Beko DS145010M User manual

DS145010M-RDP6701-RDSE450K20B-RDSE450K20W
RDSE450K20S
58 0293 0000/AD EN-FR-AR
EN / FR / AR
Congélateur/Réfrigérateur
Manuel d'utilisation
Refrigerator
User manual


Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the
user manual as well.
The user manual will help you use the product in a fast and safe way.
 Read the manual before installing and operating the product.
 Make sure you read the safety instructions.
 Keep the manual in an easily accessible place as you may need it later.
 Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.

EN
2
1 Your refrigerator 3
2 Important Safety
Warnings 4
Intended use ..................................... 4
General safety .................................. 4
For products with a .......................... 7
water dispenser;................................ 7
Child safety........................................ 7
Compliance with WEEE Directive and
Disposing of the Waste Product: ....... 7
Package information.......................... 7
HC warning ....................................... 8
Things to be done for energy saving .. 8
3 Installation 9
Points to be paid attention to when the
relocation of the refrigerator ............... 9
Electrical connection.......................... 9
Disposing of the packaging ............. 10
Disposing of your old refrigerator ..... 10
Placing and Installation .................... 10
Adjusting the legs ............................ 11
Changing the illumination lamp ....... 11
Door Open Warning......................... 11
Reversing the doors ........................12
Reversing the doors ........................13
Reversing the doors ........................14
Reversing the doors ........................15
CONTENTS
4 Preparation 16
5 Using your refrigerator 17
Thermostat setting button................17
Defrost ............................................ 17
Making ice....................................... 18
Stopping your product..................... 18
Crisper humidity control sliders........ 19
Turbo Cooling Fan ...........................19
Using the rotary crisper (in some
models) ........................................... 20
6 Maintenance and
cleaning 21
Protection of plastic surfaces .......... 21
7.
Troubleshooting 22

EN
3
1Your refrigerator
1. Ice cube tray
2. Freezer shelf
3. Interior light
4. Thermostat knob
5. Fridge compartment shelves
6. Defrost water collection channel
- Drain tube
7. Crisper humidity controls
8. Crisper cover
9. Salad crisper
10. Adjustable legs
11. Door shelf
12. Egg tray
13. Bottle shelf
14.Key
15.Freezer compartment
16.Fridge compartment
*12
1
*2
4
*6
6
7
9
11
5
15
16
*14
13
*12
8
*10
*3
6
*
CFigures that take place in this instruction manual are schematic and may not correspond
exactly with your product. If the subject parts are not included in the product you have
purchased, then it is valid for other models.


EN
4
2Important Safety Warnings
Please review the following
information. Failure to observe
this information may cause
injuries or material damage.
Otherwise, all warranty and
reliability commitments will
become invalid.
Original spare parts will be
provided for 10 years, following
the product purchasing date.
Intended use
This product is intended to be
used
 indoors and in closed areas
such as homes;
 in closed working environments
such as stores and offices;
 in closed accommodation areas
such as farm houses, hotels,
pensions.
 It should not be used outdoors.
General safety
 When you want to dispose/
scrap the product, we
recommend you to consult the
authorized service in order to
learn the required information
and authorized bodies.
 Consult your authorized
service for all your questions
and problems related to the
refrigerator. Do not intervene or
let someone intervene to the
refrigerator without notifying the
authorised services.
 For products with a freezer
compartment; Do not eat
cone ice cream and ice cubes
immediately after you take them
out of the freezer compartment!
(This may cause frostbite in your
mouth.)
 For products with a freezer
compartment; Do not put
bottled and canned liquid
beverages in the freezer
compartment. Otherwise, these
may burst.
 Do not touch frozen food by
hand; they may stick to your
hand.
 Unplug your refrigerator before
cleaning or defrosting.
 Vapor and vaporized cleaning
materials should never be
used in cleaning and defrosting
processes of your refrigerator.
In such cases, the vapor may
get in contact with the electrical
parts and cause short circuit or
electric shock.
 Never use the parts on your
refrigerator such as the door as
a means of support or step.
 Do not use electrical devices
inside the refrigerator.
 Do not damage the parts,
where the refrigerant is
circulating, with drilling or
cutting tools. The refrigerant
that might blow out when the
gas channels of the evaporator,
pipe extensions or surface
coatings are punctured causes
skin irritations and eye injuries.
 Do not cover or block the
ventilation holes on your
refrigerator with any material.
 Electrical devices must be
repaired by only authorised
persons. Repairs performed by
incompetent persons create a
risk for the user.
 In case of any failure or during
a maintenance or repair work,

EN
5
disconnect your refrigerator’s
mains supply by either
turning off the relevant fuse or
unplugging your appliance.
 Do not pull by the cable when
pulling off the plug.
 Ensure highly alcoholic
beverages are stored securely
with the lid fastened and
placed upright.
 Never store spray cans
containing flammable and
explosive substances in the
refrigerator.
 Do not use mechanical devices
or other means to accelerate
the defrosting process, other
than those recommended by
the manufacturer.
 This product is not intended
to be used by persons with
physical, sensory or mental
disorders or unlearned or
inexperienced people (including
children) unless they are
attended by a person who
will be responsible for their
safety or who will instruct them
accordingly for use of the
product
 Do not operate a damaged
refrigerator. Consult with the
service agent if you have any
concerns.
 Electrical safety of your
refrigerator shall be guaranteed
only if the earth system in
your house complies with
standards.
 Exposing the product to
rain, snow, sun and wind is
dangerous with respect to
electrical safety.
 Contact authorized service
when there is a power cable
damage to avoid danger.
 Never plug the refrigerator
into the wall outlet during
installation. Otherwise, risk of
death or serious injury may
arise.
 This refrigerator is intended
for only storing food items. It
must not be used for any other
purpose.
 Label of technical specifications
is located on the left wall inside
the refrigerator.
 Never connect your refrigerator
to electricity-saving systems;
they may damage the
refrigerator.
 If there is a blue light on the
refrigerator, do not look at the
blue light with optical tools.
 For manually controlled
refrigerators, wait for at least 5
minutes to start the refrigerator
after power failure.
 This operation manual should
be handed in to the new owner
of the product when it is given
to others.
 Avoid causing damage on
power cable when transporting
the refrigerator. Bending cable
may cause fire. Never place
heavy objects on power cable.
Do not touch the plug with
wet hands when plugging the
product

EN
6
 Do not plug the refrigerator if
the wall outlet is loose.
 Water should not be sprayed
on inner or outer parts of the
product for safety purposes.
 Do not spray substances
containing inflammable gases
such as propane gas near the
refrigerator to avoid fire and
explosion risk.
 Never place containers filled
with water on top of the
refrigerator; in the event of
spillages, this may cause
electric shock or fire.
 Do not overload the refrigerator
with food. If overloaded, the
food items may fall down
and hurt you and damage
refrigerator when you open the
door.
 Never place objects on top
of the refrigerator; otherwise,
these objects may fall down
when you open or close the
refrigerator’s door.
 As they require a precise
temperature, vaccines,
heat-sensitive medicine and
scientific materials and etc.
should not be kept in the
refrigerator.
 If not to be used for a long
time, refrigerator should be
unplugged. A possible problem
in power cable may cause fire.
 The plug’s tip should be
cleaned regularly with a dry
cloth; otherwise, it may cause
fire.
 Refrigerator may move if
adjustable legs are not properly
secured on the floor. Properly
securing adjustable legs on
the floor can prevent the
refrigerator to move.
 When carrying the refrigerator,
do not hold it from door handle.
Otherwise, it may be snapped.
 When you have to place
your product next to another
refrigerator or freezer, the
distance between devices
should be at least 8cm.
Otherwise, adjacent side walls
may be humidified.
 The product shall never be
used while the compartment
which is located at the top or
back of your product and in
which electronic boards are
available (electronic board box
cover) (1) is open.
1
1

EN
7
For products with a
water dispenser;
 Pressure for cold water inlet
shall be maximum 90 psi (6.2
bar). If your water pressure
exceeds 80 psi (5.5 bar), use a
pressure limiting valve in your
mains system. If you do not
know how to check your water
pressure, ask for the help of a
professional plumber.
 If there is risk of water
hammer effect in your
installation, always use a
water hammer prevention
equipment in your installation.
Consult Professional
plumbers is you are not
sure that there is no water
hammer effect in your
installation.
 Do not install on the hot
water inlet. Take precautions
against of the risk of
freezing of the hoses. Water
temperature operating
interval shall be 33°F (0.6°C)
minimum and 100°F (38°C)
maximum.
 Use only potable water.
Child safety
 If the door has a lock, the key
should be kept away from
reach of children.
 Children must be supervised to
prevent them from tampering
with the product.
Compliance with WEEE
Directive and Disposing of
the Waste Product:
This product complies
with EU WEEE Directive
(2012/19/EU). This product
bears a classification
symbol for waste electrical
and electronic equipment
(WEEE).
This product has been manufactured
with high quality parts and materials
which can be reused and are suitable
for recycling. Therefore, do not dispose
the product with normal domestic
waste at the end of its service life. Take
it to a collection point for the recycling
of electrical and electronic equipment.
Please consult your local authorities
to learn the nearest collection point.
Help protect the environment and
natural resources by recycling used
products. For children’s safety, cut the
power cable and break the locking
mechanism of the door, if any, so
that it will be non-functional before
disposing of the product.
Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.
Do not forget...
Any recycled substance is an
indispensable matter for nature and
our national asset wealth.

EN
8
If you want to contribute to the
re-evaluation of the packaging
materials, you can consult to your
environmentalist organizations or the
municipalities where you are located.
HC warning
If your product's cooling system
contains R600a:
This gas is flammable. Therefore, pay
attention to not damaging the cooling
system and piping during usage and
transportation. In the event of damage,
keep your product away from potential
fire sources that can cause the
product catch a fire and ventilate the
room in which the unit is placed.
Ignore this warning if your
product's cooling system contains
R134a.
Type of gas used in the product is
stated in the type label which is on the
left wall inside the refrigerator.
Never throw the product in fire for
disposal.
Things to be done for energy
saving
 Do not leave the doors of your
refrigerator open for a long time.
 Do not put hot food or drinks in your
refrigerator.
 Do not overload your refrigerator so
that the air circulation inside of it is not
prevented.
 Do not install your refrigerator
under direct sunlight or near heat
emitting appliances such as ovens,
dishwashers or radiators. Keep your
refrigerator at least 30cm away from
heat emitting sources and at least
5cm from electrical ovens.
 Pay attention to keep your food in
closed containers.
 For products with a freezer
compartment; You can store
maximum amount of food items in
the freezer when you remove the
shelf or drawer of the freezer. Energy
consumption value stated for your
refrigerator has been determined
by removing freezer shelf or drawer
and under maximum load. There
is no harm to use a shelf or drawer
according to the shapes and size of
food to be frozen.
 Thawing frozen food in fridge
compartment will both provide energy
saving and preserve the food quality.

EN
9
3Installation
BIn case the information which are given
in the user manual are not taken into
account, manufacturer will not assume
any liability for this.
Points to be paid attention
to when the relocation of the
refrigerator
1. Your refrigerator should be
unplugged.Before transportation of your
refrigerator, it should be emptied and
cleaned.
2. Before it is re-packaged, shelves,
accessories, crisper, etc. inside your
refrigerator should be fixed with
adhesive tape and secured against
impacts. Package should be bound
with a thick tape or sound ropes and
the transportation rules on the package
should be strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the refrigerator,
Check the following before you
start to use your refrigerator:
1. Attach 2 plastic wedges as
illustrated below. Plastic wedges are
intended to keep the distance which will
ensure the air circulation between your
refrigerator and the wall. (The picture is
drawn up as a representation and it is
not identical with your product.)
2. Clean the interior of the
refrigerator as recommended in the
“Maintenance and cleaning” section.
3. Connect the plug of the
refrigerator to the wall socket. When the
fridge door is opened, fridge internal
lamp will turn on.
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give rise
to noise, even if the compressor is not
running and this is quite normal.
5. Front edges of the refrigerator
may feel warm. This is normal. These
areas are designed to be warm to
avoid condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in compliance
with national regulations.
 The power plug must be easily
accessible after installation.
 Electrical safety of your refrigerator
shall be guaranteed only if the earth
system in your house complies with
standards.
 The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
 Extension cables and multi plugs
must not be used for connection.

EN
10
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated before
it is repaired! There is the risk of
electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with the
waste instructions stated by your local
authorities. Do not throw away with
regular house waste, throw away on
packaging pick up spots designated
by the local authorities.
The packing of your refrigerator is
produced from recyclable materials.
Disposing of your old
refrigerator
Dispose of your old refrigerator without
giving any harm to the environment.
 You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your refrigerator.
Before disposing of your refrigerator,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.
Placing and Installation
AIf the entrance door of the room
where the refrigerator will be installed is
not wide enough for the refrigerator to
pass through, then call the authorized
service to have them remove the
doors of your refrigerator and pass it
sideways through the door.
1. Install your refrigerator to a
place that allows ease of use.
2. Keep your refrigerator away
from heat sources, humid places and
direct sunlight.
3. Your product requires adequate
air circulation to function efficiently. If
the product will be placed in an alcove,
remember to leave at least 5 cm
clearance between the product and
the ceiling, rear wall and the side walls.
4. If the product will be placed in
an alcove, remember to leave at least
5 cm clearance between the product
and the ceiling, rear wall and the side
walls. Check if the rear wall clearance
protection component is present at its
location (if provided with the product).
If the component is not available, or if
it is lost or fallen, position the product
so that at least 5 cm clearance shall
be left between the rear surface of the
product and the wall of the room. The
clearance at the rear is important for
efficient operation of the product.
5. Do not place your product on
the materials such as rug or carpet.
6. Place your refrigerator on an
even floor surface to prevent jolts.

EN
11
Adjusting the legs
If your refrigerator is unbalanced;
You can balance your refrigerator
by turning its front legs as illustrated
in the figure. The corner where the
leg exists is lowered when you turn
in the direction of black arrow and
raised when you turn in the opposite
direction. Taking help from someone to
slightly lift the refrigerator will facilitate
this process.
Changing the illumination
lamp
To change the Bulb/LED used for
illumination of your refrigerator, call
your AuthorisedService.
The lamp(s) used in this appliance
is not suitable for household room
illumination. The intended purpose of
this lamp is to assist the user to place
foodstuffs in the refrigerator/freezer
in a safe and comfortable way.The
lamps used in this appliance have to
withstand extreme physical conditions
such as temperatures below -20 °C.
(only chest and upright freezer)
Door Open Warning
*May not be available in all models
An audio warning signal will be given
when the door of your product is
left open for at least 1 minute. This
warning will be muted when the door
is closed or any of the display buttons
(if any) are pressed.

EN
12
10
10
5
4
1
6
4
12 13
3
7
89
14
19
19
22
17
180°
23
21
16
15
24
24
11
45 °
2
20
18
Reversing the doors
Proceed in numerical order.

EN
13
1
6
3
2
4
4
45 °
7
5
8
9
11
12 12
10
10
10
13
14
22
2
23
15
16
2
180°
17
18
1
19
24
24
Reversing the doors
Proceed in numerical order.

EN
14
24
24
45 °
11
22
23
10
10
5
4
2
1
6
4
12 13
3
7
89
14
19
19
18 17
180°
21
20
16
15
Reversing the doors
Proceed in numerical order.

EN
15
10
10
5
4
1
6
4
12 13
3
7
89
14
19
19
22
17
180°
23
21
16
15
2
20
11
45 °
18
Reversing the doors
Proceed in numerical order.

EN
16
4Preparation
 Your cooler/freezer should be installed at
least 30 cm away from heat sources such
as hobs, ovens, central heater and stoves
and at least 5 cm away from electrical
ovens and should not be located under
direct sunlight.
 Please make sure that the interior of your
cooler/freezer is cleaned thoroughly.
 If two coolers are to be installed side
by side, there should be at least 2 cm
distance between them.
 When you operate your cooler/freezer for
the first time, please observe the following
instructions during the initial six hours.
 Its door should not be opened frequently.
 It must be operated empty without
placing any food in it.
 Do not unplug your cooler/freezer.
If a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for the
problems” section.
 The baskets/drawers that are provided
with the chill compartment must always
be in use for low energy consumption
and for better storage conditions.
 Food contact with the temperature
sensor in the freezer compartment may
increase energy consumption of the
appliance. Thus any contact with the
sensor(s) must be avoided.
 This product has been designed to
function at ambient temperatures up to
43 °C (90 SDgrF). Even if the ambient
temperature falls to -15 °C, frozen food
in the freezer does not thaw thanks to its
Advanced Electronic Temperature Control
System. For the first installation, the
product should NOT be placed under low
ambient temperatures. This is because
the freezer cannot go down to standard
operation temperature. When reaching
continuous operation, the product can be
moved to another place. Thus, later you
can place your product in the garage or
an unheated room without the concern
of causing frozen food to get rotten.
However, it is likely that above mentioned
low temperatures may cause the freezing
of the food in the fridge compartment;
thus, please consume the food items in
the fridge in a controlled way as needed.
When ambient temperature goes back to
normal, you may change button setting
according to your need.
 If the ambient temperature is below 0°C,
the food in fridge compartment will freeze.
Therefore, we recommend not using the
fridge compartment in such low ambient
temperatures. You may continue to use
the freezer compartment as usual.
 In some models, the instrument panel
automatically turns off 5 minutes after
the door has closed. It will be reactivated
when the door has opened or pressed on
any key.
 Due to temperature change as a result of
opening/closing the product door during
operation, condensation on the door/
body shelves and the glass containers is
normal.

EN
17
5Using your refrigerator
Thermostat setting button Defrost
Fridge compartment performs full-
automatic defrosting. Water resulting
from the defrosting passes from the
water collection groove and flows
into the evaporator through the drain
pipe and evaporates here by itself.

perform automatic defrosting in order
to prevent decaying of the frozen
food.
Check regularly to see if the drain
pipe is clogged or not and clear
it with the stick in the hole when
necessary.
The interior temperature of your
refrigerator changes for the following
reasons;
 
 
leaving the door open for long
periods,
 
without cooling down to the room
temperature,
 
room (e.g. exposing to sunlight).
 
temperature due to such reasons
by using the thermostat. Numbers
around the thermostat button
indicates the cooling degrees.
 
than 32°C, turn the thermostat
button to maximum position.
 
than 25°C, turn the thermostat
button to minimum position.

compartment must be defrosted
every 6 months. It is recommended
to defrost the ice when the deep
freezer compartment is not filled too
much or is empty.
 
by paper and keep them in the
coolest place possible or in another
refrigerator if available.

EN
18

temperature setting button or unplug
the power cord from the outlet. You
can place a container filled with hot
water into the freezer compartment
or leave the door of the freezer
compartment open in order to hasten
the defrosting.

in the lower container of the freezer
compartment with an absorbent cloth
or sponge.
Stopping your product
If your thermostat is equipped with “0”
position:
- Your product will stop operating
when you turn the thermostat button
to “0” (zero) position. Your product
will not start unless to you turn the
thermostat button to position “1” or
one of the other positions again.
If your thermostat is equipped with
“min” position:
- Unplug your product to stop it.
Making ice
*optional
Fill the ice container with water and
place it into the freezer compartment.
Your ice will be ready approximately in
two hours.
You can remove the ice in the ice
container by removing it from the
freezer and twisting it.

completely and return the
temperature setting button to its
previous position.

while it is empty and its doors are
closed before replacing your food into
the deep freezer.

EN
19
Crisper humidity control
sliders
Using the crisper humidity control
sliders
Crisper of your refrigerator is designed
specially to keep your vegetables fresh
without loosing their humidity. Cold air
circulates basically around the crisper
and the amount of the cold air passing
through the crisper is controlled by the
sliders on the front side of the crisper
cover.
You can adjust the humidity control
sliders to a suitable position according
to the humidity and cooling condition
of your food in the crisper.
If you want your food in the crisper
to cool more, open the holes of the
humidity control sliders and if you
want them to cool less and keep their
humidity for a longer time, close the
holes.
Turbo Cooling Fan
“Turbo cooling fan is designed to
ensure homogenous distribution and
circulation of the cold air inside your
refrigerator. Operation time of the
turbo cooling fan may vary depending
on the properties of your product.
While the turbo fan works only with
the compressor in some products,
the control system determines its
operation time in some products
in accordance with the cooling
requirement. This situation is explained
on a separate warning and information
label attached on the refrigerator in
products equipped with turbo fans
running under different conditions than
the compressor.”

