Beko METPOINT UD01 User manual
METPOINT®UD01
EN - English
10-148
Plug-on display for METPOINT®transducer
Installation and operating manual
Installation and operating manual EN
2 METPOINT®UD01
EN Installation and operating manual
METPOINT®UD01 3
Contents
1. Safety instructions .......................................................................................................................................... 4
1.1. Pictograms and symbols ........................................................................................................................... 4
1.2. Signal words.............................................................................................................................................. 4
1.3. General safety instructions........................................................................................................................ 5
2. Product information ........................................................................................................................................ 6
2.1. Intended use.............................................................................................................................................. 6
2.2. Type plate.................................................................................................................................................. 6
2.3. Technical data ........................................................................................................................................... 7
2.4. Dimensions................................................................................................................................................ 8
2.5. Scope of delivery....................................................................................................................................... 8
2.6. Transport and storage ............................................................................................................................... 9
2.7. Control and display elements .................................................................................................................. 10
2.8. Menu control............................................................................................................................................ 10
2.9. Password protection................................................................................................................................ 11
2.10. Menu layout........................................................................................................................................... 11
2.11. Unit ........................................................................................................................................................ 12
2.12. Menu list ................................................................................................................................................ 12
2.12.1. Special menus............................................................................................................................ 14
3. Installation...................................................................................................................................................... 15
3.1. Installation ............................................................................................................................................... 15
4. Electrical installation..................................................................................................................................... 16
4.1. Connection to power supply .................................................................................................................... 17
4.2. Power supply for METPOINT®DPM SD21 2-wire transducer................................................................. 17
4.3. Power supply for METPOINT®DPM SP21 2-wire transducer................................................................. 17
5. Commissioning.............................................................................................................................................. 18
6. Decommissioning.......................................................................................................................................... 18
7. Maintenance and servicing........................................................................................................................... 18
7.1. Cleaning .................................................................................................................................................. 18
8. Troubleshooting and repair .......................................................................................................................... 18
9. Dismantling and disposal............................................................................................................................. 18
10. Declaration of Conformity .......................................................................................................................... 19
Installation and operating manual EN
4 METPOINT®UD01
1. Safety instructions
1.1. Pictograms and symbols
General instruction
Observe installation and operating instructions
Observe installation and operating instructions
(on type plate)
General hazard symbol (danger, warning, caution)
1.2. Signal words
DANGER Imminent danger
Consequences of non-compliance: serious or even fatal injury
WARNING Potential danger
Consequences of non-compliance: serious or even fatal injury
CAUTION Imminent danger
Consequences of non-compliance: injury and/or damage to property
NOTE Additional notes, tips and hints
Consequences of non-compliance: inecient operation, extra maintenance work.
No risk to persons.
EN Installation and operating manual
METPOINT®UD01 5
1.3. General safety instructions
NOTE Installation and operating manual
Before reading this manual, make sure that it refers to your device model. This document
contains important information and instructions for the safe operation of the device. Before
carrying out any work with or on the device, all specialist technical personnel ¹ must have
read this manual.
A copy of this installation and operating manual must be kept near the device where it is at
all times accessible to sta.
In addition to the instructions in this document, always comply with the statutory regulations
for machine operation, accident prevention and safety. This also applies to the use of
accessories and spare parts.
DANGER Insucient qualication
Improper handling and operation of the device can result in serious or even fatal injury, and/
or damage to property.
• All tasks described in this installation and operating manual must be performed by
specialist technical personnel1who meet the following criteria:
• Before carrying out any work with or on the device, all specialist technical personnel¹
must have read and understood the contents of this installation and operating manual.
It is the responsibility of the owner of the device to ensure that the above requirement is
complied with.
1 Specialist technical personnel
Specialist technical personnel are persons who, due to their professional qualication and knowledge in the eld
of measuring, control and pneumatic technology, and their knowledge of the applicable statutory regulations,
guidelines and standards are in a position to foresee potential dangers in relation to the use of the device and who
are qualied to perform the tasks described in this manual. Special operating conditions (e.g. aggressive media)
require additional knowledge.
DANGER Operation of device outside limit range
If the specied limits are exceeded, there is a risk of device malfunction, potentially resulting
in injury and damage to materials.
• The device must only be operated for the intended purpose and within the permissible
limits specied on the type plate and in the technical data.
Installation and operating manual EN
6 METPOINT®UD01
2. Product information
2.1. Intended use
The METPOINT®UD01 plug-on display is compatible with all 4 ... 20 mA transducers equipped with a 2-wire
analogue output. It is designed for installation between the transducer and the cable box and is instantly ready
for use. The METPOINT®UD01 is freely programmable using a menu system operated by two buttons. The
programmed parameters are stored in EEPROM so that they are not lost in the event of a power failure. A dialogue
warning is displayed if the limits at either end of the range are exceeded. The integrated diagnostic system
continuously monitors all display functions.
The device is not suitable for operation in potentially explosive atmospheres
and must only be used for the intended use. The manufacturer shall not be liable for damage caused by improper
use or unauthorised modication of the device. Any such use or modication shall void all warranty.
2.2. Type plate
The type plate is attached to the device housing. It contains all relevant technical data of the METPOINT® UD01
plug-on display. Please have these details to hand when contacting the manufacturer or supplier. The operating
system software version (e.g. P07) of the device is displayed for approx. 1 second on the display after switching on.
Please note down the version code to have it to hand for any queries.
METPOINT® UD01 Product description
S/N Serial number
P/N Product number
PIN 1: +UvVoltage input (+Uv)
PIN 3: IOUT Current output (IOUT)
Input/output: 4 ... 20mA / 2-wire Input/output signal
Supply voltage: +Uv=24 VDC Power supply
NOTE Type plate
Do not remove or cover the type plate and protect it against damage.
EN Installation and operating manual
METPOINT®UD01 7
2.3. Technical data
Input and output signals
Input and output signal: 4 ... 20 mA (2 conductors)
Electrical protection:
Short-circuit resistance: permanent
Polarity reversal protection: No damage, no function
Electromagnetic compatibility: Emitted interference and interference resistance ac-
cording to EN 61326
Safety limits: Ui = 28 V, ∑Ii = 93 mA, ∑Pi = 660 mW
Display
Type: Four-digit red LED display, digit height 7 mm, digit width
4.85 mm
Range: -1999 ... +9999
Accuracy: 0.1 % ± 1 digit
Digital attenuation: 0.3 ... 30 s (programmable)
Display update frequency: 0.0 ... 10 s (programmable)
Mechanical resistance:
Vibration 5 g RMS (20 ... 2000 Hz)
Shock: 100 g / 11 ms
Temperature range
Operating ambient temperature: -25 ... 85 °C
Storage and transport temperature: -40 ... 85 °C
Materials
Display housing: PA 6.6, polycarbonate
Miscellaneous
Weight: approx. 100 g
Data memory: EEPROM, non-volatile
Protection category: IP 65
Installation and operating manual EN
8 METPOINT®UD01
2.4. Dimensions
Dimensions in mm
2.5. Scope of delivery
Figure Description
Plug-on display
MPa
mbar
°Ctd°C
barPSI Pa
°Ftd °F
hPa
Unit label sheet
Installation and operating manual
Connecting cable
EN Installation and operating manual
METPOINT®UD01 9
2.6. Transport and storage
Despite our best eorts regarding packaging, etc., the device is susceptible to damage during transport. Upon
receipt, please remove all packaging material and inspect the device for visible damage. If you detect any such
damage, immediately notify the carrier company and BEKO TECHNOLOGIES GMBH or one of its agents.
CAUTION Damage caused during transport or storage
Incorrect transport or storage, or the use of unsuitable lifting equipment might cause damage
to the device.
• The device must only be transported and stored by authorised and suitably trained
specialist technical personnel.
• If you detect any damage, do not start the device.
• Always adhere to the specied transport and storage temperatures.
To store the device, place it in its original
packaging and store it in an enclosed, dry
and frost-free room. Ensure that the storage
temperature does not exceed the limits
specied on the type plate.
Even when packaged, take suitable
measures to protect the device against the
elements.
While in storage, secure the device so that
it cannot topple over or fall, and protect it
against vibration.
NOTE Recycling of packaging material
• The packaging material is recyclable. Dispose of the packaging material according to the
applicable statutory regulations.
Installation and operating manual EN
10 METPOINT®UD01
2.7. Control and display elements
The measured value is displayed on a 4-digit, 7-segment display panel that is also used to congure the device.
MPa
mbar
°Ctd°C
barPSI Pa
°Ftd °F
hPa
Area for unit label
4-digit 7-segment display
Miniature push buttons
2.8. Menu control
The device menu is operated through the miniature push buttons. All settings are stored in EEPROM and thus
remain available even after a power failure.
• Menu >>▲<< UP
• Increase displayed value
• Menu >>▼<< DOWN
• Reduce displayed value
The stepping speed for the adjustment of the displayed value can be increased by pressing and holding the
respective push button for minimum 5 seconds.
+
• Confirm set value
• Change between configuration and display mode
• Open selected value
After adjusting the parameter value, conrm the entry and exit the respective menu. The new parameter value is
now applied.
EN Installation and operating manual
METPOINT®UD01 11
2.9. Password protection
The device menu is password-protected.
Factory-set password: 0005
Enable/disable password protection: see >>Menu 1<<
Change password: see >>Special menu 4<<
Reset password: see >>Special menu 3<<
2.10. Menu layout
Display mode
(measured value is
displayed)
Password protection
/ access to
special menus
Menu 1:
PAon / PAof
Special menu 1:
Span correction
FS S
Code no.: 0238
Measured
value update
(display)
Menu19: dLdS
Minimum
value display
Menu18:LoPr
Zero point
Menu3: ZP
End point
Menu4: EP
Attenuation
Menu5: FILt
Exceedance
signal
Menu6: HILo
Maximum value
display
Menu17:HIPr
PA of -
Password disabled
Decimal point
position
Menu2: dP
PA on -
Password enabled
Special menu 2:
Offset correction
oF S
Code no.: 0247
Special menu 3:
Default settings
LoAd
Code no.: 0729
Special menu 4:
Password
SEtP
Code no.: 0835
Installation and operating manual EN
12 METPOINT®UD01
2.11. Unit
The unit of the displayed value is factory-set and indicated on the area where the unit label can be placed.
2.12. Menu list
Menu 1 – Password protection
If password protection is enabled, "PAon" is shown on the display.
To disable password protection: Simultaneously press >>▲<< and
>>▼<< to conrm menu option "PAon". Then press >>▲<< or >>▼<<
to enter the password and conrm by pressing both buttons. Password
protection is now disabled and "PAof" is shown on the display.
If password protection is disabled, "PAof" is shown on the display.
To enable password protection: Simultaneously press >>▲<< and >>▼<<
to conrm menu option "PAof". Then press >>▲<< or >>▼<< to enter the
password and conrm by pressing both buttons. Password protection is now
enabled and "PAon" is shown on the display.
The factory-set password is "0005".
The password can be changed in special menu 4.
Menu 2 – Setting decimal point position
Simultaneously press >>▲<< and >>▼<< to conrm menu option "dP". Then
press >>▲<< or >>▼<< to set the decimal point to the correct position and
conrm by pressing both buttons.
Menu 3 – Setting zero point
Simultaneously press >>▲<< and >>▼<< to conrm menu option "ZP".
Then press >>▲<< or >>▼<< to set the zero point and conrm by pressing
both buttons.
The set value is displayed when the electric output signal of the transducer is
4 mA (zero point).
Menu 4 – Setting end point
Simultaneously press >>▲<< and >>▼<< to conrm menu option "EP".
Then press >>▲<< or >>▼<< to set the end point and conrm by pressing
both buttons.
The set value is displayed when the electric output signal of the transducer is
20 mA (end point).
Menu 5 – Setting attenuation (lter)
Simultaneously press >>▲<< and >>▼<< to conrm menu option "FILt".
Then press >>▲<< or >>▼<< to set the time constant of the analogue low-
pass lter and conrm by pressing both buttons.
Value range: 0.3 ... 30 s
This parameter ensures constant display, even if the measured values
uctuate greatly.
Menu 6 – Enabling/disabling range exceedance alarm
Enable/disable alarm: Simultaneously press >>▲<< and >>▼<< to conrm
menu option "HILo". Then press >>▲<< or >>▼<< to set the exceedance
alarm function to "on" or "o" and conrm by pressing both buttons.
EN Installation and operating manual
METPOINT®UD01 13
Menu 17 – Maximum value display
Simultaneously press >>▲<< and >>▼<< to conrm menu option "HIPr".
The highest value measuring during the current measuring series is
displayed.
Reset maximum value: Simultaneously press >>▲<< and >>▼<< within 1
second
after conrmation of the menu option.
The maximum value is automatically reset when the device is de-energized.
Menu 18 – Minimum value display
Simultaneously press >>▲<< and >>▼<< to conrm menu option "LoPr".
The lowest value measuring during the current measuring series is
displayed.
Reset minimum value: Simultaneously press >>▲<< and >>▼<< within 1
second
after conrmation of the menu option.
The minimum value is automatically reset when the device is de-energized.
Menu 19 – Measured value update (display)
Simultaneously press >>▲<< and >>▼<< to conrm menu option "dLdS".
Press >>▲<< and/or >>▼<< to set the time interval for the update of the
display and conrm by simultaneously pressing the two buttons.
Value range: 0 ... 10 s
Installation and operating manual EN
14 METPOINT®UD01
2.12.1. Special menus
The special menus can be accessed through menu 1.
All settings described below must be made in menu 1.
Special menu 1 – Display correction for deviating span signal (span
correction). To correct the display in the event of a deviating span, press
>>▲<< and >>▼<< to set the display value to "0238". Conrm by pressing
the two buttons simultaneously. "FS S" is shown on the display. Pressurize
the device with a reference pressure that corresponds to the upper
measuring range end point value. Press the two buttons again to save the
current output signal from the transmitter as the span signal. From now on,
the display shows the set end point value, although the sensor signal is
oset from the span signal.
Please note that the output signal is not aected by this conguration.
Special menu 2 – Zeroing display in the event of a deviating oset
(oset correction)
To zero the display in the event of a deviating oset, press >>▲<< and
>>▼<< to set the display value to "0247". Conrm by pressing the two
buttons simultaneously. "of S" is shown on the display. If the oset deviates
from the ambient pressure, pressurise the device with a reference pressure
that corresponds to the lower measuring range end point value. Press the
two buttons again to save the current output signal from the transmitter as
the oset signal. From now on, the display shows the set end point value
(zero point), although the sensor signal is oset from the span signal. Please
note that the output signal is not aected by this conguration. This oset
correction also results in an oset of the span value (full scale).
Special menu 3 – Resetting to factory settings (loading defaults)
To load the default settings, press >>▲<< and >>▼<< to set the display to
value "0729". Conrm by pressing the two buttons simultaneously. Conrm
again by pressing the two buttons simultaneously.
When the default values (factory settings) are loaded, all previously made
adjustments, the recorded measuring results and the password are reset.
Special menu 4 – Changing password
To change the password, press >>▲<< and >>▼<< to set the display to
value "0835". Conrm by pressing the two buttons simultaneously. Then
press >>▲<< or >>▼<< to enter the new password and conrm by pressing
both buttons.
Value range: 0 ... 9999
NOTE The values below are already assigned and can-
not be used as passwords:
0238, 0247, 0729 and 0835
EN Installation and operating manual
METPOINT®UD01 15
3. Installation
NOTE Risk of damage to device
• Before installing and connecting the device, ensure that the entire system is de-energized.
• Never exceed the rotation and tightening limits of the components.
3.1. Installation
1. Screw the plug-on display (2) onto the compatible transducer (3).
2. Screw the cable box (1) onto the plug-on display (2).
1
2
3
Installation and operating manual EN
16 METPOINT®UD01
4. Electrical installation
For the electrical installation, refer to the table and wiring diagrams below.
Electrical connections
Diagram Pin assignment
1 – power supply (+) 24V DC
2 – not assigned
3 – power supply (-) 0V or GND
4 – not assigned
5 – ground
1 – power supply (+) 24V DC
Wire colour: BROWN
3 – power supply (-) 0V or GND
Wire colour: BLUE
EN Installation and operating manual
METPOINT®UD01 17
4.1. Connection to power supply
The voltage drop caused by the electronics in the device is approx. 6 VDC. This must be taken into account when
dimensioning the power supply. The limit values are calculated as follows:
Minimum operating voltage: UB min =Umin MU + 6 V
Maximum operating voltage: UB max=Umax MU + 6 V
Key:
Umin MU = minimum operating voltage of installed 2-wire transducer
Umax MU = maximum operating voltage of installed 2-wire transducer
4.2. Power supply for METPOINT®DPM SD21 2-wire transducer
4.3. Power supply for METPOINT®DPM SP21 2-wire transducer
RL
td,f
METPOINT ®
DPM SD21
METPOINT ®
UD01
V
U
V
+ U
OUT
+ I +--
+
4 ... 20 mA
I
4 ... 20 mA
1
3
4
2
1
3
RL
p
METPOINT ®
PRM SP21
METPOINT ®
UD01
V
U
V
+ U
OUT
+ I +--
+
4 ... 20 mA
I
4 ... 20 mA
1
3
4
2
1
3
Installation and operating manual EN
18 METPOINT®UD01
5. Commissioning
After the METPOINT®UD01 plug-on display has been correctly installed and connected, it is ready for operation.
6. Decommissioning
To decommissioning the plug-on display, disconnect it from the power supply, remove it from the transducer by
performing the installation steps in reverse order and dispose of it according to the disposal instructions in chapter
“9. Dismantling and disposal”, page 18.
7. Maintenance and servicing
The plug-on display does not need any maintenance. From time to time, it might need to be cleaned as described
below.
7.1. Cleaning
To clean the METPOINT®UD01 plug-on display, use a damp (but not wet) cotton cloth or disposable tissue and a
mild conventional detergent.
Spray a little detergent onto the clean cotton cloth or tissue and carefully wipe the component. Dry it with a clean
cloth. Observe all hygiene instructions application on site.
NOTE Damage caused by improper cleaning
Cleaning with a wet cloth, pointed implement or aggressive detergent can cause damage to
the plug-on display and its electronic components.
• Never clean the device with a wet cloth.
• Do not use aggressive detergents.
• Do not clean the display with a pointed or sharp-edged implement
8. Troubleshooting and repair
In the event of a malfunction of the device, return it to the manufacturer for repair. Clean the device carefully and
pack it so that it is protected against impact. Return the device to the manufacturer, enclosing a return declaration
with a detailed description of the error/malfunction. If your device has come into contact with a hazardous
substance, also enclose a declaration of decontamination. The relevant templates can be downloaded from our
homepage at www.beko-technologies.de. If your device arrives at our service workshop without a declaration of
decontamination, and should our personnel be concerned about any media with which it might have come into
contact, we will contact you. A repair will only be performed after we have received the relevant declaration of
decontamination. If the device has been exposed to a hazardous substance, take all necessary safety precautions
when cleaning it!
9. Dismantling and disposal
Dispose of the device according to the European Directives 2002/96/EC and 2003/108/EC (waste electrical and
electronic equipment (WEEE)). Never dispose of it with normal household waste!
If the device has been in contact with a hazardous substance, it might need to be disposed of through a specialist
hazardous waste disposal contractor!
EN Installation and operating manual
METPOINT®UD01 19
10. Declaration of Conformity
Installation and operating manual EN
20 METPOINT®UD01
BEKO TECHNOLOGIES GMBH
Im Taubental 7
41468 Neuss, GERMANY
Phone: +49 2131 988
-0
www.beko
-technologies.com
CE_UD01-857-0416-FP-A
EU Declaration of Conformity
We hereby declare that the products indicated hereafter comply with the stipulations of the relevant directives
and technical standards. This declaration only refers to products in the condition in which they have been
placed into circulation. Parts which have not been installed by the manufacturer and/or modifications which
have been implemented subsequently remain unconsidered.
Product designation:
METPOINT® UD01
Type:
4032114
Display range:
-1999 … +9999
Supply voltage:
24 VAC
Max. supply voltage:
30 VAC
Min./max. ambient temperature:
-25°C / +85°C
Degree of protection
IP65
Drawing no.:
UD02_ALG_R00
Data sheet:
DB_UD01-0515-FP-A
Product description and function:
Plug-on display for METPOINT transducers
EMC Directive 2014/30/EU
Applied harmonized standards:
EN 61326-1:2013
RoHS II Directive 2011/65/EU
The products meet the requirements laid down in European Directive 2011/65/EU concerning the restriction
of the use of certain hazardous substances in electrical and electronic devices.
The products bear the CE Mark:
This Declaration of Conformity has been issued by the manufacturer.
Neuss, 20/04/2016 Signed:
BEKO TECHNOLOGIES GMBH
i.V. Christian Riedel
Head of International Quality Management
Table of contents
