Beko DN 150120 D User manual

DN 150120 D
DN 147120 DS
Refrigerator
Kühlschrank
Холодильник
Šaldytuvas

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
For this, we recommend you to carefully read the entire manual of your product
before using it and keep it at hand for future references.
This manual
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
This product is supplied with the selective sorting symbol for waste electrical
and electronic equipment (WEEE).
This means that this product must be handled pursuant to European Directive
2002/96/EC in order to be recycled or dismantled to minimise its impact on
the environment. For further information, please contact your local or regional
authorities.
Electronic products not included in the selective sorting process are potentially
dangerous for the environment and human health due to the presence of
hazardous substances.
Recycling
DN 147120 DS

EN
2
1 Your refrigerator 3
2 Important Safety
Warnings 4
Intended use .....................................4
General safety ...................................4
Child safety........................................6
HCA Warning ....................................6
Things to be done for energy saving..7
3 Installation 8
Preparation........................................8
Points to be considered when re-
transporting your refrigerator .............8
Before operating your refrigerator ......8
Electric connection ............................9
Disposing of the packaging ...............9
Disposing of your old refrigerator .......9
Installing the lower ventilation cover .10
Changing the illumination lamp .......10
Adjusting the legs ............................10
CONTENTS 4 Preparation 11
5 Using your refrigerator 12
Temperature setting button..............12
Setting the temperature of your
refrigerator.......................................12
Dual cooling system ........................12
Dual protection................................12
Vacation Function............................13
Odour filter ......................................14
Crisper humidity control sliders........14
Icematic and ice storage container ..14
Chill compartment ...........................15
Using the rotary crisper (in some
models) ...........................................15
Reversing the doors ........................17
Water dispenser ..............................18
6 Maintenance and
cleaning 20
Protection of plastic surfaces ..........20
7 Recommended solutions
for the problems 21

EN
3
Figures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1Your refrigerator
1- Freezer compartment shelf
2- Icematic
3- Ice storage container
4- Odour filter (in the air duct)
5- Temperature setting button
6- Adjustable glass shelves
7- Wine rack
8- Illumination lens
9- Snack compartments
10- Crisper humidity control sliders
11- Crisper cover
12- Crisper
13- Lower ventilation cover
14- Adjustable legs
15- Freezer compartment door shelf
16- Fridge compartment door shelves
17- Egg holders
18- Water dispenser
19- Rotary storage container
20- Freezer compartment
21- Fridge compartment
1
2
6
8
11
*12
13
14
4
20
21
15
15
10
5
*9
3
18
*7
17
16
16
16
*16
*19
* OPTIONAL

EN
4
2Important Safety Warnings
Please review the following
information. If these are not followed,
personal injury or material damage
may occur. Otherwise, all warranty and
reliability commitments will become
invalid.
The usage life of the unit you
purchased is 10 years. This is the
period for keeping the spare parts
required for the unit to operate as
described.
Intended use
• This appliance is intended to be used
in household and similar applications
such as
– staff kitchen areas in shops, offices
and other working environments;
– farm houses and by clients in hotels,
motels and other residential type
environments;
– bed and breakfast type environments;
– catering and similar non-retail
applications.
• It should not be used outdoors. It is
not appropriate to use it outdoor even
if the place is covered with a roof.
General safety
• When you want to dispose/scrap
the product, we recommend you
to consult the authorized service in
order to learn the required information
and authorized bodies.
• Consult your authorized service for
all your questions and problems
related to the refrigerator. Do not
intervene or let someone intervene to
the refrigerator without notifying the
authorized services.
• Do not eat cone ice cream and ice
cubes immediately after you take
them out of the freezer compartment!
(This may cause frostbite in your
mouth.)
• Do not put bottled and canned
liquid beverages in the freezer
compartment. Otherwise, these may
burst.
• Do not touch frozen food by hand;
they may stick to your hand.
• Vapor and vaporized cleaning
materials should never be used in
cleaning and defrosting processes of
your refrigerator. In such cases, the
vapor might get in contact with the
electrical parts and cause short circuit
or electric shock.
• Never use the parts on your
refrigerator such as the door as a
means of support or step.
• Do not use electrical devices inside
the refrigerator.
• Do not damage the cooling circuit,
where the refrigerant is circulating,
with drilling or cutting tools. The
refrigerant that might blow out when
the gas channels of the evaporator,
pipe extensions or surface coatings
are punctured may cause skin
irritations and eye injuries.
• Do not cover or block the ventilation
holes on your refrigerator with any
material.
• Repairs of the electrical appliances
must only be made by qualified
persons. Repairs performed by
incompetent persons may create a
risk for the user.
• In case of any failure or during
a maintenance or repair work,
disconnect your refrigerator’s mains
supply by either turning off the
relevant fuse or unplugging your
appliance.

EN
5
• Do not pull by the cable when pulling
off the plug.
• Place the beverage with higher proofs
tightly closed and vertically.
• Do not store explosive substances
such as aerosol cans with a
flammable propellant in this
appliance.
• Do not use mechanical devices
or other means to accelerate the
defrosting process, others than those
recommended by the manufacturer.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Do not operate a damaged
refrigerator. Consult your service if
you have any doubts.
• Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
• Exposing the product to rain, snow,
sun and wind is dangerous with
respect to electrical safety.
• Contact the authorized service when
there is a power cable damage and
etc. so that it will not create a danger
for you.
• Never plug the refrigerator into
the wall outlet during installation.
Otherwise, risk of death or serious
injury may arise.
• This refrigerator is designed solely for
storing food. It should not be used for
any other purposes.
• The label that describes the technical
specification of the product is
located on the inner left part of the
refrigerator.
• Do not hook up the refrigerator to
electronic energy saving systems as it
may damage the product.
• If the refrigerator has blue light do not
look at the blue light through optical
devices.
• If the power supply is disconnected
in manually controlled refrigerators
please wait for at least 5 minutes
before reconnecting the power.
• This product manual should be
passed to the next owner of the
refrigerator if the owner changes.
• When moving the refrigerator make
sure that you do not damage the
power cord. In order to prevent
fire the power cord should not be
twisted. Heavy objects should not
be placed on the power cord. When
the refrigerator is being plugged do
not handle the power outlet with wet
hands.
• Do not plug the refrigerator if the
electric outlet is loose.
• Do not splash water directly on the
outer or inner parts of the refrigerator
due to safety.
• Do not spray inflammable materials
such as propane gas etc near
refrigerator due to the risk of fire and
explosion.

EN
6
• Do not place objects filled with water
on top of the refrigerator as it may
result in electric shock or fire.
• Do not overload the refrigerator with
excess food. The excess food may
fall when the door is opened resulting
in injuring you or damaging the
refrigerator. Do not place objects on
top of the refrigerator as the objects
may fall when opening or closing the
refrigerator door.
• Materials that require certain
temperature conditions such as
vaccine, temperature sensitive
medicines, scientific materials etc
should not be kept in refrigerator.
• If refrigerator will not be operated for
an extended period of time it should
be unplugged. A problem in electrical
cable insulation may result in fire.
• The tip of the electric plug should be
cleaned regularly otherwise it may
cause fire.
• The refrigerator may move when the
adjustable feet is not positioned firmly
on the floor. Using the adjustable feet
you can unsure that the refrigerator is
positioned firmly on the floor.
• If the refrigerator has door handle
do not pull the refrigerator via door
handles when moving the product as
it may disconnect the handle from the
refrigerator.
• If you must operate your appliance
adjacent to another refrigerator or
freezer, the distance between the
appliances must be at least 8 cm.
Otherwise condensation may occur
on the side walls facing each other.
• Water mains pressure must not be
below 1 bar. Water mains pressure
must not be above 8 bars.
• Use only drinkable potable water.
Child safety
• If the door has a lock, the key should
be kept away from reach of children.
• Children should be supervised to
ensure that they do not play with the
appliance
HCA Warning
If your product is equipped with
a cooling system that contains
R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the
product catch a fire and ventilate the
room in which the unit is placed.
Ignore the warning if your product
is equipped with a cooling system
that contains R134a.
You can see the gas used in
production of your product on the
rating plate that is located on the left
inner part of it.
Never dispose the product in fire.

EN
7
Things to be done for energy
saving
• Do not leave the doors of your
refrigerator open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
• Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators.
• Pay attention to keep your food in
closed containers.
• Maximum amount of food can be
put in your refrigerator’s freezer
compartment when the freezer
compartment shelf or drawer
is removed.Declared energy
consumption value of your refrigerator
was determined when the freezer
compartment shelf or drawer was
removed and under maximum
amount of food load.There is no risk
in using a shelf or drawer according
to the shapes and sizes of the foods
to be frozen.

EN
8
3Installation
Please remember that the
manufacturer shall not be held liable if
the information given in the instruction
manual is not observed.
Preparation
CYour refrigerator should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
CThe ambient temperature of
the room where you install your
refrigerator should at least be 10°C.
Operating your refrigerator under
cooler conditions than this is not
recommended with regard to its
efficiency.
CPlease make sure that the interior
of your refrigerator is cleaned
thoroughly.
CIf two refrigerators are to be installed
side by side, there should be at least
2 cm distance between them.
CWhen you operate your refrigerator
for the first time, please observe the
following instructions during the initial
six hours.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
COriginal packaging and foam
materials should be kept for future
transportations or moving.
Points to be considered
when re-transporting your
refrigerator
1. Your refrigerator must be
emptied and cleaned prior to any
transportation.
2. Shelves, accessories, crisper and etc.
in your refrigerator must be fastened
securely by adhesive tape against any
jolt before repackaging.
3. Packaging must be tied with thick
tapes and strong ropes and the
rules of transportation printed on the
package must be followed.
Please remember…
Every recycled material is an
indispensable source for the nature
and for our national resources.
If you wish to contribute to recycling
the packaging materials, you can
get further information from the
environmental bodies or local
authorities.
Before operating your
refrigerator
Before starting to use your refrigerator
check the following:
1. Is the interior of the refrigerator dry
and can the air circulate freely in the
rear of it?
2. Insert the 2 plastic wedges onto
the rear ventilation as illustrated in
the following figure. Plastic wedges
will provide the required distance
between your refrigerator and the wall
in order to allow the air circulation.

EN
9
Product must not be operated before it
is repaired! There is danger of electric
shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose them of by
classifying them in accordance
with the waste instructions. Do not
dispose them of along with the normal
household waste.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old machine without
giving any harm to the environment.
You may consult your authorized dealer
or waste collection center of your
municipality about the disposal of
your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
3. Clean the interior of the refrigerator as
recommended in the “Maintenance
and cleaning” section.
4. Plug the refrigerator into the wall
outlet. When the fridge door is open
the fridge compartment interior light
will come on.
5. You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
even if the compressor is not running
and this is quite normal.
6. Front edges of the refrigerator may
feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electric connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
The power cable plug must be easily
accessible after installation.
Voltage and permitted fuse protection
are indicated in the “Specifications”
section.
The specified voltage must be equal to
your mains voltage.
Extension cables and multiway plugs
must not be used for connection.
A damaged power cable must be
replaced by a qualified electrician.

EN
10
Installing the lower
ventilation cover
You can install the lower ventilation
cover as illustrated in the figure.
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator by
turning the front legs of it as illustrated
in the figure. The corner where the
leg exists is lowered when you turn
in the direction of black arrow and
raised when you turn in the opposite
direction. Taking help from someone to
slightly lift the refrigerator will facilitate
this process.
Changing the illumination
lamp
To change the lamp used for
illumination of your refrigerator, please
call your Authorized Service.
CThis appliance is designed to
operate at temperatures specified
in the table below is equipped with
Advanced Electronic Temperature
Control System [AETCS] which
ensures that at the advised setting [4
- four on the knob] the frozen food in
the freezer will not defrost even if the
ambient temperature falls as low as
-15 °C. When first installed the product
MUST NOT be placed in low ambient
temperatures because the freezer will
not reduce to it’s standard operating
temperature. Once it has reached its
steady operating state it can be re-
located. So you may then install your
appliance in a garage or an unheated
room without having to worry about
frozen food in the freezer being spoilt.
However at low ambient temperatures
mentioned above, fridge contents are
likely to freeze, so check and consume
food in the fridge accordingly. When
the ambient temperature returns to
normal, you may change the knob
setting to suit your needs.
CIf the ambient temperature is
below 0°C, the food in the fridge
compartment will freeze.So, we
recommend you don’t use the fridge
compartment in such low ambient
conditions. You can continue using the
freezer compartment as usual.

EN
11
4Preparation
CYour freezer should be installed at
least 30 cm away from heat sources
such as hobs, ovens, central heater
and stoves and at least 5 cm away
from electrical ovens and should not
be located under direct sunlight.
CThe ambient temperature of the room
where you install your freezer should
at least be 10°C. Operating your
freezer under cooler conditions this is
not recommended with regard to its
efficiency.
CPlease make sure that the interior of
your freezer is cleaned thoroughly.
CIf you want to place two products
side by side, e.g. a refrigerator and
a freezer, as a side by side solution
you have to use a decoration kit
which contains a small mat and a
decoration part. The mat is mounted
on the side of one of the products
to create a space between the
products. The decoration part is
placed between the products to hide
the gap between the products (Fig.
2). The decoration kit is not a part of
the product but can be delivered as
an accessory.
CWhen you operate your freezer for
the first time, please observe the
following instructions during the initial
six hours.
- The door should not be opened
frequently.
- It must be operated empty without
any food in it.
- Do not unplug your freezer. If a
power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for
the problems” section.
COriginal packaging and foam
materials should be kept for future
transportations or moving.
C Clean the interior of the freezer as
recommended in the Maintenance
and cleaning" section.

EN
12
5Using your refrigerator
Dual protection
Hygiene : Odour filter in the air duct of
the fridge compartment helps to clean
the air in the refrigerator. This filter
reduces the formation of bad odours
by means of its coating.
Silver: Inner surfaces and crispers
of the refrigerator are rendered
antibacterial by means of the silver-
ion additive. Thus, growth and
reproduction of bacteria on interior
body parts and crisper are prevented.
Temperature setting button
Temperature setting button allows you
to make the temperature setting of
your refrigerator.
Setting the temperature of
your refrigerator
The overall temperature setting of
your refrigerator is made by means of
the temperature setting button on the
right wall of the fridge compartment.
This button has 5different temperature
setting position. Select the position
suitable to your needs.
Dual cooling system
Your refrigerator is equipped with
two separate cooling systems to
cool the fresh food compartment and
freezer compartment. Thus, air in the
fresh food compartment and freezer
compartment do not get mixed.
Thanks to these two separate cooling
systems, cooling speed is much higher
then other refrigerators. Odours in the
compartments do not get mixed. Also
additional power saving is provided
since the automatic defrosting is
performed individually.

EN
13
Vacation Function
If the doors of the product are
not opened for 12 hours after the
thermostat is switched to the hottest
position, then the vacation function will
be activated automatically.
Open the door of the product or
change the thermostat setting to
cancel the function.
Vacation function is optional. It may
vary depending on the product type
and may not be contained in every
product.
It is not recommended to store food
in cooler compartment when the
vacation function is active.
Figures that take place in this instruction
manual are schematic and may not
correspond exactly with your product.
If the subject parts are not included
in the product you have purchased,
then it is valid for other models.

EN
14
Odour filter
Odour filter in the air duct of the fridge
compartment prevents the build-up of
unpleasant odours in the refrigerator.
Crisper humidity control
sliders
Using the crisper humidity control
sliders
Crisper of your refrigerator is designed
specially to keep your vegetables fresh
without loosing their humidity. Cold air
circulates basically around the crisper
and the amount of the cold air passing
through the crisper is controlled by the
sliders on the front side of the crisper
cover.
You can adjust the humidity control
sliders to a suitable position according
to the humidity and cooling condition
of your food in the crisper.
If you want your food in the crisper
to cool more, open the holes of the
humidity control sliders and if you
want them to cool less and keep their
humidity for a longer time, close the
holes.
Icematic and ice storage
container
Using the Icematic
* Fill the Icematic with water and place
it into its seat. Your ice will be ready
approximately in two hours. Do not
remove the Icematic from its seating to
take ice.
* Turn the knobs on it clockwise by 90
degrees.
Ice cubes in the cells will fall down into
the ice storage container below.
* You may take out the ice storage
container and serve the ice cubes.
* If you wish, you may keep the ice
cubes in the ice storage container.
Ice storage container
Ice storage container is only intended
for accumulating the ice cubes. Do not
put water in it. Otherwise, it will break.

EN
15
Chill compartment
You can increase the inner volume
of your refrigerator by removing the
desired snack compartment. Pull the
compartment towards yourself until it
is stopped by the stopper. Raise the
front part for approximately 1 cm and
pull the compartment towards yourself
again to remove it completely.
You can place the food that you want
to freeze in order to prepare them for
freezing in these compartments. You
can also use these compartments
if you want to store your food at a
temperature a few degrees below the
fridge compartment.
Using the rotary crisper (in
some models)
The crisper of your refrigerator which
opens with a rotating movement is
designed specially to provide ease of
usage and allow you to store more ve-
getables and fruits (large volume) you
buy during large shopping.
When you grab and pull the handle
on the lower left hand side of the
crisper, it will rotate from left to right
and open easily. The separator in the
crisper will allow you to separate the
vegetables and fruits according to their
types and prevent them from crushing.

EN
16
3
1
2
4
Rotary storage container
Sliding body shelf can be moved to left
or right in order to allow you place long
bottles, jars or boxes to a lower shelf
(Fig. 1)
You can reach the food that you have
placed into the shelf by grabbing and
turning it from its right edge (Fig.2).
When you want to load or remove it to
clean, turn it by 90 degrees, raise it up
and pull towards yourself (Fig. 3-4).

EN
17
25
24
26
1
6
3
17
18
12
13
5
27
27
23
2
4
4
19
19
16
14
15
45 °
8
180°
20
21
22
22
7
9
10
11
Reversing the doors
Proceed in numerical order .

EN
18
Water dispenser
Water dispenser is a very useful feature
to obtain chilled water without opening
the door of your fridge. Since you do
not have to open the door of your
fridge frequently, you also save on
electricitiy.
Using the water dispenser
Push in the lever of the water
dispenser with your glass. By releasing
the lever, you cut off the dispensing.
When operating the water dispenser,
maximum flow is achieved by fully
depressing the lever. Please note, how
much water flows from the dispenser
depends on how far you depress the
lever. As the level of water in your
cup / glass rises, gently reduce the
amount of pressure on the lever to
avoid overflow. If you depress the lever
a small amount, then water will trickle;
this is perfectly normal and is not a
fault.
Filling in the water tank of water
dispenser
Open the cap of the water tank as
illustrated in the figure. Fill in with pure
and clean drinking water. Close the
cap.
Caution!
• Do not fill water tank with any liquid
other than drinking water; beverages
such as fruit juice, carbonated fizzy
soda drinks, alcoholic drinks are not
suitable for use with water dispenser.
If such liquids are used, the water
dispenser will malfunction and may
be damaged beyond repair. The
guarantee does not cover such uses.
Some chemical ingredients and
additives in such drinks / beverages
may also attack and damage water
tank material.
• Only use clean pure drinking water.
• Capacity of water dispenser tank is 2.2
litres [3.8 pints], do not overfill.
• Push the water dispenser lever with
a rigid cup. If you are using a plastic
disposable cup, then push the lever
with your fingers from behind the cup.

EN
19
Cleaning the water tank
Remove the water tank, open the
latches on both sides and detach the
top cover mechanism from the water
tank. Clean the water tank with warm
clean water, reinstall the top cover
mechanism and fasten the latches.
When installing the water tank, make
sure that hooks behind it fits securely
into the hangers on the door. Make
sure that parts removed during
cleaning (if any) are installed correctly
into their original locations. Otherwise,
water may leak.
Important:
Water tank and components of water
dispenser are not dishwasher-proof.
Water tray
Water that drips while using the water
dispenser accumulates in the drip
tray. Remove the drip tray by pulling
it towards yourself and empty it from
time to time.
Remove the plastic drainer part as
shown in the diagram by pressing
down on the edge.
Remove the water valve from the water
tank as shown in the diagram. When
re-fitting, make sure the O-shaped seal
is in place.
