Beko CXFD 6114B User manual

CXFD 6114B
Frost Free Combi
Fridge / Freezer

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in a 1st-class
manufacturing facility and checked under the most meticulous quality control
procedures, will provide you with years of good service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future reference.
This manual
• Will help you use your appliance quickly and safely.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
3
1 Your refrigerator 4
2 Warnings 5
Electrical Requirements ..................... 6
Warning! This Appliance Must Be
Earthed ............................................. 6
Energy Saving Tips............................ 7
Compliance with WEEE Directive and
Disposing of the Waste Product: ....... 7
Compliance with RoHS Directive: ..... 7
Package information.......................... 7
3 Installation 8
Transportation Instructions................. 8
Installation Instructions ...................... 8
Replacing The Interior Light Bulb .... 10
Reversing The Doors ....................... 11
Reversing the doors ........................ 13
4 Before operating 14
Final Check ..................................... 14
5 Using your refrigerator 15
Temperature Control And
Adjustment ...................................... 15
Suggested Arrangement Of Food In
The Fridge/Freezer .......................... 16
Storing Frozen Food........................17
Freezing Fresh Food ........................ 17
Making Ice Cubes............................ 18
Defrosting........................................ 18
Water Dispenser .............................. 19
*optional .......................................... 19
6 Maintenance and
cleaning 22
7 Do's and Don'ts 23

EN
4
1Your refrigerator
13
3
6
9
9
8
3
3
7
5
11
14
15
9
10
12
2
1
9
4
1. Thermostat control
2. Interior Light
3. Adjustable body shelves
4. Wine rack
5. Defrost water collection
channel - Drain tube
6. Crisper cover
7. Crisper
8. Icebank tray
9. Deep-freeze compartment
10. Adjustable front feet
11. Fridge compartment door
shelves
12. Egg holders
13. Water dispenser
14. Fridge compartment
15. Freezer compartment
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.

EN
5
2Warnings
• Do not connect your appliance to
the electricity supply until all packing
and transit protectors have been
removed.
• If transported horizontally leave
to stand upright for at least 4
hours before switching on to allow
compressor oil to settle
• If you are discarding an old
refrigerator with a lock or latch fitted
to the door, disable the lock/latch,
ensure that it is left in a safe condition
to prevent the entrapment of young
children.
• This fridge/freezer must only be used
for its intended purpose i.e the storing
and freezing of edible foodstuff.
• Do not dispose of the appliance
on a fire. At BEKO, the care and
protection of our environment is an
ongoing commitment. This appliance
which is among the latest range
introduced is particularly environment
friendly. Your appliance contains non
CFC / HFC natural substances in the
cooling system (Called R600a) and in
the insulation (Called cyclopentane)
which are potentially flammable
if exposed to fire. Therefore, take
care not to damage, the cooling
circuit / pipes of the appliance in
transportation and in use. In case of
damage do not expose the appliance
to fire or potential ignition source and
immediately ventilate the room where
the appliance is situated.
• We suggest you contact your local
authority for disposal information and
facilities available.
• See Installation Instructions on on
page 8 for information on suitable
location.
• To obtain the best possible
performance and trouble free operation
from your appliance it is very important
to carefully read these instructions.
• On delivery, check to make sure that
the product is not damaged and that
all the parts and accessories are in
perfect condition.
• Ensure that the plug remains readily
accessible. Do not use multiple
adapter or extension cable.
• Failure to observe these instructions
may invalidate your right to free service
during the guarantee period.
• Keep ventilation openings, in the
appliance enclosure or in the built-in
structure, clear of obstruction.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances
inside the food storage compartments
of the appliance, unless they are
of the type recommended by the
manufacturer.
• We suggest you keep these
instructions in a safe place for easy
reference.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to
ensure that they do not play with the
appliance.

EN
6
Electrical Requirements
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown on the rating
plate inside the appliance corresponds
to yourelectricity supply.
Rating label is on the left hand side of
fridge inner liner.
We recommend that this appliance be
connected to the mains supply via a
suitable switched and fused socket.
The appliance must be positioned so
that the plug is accessible.
Should the mains lead of the appliance
become damaged or should it need
replacing at any time, it must be
replaced by a special purpose made
mains lead which can only be obtained
from a BEKO Authorised Service
Agent.
Warning! This Appliance
Must Be Earthed
If the fitted moulded plug is not
suitable for your socket, then the plug
should be cut off and an appropriate
plug fitted. Destroy the old plug which
is cut off as a plug with bared cord
could cause a shock hazard if inserted
into a socket elsewhere in the house.
The moulded plug on this appliance
incorporates a 13 A fuse. Should
the fuse need to be replaced an
ASTABEAB approved BS 1362 fuse
of the same rating must be used. Do
not forget to refit the fuse cover. In the
event of losing the fuse cover the plug
must not be used until a replacement
fuse cover has been fitted.
Colour of the replacement fuse cover
must be the same colour as that
visible on the pin face of the plug. Fuse
covers are available from any good
electrical store.
Important! Fitting A Different Plug
As the colours of the wires in the
mains lead of this appliance may
not correspond with the coloured
markings identifying the terminals in
your plug proceed as follows: (See
diagram).
1. Connect the green-yellow or green
(Earth) wire to the terminal in the plug
marked ‘E’ or with the symbol or
coloured green and yellow or green.
2. Connect the blue (Neutral) wire to
the terminal in the plug marked ‘N’ or
coloured black.
3. Connect the brown (Live) wire to
the terminal in the plug marked ‘L’ or
coloured red.
With alternative plugs a 13 A fuse must
be fitted either in the plug or adaptor
or in the main fuse box. If in doubt
contact a qualified electrician.
FITTED WITH
BS 1362 13A FUSE ALWAYS
FIT BS 1362 REPLACEMENT
CARTRIDGE FUSE
GREEN &
YELLOW
OR
GREEN
N
BLUE
OR
BLACK
L
BROWN
OR
RED
22mm.
6mm.
6mm.
6mm. 32mm.
12mm.
FUSE
CORD GRIP

EN
7
Energy Saving Tips
1- Ensure your appliance is installed in
a well ventilated area.
2- Ensure the time between buying
chilled/frozen food and placing them
in your appliance is kept at minimum,
particularly in summer. We recommend
you use a cool bag or a special carrier
bag to carry perishable food.
3- Do not leave the door (s) of your
appliance open longer than necessary
and ensure they are closed properly
after each opening.
4- Defrost frozen food in the fridge
compartment, so that frozen food acts
as an ice pack to assist cooling in the
fridge.
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This
product bears a
classification symbol for
waste electrical and
electronic equipment
(WEEE).This product has
been manufactured with
high quality parts and materials which
can be reused and are suitable for
recycling. Do not dispose of the waste
product with normal domestic and
other wastes at the end of its service
life. Take it to the collection center for
the recycling of electrical and
electronic equipment. Please consult
your local authorities to learn about
these collection centers.
Compliance with RoHS
Directive:
The product you have purchased
complies with EU RoHS Directive
(2011/65/EU). It does not contain
harmful and prohibited materials
specified in the Directive.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.

EN
8
3Installation
Transportation Instructions
1. The appliance should be
transported only in a vertical upright
position. The packing as supplied
must be intact during transportation.
2. If during the course of
transport the appliance has to be
transported horizontally, it must
only be laid on its right hand side
when standing in the front of the
appliance. After bringing it to
upright position,it must not be
operated for at least 4 hours to
allow the system to settle.
3. Failure to comply with the
above instructions could result in
damage occuring to the appliance.
The manufacturer will not be held
responsible if these instructions are
disregarded.
4. The appliance must be protected
against rain, moisture and other
atmospheric influences.
5. When positioning your appliance
take care not to damage your flooring,
pipes, wall coverings etc. Do not move
the appliance by pulling by the door or
handle.
6. Empty any water in the drain
tray before moving. See section
‘Defrosting’ and ‘Care & cleaning’ for
further information.
7. Make sure that the defrost water
pipe at the back of the product is fixed
to the plastic evaporating pan on the
top of the compressor, to avoid defrost
water spillage on the floor.
IMPORTANT : Care must be taken
while cleaning / carrying the appliance
to avoid touching the bottom of the
condenser metal wires at the back of
the appliance as you might injure your
fingers and hands.
Do not attempt to sit or stand on top
of your appliance as it is not designed
for such use. You could injure yourself
or damage the appliance.
“IMPORTANT: Make sure that
mains cable is not caught under the
appliance during and after carrying
/ moving the appliance, to avoid
the mains cable becoming cut or
damaged.”
Do not allow children to play with the
appliance or tamper with the controls.
BEKO declines to accept any liability
should the instructions not be
followed.
Installation Instructions
1. The space in the room where the
appliance is installed must not be
smaller than 10 cubic metres.
2. This appliance is designed to
operate at temperatures specified
in the table below is equipped with
‘Freezer Guard’ which ensures that
at the advised setting [4 - four on
the control] the frozen food in the
freezer will not defrost even if the
ambient temperature falls as low as
-15 °C. So you may then install your
appliance in a garage or an unheated
room without having to worry about
frozen food in the freezer being spoilt.
However at low ambient temperatures
mentioned above, fridge contents are
likely to freeze, so check and consume

EN
9
food in the fridge accordingly. When
the ambient temperature returns to
normal, you may change the setting to
suit your needs.
CIf the ambient temperature is
below 0°C, the food in the fridge
compartment will freeze.So, we
recommend you don’t use the fridge
compartment in such low ambient
conditions. You can continue using the
freezer compartment as usual.
3. Do not place the appliance near
cookers, radiators or in direct sunlight
as this will cause your appliance to
work harder. If installed next to a
source of heat or freezer, maintain the
following minimum side clearances:
From Cookers 50 mm (2”)
From Radiators 300 mm (12”)
From Freezers 25 mm (1”)
4. Make sure that sufficient room is
provided around the appliance to
ensure free air circulation. Fit the two
plastic wall spacers supplied with the
appliance to the condenser on the
back of the appliance by rotating 1/4
turn.
(See Diagram).
5. The fridge/freezer should be located
on a smooth surface. The two front
feet can be adjusted as required. To
ensure that your appliance is standing
upright adjust the two front feet by
turning clockwise or anti-clockwise,
until the product is in firm contact with
the floor. Correct adjustment of feet
avoids excessive vibration and noise.
6. Refer to cleaning and care section
to prepare your appliance for use.
7. A special receptacle is supplied to
store the mains plug during transit.
The receptacle is fixed at the back
of the cabinet, on the side of the
compressor. (See diagram) Gently
remove the plug from the receptacle.
Never pull the mains cord, you may
damage the appliance. In the case
of transportation, ensure you locate
the plug in the receptacle provided to
avoid transit damage.

EN
10
Replacing The Interior Light
Bulb
Should the light fail to work, proceed
as follows.
1. Switch off at the socket outlet and
pull out the mains plug.
• You may find it useful to remove
shelves for easy access.
2. Use a flat tipped screwdriver to
remove the light diffuser cover by
inserting the blade in each of the two
recesses to prise off each side.
3. First check that the bulb hasn’t
worked loose by ensuring it is screwed
securely in the holder. Replace the
plug and switch on. If the bulb works,
replace the light cover by inserting the
rear lug and pushing up to locate the
front two lugs.
4. If the light still fails to work, switch
off at the socket outlet and pull out
the mains plug. Replace the bulb with
a new 15 watt (max) screw cap (SES)
bulb.
5. Carefully dispose of the burnt-out
light bulb immediately. Replacement
light bulb can easily be obtained from
a good local electrical or DIY store.

EN
11
Reversing The Doors
We recommend that you reverse doors
before switching on for the first time.
Tools required: Small and medium size
flat and cross-headed screwdrivers, a
pair of pliers.
Spare Parts supplied in the plastic
bag: The following parts, which are
exclusively for left hand side fitted
hinge operation are supplied in a
plastic bag with the appliance:
- Upper door top trim hinge covers –
there are 2 different parts, one for each
side of top trim.
- Upper door middle hinge bushing/
door stopper assembly.
We suggest you keep all the parts
supplied in the plastic bag and also
parts, which have been removed when
reversing doors, in a safe place for
possible future, re-use.
IMPORTANT: We suggest you ask
somebody to help you when moving
the appliance around and to hold
doors when removing / re-fitting
hinges and doors to avoid any injury
and damage to the product.
Please refer to diagrams supplied. To
follow numbers in brackets below,
refer to the main diagram.
1.Switch off the appliance at the
socket outlet and pull out the mains
plug.
2.Remove all loose items and fittings
and food, if any, from inside the
appliance and door racks.
3.Gently prise off plastic hinge cover of
upper door top trim and hinge covers
on both sides of front top panel using
a small flat-headed screwdriver. (1)
4.Gently tilt the appliance back
against a strong wall on its rear side
sufficiently to allow the lower hinge
to be removed. Take care to protect
the appliance, your wall and floor
coverings. You can utilise the original
packaging to do this. Once you tilt the
appliance back, check to make sure
the appliance is completely stable and
safe before you carry on. (2)
5.Unscrew and remove the lower hinge
using a cross-headed screwdriver
while holding the lower door firmly.(3)
6.Remove lower door carefully off the
middle hinge and stand door upright in
a safe place.(4)
7.Open upper door and unscrew and
remove the middle hinge while holding
the upper door firmly. Use a flat-
headed screwdriver. Middle hinge will
need to be rotated 180 degrees before
re-fitting on the opposite side.(5)
8.Remove upper door carefully off the
upper hinge and stand door upright in
a safe place.(6)
9.Unscrew and remove the upper
hinge using a flat-headed screwdriver.
(7)
10.Rotate the upper hinge 180
degrees and then unscrew and
remove the hinge pin using a pair of
pliers and re-fit to
opposite side of hinge.(8)
11.Reposition plugs and hinge pin
bushings on top of doors on the
opposite side of both doors. Use small
flatheaded screwdrivers to remove
plugs and bushings. Take care not to
mark doors.(9)
12.Reposition left hand side feet on
the opposite side.(10)

EN
12
13.Unscrew and remove the bottom
door hinge pin bushing/door stopper
using a cross-headed screwdriver. (11)
Unscrew and remove the upper door
middle hinge pin bushing/door stopper
using a cross-headed screwdriver.
Important: This part cannot be used
on the opposite side; left hand side
middle hinge pin bushing/door stopper
part is supplied in the plastic bag.(11)
14.Re-fit the upper hinge on the
left hand side using flat-headed
screwdriver.(12)
15.Fit upper door left hand side middle
hinge pin bushing/door stopper
supplied in the plastic bag using cross-
headed screwdriver.(13)
16.Reposition three small plastic
plugs on the left hand side, which are
covering middle hinge holes, on the
opposite side to cover holes left empty.
(14)
17.Locate and re-fit upper door to
upper hinge and hold the door firmly.
(15)
18.Locate the middle hinge pin to
middle hinge pin bushing of upper
door on the left hand side and re-fit the
middle hinge.(16) First fit the left screw
when the door is closed and then fit
the right screw after opening the door
for access.
19.Reposition the screw fitted to lower
hinge hole on the left hand side at the
bottom of the cabinet on the opposite
side.(17)
20.Locate and re-fit lower door to
middle hinge pin and then re-fit the
lower hinge on the left hand side.
(18),(19)
21.Carefully stand the appliance
upright and adjust the two front feet if
necessary.
22.Check that doors open and close
easily, they are aligned correctly and
that there are no gaps allowing ir into
the cabinet. If there are gaps between
the door seal and the cabinet, adjust
the door seal by gently pulling away
from the door using fingers.
23.Check that all the hinge screws are
tightened. Avoid over tightening the
screws.
24.Put all items, fittings back in the
appliance.
25.Fit upper door top trim and front
top panel plastic hinge covers.
Upper door top trim hinge covers are
supplied in the plastic bag.(20)
26.Wait for at least 4 hours to allow the
system to settle before switching on.
27.Once the correct storage
temperatures have been reached in
the appliance, put back all the food.

EN
13
Reversing the doors
Proceed in numerical order .
1
17
1
20
11
13 9
2
10
5
3
20
20
8
18
17
19
14
12
16
21
21
45°
180°
(8) (13)
6
4
15

EN
14
4Before operating
Final Check
Before you start using the fridge/
freezer check that:
1. The feet have been adjusted for
perfect levelling.
2. The interior is dry and air can
circulate freely at the rear of the
cabinet.
3. Clean the interior as recommended
under “CLEANING AND CARE.”
4. Insert the plug into the wall socket
and switch on the electricity supply.
• When the door is open the fridge
interior light will come on.
5. You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
whether the compressor is running or
not which is quite normal.
“Due to operation of the fan inside
the frost free freezer compartment,
overall noise level is slightly higher
in comparison to non-frost free
appliances. This is quite normal and is
not a fault.”
6. Set the setting half way between
min and max.
7. Front edges of the cabinet may feel
warm. This is normal. These areas
are designed to be warm to avoid
condensation.
8. “Do not load the appliance
immediately it is switched on. Wait
until the correct storage temperature
has been reached. We recommend
that you check the temperature
with an accurate thermometer (see;
Temperature Control and Adjustment)”
9. When the freezer reaches the
desired temperature the freezer fan will
stop. When the freezer fan is on, the
noise will be louder when the freezer
door is opened.
10. Avoid spillage of food particularly
small items like rice, peas, beans
through the fan guard as they may
cause the cooling system to block and
therefore operate less efficiently.

EN
15
5Using your refrigerator
Temperature Control And Adjustment
Operating temperatures are controlled
by the thermostat (see diagram)
located on the ceiling of fridge
compartment. Settings may be made
from 1 to 5, 5 being the coldest
position.
When the appliance is switched
on for the first time, the thermostat
should be adjusted so that after 24
hours, the average fridge temperature
is no higher than +5°C (+41°F). We
recommend you set the thermostat
half way between the 1 and 5 setting
and monitor to obtain the desired
temperature i. e. towards 5 you will
obtain a colder fridge temperature and
vice versa. Some sections of the fridge
may be cooler or warmer ( such as the
salad crisper and the top part of the
cabinet ) which is quite normal.
The normal storage temperature of the
freezer should be -18°C (0°F). Lower
temperatures may be obtained by
adjusting the thermostat towards 5
position.
We recommend that you check
the temperature with an accurate
thermometer to ensure that the
storage compartments are kept to the
desired temperature.
Remember you must take your reading
very quickly since the thermometer
temperature will rise very rapidly after
you remove it from the freezer.
Please remember each time the door
is opened cold air escapes and the
internal temperature rises. Therefore
never leave the door open and ensure
it is closed immediately after food is
put in or removed.
In case of a temporary ice build up in
the fridge compartment, reduce the
thermostat setting to 1, monitoring
at the same time that the fridge
temperature is maximum +5 degrees
C [41 degrees F]. Once the ice build
up disappears and the appliance
starts auto defrosting again as normal,
then you may increase the thermostat
setting, if required.

EN
16
Suggested Arrangement Of
Food In The Fridge/Freezer
2
3
8
10
1
4
6
5
5
7
9
Arrangement Examples (See diagram)
1. Baked, chilled cooked food, dairy
products, cans.
2. Meat, sausages, cold cuts.
3. Fruit, vegetables, salads.
4. Making, storing ice cubes.
5. Frozen food.
6. Frozen food and freezing of fresh
food.
7. Butter, cheese.
8. Small bottles, cans, tubes.
9. Eggs
10.Water dispenser
The following guidelines and
recommendations are suggested to
obtain the best
results and storage hygiene.
1. The fridge compartment is for the
short term storage of fresh food and
drinks.
2. The freezer compartment is
rated and suitable for the freezing
and storage of pre frozen food. The
recommendation for storage
as stated on the food packaging
should be observed at all times.
3. Cooked dishes must be stored in
airtight covered containers.
4. Fresh wrapped produce can be
placed on the shelf. Fresh fruit and
vegetables should be cleaned and
stored in the crisper bins.
5. Bottles can be placed in the door
section.
6. To store raw meat, wrap in
polythene bags and place on the
lowest shelf. Do not allow to come
into contact with cooked food to avoid
contamination. For safety, only store
raw meat for two to three days.
7. Keep the food packed wrapped
or covered. Allow hot food and
beverages to cool before placing them
in the fridge. Do not store explosive
substances. High proof alcohol must
be stored upright in sealed containers.
Left over canned food should not be
stored in the can.
8. Fizzy drinks should not be frozen
and products such as flavoured water
ices should not be consumed too cold.

EN
17
9. Some fruit and vegetables suffer
damage if kept at temperatures near
0°C. Therefore wrap pineapples,
melons, cucumbers, tomatoes and
similar produce in polythene bags.
10. Place chilled cooked food and
similar food near the rear of the fridge
inner liner where the cold wall is
located.
11. Shelves, racks, crisper bins,
drawers, flaps, bottle grippers are all
removable.
12. Do not leave frozen food at room
temperature to thaw; the best way to
defrost food is to put it in the fridge
to thaw slowly. Make sure you avoid
defrosting food or food juices drip onto
other food.
13. For hygiene reasons, always
wrap food using a suitable packaging
material before storing in your
appliance to avoid contact with the
appliance surface.
Storing Frozen Food
Prepacked commercially frozen food
should be stored in accordance with
the
frozen food manufacturer’s instructions
for a frozen food storage
compartment.
To ensure that the high quality
achieved by the frozen food
manufacturer and the
food retailer is maintained, the
following should be remembered:
1. Put packets in the freezer as quickly
as possible after purchase.
2. Ensure that contents are labelled
and dated.
3. Do not exceed “Use By”, “Best
Before” dates on the packaging.
If there is a power failure do not open
the door. Frozen food should not be
affected if the failure lasts for less than
13 hrs. If the failure is longer, then the
food should be checked and either
eaten immediately or cooked and then
re-frozen.
Freezing Fresh Food
Please observe the following
instructions to obtain the best results.
Do not freeze too large a quantity at
any one time. The quality of the food
is best preserved when it is frozen
right through to the core as quickly as
possible.
Placing warm food into the freezer
compartment causes the refrigeration
compressor to operate continuously
until the food is frozen solid. This can
temporarily lead to excessive cooling
of the refrigeration compartment.
When freezing fresh food turn the
setting towards Max. Small quantities
of food up to 1/2 kg. (1 lb) can be
frozen without having to rotate the
temperature control.
You may place fresh food to be frozen
in any part of the freezer.
Take special care not to mix already
frozen food and fresh food.

EN
18
Making Ice Cubes
Fill the ice - cube tray 3/4 full with
water and place it in the Ice Bank.
Loosen frozen trays with the handle
of a spoon, never use sharp edged
objects such as knives, forks. Store
ice-cubes in the Ice Bank.
Note: If freshly made ice cubes are
not consumed for several weeks
and stored in Ice Bank, they will
slowly reduce in size and eventually
disappear completely.
Defrosting
A) Fridge Compartment
The fridge compartment defrosts
automatically. The defrosting water
runs to the drain tube via a collection
container at the back of the appliance
(1).(see diagram) During defrosting
water droplets may form at the back of
the fridge compartment
where concealed evaporator is
located.Some droplets may remain on
the liner and refreeze when defrosting
is completed. Do not use pointed or
sharp edged objects such as knives,
forks to remove the droplets which
have frozen.
If at any time the defrost water does
not drain from the collection channel,
check to ensure that no food particles
have blocked the drain tube. The drain
tube can be cleared by pushing the
special plastic plunger provided down
the drain tube (2). If the frost layer
reaches about 1/4”(7 mm), reduce
the setting (i.e. from 4 to 1) to restart
automatic defrosting.
B) Freezer Compartment
The freezer compartment defrosts
automatically.
Warnings!
The fan inside the freezer compartment
circulates cold air. Never insert
any object through the guard. Do not
allow children to play with
the freezer fan.
Never store products that contain
inflammable propellant gas
(eg dispensers, spray cans etc.) or
explosive substances.
Don’t cover the shelves with any
protective materials, which may
obstruct air circulation.
Do not allow children to play with the
appliance or tamper with the controls.
Do not obstruct the freezer fan guard
to ensure that you obtain the best
possible performance from your
appliance.

EN
19
Water Dispenser
*optional
Water dispenser is a very useful
feature based on reaching cold water
without opening the door of your
refrigerator. As you will not have to
open your refrigerator door frequently,
you will have saved energy.
.
Using the water dispenser
Push the arm of the water dispenser
with your glass. The dispenser will
cease operating once you release the
arm.
When operating the water dispenser,
maximum flow can be obtained
by pressing the arm fully. Please
remember that the amount of flow
from the dispenser is subject to the
degree you press the arm.
As the level of the water in your glass/
container rises, slightly lessen the
pressure on the arm to prevent the
overspill. If you slightly press the arm,
the water will drip; this is quite normal
and not a failure.
Filling the water dispenser's tank
Open the cover of the water tank as
shown in the figure. Fill in the pure and
clean drinking water. Close the cover.
To avoid flowing of water by mistake,
we recommend you to lock the water
dispenser.
Warning!
• Do not fill the water tank with any
other liquid except for water such as
fruit juices, carbonated beverages
or alcoholic drinks which are not
suitable to use in the water dispenser.

EN
20
Water dispenser will be irreparably
damaged if these kinds of liquids are
used. Warranty does not cover such
usages. Some chemical substances
and additives contained in these
kinds of drinks/liquids may damage
the water tank.
• Use clean and pure drinking water only.
• Capacity of the water tank is 2.2 liters
(3.8 pints); do not overfill.
• Push the arm of the water dispenser
with a rigid glass. If you are using
disposable plastic glasses, push the
arm with your fingers from behind the
glass.
1
1
2
Cleaning the water tank
Release the tank cover from the water
tank by opening latches at both sides.
Remove the water tank and clean with
warm and clean water. Place the water
tank to its seating, install the tank
cover and close the latches.
3
Make sure that the parts removed
(if any) during cleaning are properly
attached to their original places.
Otherwise, water leakage may occur.
Important:
Components of the water tank and
water dispenser should not be washed
in dishwasher.
