Beko BU 1101 User manual

Refrigerator
Kühlschrank
Koelkast
Frigorífico
Réfrigérateur
BU 1100 HCA
BU 1101

BU 1100 HCA
BU 1101
Холодильник
Ledusskapis
Hladilnik
Chladnička

BU 1100 HCA
BU 1101
Frigorífico
Chłodziarka
Frigorifero
Frižider
BU 1100 HCA
BU 1101

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you an
effective service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimise its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
Recycling

EN
2
1 Your Refrigerator 3
2 Warnings 4
General security................................. 4
Starting Up........................................5
If there are any children at home........5
Purpose of use ..................................5
Safety instructions .............................5
HCA Warning ....................................5
3 Installation 6
Preparation........................................6
Important points to note while relocating
your refrigerator .................................6
Before operating the refrigerator ........6
Electric connection ............................7
Destroying the packing......................7
Disposing your old refrigerator...........7
Placing the refrigerator under the counter
and adjusting the legs........................ 8
4 Using your refrigerator 9
Temperature setting button................9
Defrost ..............................................9
5 Maintenance and
cleaning 10
Protection of plastic surfaces ..........10
Changing the Interior Lighting Bulb..11
6 Suggestions for Solving the
Problems 12

EN
3
1Your Refrigerator
2
1
1
1
3
4
6
8
7
5
1- Body shelves
2- Bulb thermostate box
3- Sliding crisper cover
4- Food storage cabin
5- Adjustable front legs
6- Egg compartment
7- Door shelf
8- Bottle shelf
C The figures in this manual are schematic, and they may not be in exact
accordance with your product. If the product you purchased does not have the
related parts, then they are valid are for other models.

EN
4
2Important Safety Warnings
Please review the following
information. Failure to observe this
information may cause injuries or
material damage. Otherwise, all
warranty and reliability commitments
will become invalid.
The usage life of the unit you
purchased is 10 years. This is the
period for keeping the spare parts
required for the unit to operate as
described.
Intended use
This product is intended to be used
– indoors and in closed areas such as
homes;
– in closed working environments such
as stores and offices;
– in closed accommodation areas such
as farm houses, hotels, pensions.
• This product should not be used
outdoors.
General safety
• When you want to dispose/scrap
the product, we recommend you
to consult the authorized service in
order to learn the required information
and authorized bodies.
• Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene to
the refrigerator without notifying the
authorised services.
• For products with a freezer
compartment; Do not eat cone ice
cream and ice cubes immediately
after you take them out of the freezer
compartment! (This may cause
frostbite in your mouth.)
• For products with a freezer
compartment; Do not put bottled and
canned liquid beverages in the freezer
compartment. Otherwise, these may
burst.
• Do not touch frozen food by hand;
they may stick to your hand.
• Unplug your refrigerator before
cleaning or defrosting.
• Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes of
your refrigerator. In such cases, the
vapor may get in contact with the
electrical parts and cause short circuit
or electric shock.
• Never use the parts on your
refrigerator such as the door as a
means of support or step.
• Do not use electrical devices inside
the refrigerator.
• Do not damage the parts, where
the refrigerant is circulating, with
drilling or cutting tools. The refrigerant
that might blow out when the gas
channels of the evaporator, pipe
extensions or surface coatings are
punctured causes skin irritations and
eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Electrical devices must be repaired
by only authorised persons. Repairs
performed by incompetent persons
create a risk for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the
relevant fuse or unplugging your
appliance.

EN
5
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
• Never store spray cans containing
flammable and explosive substances
in the refrigerator.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• This product is not intended to be
used by persons with physical,
sensory or mental disorders or
unlearned or inexperienced people
(including children) unless they are
attended by a person who will be
responsible for their safety or who will
instruct them accordingly for use of
the product
• Do not operate a damaged
refrigerator. Consult with the service
agent if you have any concerns.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
• Contact authorized service when
there is a power cable damage to
avoid danger.
• Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
• This refrigerator is intended for only
storing food items. It must not be
used for any other purpose.
• Label of technical specifications is
located on the left wall inside the
refrigerator.
• Never connect your refrigerator to
electricity-saving systems; they may
damage the refrigerator.
• If there is a blue light on the
refrigerator, do not look at the blue
light with optical tools.
• For manually controlled refrigerators,
wait for at least 5 minutes to start the
refrigerator after power failure.
• This operation manual should be
handed in to the new owner of the
product when it is given to others.
• Avoid causing damage on power
cable when transporting the
refrigerator. Bending cable may cause
fire. Never place heavy objects on
power cable. Do not touch the plug
with wet hands when plugging the
product.
• Do not plug the refrigerator if the wall
outlet is loose.
• Water should not be sprayed directly
on inner or outer parts of the product
for safety purposes.
• Do not spray substances containing
inflammable gases such as propane
gas near the refrigerator to avoid fire
and explosion risk.
• Never place containers filled with
water on top of the refrigerator,
otherwise this may cause electric
shock or fire.
• Do not overload your refrigerator
with excessive amounts of food. If
overloaded, the food items may fall
down and hurt you and damage
refrigerator when you open the
door. Never place objects on top
of the refrigerator; otherwise, these
objects may fall down when you
open or close the refrigerator's door.

EN
6
• As they require a precise temperature,
vaccines, heat-sensitive medicine and
scientific materials and etc. should
not be kept in the refrigerator.
• If not to be used for a long time,
refrigerator should be unplugged. A
possible problem in power cable may
cause fire.
• The plug's tip should be regularly
cleaned; otherwise, it may cause fire.
• Refrigerator may move if adjustable
legs are not properly secured on the
floor. Properly securing adjustable
legs on the floor can prevent the
refrigerator to move.
• When carrying the refrigerator, do not
hold it from door handle. Otherwise, it
may be snapped.
• When you have to place your product
next to another refrigerator or freezer,
the distance between devices should
be at least 8cm. Otherwise, adjacent
side walls may be humidified.
For products with a water
dispenser;
Pressure of water mains should be
minimum 1 bar. Pressure of water
mains should be maximum 8 bars.
• Use only potable water.
Child safety
• If the door has a lock, the key should
be kept away from reach of children.
• Children must be supervised to
prevent them from tampering with the
product.
HCA Warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the
product catch a fire and ventilate the
room in which the unit is placed.
Ignore this warning if your
product's cooling system contains
R134a.
Type of gas used in the product is
stated in the type plate which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.

EN
7
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators.
• Pay attention to keep your food in
closed containers.
• For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
• Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.

EN
8
3Installation
CPlease note that the production
company cannot be held responsible
when the instructions in the manual
are not followed.
Preparation
• Your refrigerator must be placed with
at least 30 cm distance from heat
sources like burners, ovens, radiators
and stoves, and with at least 5 cm
distance from electrical ovens, and
it must not be placed under direct
sunlight.
• The temperature of the room where
your refrigerator is placed must be at
least 10°C. It is not recommended
to operate your refrigerator in colder
environments for performance
purposes.
• Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
• If two refrigeration units are being
placed side by side, there must be
at least 2 cm clearance between the
units.
• When starting up your refrigerator for
the first time, note the following points
for six hours.
- The temperature setting button
mustn’t be switched off.
- The door must not be opened too
frequently.
- It must be operated empty, without
putting food into refrigerator.
Do not pull the plug out from
the power socket; if there is any
undesired power blockout, note the
warnings in the “Solution Suggestions
for Problems” section.
• The original package and styrofoam
must be kept for future transfer and
moving of your product.
Important points to note
while relocating your
refrigerator
1. Your refrigerator must be emptied
and cleaned before moving the
product.
2. The shelves, accessories, crisper, etc.
in your refrigerator must be wrapped
and reinforced against shaking before
packing it again.
3. The package must be fixed with
thick tapes or strong strings, and the
safety rules on the packing must be
followed.
Please Note...
Each recycled item is an indispenseble
source for the nature and our national
wealth.
If you would like to contribute to
the recycling of package materials,
you may get information from
the environmental instutitions or
municipalities.
Before operating the
refrigerator
Before starting to use your refrigerator
check the following.
1- Is the interior of the refrigerator dry
and can the air circulation be made
easly in the back part?
2- Clean the interior of the refrigerator as
recommended in “Maintenance and
cleaning” section.
3- Insert the plug of the refrigerator into
the wall socket. The related interior
lighting will be switched on when the
door is opened.
4- You will hear a sound when the
compressor starts operating. The
pressed coolants in the cooling
system may create a noise even if
the compressor is not operating, and
this is very normal. The general noise

EN
9
level is a little higher when compared
to other non-no-frost units because
of the operation of the fans inside the
unit. This is very normal and is not a
malfunction.
5- The front edges of the refrigerator
may be warm. This is normal. These
areas are designed to be warm to
prevent condensation.
Electric connection
Connect the machine to a grounded
socket protected by a fuse having
appropriate capacity.
Important:
• The connection must be in
compliance with national regulations.
• The electric cablo plug must be easily
accessible after installation.
• Voltage and permitted fuse protection
are specified in “Specifications”
section.
• The specified voltage must be equal
to your mains voltage.
• Extension cables and multiway plugs
must not be used for connecting the
unit.
BA damaged electric cable must be
replaced by a qualified electrician.
BThe appliance must not be operated
before it is repaired! There is danger
of electric shock!
Destroying the packing
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or throw them away by
classifying them in accordance with
the waste instructions. Do not throw
them away along with the normal
household waste.
The packing of your machine is
produced from recyclable materials.
Disposing your old
refrigerator
Dispose your old machine without
harming the environment.
• You may consult your authorized
seller or disposal center of your
municipality about the disposal of
your machine.
Before disposing your machine, cut
out the electric plug and, if there are
any locks on the door, make them
unoperatable not to expose children to
any danger.

EN
10
Placing the refrigerator
under the counter and
adjusting the legs
When you place your refrigerator, the
distance between the product and the
wall must be at least 10 cm, as seen in
the figure.
The air sucking channels must not be
blocked so that the performance of
your refrigerator does not decrease.
(140 cm2)
If your refrigerator is unstable;
You may turn the front legs of your
refrigerator as seen in the figure and
make it stay balanced. The corner of
the leg lowers when the leg is turned in
the direction of the black arrow; it rises
when the leg is turned in the opposite
direction. It will be easier for you when
you get some help from someone to
lift the unit a little during this process.
10 mm
40 mm 40 mm
10 mm

EN
11
4Using your refrigerator
Temperature setting button
The interior temperature of your
refrigerator changes for the following
reasons;
• Seasonal temperatures,
• Frequent opening of the door and
leaving the door open for long
periods,
• Foods put into the refrigerator without
decreasing the temperature to room
temperature.
• The location of the refrigerator in the
room (eg. exposing to sunlight)
You may adjust the varying interior
temperature using the thermostate. If
the ambient temperature is higher than
32°C, switch the thermostate button
to maximum position.
Defrost
It is normal when ice particles form
on the back wall during the operation.
These do not need to be scratched
or wiped out. Your refrigerator makes
automatical defrost. Water formed
after defrost flows into the evaporation
container via the drain pipe through
the water collecting chute, and here it
evaporates automatically.
•Check periodically whether the
evaporation pipe is clogged and
unclog it using the stick in the hole if
necessary.

EN
12
5Maintenance and cleaning
A Never use gasoline, benzene or
similar substances for cleaning
purposes.
BWe recommend that you unplug the
appliance before cleaning.
• Never use any sharp abrasive
instrument, soap, household
cleaner, detergent and wax polish for
cleaning.
• Use lukewarm water to clean the
cabinet of your refrigerator and wipe it
dry.
• Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe it
dry.
• If your refrigerator is not going to be
used for a long period of time, unplug
the power cable, remove all food,
clean it and leave the door ajar.
• Check door seals regularly to ensure
they are clean and free from food
particles.
Protection of plastic
surfaces
• Do not put the liquid oils or oil-cooked
meals in your refrigerator in unsealed
containers as they damage the
plastic surfaces of your refrigerator. In
case of spilling or smearing oil on the
plastic surfaces, clean and rinse the
relevant part of the surface at once
with warm water.

EN
13
Changing the Interior
Lighting Bulb
If the lamp does not operate, follow
the following procedures:
1. Switch off the electric connection of
the refrigerator and pull out the plug.
Remove all shelves and drawers for
easy access.
2. Remove the cover carefully by
pressing it on the edge with your index
finger, as seen in figure b. Try not to
damage the plastic cover and interior
facing.
3. First, screw the bulb into its
socket tightly and check whether it is
loosened. Insert the plug again and
switch on the electricity. If the bulb
operates, replace the light cover by
placing the back lock, pushing it onto
its place.
4. If the bulb does not operate,
switch off the electric connection of
the refrigerator and pull out the plug.
Replace the bulb with a new 15 watt
(maximum), screw covered E14 (SES)
bulb.
5. Immediately chuck out the damaged
bulb carefully and properly.
Spare bulb can be obtained from
authorized services.

EN
14
6Recommended solutions for the problems
Please review this list before calling the service. It might save you time and
money. This list includes frequent complaints that are not arising from defective
workmanship or material usage. Some of the features described here may not
exist in your product.
The refrigerator does not operate.
• Is the refrigerator properly plugged in? Insert the plug to the wall socket.
• Is the fuse of the socket which your refrigerator is connected to or the main fuse
blown out? Check the fuse.
Condensation on the side wall of the fridge compartment (MULTIZONE, COOL
CONTROL and FLEXI ZONE).
• Very cold ambient conditions. Frequent opening and closing of the door. Highly
humid ambient conditions. Storage of food containing liquid in open containers.
Leaving the door ajar. Switching the thermostat to a colder degree.
• Decreasing the time the door left open or using it less frequently.
• Covering the food stored in open containers with a suitable material.
• Wipe the condensation using a dry cloth and check if it persists.
Compressor is not running
• Protective thermic of the compressor will blow out during sudden power
failures or plug-out plug-ins as the refrigerant pressure in the cooling system of
the refrigerator has not been balanced yet. Your refrigerator will start running
approximately after 6 minutes. Please call the service if the refrigerator does not
startup at the end of this period.
• The fridge is in defrost cycle. This is normal for a full-automatically defrosting
refrigerator. Defrosting cycle occurs periodically.
• Your refrigerator is not plugged into the socket. Make sure that the plug is
properly fit into the socket.
• Are the temperature adjustments correctly made?
• Power might be cut off.

EN
15
The fridge is running frequently or for a long time.
• Your new product may be wider than the previous one. This is quite normal.
Large refrigerators operate for a longer period of time.
• The ambient room temperature may be high. This is quite normal.
• The refrigerator might have been plugged in recently or might have been loaded
with food. Cooling down of the refrigerator completely may last for a couple of
hours longer.
• Large amounts of hot food might have been put in the refrigerator recently. Hot
food causes longer running of the refrigerator until they reach the safe storage
temperature.
• Doors might have been opened frequently or left ajar for a long time. The warm
air that has entered into the refrigerator causes the refrigerator to run for longer
periods. Open the doors less frequently.
• Freezer or fridge compartment door might have been left ajar. Check if the doors
are tightly closed.
• The refrigerator is adjusted to a very low temperature. Adjust the refrigerator
temperature to a warmer degree and wait until the temperature is achieved.
• Door seal of the fridge or freezer may be soiled, worn out, broken or not properly
seated. Clean or replace the seal. Damaged/broken seal causes the refrigerator
to run for a longer period of time in order to maintain the current temperature.
Freezer temperature is very low while the fridge temperature is sufficient.
• The freezer temperature is adjusted to a very low temperature. Adjust the freezer
temperature to a warmer degree and check.
Fridge temperature is very low while the freezer temperature is sufficient.
• The fridge temperature might have been adjusted to a very low temperature.
Adjust the fridge temperature to a warmer degree and check.
Food kept in the fridge compartment drawers are freezing.
• The fridge temperature might have been adjusted to a very low temperature.
Adjust the fridge temperature to a warmer degree and check.
Temperature in the fridge or freezer is very high.
• The fridge temperature might have been adjusted to a very high degree.
Fridge adjustment has an effect on the temperature of the freezer. Change
the temperature of the fridge or freezer until the fridge or freezer temperature
reaches to a sufficient level.
• Doors might have been opened frequently or left ajar for a long time; open them
less frequently.
• Door might have been left ajar; close the door completely.
• Large amount of hot food might have been put in the refrigerator recently. Wait
until the fridge or freezer reaches the desired temperature.
• The refrigerator might have been plugged in recently. Cooling down of the
refrigerator completely takes time.

EN
16
The operation noise increases when the refrigerator is running.
• The operating performance of the refrigerator may change due to the changes in
the ambient temperature. It is normal and not a fault.
Vibrations or noise.
• The floor is not even or it is weak. The refrigerator rocks when moved slowly.
Make sure that the floor is strong enough to carry the refrigerator, and level.
• The noise may be caused by the items put onto the refrigerator. Items on top of
the refrigerator should be removed.
There are noises coming from the refrigerator like liquid spilling or spraying.
• Liquid and gas flows happen in accordance with the operating principles of your
refrigerator. It is normal and not a fault.
There is a noise like wind blowing.
• Fans are used in order to cool the refrigerator. It is normal and not a fault.
Condensation on the inner walls of refrigerator.
• Hot and humid weather increases icing and condensation. It is normal and not a
fault.
• Doors might have been left ajar; make sure that the doors are closed fully.
• Doors might have been opened frequently or left ajar for a long time; open them
less frequently.
Humidity occurs on the outside of the refrigerator or between the doors.
• There might be humidity in the air; this is quite normal in humid weather. When
the humidity is less, condensation will disappear.
Bad odor inside the refrigerator.
• Inside of the refrigerator must be cleaned. Clean the inside of the refrigerator with
a sponge, lukewarm water or carbonated water.
• Some containers or package materials might cause the smell. Use a different
container or different brand packaging material.
The door is not closing.
• Food packages may prevent the door's closing. Replace the packages that are
obstructing the door.
• The refrigerator is not completely upright on the floor and rocking when slightly
moved. Adjust the elevation screws.
• The floor is not level or strong. Make sure that the floor is level and capable to
carry the refrigerator.
Crispers are stuck.
• The food might be touching the ceiling of the drawer. Rearrange food in the
drawer.

Bitte lesen Sie diese Anleitung aufmerksam durch, bevor Sie das Gerät
benutzen!
Sehr geehrte Kundin, sehr geehrter Kunde,
Wir möchten, dass Sie mit Ihrem Produkt, das in modernen Fertigungsstätten hergestellt
wurde und gründliche Qualitätsprüfungen durchlaufen hat, rundum zufrieden sind.
Darum bitten wir Sie, diese Anleitung gründlich durchzulesen, bevor Sie Ihr neues Produkt
benutzen. Bewahren Sie die Anleitung gut auf, damit Sie später darin nachlesen können.
Diese Anleitung...
... hilft Ihnen, Ihr Gerät schnell und sicher zu bedienen.
* Lesen Sie die Anleitung, bevor Sie Ihr Produkt aufstellen und bedienen.
* Halten Sie sich an die Anweisungen, beachten Sie insbesondere die
Sicherheitshinweise.
* Bewahren Sie die Anleitung an einem leicht zugänglichen Ort auf, damit Sie jederzeit
darin nachschlagen können.
* Lesen Sie auch die weiteren Dokumente, die mit Ihrem Produkt geliefert wurden.
Bitte beachten Sie, dass diese Anleitung eventuell auch für andere Geräte eingesetzt
werden kann.
Symbole und ihre Bedeutung
Die folgenden Symbole werden in dieser Anleitung genutzt:
CWichtige Informationen oder nützliche Tipps.
AWarnung vor Verletzungen oder Sachschäden.
BWarnung vor elektrischem Strom.
Dieses Produkt ist mit dem selektiven Entsorgungssymbol für elektrische
und elektronische Altgeräte (WEEE) gekennzeichnet.
Das bedeutet, dass dieses Produkt gemäß der europäischen Direktive
2002/96/EC gehandhabt werden muss, um mit nur minimalen
umweltspezifischen Auswirkungen recycelt oder zerlegt werden zu können.
Weitere Informationen erhalten Sie von Ihren regionalen Behörden.
Elektronikprodukte, die nicht durch den selektiven Entsorgungsvorgang
erfasst werden, stellen durch das Vorhandensein potenziell gefährlicher
Substanzen umwelt- und gesundheitsrelevante Risiken dar.
Recycling
