Beko EDF95243CSH2A User manual

EDF95243CSH2A
XDF95245CSH3BHST
EN / HU
Dryer
User Manual
Szárítór
Használati útmutató
2960313533_EN/120922.1710

Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product.
We hope that your product which has been
manufactured with high quality and technology
will give you the best results. We advise you
to read through this manual and the other
accompanying documentation carefully
before using your product and keep it for
future reference. If you transfer the product
to someone else, give its manual as well. Pay
attention to all details and warnings specified
in the user manual and follow the instructions
given therein.
Use this user manual for the model indicated
on the cover page.
• Read the instructions.
Explanation of symbols
Throughout this user manual the following
symbols are used:
BDANGER!
• Warning against electric shock.
DANGER!
• Warning against fire hazard.
AWARNING!
• Warning for hazardous situations with regard
to life and property.
WARNING!
• Warning against hot surfaces.
WARNING!
• Warning against scalding hazard.
CNOTE
• Important information or useful hints about
usage.
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations.
Do not dispose of the packaging wastes with
the domestic waste or other wastes, discard
them to the dedicated collection points
designated by the local authorities.

3
Dryer / User Manual
1 Important instructions for safety and environment
CNOTE
• This section contains safety
instructions that will help protect
from risk of personal injury or
property damage. Failure to follow
these instructions shall void any
warranty.
1.1 General safety
AWARNING!
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved. Children shall not
play with the appliance. Cleaning
and user maintenance shall not
be made by children without
supervision.
Children of less than 3 years should
be kept away unless continously
supervised.
• Adjustable feet should not be
removed. The gap between the
dryer and the floor should not be
reduced with materials such as
carpet, wood and tape. This will
cause problems with the dryer.
AWARNING!
Always have the installation and
repairing procedures carried
out by the Authorized Service.
Manufacturer shall not be held
liable for damages that may arise
from procedures carried out by
unauthorized persons.
• Never wash the dryer by spraying
or pouring water onto it! There is
the risk of electric shock!
For the products with a steam
function:
AWARNING!
• Use only distilled water or water
condensed in the water tank of the
machine in steam programs. Do
not use mains water or additives.
When using condensed water in the
water tank, it should be filtered and
cleared of fibres.
• Do not open the door when steam
programs are running. Hot water
may be expelled.
• Before putting laundry in a steam
program, stains on it should be
removed.
• You may only put laundry that is not
dirty or stained but permeated with
unpleasant odour in steam (odour
removal) program.
• Do not use any dry cleaning sets
or additional materials in a steam
program or in any program.

4 Dryer / User Manual
1.1.1 Electrical safety
BDANGER!
• Electrical safety instructions
should be followed while electrical
connection is made during the
installation.
• Connect the dryer to a grounded
outlet protected by a fuse at the
value specified on the type label.
Have the grounding installation
performed by a qualified electrician.
Our company shall not be liable for
any damages that will arise when
the dryer is used without grounding
in accordance with the local
regulations.
• The voltage and allowed fuse
protection is stated on the type label
plate.
• The voltage specified on the type
label must be equal to your mains
voltage.
• Unplug the dryer when it is not in
use.
• Unplug the dryer from the mains
during installation, maintenance,
cleaning and repair works.
• Do not touch the plug with wet
hands! Never unplug by pulling
on the cable, always pull out by
grabbing the plug.
AWARNING!
• The appliance must not be
supplied through an external
switching device, such as a timer,or
connected to a circuit that is
regularly switched on and off by
utility.
BDANGER!
• Do not use extension cords, multi-
plugs or adaptors to connect the
dryer to power supply in order to
decrease the risk of fire and electric
shock.
• Power cable plug must be easily
accessible after installation.
• Damaged mains cable should be
changed notifying the Authorized
Service.
• If the dryer is faulty, it must not be
operated unless it is repaired by an
authorized service agent! There is
the risk of electric shock!
1.1.2 Product safety
DANGER!
• Superheating of the clothes inside
of the dryer can occur if you cancel
the programme or in the event of
a power failure whilst the dryer is
running, this concentration of heat
can cause self-combustion and fire
so always activate the ventilation
programme to cool down or quickly
remove all laundry from the dryer in
order to hang them up and dissipate
the heat.
AWARNING!
• Ensure that the air inlet of the dryer
is open and it is well-ventilated.
• Product contains R290 refrigerant.
• R290 is an environment-friendly, but
flammable refrigerant.
• Keep the product away from
potential heat sources that may
cause it to ignite.

5
Dryer / User Manual
DANGER!
Points to be taken into
consideration for fire hazard:
Below specified laundry or items
must not be dried in the dryer
considering fire hazard.
• Unwashed laundry items
• Items soiled with oil, acetone,
alcohol, fuel oil, kerosene, stain
removers, turpentine, paraffin,
paraffin removers, petrol, wax or
wax removers must be washed in
hot water with plenty of detergent
before being dried in the dryer.
For this reason especially the items
containing the above specified
stains must be washed very well,
to do this use adequate detergent
and choose a high washing
temperature.
Below specified laundry or
items must not be dried in the
dryer due to the fire hazard:
• Garments or pillows bolstered with
rubber foam (latex foam), shower
bonnets, water resistant textiles,
materials with rubber reinforcement
and rubber foam pads.
Clothing cleaned with industrial
chemicals.
Items such as lighter, match,
coins, metal parts, needle etc. may
damage the drum set or may lead
to functional problems. Therefore
check all the laundry that you will
load into your dryer.
AWARNING!
Never stop your dryer before the
programme completes. If you must
do this, remove all laundry quickly
and lay them out to dissipate the
heat.
DANGER!
• Clothes that are washed
inadequately may ignite on their
own and even may ignite after
drying ends.
• You must provide enough ventilation
in order to prevent gases exiting
from devices operating with other
types of fuels including the naked
flame from accumulating in the
room due to the back fire effect.
AWARNING!
• Underwear that contains metal
reinforcements should not be dried
in the dryer. Dryer may be damaged
if metal reinforcements come loose
and break off during drying.
CNOTE
• Use softeners and similar products
in accordance with the instructions
of their manufacturers.
Always clean the lint filter before or
after each loading. Never operate
the dryer without the lint filter
installed.

6 Dryer / User Manual
AWARNING!
• Never attempt to repair the dryer
by yourself. Do not perform any
repair or replacement procedures
on the product even if you know
or have the ability to perform the
required procedure unless it is
clearly suggested in the operating
instructions or the published service
manual. Otherwise, you will be
putting your life and others’ lives in
danger.
• There must not be a lockable, sliding
or hinged door that may block the
opening of the loading door in the
place where your dryer is to be
installed.
• Install your dryer at places suitable
for home use. (Bathroom, closed
balcony, garage etc.)
• Make sure that pets do not enter the
dryer. Check the inside of the dryer
before operating it.
• Do not lean on the loading door of
your dryer when it is open, otherwise
it may fall over.
• The lint must not be allowed to
accumulate around the tumble dryer
• The tumble dryer is not to be used if
industrial chemicals have been used
for cleaning.
• Fabric softeners, or similar products.
should be used as specified by the
fabric softener instructions.
• Exhaust air must not be discharged
into a flue which is used for
exhausting fumes from appliances
burning gas or other fuels.
1.2 Mounting over a washing machine
• A fixing device should be used between
the two machines when installing the
dryer above a washing machine. The
fitting device must be installed by the
authorized service agent.
• Total weight of the washing machine
and the dryer -with full load- when
they are placed on top of each other
reaches to approx. 180 kilograms. Place
the products on a solid floor that has
sufficient load carrying capacity!
AWARNING!
• Washing machine cannot be placed on
the dryer. Pay attention to the above
warnings during the installation on your
washing machine.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm < 50 cm
54 cm Can be installed Cannot be
installed
60 cm Can be installed Cannot be installed
1.3 Intended use
• Dryer has been designed for domestic
use. It is not suitable for commercial
use and it must not be used out of its
intended use.
• Use the dryer only for drying laundry that
are marked accordingly.
• The manufacturer waives any
responsibility arisen from incorrect usage
or transportation.
• The service life of the dryer that you
purchased is 10 years. During this period,
original spare parts will be available to
operate the dryer properly.
1.4 Child safety
• Packaging materials are dangerous for
the children. Keep packaging materials
away from children.

7
Dryer / User Manual
• Electrical products are dangerous for the
children. Keep children away from the
product when it is operating. Do not let
them tamper with the dryer. Use the child-
proof lock in order to prevent the children
to tamper with the dryer.
CNOTE
Child-proof lock is on the control panel.
(See Child lock)
• Keep loading door closed even when the
dryer is not in use.
1.5 Compliance with the WEEE
Directive and Disposing of the Waste
Product:
This product complies with EU WEEE
Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and
electronic equipment (WEEE).
This symbol indicates that this
product shall not be disposed with
other household wastes at the end
of its service life. Used device must
be returned to offical collection
point for recycling of electrical and
electronic devices. To find these collection
systems please contact to your local authorities
or retailer where the product was puchased.
Each household performs important role in
recovering and recycling of old appliance.
Appropriate disposal of used appliance helps
prevent potential negative consequences for
the environment and human health.
.
DANGER!
• R290 is an flammable refrigerant. Thus,
ensure that the system and the pipes
are not harmed during operation and
handling.
• Keep the product away from potential
heat sources that may cause it to ignite in
case of damage.
• Do not dispose of the product by putting
it in fire.
1.6 Compliance with RoHS Directive
The product you have purchased complies
with EU RoHS Directive (2011/65/EU). It does
not contain harmful and prohibited materials
specified in the Directive.
1.7 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.
1.8 Technical Specifications
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 63,3 cm
Capacity (max.) 9 kg**
Net weight (± %10) 48 kg
Voltage
See type label***Rated power input
Model code
* Min. height: Height with adjustable feet are
closed.
Max. height: Height with adjustable feet are
opened maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading
door.
CNOTE
• Technical specifications of the dryer are
subject to specification without notice to
improve the quality of the product.
• Figures in this manual are schematic and
may not match the product exactly.
• Values stated on markers on the dryer
or in the other published documentation
accompanying with the dryer are
obtained in laboratory in accordance with
the relevant standards. Depending on
operational and environmental conditions
of the dryer, these values may vary.

8 Dryer / User Manual
2 Your Dryer
11
10
1
2
3
4
5
6
7
8
9
1. Top panel
2. Control panel
3. Loading door
2.1 Overview
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. In models where the tank is placed
below, the water tank is inside the toe board
8. Type label
9. Lint filter
10. Water tank drawer (in models where the
tank is placed above)
11. Power cord
2.2 Package Contents
1. Water
drain
hose *
6. Water
Filling
Container*
2. Filter
drawer
spare
sponge*
7. Pure
Water*
3. User
Manual
8.
Fragrance
Capsules
Group*
4. Drying
basket* 9. Brush*
5. Drying
basket
user
manual*
10. Filter
cloth*
*Optional - may not be included, depends on
model.

9
Dryer / User Manual
3 Installation • Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer will
be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer shall
be placed against a wall.
BDANGER!
Do not place the dryer on the power cable.
* Ignore following warning if
your product’s system does not
contains R290.
DANGER!
• Dryer contains R290 refrigerant.*
• R290 is an environment-friendly, but
flammable refrigerant.*
• Ensure that the air inlet of the dryer is
open and it is well-ventilated.*
• Keep potential flame sources away from
the dryer.*
3.2 Removing the transportation
safety assembly
AWARNING!
• Remove the
transportation
safety assembly
before using the
dryer for the first
time.
• If the door swing
side of your
appliance can
be modified, see
the reversible
door mounting
instructions.
Before the calling the nearest Authorized
Service for the installation of the dryer, ensure
that electrical installation and water drain is
appropriate referring to the user’s manual.
If they are not suitable, contact a qualified
electrician and technician to make necessary
arrangements.
CNOTE
• Preparation of the dryer’s location
as well as the electrical and waste
water installations is under customer’s
responsibility.
AWARNING!
• Prior to installation, visually check if the
dryer has any defects on it. If the drier
is damaged, do not have it installed.
Damaged products cause risks for your
safety.
• Let your dryer wait for 12 hours before
starting to use it.
3.1 Appropriate installation location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.

10 Dryer / User Manual
3.3 Connecting to the drain
You can directly drain accumulated water
through the water drain hose supplied with
the product instead of periodically draining the
water collected in the water tank.
Connecting the water drain hose
1
3 4
2
1-2 Pull hose at
the behind of
the dryer by
hand in order
to disconnect
it from where it
is connected.
Do not use
any tools to
remove the
hose.
3 Connect one end of the drain hose
supplied with the dryer to the connection
point from where you removed the hose of
the product in previous step.
4 Connect the other end of the drain hose
directly to the wastewater drain or to the
washbasin.
CNOTE
• Water drain hose should be attached to a
height of maximum 80 cm.
• Make sure that the water drain hose is not
stepped on and it is not folded between
the drain and the machine.
• If there is an accessories pack supplied
with your product, please see the detailed
description.
3.4 Adjusting the feet
• Turn the feet to
left or right until
the dryer stands
level and firmly.
3.5 Transportation of the dryer
Drain all water that has remained in the dryer.
If direct water drain connection is made, then
remove the hose connections.
AWARNING!
• We recommend carrying the dryer in
upright position. If it is not possible to
carry the machine in the upright position,
we recommend carrying it by tilting
towards the right side when looked from
the front.
3.6 Warnings about sounds
CNOTE
• It is normal to
hear a metallic
noise from the
compressor
sometimes during
operation.
• Water collected during operation is
pumped to water tank. It is normal to
hear pumping noise during this process.
3.7 Changing the illumination lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.The lamp(s) used in this
appliance is not suitable for household room
illumination. The intended purpose of this
lamp is to assist the user to place laundry in
the tumble dryer in a comfortable way. The
lamps used in this appliance have to withstand
extreme physical conditions such as vibrations
and temperatures above 50 °C

11
Dryer / User Manual
4 Preparation • For models with a condenser unit: clean
the condenser once in a month or after
every 30 operations regularly. .
• Clean the filter periodically.Read the
Maintenance and cleaning of filters for
detalied information.
• For models with flue unit: comply with the
flue connection instructions and clean the
flue.
• During the drying process, air the room
well where your tumble dryer is operating.
4.5 Correct load capacity
Follow the instructions
in the “Programme
selection and
consumption table”.
Do not load more than
the capacity values
stated in the table.
Following weights are given as examples.
Laundry Approximate
weights (g)* Laundry Approximate
weights (g)*
Cotton
quilt covers
(double) 1500 Blouses 150
Cotton quilt
covers (single) 1000 Cotton shirts 300
Bed sheets
(double) 500 Shirts 250
Bed sheets
(single) 350 Cotton dresses 500
Large
tablecloths 700 Dresses 350
Small
tablecloths 250 Jeans 700
Tea napkins 100 Handkerchiefs
(10 pieces) 100
Bath towels 700 T-Shirts 125
Hand towels 350
*Dry laundry weight before washing.
4.1 Laundry suitable for drying in the
dryer
Always obey the instructions given on the
garment tags. Dry only the laundry having a
label stating that they are suitable for drying in
a dryer.
4.2 Laundry not suitable for drying in
the dryer
Items with this symbol Do not dry
with dryer should not be
dried in the dryer.
CNOTE
• Delicate embroidered fabrics, woollen,
silk garments, delicate and valuable
fabrics, airtight items and tulle curtains
are not suitable for machine drying.
4.3 Preparing laundry for drying
• Laundry may be tangled with each other
after washing. Separate the laundry items
before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for energy
saving
• Spin your laundry at the highest speed
possible when washing them. Thus,
the drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type of
laundry together. For example thin kitchen
towels and tableclothes dries earlier than
thick bathroom towels.
• Follow the instructions in the user manual
for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must open the loading door, do not
keep it open for a long time.
• Do not add wet laundry while the dryer is
in operation

12 Dryer / User Manual
5 Running the product
5.1 Control Panel
5.3. Preparation of drying machine
• Plug the drying machine.
• Open the loading door.
• Place the laundry to the drying machine
without jamming them.
• Push and close the loading door.
AWARNING !
• Ensure that no
laundry is jammed
to the loading
door.
Filter
cleaning
Tank
full
Filter drawer /
Heat exchanger
cleaning
Start
pause
cancel
Iron Dry
Drying Buzzer Cupboard
Dry
Cupboard
Dry +
Extra dry End Anti-
creasing
Child-proof
lock
Low
temperature
TimeDry Ending In RapiDry
Drum
Light
Dryness
Level
Daily Delicates Synthetics
Towels Mix Cottons
Eco
Cottons Jeans Sport Bedding/
Duvet
Shirts Express Hygienic
Drying
Hygienic
Refresh
Steam Steam
Level1
Steam
Level2
On / O Wool Protect
Night
Freshen
Up
Outdoor
Hygiene
(Baby Protect+)
Environmentally
friendly lter full
Environmentally
friendly lter
Downwear Wi Remote
Control
Bluetooth Gentle
Dry
Reverse
Drum
4
5 6
32
7
8
9
1
1.On/Off/Program Selection button.
2.Start / Stand-by button.
3.Drum light button.
4.End time selection button.
5.Time program selection button.
6.Low temperature selection button.
7.Audible warning and child lock selection
button.
8.Wrinkle prevention selection button.
9. Dryness level selection button.
5.2 Symbols
• Select the desired program by using
On/Off/Program Selection button, the
machine will turn on.
CNOTE!
• Selecting the program with the On/Off/
Program Selection button does not mean
that the program started. Press Start /
Stand-by button to start the program.

13
Dryer / User Manual
5.4 Program selection and consumption chart
EN
Programmes Programme Description
Capacity (kg)
Spin speed
in washing
machine (rpm)
Drying Time
(minutes)
Cottons
You can dry your heat-resistant cotton textiles
with this programme. A drying setting suitable for
the thickness of the products to be dried and the
desired level of dryness should be selected.
9 1000 225
Cottons Eco It dries single layer, casual cotton textiles in the
most economical way. 9 1000 215
Cottons Iron dry You may dry your cotton laundry to be ironed in this program to have them slightly damp for ease
of ironing. (Shirt, T-shirt, tablecloth, etc.) 9 1000 159
Synthetics You can dry all your synthetic textiles with this programme. A drying setting suitable for the level
of dryness you desire should be selected. 4 800 80
Mix(Daily)
Use this programme to dry non-pigmenting
synthetic and cotton laundry items together.
Sports and fitness clothes may be dried with this
program.
4 1000 115
Wool protect
Use this programme to dry woolen garments
such as jumpers that are washed according to
the instructions.It is recomended that garments
would be removed at the end of the programme.
1,5 600 148
Night (silent)
In this programme the level of noise emitted
to the environment will be the lowest.With this
program you can dry your cotton or synthetic
blend clothes silently.
9 1000 240
GentleCare
You may dry your delicate laundry or laundry
with hand wash symbol (silk blouses, thin
underwear, etc.) at low temperature in this
program.
2 1200 50
Drying Rack/ TimeDry
You may select from time programmes
between 10 and 160 minutes to achieve the
desired drying level at low temperature. In this
programme, tumble drier’s operation lasts for
the set time independently from the dryness of
laundry. This product is available to be used with
a drying basket as option. For products that are
sold without a basket, you can obtain a basket
from an authorized service and use the drying
programs specified above. For details of use, see
the drying basket user guide.
- - -
Jeans You may dry denim pants, skirts, shirts or jackets
in this program. 4 1200 130
Outdoor/Sports (Goretex)
Use it to dry your clothes made of synthetics,
cotton or mixed fabrics or waterproof products
such as functional jacket, raincoat etc. Turn them
inside out prior to drying.
2 1000 135

14 Dryer / User Manual
Duvet/Downwear
You can dry your feather or fibre filled textile that
bears can be dried in drier label as a single piece
of laundry. You can dry double duvet, pillow or
coats as single piece of laundry. Dry your cloths
such as coats and jackets turned inside out.
- 800 165
Shirts It dries the shirts in a more sensitive manner, and
causes less creasing and easier ironing. 1,5 1200 50
Express Super Short Use this program to have 2 shirts ready for
ironing. 0,5 1200 30
Hygienic Drying
It is the programme that you can dry your
washed products you want to provide with extra
hygiene (baby clothes, underwear, towels, etc.).
It provides high hygiene for your textiles via heat
effect.
5 800 200
Hygienic Refresh
You can use this programme for your dry clothes
and laundry that you want to provide with
hygiene without washing them. It provides high
hygiene for your dry textiles via heat effect.
1,5 - 120
Energy consumption values
Programmes Capacity (kg)
Spin speed in
washing machine
(rpm)
Approximate
amount of remaining
humidity
Energy consumption
value kWh
Cottons Eco * 9 1000 60% 1,62
Cottons Iron dry 9 1000 60% 1,50
Synthetics cupboard dry 4 800 40% 0,60
"Cottons Eco programme" used at full and partial load is the standard drying programme to which
the information in the label and the fiche relates, that this programme is suitable for drying normal wet
Cottons laundry and that it is the most efficient programme in terms of energy consumption for Cottons.
* : Energy Label standard program (EN 61121) The values in the table are determined according to
the EN 61121 standard. Consumption values may vary from the valued in the chart depending on
laundry type, wringing speed, ambient conditions and voltage levels.

15
Dryer / User Manual
Allergy UK is the trademark of
the British Allergy Foundation.
The Seal of Approval has been
created to guide people
requesting an advice that the
product significantly reduces
the amount of the allergens in an
environment where allergic people are
present or the product restricts/reduces/
eliminates the allergens. The purpose is to
provide evidence that the products have
been scientifically tested or analysed to yield
measurable results.
5.5 Auxiliary functions
Dryness level
Dryness level button is used for adjusting
to desired dryness. Program time may change
depending on the selection.
CNOTE!
• You can activate this function only prior
to start of program.
Wrinkle prevention
You can turn on and off the wrinkle prevention
function by pressing the wrinkle prevention
selection button. If you will not take the
laundry out immediately after the program has
completed, you may use Wrinkle prevention
function to prevent wrinkling of your laundry.
Audible warning
Drying machine makes an audible warning
when the program is completed. Press the
“Audible Warning” button if you do not want
audible warning. When you press the audible
warning button, the light goes off and it does
not sound when the program is completed.
CNOTE!
• You can select this function before the
program starts or after the program
starts.
Low temperature
You can activate this function only prior to start
of a program. You can activate this function
if you want to dry your laundry at a lower
temperature. The program duration will be
longer after it becomes activated.
End time
You can delay the end time of the program up
to 24 hours with end time function.
1.Open the loading door and place the laundry.
2.Select the drying program.
3.Press the End Time selection button and set
the delay time you wish. End Time LED turns
on. (When pressed and hold the button, End
Time proceeds non-stop).
4.Press the Start / Stand-by button. End Time
countdown begins. The “:” sign in the middle of
displayed delay time flashes.
CNOTE!
• You can add or remove laundry within
end time. Displayed time is the sum
of normal drying time and end time.
End Time LED turns off at the end of
countdown, the drying starts and the
drying LED turns on.
Changing the end time
If you want to change the duration during the
countdown:
Pause the program and Turn the On/Off/
Program Selection button and cancel the
program. Select the desired program and
repeat the End Time selection.
Cancelling the end time function
If you want to cancel the end time countdown
and start the program immediately:
Pause the program and Turn the On/Off/
Program Selection button and cancel the
program. Select the desired program and press
the “Start/Pause” button.
Drum Light
You can turn on and off the drum light by
pressing this button. The light turns on when
the button is pressed and turns off after certain
time.
5.6 Warning indicators
CNOTE!
• Warning indicators may vary depending
on the model of your drying machine.
Filter cleaning
When the program is completed, the warning
indicator for filter cleaning turns on.

16 Dryer / User Manual
Water tank
If the water tank fills up while the program
continues, the warning indicator starts flashing
and the machine goes into stand-by. In this
case, empty the water tank and start the
program by pressing the Start / Stand-by
button. Warning indicator turns off and program
resumes.
Cleaning of filter drawer/
heat exchanger
Warning symbol flashes periodically to remind
that filter drawer must be cleaned.
5.7 Starting the program
Press the Start/Stand-by button to start the
program.
Start/Stand-by and Drying indicators turn on to
show that program started.
5.8 Child Lock
The drying machine has a child lock which
prevents the program flow from being
interrupted when the buttons are pressed
during a program. When the Child Lock is
activated, all buttons on the panel except
the On/Off/Program Selection button are
deactivated.
Press the Audible Warning button for 3
seconds in order to activate the child lock.
The child lock has to be deactivated to be
able to start a new program after the current
program is finished or to be able to interfere
with the program. To deactivate the child lock,
keep the same buttons pressed for 3 seconds.
CNOTE!
• When the child lock is activated, the child
lock warning indicator on the screen
turns on.
When the child lock is active:
The drying machine runs, or in stand-by state
the indicator symbols will not change upon
changing the position of the program selection
button.
CNOTE!
• When the drying machine is operating
and the child lock is activated, double
beep sound is heard when the program
selector switch is turned. If the child lock
is cancelled without turning the program
selector button back to its original
position, the program is terminated since
the program selector button is turned.
5.9 Changing the program
after it is started
You can change the program you selected to
dry your laundry with a different program after
the drying machine starts running.
• For example, Pause the program and turn
the On/Off/Program Selection button to
select the Extra Dry program in order to
select the Extra Dry program instead of
Ironing Dryness.
• Press the Start/Stand-by button to start
the program.
Adding and removing clothes during stand-by
If you want to add or remove clothes to/from
the drying machine after the drying program
starts:
• Press the Start/Stand-by button to put
the drying machine in Stand-by state. The
drying operation stops.
• Open the loading door while in Stand-
by state, and close the door after you
remove or add laundry.
• Press the Start/Stand-by button to start
the program.

17
Dryer / User Manual
CNOTE!
• Adding laundry after the drying operation
starts may cause the dried laundry inside
the drying machine to mix with wet
laundry and leave the laundry damp at
the end of operation.
• Adding or removing laundry during drying
may be repeated as many times as you
wish. But this operation continuously
interrupts the drying operation, and thus
increases program duration and energy
consumption. So, it is recommended to
add laundry before the program starts.
• If a new program is selected by turning
the program selection button while
the drying machine is in stand-by, the
running program terminates.
WARNING !
• Do not touch the inner surface of the drum
while adding or removing clothes during a
continuing program. The drum surface is hot.
5.10 Cancelling the program
If you want to cancel the program and
terminate the drying operation for any reason
after the drying machine starts running, Pause
the program and turn the On/Off/Program
Selection button; the program terminates.
AWARNING !
• The inside of the drying machine shall
be extremely hot when you cancel the
program during machine operation, so
run the refreshing program to allow it to
cool down.
5.11 End of program
When the program ends, the LED’s of End/
Wrinkle Prevention and Fibre Filter Cleaning
Warning on the program follow-up indicator
turn on. Loading door can be opened and
drying machine is ready for another operation.
Turn the On/Off/Program Selection button to
On/Off position in order to turn off the drying
machine.
CNOTE!
• If the Wrinkle Prevention mode is active
and the laundry is not removed after
the program is completed, the wrinkle
prevention function activates for 2 hours
to prevent the laundry inside the machine
to get wrinkled. The program tumbles
the laundry with 10-minute intervals to
prevent them from wrinkling.
5.12 Odour feature
If your drying machine has odour feature, read
the ProScent manual to use this feature.

18 Dryer / User Manual
6 Maintenance and cleaning
• Clean both filters under water running in
reverse direction of fibre accumulation
or with a soft brush. Dry the filter before
placing it back.
• Insert the fibre filters
on one another and
place it back in its
place.
• Clean the front door interior surface and its
gaskets with a soft damp cloth or with the
brush on air routing cover.
6.1 Loading Door Inner Surface
The hair and fibres that are separated from the
laundry during drying process is collected by
the Fibre Filter.
CNOTE
• Fibres are formed during wearing and
washing clothes.
• You can clean the filter slot with a
vacuum cleaner.
AWARNING!
• After each drying cycle, clean the fibre
filter and the inner surface of the loading
door.
To clean the fibre filter:
• Open the loading door.
• Hold the first part (inner filter) of the two
part fibre filter and remove it by pulling it
upwards.
• Collect the hair, fibres and cotton balls with
hand or with a soft cloth.
• Remove the second part (outer filter) by
pulling it upwards.
CNOTE
• Ensure that hair, fibre and cotton balls do
not fall into the slot where the filters are
installed.
• Open both filters (top and bottom filters)
and to remove the lint with your hand, or
use cleaning brush at air routing cover. And
if necessary, use a vacuum cleaner to clean
filters.

19
Dryer / User Manual
6.2 Cleaning the sensor
There are
dampness sensors
in the dryer that
detect whether
the laundry is dry
or not.
To clean the
sensors:
• Open the loading door of the dryer.
• Allow the machine to cool down if it is still
hot due to the drying process.
• Wipe the metal surfaces of the sensor
with a soft cloth, dampened with vinegar
and dry them.
CNOTE
• Clean metal surfaces of the sensors 4
times a year.
• Do not use metal tools when cleaning
metal surfaces of the sensors.
AWARNING!
• Never use solvents, cleaning agents or
similar substances for cleaning due to the
risk of fire and explosion!
6.3 Draining the water tank
Dampness of the laundry is removed and
condensed during drying process and the
water that arise accumulates in the water tank.
Drain the water tank after each drying cycle.
AWARNING!
• Condensed water is not drinkable!
• Never remove the water tank when the
program is running!
If you forget to drain the water tank, the
machine will stop during the subsequent drying
cycles when the water tank is full and the Water
Tank warning symbol will flash. If this is the
case, drain the water tank and press Start /
Pause button to resume the drying cycle.
To drain the water tank:
1. Remove the water tank in the drawer
or container carefully.
2. Drain the water in the tank.
• If there is lint accumulation in the funnel
of the water tank, clean it under running
water.
• Place the water tank into its seat.
CNOTE
• If the direct water draining is used as an
option, there is no need to empty the
water tank.
6.4 Cleaning the Condenser
Small amount of lint may pass through the lint
filter and be collected on the metal surface of
the condenser.
Condenser metal surface needs to be cleaned
regularly.
If the evaporator icon is flashing on the display,
please inspect the metal surface of the
condenser. If it is dirty, clean it. This part should
be checked at lease once every 6 months.
• Open the toe
board by pressing
on it.

20 Dryer / User Manual
• To open the air
routing door, move
the release latch.
• Pull the brush to
the left side and
remove it. You can
use the cleaning
brush for removing
collected fluff on the
metal surface of the
condenser.
CNOTE
• Brush is inside the printing materials bag.
You can place it in its housing on the air
routing cover after the first usage.
• Collected fluff
on condenser
surface should
be removed by
a damp cloth or
rubbing the brush
placed on the air
routing cover up
and down on the
condenser.
• Please do not
clean condenser
fins in right-left
direction to avoid
damage.
• You can also use
a vacuum cleaner
with a brush
for cleaning.
Condenser
cleaning is not
recommended
with a brushless
vacuum cleaner.
• Insert the brush
into its slot pushing
to the right, after
cleaning condenser,
front cover and lint
filter.
• After the cleaning
process is
completed, place
the air router door
to its place, move
the latches to close
it and close the toe
board.
AWARNING!
• You can clean by hand, provided you wear
protective gloves. Do not try to clean with
bare hands. Condenser fins may damage
your hands. Cleaning by the left to right
movements may damage the condenser
fins. This may lead to drying issues.
AWARNING!
• It is normal to see some water on the
plastic surface in front of the condenser
when you open the air routing cover.
