Beko GN163020X User manual

Refrigerator
GN163020X
GN162320X

Please read this manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked under the most
meticulous quality control procedures, will provide you an effective service.
For this, we recommend you to carefully read the entire manual of your product before using it and keep
it at hand for future references.
The user manual will help you use the product in a fast and safe way.
• Will help you use your appliance in a fast and safe way.
• Read the manual before installing and operating your product.
• Follow the instructions, especially those for safety.
• Keep the manual in an easily accessible place as you may need it later.
• Besides, read also the other documents provided with your product.
Please note that this manual may be valid for other models as well.
Symbols and their descriptions
This instruction manual contains the following symbols:
CImportant information or useful usage
tips.
AWarning against dangerous conditions
for life and property.
BWarning against electric voltage.
Packaging materials of the product are
manufactured from recyclable materi-
als in accordance with our National
Environment Regulations.

2 / 35 EN Refrigerator / User Manual
1 Important instructions for safety and
environment 3
1.1 General safety . . . . . . . . . . . . . . . . . . . .3
1.1.1HCA warning . . . . . . . . . . . . . . . . . . . . .4
1.1.2For products with a water dispenser . . . .4
1.2 Intended use . . . . . . . . . . . . . . . . . . . . .4
1.3 Children's safety . . . . . . . . . . . . . . . . . .4
1.4 Compliance with WEEE Directive and Disposing
of the Waste Product: . . . . . . . . . . . . . .5
1.5 Compliance with RoHS Directive:. . . . . . . .5
1.6 Package information. . . . . . . . . . . . . . . . .5
2 Your refrigerator 6
3 Installation 7
3.1. Appropriate installation location . . . . . . .7
3.2. Installing the plastic wedges. . . . . . . . . .7
3.3. Electrical connection . . . . . . . . . . . . . . .8
3.4. Adjusting the feet. . . . . . . . . . . . . . . . . .8
3.5. Illumination lamp . . . . . . . . . . . . . . . . . .8
3.6. Door open warning. . . . . . . . . . . . . . . . .9
3.7. Water connection . . . . . . . . . . . . . . . . .9
3.8. Connecting the water hose to the
refrigerator . . . . . . . . . . . . . . . . . . . . .10
3.9. Connecting of the water hose to the cold
water mains line . . . . . . . . . . . . . . . . .10
3.10.Water filter. . . . . . . . . . . . . . . . . . . . . .11
3.11. Mounting the external filter onto the wall11
3.12.Attaching the internal filter into the
refrigerator . . . . . . . . . . . . . . . . . . . . .12
3.13. Connecting the water hose to demijohn13
3.14.Things to do to have the filter usage time
calculated automatically. . . . . . . . . . . .14
3.15. Before starting to use the water/ice
dispenser . . . . . . . . . . . . . . . . . . . . . .14
3.16.Transportation of the product . . . . . . . .15
4 Preparation 16
4.1. Things to be done for energy saving . . .16
4.2. Efficient operation . . . . . . . . . . . . . . . .16
4.3. Recommendations on the fridge
compartment. . . . . . . . . . . . . . . . . . . .16
4.4. Initial use. . . . . . . . . . . . . . . . . . . . . . .17
5 Operating the product 18
5.1. Indicator panel. . . . . . . . . . . . . . . . . . .18
5.2. Dual cooling system. . . . . . . . . . . . . . .26
5.3. Freezing fresh food . . . . . . . . . . . . . . .26
5.4. Recommendations for preserving the frozen
food . . . . . . . . . . . . . . . . . . . . . . . . . .27
5.5. Placing the food. . . . . . . . . . . . . . . . . .27
5.6. Deep-freeze information. . . . . . . . . . . .27
5.7. Icematic and ice storage container . . . .28
5.8. Ice making. . . . . . . . . . . . . . . . . . . . . .28
5.9. Chiller compartment. . . . . . . . . . . . . . .29
5.10. Butter & cheese section . . . . . . . . . . .29
5.11.Egg section . . . . . . . . . . . . . . . . . . . . .29
5.12.Crisper . . . . . . . . . . . . . . . . . . . . . . . .29
5.13. Blue light . . . . . . . . . . . . . . . . . . . . . . .29
5.14.Ion . . . . . . . . . . . . . . . . . . . . . . . . . . .29
5.15.Odor filter . . . . . . . . . . . . . . . . . . . . . .29
5.16. Using the water dispenser . . . . . . . . . .30
5.17.Drip tray . . . . . . . . . . . . . . . . . . . . . . .30
5.18. Minibar . . . . . . . . . . . . . . . . . . . . . . . .31
6 Maintenance and cleaning 32
6.1 Avoiding bad odours. . . . . . . . . . . . . . .32
6.2 Protecting the plastic surfaces . . . . . . .32
7 Troubleshooting 33

3 / 35 EN
Refrigerator / User Manual
1 Important instructions for safety and environment
This section contains safety instructions that will
help protect from risk of personal injury or property
damage. Failure to follow these instructions shall
void any warranty.
1.1 General safety
• This product can be used by children at and
above 8 years old and by persons whose
physical, sensory or mental capabilities were
not fully developed or who lack experience and
knowledge provided that they are supervised
or trained on the safe usage of the product and
the risks it brings out. Children must not play
with the product. Cleaning and maintenance
works should not be performed by children
unless they are supervised by someone.
• Unplug the product if a failure occurs while it
is in use.
• If the product has a failure, it should not be
operated unless it is repaired by the Authorised
Service Agent. There is the risk of electric
shock!
• Connect the product to a grounded outlet
protected by a fuse complying with the
values in the rating plate. Have the grounding
installation made by a qualified electrician. Our
company shall not be liable for any damages
that will arise when the product is used
without grounding in accordance with the local
regulations.
• Unplug the product when not in use.
• Never wash the product by spreading or
pouring water onto it! There is the risk of
electric shock!
• Never touch the plug with wet hands! Never
unplug by pulling on the cable, always pull out
by grabbing the plug.
• It is recommended to clean the tip of the plug
regularly with a dry cloth.
• Do not plug the refrigerator if the wall outlet is
loose.
• Never connect your refrigerator to electricity-
saving systems. Such systems are harmful for
the product.
• Unplug the product during installation,
maintenance, cleaning and repairing
procedures.
• Always have the installation and repairing
procedures carried out by the Authorised
Service Agent. Manufacturer shall not be
held liable for damages that may arise from
procedures carried out by unauthorised
persons.
• Do not eat cone ice cream and ice cubes
immediately after you take them out of the
freezer compartment! This may cause frostbite
in your mouth!
• Do not touch frozen food by hand! They may
stick to your hand!
• Do not put bottled and canned liquid beverages
in the freezer compartment. They may burst!
• Never use steam and steam assisted cleaning
materials to clean or defrost the refrigerator.
Steam will cause short circuit or electric
shock since it would get into contact with the
electrical parts in the refrigerator!
• Do not use mechanical devices or other
methods to accelerate the defrosting process,
other than those recommended by the
manufacturer.
• Never use the parts on your refrigerator such
as the door and drawer as a means of support
or step. This will cause the product to tip over
or parts of it get damaged.
• Do not damage the cooling circuit, where the
refrigerant is circulating, with drilling or cutting
tools. The refrigerant that might blow out
when the gas channels of the evaporator, pipe
extensions or surface coatings are punctured
may cause skin irritations and eye injuries.
• Do not cover or block the ventilation holes on
the refrigerator with any material.
• Place the beverage with higher proofs tightly
closed and vertically.

4 / 35 EN Refrigerator / User Manual
Important instructions for safety and environment
• Do not use gaseous sprays near the product
since there is the risk of fire or explosion!
• Flammable items or products that contain
flammable gases (e.g. spray) as well as the
explosive materials should never be kept in the
appliance.
• Do not place containers filled with liquid on top
of the product. Spilling water on an electrical
component may cause electric shocks or risk
of fire.
• Do not store products (vaccines, heat-sensitive
medicines, scientific materials and etc.) that
require a precise temperature control in the
refrigerator.
• If you will not operate the product for a long
period of time, unplug and unload the food in
it.
• If the product is equipped with blue light, do
not look at the blue light with optical tools.
• Exposing the product to rain, snow, sun and
wind is dangerous with respect to electrical
safety.
• In products with mechanical control
(thermostat), wait for minimum 5 minutes to
plug in the product again after unplugging it.
• Do not overload the product. It may fall when
the door is opened, and cause injury or
damage. Similar problems may occur in case
of putting things on top of the product.
• If the product's door is equipped with a handle,
do not pull by the handle when changing the
place of the product. Handle may get loose.
• Pay attention not to have your hand or any part
of your body get caught by the moving parts
inside the product.
1.1.1 HCA warning
• If the product is equipped with a cooling
system containing R600a gas, pay attention
not to damage the cooling system and piping
during usage and transportation. This gas is
flammable. If the cooling system is damaged,
keep the product away from potential sources
that can cause the system catch a fire and
ventilate the room in which the unit is placed
immediately.
CIf the product is equipped with a cooling
system containing R134a gas, ignore this
warning.
CYou can learn the gas used in production of
your product on the rating plate located on
the left inner part of it.
AWARNING: Never dispose the product
in fire.
1.1.2 For products with
a water dispenser
• Pressure of water mains should be minimum 1
bar and maximum 8 bars.
• Use only potable water.
1.2 Intended use
• This product has been designed for domestic
use. It is not suitable for commercial use and it
must not be used out of its intended use.
• Product must be used only for storing food.
• The manufacturer waives any responsibility
arisen from incorrect usage or transportation.
• The service life of your product is 10 years.
During this period, original spare parts will be
available to operate the appliance properly.
1.3 Children's safety
• Packaging materials are dangerous for the
children. Keep packaging materials in a safe
place away from reach of the children.
• Electrical products are dangerous for the
children. Keep children away from the product
when it is in use.
• If the product's door is equipped with a lock,
keep the keys away from reach of children.

5 / 35 EN
Refrigerator / User Manual
Important instructions for safety and environment
1.4 Compliance with WEEE
Directive and Disposing
of the Waste Product:
This product complies with EU WEEE
Directive (2012/19/EU). This product
bears a classification symbol for
waste electrical and electronic equipment (WEEE).
This product has been manufactured with high
quality parts and materials which can be reused
and are suitable for recycling. Do not dispose of
the waste product with normal domestic and other
wastes at the end of its service life. Take it to the
collection center for the recycling of electrical and
electronic equipment. Please consult your local
authorities to learn about these collection centers.
1.5 Compliance with
RoHS Directive:
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
1.6 Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local
authorities.

6 / 35 EN Refrigerator / User Manual
2 Your refrigerator
2
1
9
*8
*15
*14
12
13
*17
*16
10
*11
9
*7
*4
3
5
6
C*Optional: Figures in this user manual are schematic and may not match the product exactly. If
the relevant parts are not available in the product you purchased, it applies to other models.
1- Freezer compartment
2- Fridge compartment
3- Fan
4- Butter-cheese compartments
5- Glass racks
6- Fridge compartment door racks and egg
compartment
7- Minibar accessory
8- Crispers
9- Adjustable feet
10- Chiller compartment
11- Blue light
12- Frozen food storage compartments
13- Freezer compartment door racks
14- Odor filter
15- Ice makers
16- Ice storage compartment
17- Ice maker decorative cover
*optional

7 / 35 EN
Refrigerator / User Manual
3 Installation
Always have the installation and repairing
procedures carried out by the Authorized Service
Agent. Manufacturer shall not be held liable for
damages that may arise from procedures carried
out by unauthorized persons.
Refer to the nearest Authorized Service Agent for
installation of the product. To make the product
ready for use, make sure that the electricity
installation is appropriate before calling the
Authorized Service Agent. If not, call a qualified
electrician to have any necessary arrangements
carried out.
C
Preparation of the location and electrical
installation at the place of installation is
under customer's responsibility.
B
Product must not be plugged in during
installation. Otherwise, there is the risk of
death or serious injury!
B
WARNING: Installation and electrical
connections of the product must be
carried out by the Authorized Service
Agent. Manufacturer shall not be held
liable for damages that may arise from
procedures carried out by unauthorized
persons.
A
WARNING: Prior to installation, visually
check if the product has any defects on
it. If so, do not have it installed. Damaged
products cause risks for your safety.
CMake sure that the power cable is not
pinched or crushed while pushing the
product into its place after installation or
cleaning procedures.
3.1. Appropriate
installation location
A
WARNING: If the door of the room where
the product will be placed is too small for
the product to pass, then the product's
doors must be removed and the product
must be turned aside to pass it through.
• Choose a place at where you would use the
product comfortably.
• Install the product at least 30 cm away from
heat sources such as hobs, ovens, heater
cores and stoves and at least 5 cm away from
electrical ovens. Product must not be subjected
to direct sun light and kept in humid places after
installation.
• Appropriate air ventilation must be provided
around your product in order to achieve an
efficient operation. If the product is to be placed
in a recess in the wall, pay attention to leave at
least 5 cm distance with the ceiling and side
walls.
• Do not place the product on the materials such
as rugs or carpets.
• Place the product on an even floor surface to
prevent jolts.
• Do not install the product in places where the
temperature falls below 10°C.
C
If two coolers are to be installed side
by side, there should be at least 4 cm
distance between them.
3.2. Installing the
plastic wedges
Plastic wedges are used to create the distance
for the air circulation between the product and
the rear wall. Insert the 2 plastic wedges onto the
rear ventilation cover as illustrated in the figure.
To install the wedges, remove the screws on the
product and use the screws given in the same
pouch with the wedges.

8 / 35 EN Refrigerator / User Manual
Installation
3.3. Electrical connection
Connect the product to a grounded outlet
protected by a fuse complying with the values in
the rating plate. Our company shall not be liable
for any damages that will arise when the product
is used without grounding in accordance with the
local regulations.
• Electrical connection must comply with national
regulations.
• Power cable plug must be within easy reach
after installation.
• The voltage and allowed fuse or breaker
protection are specified in the Rating Plate
which is affixed to interior of the product. If
the current value of the fuse or breaker in the
house does not comply with the value in the
rating plate, have a qualified electrician install a
suitable fuse.
• The specified voltage must be equal to your
mains voltage.
• Do not make connections via extension cables
or multi-plugs.
BWARNING: Damaged power cable must
be replaced by the Authorized Service
Agents.
BWARNING: If the product has a failure,
it should not be operated unless it is
repaired by the Authorized Service Agent!
There is the risk of electric shock!
3.4. Adjusting the feet
If the product stands unbalanced after installation
adjust the feet. Taking help from someone to
slightly lift the refrigerator will facilitate this
process.
BWARNING: First unplug the product.
Product must not be plugged in when
adjusting the feet. There is the risk of
electric shock!
Turn the front feet to balance the product. The
corner where the foot exists is lowered when you
turn in the direction of arrow and raised when you
turn it in the opposite direction.
3.5. Illumination lamp
Do not attempt to repair yourself but call the
Authorized Service Agent if the LED illumination
lamps do not go on or are out of order.

9 / 35 EN
Refrigerator / User Manual
Installation
3.6. Door open warning
(This feature is optional)
An audio warning signal will be given when the
door of your product is left open for 1 minute. This
warning will be muted when the door is closed or
any of the display buttons (if any) are pressed.
3.7. Water connection
(This feature is optional)
Water system installation of the refrigerator must
be performed by the Authorized Service Agent.
Depending on the model of the refrigerator, you
can connect it either to a demijohn or water mains.
First you must connect the water hose to the
refrigerator.
C
In cases where a demijohn is used, a
separate pump must also be used.
A
WARNING: Refrigerator and the pump, if
any, must be unplugged during connection.
C
Following parts may not be supplied with
your product since they are not required
when using a demijohn.
Check that following parts have been delivered
together with the product:
1. Union for connecting the water hose to the rear of
the refrigerator
2. 3 pieces of pipe clips (used to secure the water
hose)
c
a
a
b
1
2
3
1
4
2
*5
3. 5-meter long water hose (1/4 inch in diameter)
4. (4) Cold mains water valve with mesh filter (tap
adapter)
5. (5) External water filter. (If there is a demijohn
connection; it is not necessary to use a water
filter.)

10 / 35 EN Refrigerator / User Manual
Installation
3.8. Connecting the water
hose to the refrigerator
1. Slip the union (b) onto the water hose (a).
2. Push the water hose downwards firmly to slip it
onto the water inlet valve (c).
3. Tighten the union (c) by hand to secure it onto the
water inlet valve.
C
Normally, you are not required to tighten
the union with a tool. However, you can use
a spanner or pliers to tighten the union if
there is a leakage.
3.9. Connecting of the water
hose to the cold water mains line
(This feature is optional)
If you will use the refrigerator by connecting it
to the cold water mains line, you must install a
standard 1/2" valve connector to the cold water
installation of your home. If this valve is not present
or you are not sure, consult a qualified plumber.
1. Separate the union from the tap adaptor.
2. Install the tap adaptor to standard 1/2” valve
connector.
3. After inserting the water hose to the union, install
it to the tap adaptor and insert to the union to the
tap adapter.
4. Tighten the union by hand.
A
WARNING: Secure the water hose
to suitable points by means of the
clips supplied to avoid any damage or
displacement or accidental disconnection.
A
WARNING: After turning on the water
valve, make sure that there is no leakage
at both connection points of the water
hose. If there is a leakage, turn off the
valve immediately and tighten all joints
again using a spanner or a pliers.
A
WARNING: Make sure that standard 1/2"
valve connector is available and completely
turned off on your cold water mains line.

11 / 35 EN
Refrigerator / User Manual
Installation
3.10.Water filter
(This feature is optional)
Your refrigerator may be equipped with an external
or internal filter depending on its model. To fit the
water filter, follow the instructions below referring
to the figures supplied:
3.11.Mounting the external
filter onto the wall
1. First, determine the location to mount the external
filter.
2. Then, determine the distance between the
filter and the tap and filter and the water inlet
respectively. Prepare hoses at required lengths.
3. Mount the filter connection kit onto the wall by
using a screwdriver and attach the filter.
B
WARNING: Water filter must be hold
upright as shown in the figure. It is critical
to connect the water inlet and outlet
hoses on the filter correctly.
C
After connecting the filter, do not
consume the first 10 glasses of
water.
B
WARNING: Never mount the filter onto
the refrigerator. Coolant pipes might be
pierced!

12 / 35 EN Refrigerator / User Manual
Installation
3.12.Attaching the internal
filter into the refrigerator
1. Press “Ice Off” button on the display.
2. Remove the crisper and chiller compartments to
access the water filter.
3. Remove the water filter bypass cover by turning it
downwards.
A
WARNING: Ensure that the Ice Off mode
is enabled before removing the by-pass
cover.
C
It is normal that a few drops of water drip
after the cover has been removed.
4. Seat the water filter cover into the mechanism
and push forwards to lock it in place.
5. Press “Ice Off” button on the display again to exit
this mode.
C
Water filter must be replaced every 6
months. When replacing the water filter
or if you will not use the filter anymore,
remove it as illustrated in the figure and
install the bypass cover. Make sure that the
"Ice Off" mode is enabled before removing
the filter.
A
WARNING: Water filter cleans some
foreign particles in the water. It does not
purify water from microorganisms.
A
WARNING: Ice Off button must be
pressed before replacing the water filter or
installing the by-pass cover.
A
WARNING: Unplug the product during
the replacement of the filter.

13 / 35 EN
Refrigerator / User Manual
Installation
3.13. Connecting the water
hose to demijohn
(This feature is optional)
To make the water supply connection between
the refrigerator and the demijohn, you must use
a water pump. Follow the instructions below after
connecting one end of the water hose coming out
of the pump to the refrigerator.
1. Complete the connection by pushing the other
end of the water hose into the water hose inlet of
the pump.
2. Put and fix the pump hose into the demijohn.
3. After completing the connection, plug in and run
the pump.
C
After the pump starts to operate, wait for
2-3 minutes to allow it attain the required
efficiency.
C
You can refer to the user manual of the
pump while making the water connection.
C
There is no need to use water filter if you
will be using a demijohn.

14 / 35 EN Refrigerator / User Manual
Installation
3.14.Things to do to have
the filter usage time
calculated automatically
(For products connected to the mains water line
and equipped with filter)
1. Plug in the refrigerator. Press A (key lock) button
simultaneously to enable the key lock.
A
3
42
1
2. Then press on the following buttons in turn.
A
3
42
1
1.Vacation button
2.Fridge temperature setting button
3.Quick Cool setting button
4.Freezer temperature setting button
When the buttons are pressed in the correct order,
Key Lock symbol will turn off, buzzer will sound
shortly and Filter Change Warning indicator will
turn on. When the Filter Replacement Warning
button is pressed on, filter usage times are started
to be calculated automatically.
CIf the filter usage time is calculated
automatically, Filter Change Warning
indicator will illuminate continuously in a
few seconds after the product is plugged
in.
CAutomatic filter usage time calculation is
not enabled ex factory. It must be enabled
in products equipped with a filter.
CIf the same procedure is repeated when
the automatic filter usage time calculation
is enabled, then the function will be
cancelled.
3.15.Before starting to use
the water/ice dispenser
(This feature is optional)
• If the water pressure is below 1 bar or a
demijohn will be used, than a separate must be
used as well.
• Water system of the refrigerator must be
connected to the cold water line. It must not be
connected to hot water line.
• No water may be obtained in the initial start-
up of the refrigerator. Because there is air in
the system. To discharge air from the system,
press dispenser latch for 1-2 minutes until
water comes from the dispenser. Water flow
may be irregular at the beginning. After the
air in the system is discharged, water flow will
return to normal.
• During initial use, you will have to wait
approximately 12 hours for the water to cool
down.
• It will take around 1-2 days for the system to
produce required amount of ice.
• Water pressure must be between 1-8 bars for
the operation of ice/water dispenser smoothly.
For this, check that 1 glass of water (100 cc)
can be filled in 10 seconds.
• The first 10 glasses of water should not be
consumed.
• You must wait approximately 12 hours to
obtain ice from the ice dispenser for the first
time. If there is not enough ice in the ice
container, ice may not be obtained from ice
dispenser.
• Do not consume the first 30 pieces (3-4 Liters)
of ice cubes.
• First several glasses of water may be turbid
when the filter is used for the first time.
Therefore, do not consume the first several
glasses of water.

15 / 35 EN
Refrigerator / User Manual
Installation
• If the water dispenser is not used for a long
period of time, first 1-2 glasses of water can
be hot.
• If a power outage or a temporary failure occurs
while the refrigerator is operating, ice can melt
down a little bit and then get frozen again. In
such a case, ice cubes can stick to each other.
If the outage or failure prolongs, ice can melt
down causing water leakage. If you experience
such a problem, empty and clean the ice
container.
• Ice cubes can stick to each other if they are left
in the container for a long time.
• If the product is to be connected to the water
mains, make sure that you use potable water.
• Water system of the product is designed to
operate only with water. Do not use beverage
such as soft drinks and/or juices in the water
system.
• It is recommended that the water is
disconnected if you will not be using the
refrigerator for a long period of time due to
vacation or similar reasons.
• Do not attempt to dismantle the ice container
group assembly parts.
• Do not attempt to clean the ice container
assembly without removing it from the
refrigerator.
3.16.Transportation
of the product
1. Unplug the product before transporting it.
2. Remove water connections.
3. Secure the shelves, accessories, crisper and
etc. in the refrigerator by adhesive tape before
repackaging it.
CPackaging must be tied with thick tapes or
strong ropes and the rules of transportation
printed on the package must be followed.
COriginal packaging and foam materials
should be kept for future transportations.
AWARNING: Packaging materials
are dangerous for the children. Keep
packaging materials in a safe place away
from reach of the children.

16 / 35 EN Refrigerator / User Manual
4 Preparation
4.1. Things to be done
for energy saving
AConnecting the product to electric energy
saving systems is risky as it may cause
damage on the product.
• Do not leave the doors of your refrigerator
open for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload the refrigerator. Cooling
capacity will fall when the air circulation inside
is hindered.
• Do not place the refrigerator in places subject
to direct sunlight. Install the product at least
30 cm away from heat sources such as hobs,
ovens, heater cores and stoves and at least 5
cm away from electrical ovens.
• Store your food in refrigerator in closed
containers.
• You can load maximum amount of food to the
freezer compartment of the refrigerator by
removing the freezer compartment shelf of
drawer. Declared energy consumption value
of the refrigerator was determined with the
freezer compartment shelf or drawer removed
and with maximum amount of food loaded.
There is no risk in using a shelf or drawer
suitable for the shapes and sizes of the foods
to be frozen.
• Thawing frozen food in fridge compartment
will both provide energy saving and preserve
the food quality.
CThe ambient temperature of the room
where you install the refrigerator
should at least be 10°C. Operating your
refrigerator under cooler conditions than
this is not recommended.
CInside of your refrigerator must be
cleaned.
CIf two coolers are to be installed side
by side, there should be at least 4 cm
distance between them.
4.2. Efficient operation
Specified energy consumption value of your
refrigerator is determined under maximum load by
removing the freezer compartment upper rack and
while other racks and two bottom drawers are in
place. There is no harm to use a shelf or drawer
according to the shapes and size of food to be
frozen.
4.3. Recommendations on
the fridge compartment
• Do not allow the food to touch the
temperature sensor in fridge compartment.
To allow the fridge compartment keep its
ideal storage temperature, sensor must not
be hindered by food.
• Do not put hot food and beverages inside the
product.

17 / 35 EN
Refrigerator / User Manual
Preparation
4.4. Initial use
Before starting to use the product, check that all
preparations are made in accordance with the
instructions in sections "Important instructions for
safety and environment" and "Installation".
• Clean the interior of the refrigerator as
recommended in the “Maintenance and
cleaning” section. Check that inside of it is dry
before operating it.
• Plug the refrigerator into the grounded wall
outlet. When the door is opened the interior
illumination will turn on.
• Run the refrigerator without putting any food
for 6 hours and do not open its door unless
certainly required.
CYou will hear a noise when the compressor
starts up. The liquids and gases sealed
within the refrigeration system may also
give rise to noise, even if the compressor is
not running and this is quite normal.
CFront edges of the refrigerator may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.

18 / 35 EN Refrigerator / User Manual
5 Operating the product
5.1. Indicator panel
Indicator panels may vary according to the product model.
Audio – visual functions on the indicator panel helps you in using your refrigerator.
8123
45
7 6
9
1. Fridge compartment indicator
2. Error status indicator
3. Temperature indicator
4. Vacation function button
5. Temperature setting button
6. Compartment selection button
7. Freezer compartment indicator
8. Economy mode indicator
9. Vacation function indicator
*optional
C*Optional:Figures in this user manual are schematic and may not match the product exactly. If the
subject parts are not included in the product you have purchased, then those parts are valid for other
models.

19 / 35 EN
Refrigerator / User Manual
Operating the product
1. Fridge compartment Indicator
Fridge compartment light is illuminated while the
fridge compartment temperature is set.
2. Error status indicator
If your refrigerator does not perform enough
cooling or in case of a sensor fault, this indicator
is activated. When this indicator is activated, “E” is
displayed on the freezer compartment temperature
indicator, and numbers such as “1,2,3...” are
displayed on the fridge compartment temperature
indicator. These numbers on the indicator inform
service personnel about the error.
3. Temperature indicator
Indicates freezer, fridge compartment temperature.
4. Vacation function button
Press on Vacation Button for 3 seconds to
activate this function. When the vacation function
is activated, “- -” is displayed on the fridge
compartment temperature indicator and no active
cooling is performed on the fridge compartment.
It is not suitable to keep the food in the fridge
compartment when this function is activated. Other
compartments shall be continued to be cooled as
per their set temperature.
To cancel this function press vacation button
again.
5. Temperature setting button
Changes the temperature of the relevant
compartment between -24°C... -18°C and
8°C...1°C.
6. Compartment selection button
Selection button: Press compartment selection
button to switch between fridge and freezer
compartments.
7. Freezer compartment indicator
Fridge compartment light is illuminated while the
freezer compartment temperature is set.
8. Economy mode indicator
Indicates that the refrigerator operates in energy
saving mode. This display shall be activated if the
freezer compartment temperature is set to -18°C.
9. Vacation function indicator
Indicates that vacation is activated.
