Beko BK 7120 T User manual

BK 7120 T
BK 7121 T
Refrigerator

EN
2
Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimise its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
Recycling

EN
3
1 The refrigerator 4
2 Important Safety
Warnings 5
3 Installation 9
Preparation........................................ 9
Points to be considered when re-
transporting your refrigerator .............9
Adjusting the legs .............................. 9
Placing your refrigerator under the
counter (for model BK 7120 T)......... 10
Before operating your refrigerator .... 11
Electric connection .......................... 11
Disposing of the packaging ............. 12
Disposing of your old refrigerator ..... 12
Changing the illumination lamp ....... 12
Changing the door opening direction 12
CONTENTS
4Using your refrigerator 13
Thermostat setting button................13
Defrost ............................................ 13
5 Cleaning and care 15
Protection of plastic surfaces .......... 15
6 Recommended solutions
for the problems 16

EN
4
1The refrigerator
1- Freezer compartment
2- Bulb and thermostat box
3- Wire shelves
4- Water drain stick
5- Crisper glass
6- Crisper
7- Adjustable legs
8- Removable upper tray (BK 7120 T)
9- Door shelves
10- Egg tray
11- Bottle shelf
* (in model BK 7120 T)
*
*
5
6
3
7
4
1
2
11
9
10
9
8
C Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the product
you have purchased, then it is valid for other models.

EN
5
2Important Safety Warnings
Please review the following
information. If these are not
followed, personal injury or material
damage may occur. Otherwise,
all warranty and reliability
commitments will become invalid.
The usage life of the unit you
purchased is 10 years. This is the
period for keeping the spare parts
required for the unit to operate as
described.
Intended use
• This product is designed for
domestic use.
• It should not be used outdoors. It
is not appropriate to use it outdoor
even if the place is covered with a
roof.
General safety
• When you want to dispose/scrap
the product, we recommend you
to consult the authorized service
in order to learn the required
information and authorized bodies.
• Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene
to the refrigerator without notifying
the authorised services.
• Do not eat cone ice cream and
ice cubes immediately after you
take them out of the freezer
compartment! (This may cause
frostbite in your mouth.)
• Do not put bottled and canned
liquid beverages in the freezer
compartment. Otherwise, these
may burst.
• Do not touch frozen food by hand;
they may stick to your hand.
• Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes
of your refrigerator. In such cases,
the vapor might get in contact with
the electrical parts and cause short
circuit or electric shock.
• Never use the parts on your
refrigerator such as the door and
drawer as a means of support or
step. You may cause the product
to tip over or parts of it get
damaged.
• Do not use electrical devices inside
the refrigerator.
• Do not damage the cooling circuit,
where the refrigerant is circulating,
with drilling or cutting tools. The
refrigerant that might blow out
when the gas channels of the
evaporator, pipe extensions or
surface coatings are punctured
may cause skin irritations and eye
injuries.
• Do not cover or block the
ventilation holes on your
refrigerator with any material.
• Repairs of the electrical products
must only be made by qualified
persons. Repairs performed by
incompetent persons may create a
risk for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s
mains supply by either turning off
the relevant fuse or unplugging
your appliance.
• Do not pull by the cable when
pulling off the plug.

EN
6
• Place the beverage with higher
proofs tightly closed and vertically.
• Flammable items or products that
contain flammable gases (e.g.
spray) as well as the explosive
materials should never be kept in
the product.
• Do not use mechanical devices
or other means to accelerate
the defrosting process, others
than those recommended by the
manufacturer.
• This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use
of the appliance by a person
responsible for their safety.
• Do not operate a damaged
refrigerator. Consult your service if
you have any doubts.
• Electrical safety of your refrigerator
shall be guaranteed only if the
earth system in your house
complies with standards.
• Exposing the product to rain,
snow, sun and wind is dangerous
with respect to electrical safety.
• If there is any problem with the
power cable or the plug, they must
be replaced by the authorised
service in order to avoid any
accidents.
• Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
• Intended use of the product is to
preserve foods; it should never be
used for other purposes.
• Rating plate containing product's
technical specifications is in the
inner left part of the product.
• Connecting the product to electric
energy saving systems is risky
as it may cause damage on the
product.
• If your product is equipped with
blue light, the light should not be
looked into by optical appliances.
• In products with mechanical
control (thermostat), wait for 5
min. to re-plug the product if it is
unplugged.
• This operation manual should be
handed in to the new owner of the
product when it is given to others.
• Power cable and plug should not
be damaged when moving the
refrigerator. To avoid risk of fire, the
cable should not be kinked or put
under heavy things. Do not touch
the plug with wet hands when
plugging the product.
• The product should not be
plugged if the receptacle is loose.
• Water should not be sprayed
directly on inner or outer parts of
the product for safety purposes.
• Flammable pressurized sprays
should not be sprayed near the
product to avoid risk of fire or
explosion.

EN
7
• Containers with liquid inside
should not be placed on top of
the product. Spilling water on an
electrical component may cause
electric shocks or risk of fire.
• Foods more than the capacity of
the product should not be kept in
the product. It may fall when the
door is opened, and cause injury
or damage. Similar problems may
occur in case of putting things on
the product.
• Products that need a precise
temperature control (vaccines,
heat-sensitive medicine, scientific
materials, etc.) should not be kept
in the refrigerator.
• Refrigerator should be
disconnected if it is not going to be
used for a long time. Any problem
in the cable insulation may cause
fire.
• Dirt and dusts on tip of the electric
plug must be cleaned, otherwise,
they may cause risk of fire.
• The product may move when level
adjustment feet of the product do
not stand on the floor well.
• If your product has a door handle,
the product must not be pulled by
the handle, because the handle
may be forced out.
• Care should be paid as there is
risk of squeezing hands or feet
between the movable parts inside
the product.
• When you need to operate
your refrigerator next to another
refrigerator, leave at least 8
cm distance between two
refrigerators. If you leave a shorter
distance, condensation may
arise on the side walls of your
refrigerator.
• Water mains pressure must not be
below 1 bar. Water mains pressure
must not be above 8 bar.
• Use only potable water.
Child safety
• If the door has a lock, the key
should be kept away from reach of
children.
• Children should be supervised to
ensure that they do not play with
the appliance

EN
8
HCA Warning
If your product is equipped with a
cooling system that contains
R600a:
This gas is flammable. Therefore,
pay attention to not damaging
the cooling system and piping
during usage and transportation.
In the event of damage, keep
your product away from potential
fire sources that can cause the
product catch a fire and ventilate
the room in which the unit is
placed.
Ignore the warning if your product is
equipped with a cooling system
that contains R134a.
You can see the gas used in
production of your product on the
rating plate that is located on the
left inner part of it.
Never dispose the product in fire.
Things to be done
for energy saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in
your refrigerator.
• Do not overload your refrigerator
so that the air circulation inside of
it is not prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators.
• Pay attention to keep your food in
closed containers.
• In order to load maximum amount
of food in your refrigerator's
freezer compartment, place the
food onto the wire shelves instead
of the drawer and remove the
upper cover. Maximum power
consumption with maximum
amount of food as described
above has been measured and
indicated on the energy label.
Depending on the shape of the
food to be frozen, there is no
inconvenience in using the drawers
and upper shelf cover.

EN
9
3Installation
Points to be considered
when re-transporting your
refrigerator
1. Your refrigerator must be
emptied and cleaned prior to any
transportation.
2. Shelves, accessories, crisper and etc.
in your refrigerator must be fastened
securely by adhesive tape against any
jolt before repackaging.
3. Packaging must be tied with thick
tapes and strong ropes and the
rules of transportation printed on the
package must be followed.
Please do not forget…
Every recycled material is an
indispensable source for the nature
and for our national resources.
If you wish to contribute to recycling
the packaging materials, you can
get further information from the
environmental bodies or local
authorities.
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning the front legs of it as illustrated in
the figure. The corner where the leg exists
is lowered when you turn in the direction
of black arrow and raised when you turn
in the opposite direction. Taking help from
someone to slightly lift the refrigerator will
facilitate this process.
BPlease remember that the
manufacturer shall not be held liable if
the information given in the instruction
manual is not observed.
Preparation
• Your refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
• The ambient temperature of
the room where you install your
refrigerator should at least be 10°C.
Operating your refrigerator under
cooler conditions than this is not
recommended with regard to its
efficiency.
• Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
• If two refrigerators are to be installed
side by side, there should be at least
2 cm distance between them.
• When you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.

EN
10
1.
a
ac
b
b
d
e
2.
b b
Placing your refrigerator under the counter (for model BK 7120 T)
* Your refrigerator is designed for standard kitchen counters. If you like, you can
place your refrigerator under the counter.
* Pay attention to the below warnings when placing under the counter:
1. Rear wedges must be installed.
2. It must be centered so that there are equivalent distances at left and right
side.
3. Adjust the feet so that the refrigerator is parallel to the ground.

EN
11
3.
55 mm
595 mm
820 mm
Before operating your
refrigerator
Before starting to use your refrigerator
check the following:
1. Is the interior of the refrigerator dry
and can the air circulate freely in the
rear of it?
2. Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
3. Plug the refrigerator into the wall
outlet. When the fridge door is open
the fridge compartment interior light
will come on.
4. You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
even if the compressor is not running
and this is quite normal.
5. Front edges of the refrigerator may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electric connection
Connect your refrigerator to a
grounded socket which is being
protected by a fuse with the
appropriate capacity.
Important:
• The connection must be in
compliance with national regulations.
• The power cable plug must be easily
accessible after installation.
• Voltage and allowable fuse protection
are specified in the “Technical
Specifications” section.
• The specified voltage must be equal
to your mains voltage.
• Extension cables and multiway plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BThe appliance must not be operated
before it is repaired! There is danger
of electric shock!

EN
12
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose them of by
classifying them in accordance
with the waste instructions. Do not
dispose them of along with the normal
household waste.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old machine without
giving any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
Insert the 2 plastic wedges between
the wires of the condenser as
illustrated in the following figure. Plastic
wedges will provide the required
distance between your refrigerator
and the wall in order to allow the air
circulation.
Changing the illumination
lamp
To change the lamp used for
illumination of your refrigerator, please
call your Authorized Service.
Changing the door opening
direction
Door opening direction of your
refrigerator can be changed according
to the place you are using it. If this
is necessary, please call Authorized
Service.

EN
13
4Using your refrigerator
Thermostat setting button
The interior temperature of your
refrigerator changes for the following
reasons;
• Seasonal temperatures,
• Frequent opening of the door and
leaving the door open for long
periods,
• Food put into the refrigerator
without cooling down to the room
temperature,
• The location of the refrigerator in the
room (e.g. exposing to sunlight).
• You may adjust the varying interior
temperature due to such reasons
by using the thermostat. Numbers
around the thermostat button
indicates the cooling degrees.
• If the ambient temperature is higher
than 32°C, turn the thermostat button
to maximum position.
• If the ambient temperature is lower
than 25°C, turn the thermostat button
to minimum position.
Defrost
Fridge compartment performs full-
automatic defrosting. Water drops and
a frosting up to 7-8 mm can occur
on the inner rear wall of the fridge
compartment while your refrigerator
cools down. Such formation is normal
as a result of the cooling system.
The frost formation is defrosted by
performing automatic defrosting
with certain intervals thanks to the
automatic defrosting system of the rear
wall. User is not required to scrape the
frost or remove the water drops.
Water resulting from the defrosting
passes from the water collection
groove and flows into the evaporator
through the drain pipe and evaporates
here by itself.
Check regularly to see if the drain pipe
is clogged or not and clear it with the
stick in the hole when necessary.
Deep freezer compartment does not
perform automatic defrosting in order
to prevent decaying of the frozen food.

EN
14
Frost formation in the freezer
compartment must be defrosted
every 6 months. It is recommended to
defrost the ice when the deep freezer
compartment is not filled too much or
is empty. To do this, wrap the frozen
food by paper and keep them in the
coolest place possible or in another
refrigerator if available.
Stop your refrigerator by means of the
temperature setting button or unplug
the power cord from the outlet.
Place a container filled with hot water
into the freezer compartment with a
smooth pad under it in order to hasten
the defrosting.
Never use items such as candles, oil
lamps or heaters in your refrigerator to
hasten the defrosting.
Defrosting sprays may contain liquids
and gases that can be harmful for your
refrigerator and health. Be careful while
using such materials.
Do not keep the door of your
refrigerator during cleaning.
Remove the water that accumulates
in the lower container of the freezer
compartment with an absorbent cloth
or sponge.
Dry the freezer compartment
completely and return the temperature
setting button to its previous position.
Operate your refrigerator for 2 hours
while it is empty and its doors are
closed before replacing your food into
the deep freezer.

EN
15
5Cleaning and care
A Never use gasoline, benzene or
similar substances for cleaning
purposes.
BWe recommend that you unplug the
appliance before cleaning.
CNever use any sharp abrasive
instrument, soap, household
cleaner, detergent and wax polish for
cleaning.
C Use lukewarm water to clean the
cabinet of your refrigerator and wipe it
dry.
C Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
BMake sure that no water enters the
lamp housing and other electrical
items.
BIf your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
CCheck door seals regularly to ensure
they are clean and free from food
particles.
ATo remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
CMaterials that may cause odor
are not used in the production of
our refrigerators. However, due
to inappropriate food preserving
conditions and not cleaning the inner
surface of the refrigerator as required
can bring forth the problem of odor.
Points to be taken into consideration to
prevent this problem are as follows:
C Keeping the products clean is
important. For this, refrigerators must
be cleaned with carbonated water in
every 15 days. (Detergents and soap
must never be used.) Food residuals,
stains, etc. can cause odor.
CFoods must be kept in closed
containers. Microorganisms
spreading out from uncovered
containers can cause unpleasant
odors.
C Foods that have expired best before
dates and spoiled foods should never
be kept in the refrigerator.
Depending on the usage condition, you
may apply the following in case of
odor formation in your refrigerator.
CTea is one of the best deodorants.
Open hydroxyl (OH) ends of Catechin
substance molecules in the tea hold
the odor creating volatile organics to
remove unpleasant odors.
CPut the pulp of the tea you prepared
in your refrigerator in an uncovered
container and keep it there for
maximum 12 hours. If you leave it
in the refrigerator for more than 12
hours, it may become the source
of the odor as it will collect the
microorganisms that cause the odor;
therefore, it must be thrown away.
Protection of plastic
surfaces
CDo not put the liquid oils or oil-cooked
meals in your refrigerator in unsealed
containers as they damage the
plastic surfaces of your refrigerator. In
case of spilling or smearing oil on the
plastic surfaces, clean and rinse the
relevant part of the surface at once
with warm water.

EN
16
6Recommended solutions for the problems
Please review this list before calling the service. It might save you time and money. This list
includes frequent complaints that are not arising from defective workmanship or material
usage. Some of the features described here may not exist in your product.
The refrigerator does not operate.
• Is the refrigerator properly plugged in? Insert the plug to the wall socket.
• Is the fuse of the socket which your refrigerator is connected to or the main fuse
blown out? Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL
CONTROL and FLEXI ZONE).
• Very cold ambient conditions. Frequent opening and closing of the door. Highly
humid ambient conditions. Storage of food containing liquid in open containers.
Leaving the door ajar. Switching the thermostat to a colder degree.
• Decreasing the time the door left open or using it less frequently.
• Covering the food stored in open containers with a suitable material.
• Wipe the condensation using a dry cloth and check if it persists.
Compressor is not running
• Protective thermic of the compressor will blow out during sudden power
failures or plug-out plug-ins as the refrigerant pressure in the cooling system of
the refrigerator has not been balanced yet. Your refrigerator will start running
approximately after 6 minutes. Please call the service if the refrigerator does not
startup at the end of this period.
• The fridge is in defrost cycle. This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
• Your refrigerator is not plugged into the socket. Make sure that the plug is
properly fit into the socket.
• Are the temperature adjustments correctly made?
• Power might be cut off.

EN
17
The fridge is running frequently or for a long time.
• Your new product may be wider than the previous one. This is quite normal.
Large refrigerators operate for a longer period of time.
• The ambient room temperature may be high. This is quite normal.
• The refrigerator might have been plugged in recently or might have been loaded
with food. Cooling down of the refrigerator completely may last for a couple of
hours longer.
• Large amounts of hot food might have been put in the refrigerator recently. Hot
food causes longer running of the refrigerator until they reach the safe storage
temperature.
• Doors might have been opened frequently or left ajar for a long time. The warm
air that has entered into the refrigerator causes the refrigerator to run for longer
periods. Open the doors less frequently.
• Freezer or fridge compartment door might have been left ajar. Check if the doors
are tightly closed.
• The refrigerator is adjusted to a very low temperature. Adjust the refrigerator
temperature to a warmer degree and wait until the temperature is achieved.
• Door seal of the fridge or freezer may be soiled, worn out, broken or not properly
seated. Clean or replace the seal. Damaged/broken seal causes the refrigerator
to run for a longer period of time in order to maintain the current temperature.
Freezer temperature is very low while the fridge temperature is sufficient.
• The freezer temperature is adjusted to a very low temperature. Adjust the freezer
temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufficient.
• The fridge temperature might have been adjusted to a very low temperature.
Adjust the fridge temperature to a warmer degree and check.
Food kept in the fridge compartment drawers are freezing.
• The fridge temperature might have been adjusted to a very low temperature.
Adjust the fridge temperature to a warmer degree and check.
Temperature in the fridge or freezer is very high.
• The fridge temperature might have been adjusted to a very high degree.
Fridge adjustment has an effect on the temperature of the freezer. Change the
temperature of the fridge or freezer until the fridge or freezer temperature reaches
to a sufficient level.
• Doors might have been opened frequently or left ajar for a long time; open them
less frequently.
• Door might have been left ajar; close the door completely.
• Large amount of hot food might have been put in the refrigerator recently. Wait
until the fridge or freezer reaches the desired temperature.
• The refrigerator might have been plugged in recently. Cooling down of the
refrigerator completely takes time.

EN
18
The operation noise increases when the refrigerator is running.
• The operating performance of the refrigerator may change due to the changes in
the ambient temperature. It is normal and not a fault.
Vibrations or noise.
• The floor is not even or it is weak. The refrigerator rocks when moved slowly.
Make sure that the floor is strong enough to carry the refrigerator, and level.
• The noise may be caused by the items put onto the refrigerator. Items on top of
the refrigerator should be removed.
There are noises coming from the refrigerator like liquid spilling or spraying.
• Liquid and gas flows happen in accordance with the operating principles of your
refrigerator. It is normal and not a fault.
There is a noise like wind blowing.
• Fans are used in order to cool the refrigerator. It is normal and not a fault.
Condensation on the inner walls of refrigerator.
• Hot and humid weather increases icing and condensation. It is normal and not a
fault.
• Doors might have been left ajar; make sure that the doors are closed fully.
• Doors might have been opened frequently or left ajar for a long time; open them
less frequently.
Humidity occurs on the outside of the refrigerator or between the doors.
• There might be humidity in the air; this is quite normal in humid weather. When
the humidity is less, condensation will disappear.
Bad odor inside the refrigerator.
• Inside of the refrigerator must be cleaned. Clean the inside of the refrigerator with
a sponge, lukewarm water or carbonated water.
• Some containers or package materials might cause the smell. Use a different
container or different brand packaging material.
The door is not closing.
• Food packages may prevent the door's closing. Replace the packages that are
obstructing the door.
• The refrigerator is not completely upright on the floor and rocking when slightly
moved. Adjust the elevation screws.
• The floor is not level or strong. Make sure that the floor is level and capable to
carry the refrigerator.
Crispers are stuck.
• The food might be touching the ceiling of the drawer. Rearrange food in the
drawer.

48 3926 0000
EN
