programme is suitable for drying normal wet cotton laundry and that it is the
most efficient programme in terms of energy consumption for cotton.

20 / EN Dryer / User Manual
5.7 Auxiliary functions
Audio Warning
The machine will give an audio warning
when the programme comes to an end. If you
do not want the machine give an audio warn-
ing, press the Volume Level button repeat-
edly until “x” appears on the display. Use the
same button to adjust the volume level.
CYou can activate this function
either before or after the pro-
gramme starts.
Cancel
audio warning
Audio warning
level 1
Audio warning
level 2
Audio warning
level 3
Dryness level
Used to adjust the required dryness level.
More drying is performed compared to the
default settings when “+” sign appears and
less drying is performed when “-” sign ap-
pears. Programme duration can change de-
pending on the selection.
CYou can activate this function
only before the programme has
started.
Anti-creasing
You can use Anti-creasing function to pre-
vent laundry from creasing if you will not
take the laundry out after the program has
come to an end. This program rotates the
laundry in every 240 second for 2 hours to
prevent creasing.
Anti-creasing is activated but the programme
is still running in the rst display image
below. Drying cycle is completed and the
Anti-creasing step has started in the second
display image.
CPress Anti-creasing button to
activate this function.
Changing the contrast
Adjust the display contrast in order to make
the symbols on the display appear clearer.
It may particularly be necessary to change
the contrast setting of the display when the
dryer is installed over a washing machine.
Press and hold the Spin Speed / Timer
Programme button for 3 seconds.
When the contrast is changed, all symbols on
the display will appear for 3 seconds in order
to indicate that the process is complete.
CPerform the same procedure to
revert back to the previous con-
trast setting.
5.8 Warning symbols
CWarning symbols may dier ac-
cording to the model of your
machine.
Lint filter cleaning
When the programme is completed, a warn-
ing symbol will appear to remind that the
lter needs to be cleaned.
CIf the Filter Cleaning symbol
ashes continuously, refer to
“Troubleshooting” section.
Water tank
When the programme is completed, a warn-
ing symbol will appear to remind that the
water tank needs to be drained.
If the water tank becomes full while the pro-
gramme is running, the warning symbol will
start to ash and machine will pause. Drain
the water in the water tank and press Start
/ Pause / Cancel button to resume the pro-
gramme. The warning symbol turns o and
the programme resumes operating.
