Beko RDNE650E60XP User manual

RDNE650E60XP-RDNE650E60ZXR
EN/AR
58 5779 0000/AG EN-AR
Refrigerator
User Manual


Dear Customer,
Please read this manual before using the product.
Thank you for choosing this product. We would like you to achieve the optimal efficiency
from this high quality product which has been manufactured with state of the art tech-
nology. To do this, carefully read this manual and any other documentation provided
before using the product and keep it as a reference.
Heed all information and warnings in the user manual. This way, you will protect yourself
and your product against the dangers that may occur.
Keep the user manual. Include this guide with the unit if you hand it over to someone
else.
The following symbols are used in the user guide:
Hazard that may result in death or injury.
NOTICE A hazard that may cause material damage to the product or its
surroundings
Important information or useful tips on operation.
Read the user manual.
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
.The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/

2 / 32 EN Refrigerator / User Guide
1 Safety Instructions 3
1.1 Purpose of usage . . . . . . . . . . . . . . . . . . 3
1.2 Safety of children, vulnerable persons and
pets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Electrical safety. . . . . . . . . . . . . . . . . . . 4
1.4 Handling Safety. . . . . . . . . . . . . . . . . . . 4
1.5 Installation Safety . . . . . . . . . . . . . . . . . 4
1.6 Operational safety . . . . . . . . . . . . . . . . . 5
1.7 Maintenance and cleaning safety. . . . . . 7
1.8HomeWhiz . . . . . . . . . . . . . . . . . . . . . . . 7
1.9 Lighting . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Environmental instructions 8
2.1 Compliance with the WEEE Directive and
Disposing of the Waste Product: . . . . . . . . 8
2.2 Compliance with RoHS Directive . . . . . . . . . . 8
2.3 Package information. . . . . . . . . . . . . . . . . . . 8
3 Your Refrigerator 9
4 Installation 10
4.1 The right place for installation . . . . . . . . . . . 10
4.2 For Products With Water Fountain / Ice
Maker . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.3 Attaching the plastic wedges . . . . . . . . . . . 10
4.4 Adjustment of the feet. . . . . . . . . . . . . . . . . 11
4.5 Electrical connection. . . . . . . . . . . . . . . . . . 11
5 Preparation 12
5.1 What to do for energy saving . . . . . . . . . . . 12
5.2 First operation . . . . . . . . . . . . . . . . . . . . . . 12
6 Operating the Product 13
6.1 Turning off the product . . . . . . . . . . . . . . . . 13
6 Operation of the Product 14
6.2 Indicator panel . . . . . . . . . . . . . . . . . . . . . . 14
6.3 Support Service Feature . . . . . . . . . . . . . . . 17
6.4 Entering Phone Number for Support Service 17
6.5 Creating a Request Via Support Service . . . 17
6.6 Cancelling a Support Service Request . . . . 17
6.7 Troubleshooting . . . . . . . . . . . . . . . . . . . . 17
6.8 Humidity controlled crisper (EverFresh+) . . . 18
6.9 Blue Light/HarvestFresh . . . . . . . . . . . . . . 18
6.10 Anti-Odour Module . . . . . . . . . . . . . . . . . . 19
(FreshGuard) . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.11 Ice bucket . . . . . . . . . . . . . . . . . . . . . . . . 20
6.12 Ice maker. . . . . . . . . . . . . . . . . . . . . . . . . 20
6.13The dairy (cold storage) compartment . . . . 20
6.14Crisper . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.15Crisper . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Separator . . . . . . . . . . . . . . . . . . . . . . . . 21
6.16 Cleaning of the Ethylene Filter . . . . . . . . . 21
6.17 Cleaning of the Crisper Separator . . . . . . . 22
6.18 Operation of the Legumes Dispenser. . . . . 22
6.19Using the water fountain . . . . . . . . . . . . . . 25
6.20Filling the water tank of the water fountain 25
6.21Cleaning the water tank . . . . . . . . . . . . . . 25
6.22Filling the water tank of the water fountain 26
6.23Cleaning the water tank . . . . . . . . . . . . . . 27
6.24Drip tray . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.25 Freezing fresh food. . . . . . . . . . . . . . . . . . 28
6.26Recommendations for storing frozen foods in
the freezer compartment . . . . . . . . . . . . . 28
6.27Deep freezer details . . . . . . . . . . . . . . . . . 29
6.28Placing food . . . . . . . . . . . . . . . . . . . . . . . 29
6.29 Door open alert . . . . . . . . . . . . . . . . . . . . 29
6.30 Illumination lamp . . . . . . . . . . . . . . . . . . . 29
6.31 Convertible Feature of the Product . . . . . . 29
7 Maintenance and cleaning 30
7.1 Stainless Steel External Surfaces. . . . . . . . . 30
7.2 Cleaning of the Products with Glass Doors. . 30
7.3 Preventing Odours. . . . . . . . . . . . . . . . . . . 31
7.4 Protecting Plastic Surfaces . . . . . . . . . . . . 31
7 Maintenance and cleaning 31
8 Troubleshooting 32

3 / 32 EN
Refrigerator / User Guide
1 Safety Instructions
 This section includes the safety
instructions necessary to prevent
the risk of personal injury or material
damage.
 Our company shall not be held
responsible for damages that may
occur if these instructions are not
observed.
Installation and repair operations shall always
be performed by Authorized Service.
Always use genuine spare parts and
accessories.
Original spare parts will be provided for
10 years, following the product purchasing date.
Do not repair or replace any part of the
product unless specified expressly in the user
manual.
Do not perform any modifications on the
product.
1.1 Purpose of usage
 This product is not intended for commercial
use and it shall not be used out of its intended
purpose.
This product is intended for operating interiors,
such as households or similar.
For example;
- In the staff kitchens of the stores, offices and
other working environments,
- In farm houses,
- In the units of hotels, motels or other resting
facilities that are used by the customers,
- In hostels, or similar environments,
- In catering services and similar non-retail
applications.
This product shall not be used in open or enclosed
external environments such as vessels, balconies
or terraces. Exposing the product to rain, snow,
sunlight and wind may cause risk of fire.
1.2 Safety of children,
vulnerable persons and pets
 This product may be used by children
aged 8 years and older and persons
with underdeveloped physical,
sensory or mental capabilities or
lack of experience and knowledge
if they have been given supervision
or instruction concerning use of the
appliance in a the product safe way
and the hazards involved.
 Children between 3 and 8 years are
allowed to put and take out food to/
from the cooler product.
 Electrical products are dangerous for
children and pets. Children and pets
must not play with, climb on, or enter
the product.
 Cleaning and user maintenance
should not be performed by children
unless there is someone overseeing
them.
 Keep the packaging materials away
from children. Risk of injury and
suffocation.
 Before disposing of old products that
shall not be used any more:
1. Unplug the power cord from the mains socket.
2. Cut the power cord and remove it from the
appliance together with the plug.
3. Do not remove the racks and drawers from the
product to prevent children from getting inside the
appliance.
4. Remove the doors.
5. Store the product so that it shall not be tipped over.
6. Do not allow children to play with the scrapped
product.
 Do not dispose of the product by throwing it
into fire. Risk of explosion.
 If there is a lock available in the product’s door,
keep the key out of children’s reach.

4 / 32 EN Refrigerator / User Guide
Important safety and environment instructions
1.3 Electrical safety
 The product shall not be plugged
into the outlet during installation,
maintenance, cleaning, repair, and
transportation operations.
 If the power the cord is damaged, it
shall be replaced by authorized service
only to avoid any risk that may occur.
 Do not tuck the power cord under the
product or to the rear of the product.
Do not put heavy items on the power
cord. The power cord should not be
bent, crushed, and come into contact
with any heat source.
 Do not use an extension cord, multi-
plug or adaptor to operate your
product.
 Portable multisockets or portable
power supplies may overheat and
cause fire. Thus, do not have a multi-
plug behind or in the vicinity of the
product.
 The plug shall be easily accessible. If
this is not possible, a mechanism that
meets the electrical legislation and
that disconnects all terminals from
the mains (fuse, switch, main switch,
etc.) shall be available on the electrical
installation.
 Do not touch the plug with wet hands.
 When unplugging the appliance, don’t
hold the power cord, but the plug.
1.4 Handling Safety
 This product is heavy, do not handle it
by yourself.
 Do not hold the product from its door
while handling the product.
 Be careful not to damage the cooling
system and the pipes while handling
the product. Do not operate the
product if the pipes are damaged, and
contact an authorized service.
1.5 Installation Safety
 Contact the Authorized Service
for the product’s installation. To
prepare the product for installation,
see the information in the user
guide and make sure the electric
and water utilities are as required.
If the installation is not suitable, call
a qualified electrician and plumber
to have them make the necessary
arrangements. Otherwise, electric
shock, fire, issues with the product or
injuries may occur.
 Check for any damage on the product
before installing it. Do not have the
product installed if it is damaged.
 Place the product on a level and
hard surface and balance with the
adjustable legs. Otherwise, the
refrigerator may tip over and cause
injuries.
 The product shall be installed in a
dry and ventilated environment.
Do not keep carpets, rugs or similar
floor covers under the product. This
may cause risk of fire as a result of
inadequate ventilation!
 Do not block or cover ventilation
holes. Otherwise, power consumption
may be increased and damage to your
product may occur.
 Do not connect the product to supply
systems such as solar power supplies.
Otherwise, damage to your product
may occur as a result of the abrupt
voltage fluctuations!
 The more refrigerant a refrigerator
contains, the bigger its installation
room shall be. In very small rooms,
a flammable gas-air mixture may
occur in case of a gas leak in the
cooling system. At least 1 m3of
volume is required for each 8 grams
of refrigerant. The amount of the

5 / 32 EN
Refrigerator / User Guide
Important safety and environment instructions
refrigerant available in your product is
specified in the Type Label.
 The installation place of the product
shall not be exposed to direct sunlight
and it shall not be in the vicinity of a
heat source such as stoves, radiators,
etc.
If you cannot prevent installation of the product
in the vicinity of a heat source, you shall use a
suitable insulation plate and the minimum distance
to the heat source shall be as specified below.
- At least 30 cm away from heat sources such
as stoves, heating units and heaters, etc.,
- And at least 5 cm away from electric ovens.
 Your product has the protection
class of I. Plug the product in a
grounded socket that conforms with
the Voltage, Current and Frequency
values specified in the type label. The
socket outlet shall be equipped with a
fuse with a rating of 10 A – 16 A. Our
company shall not be responsible for
the damages that shall be incurred
as a result of operating the product
without ensuring ground and
electrical connections made as per
local or national regulations.
 The product’s power cable must
be unplugged during installation.
Otherwise, risk of electric shock and
injury may occur!
 Do not plug the product to loose, broken, dirty,
greasy sockets or sockets that has come out
their seats or sockets with a risk of water
contact.
 Place the power cord and hoses (if available) of
the product so that they shall not cause a risk
of tripping over.
 Penetration of humidity to live parts or to the
power cord may cause short circuit. Thus, do
not use the product in humid environments or
in areas where water may splash (e.g. garage,
laundry room, etc.) If the refrigerator is wet
by water, unplug it and contact an authorized
service.
 Do not connect your refrigerator to power
saving devices. These systems are harmful for
the product.
1.6 Operational safety
 Do not use chemical solvents on the product.
These materials contain an explosion risk.
 In case of a failure of the product, unplug it
and do not operate until it is repaired by the
authorized service. There is a risk of electric
shock!
 Do not place a source of flame (e.g. candles,
cigarettes, etc.) on the product or in the vicinity
of it.
 Do not get on the product. Risk of falling and
injury!
 Do not cause damage to the pipes of the
cooling system using sharp and piercing tools.
The refrigerant that sprays out in case of
puncturing the gas pipes, pipe extensions or
upper surface coatings may cause irritation of
skin and injuries of the eyes.
 Do not place and operate electric appliances
inside the refrigerators/deep freezer unless it is
advised by the manufacturer.
 Do not jam any parts of your hands or your
body to the moving parts inside the product.
Be careful to prevent jamming of your fingers
between the refrigerator and its door. Be
careful while opening or closing the door if
there are children around.
 Do not put ice cream, ice cubes or frozen food
to your mouth as soon as you take them out of
the freezer. Risk of frostbite!
 Do not touch the inner walls, metal
parts of the freezer or food kept
inside the refrigerator with wet
hands. Risk of frostbite!
 Do not place soda cans or cans
and bottles that contain fluids
that may be frozen to the freezer
compartment. Cans or bottles may
explode. Risk of injury and material
damage!
 Do not use or place materials
sensitive against temperature
such as flammable sprays,

6 / 32 EN Refrigerator / User Guide
Important safety and environment instructions
flammable objects, dry ice or other
chemical agents in the vicinity of
the refrigerator. Risk of fire and
explosion!
 Do not store explosive materials
such as aerosol cans with flammable
materials inside the product.
 Do not place cans containing fluids
over the product. Splashing of water
on an electrical part may cause the
risk of an electric shock or a fire.
 This product is not intended for
storage and cooling of medicines,
blood plasma, laboratory preparations
or similar materials and products that
are subject to the Medical Products
Directive.
 If the product is used against its
intended purpose, it may cause
damage to or deterioration of the
products kept inside.
 If your refrigerator is equipped with
blue light, do not look at this light
with optical devices. Do not stare
directly at UV LED light for a long
time. Ultraviolet rays may cause eye
strain.
 Do not fill the product with more food
than its capacity. Injuries or damages
may occur if the contents of the
refrigerator falls when the door is
opened. Similar problems may occur
when an object is placed over the
product.
 Ensure that you have removed any
ice or water that may have fallen to
the floor to prevent injuries.
 Change the locations of the racks/
bottle racks on the door of your
refrigerator while the racks are
empty only. Danger of physical injury!
 Do not place objects that may fall/
tipped over on the product. These
objects may fall while opening or
closing the door and cause injuries
and/or material damages.
 Do not hit or exert excessive pressure
on glass surfaces. Broken glass
may cause injuries and/or material
damages.
 The cooling system in your product
contains R600a refrigerant. The
refrigerant type used in the product
is specified in the the type label.
This gas is flammable. Therefore, be
careful not to damage the cooling
system and the pipes while operating
the product. In case of damage to the
pipes;
- do not touch the product or the power cord,
- Keep the product away from potential sources
of fire that may cause the product to catch fire.
- ventilation the area where the product is
placed. Do not use a fan.
- Contact authorized service.
 If the product is damaged and you
observe gas leak, please stay away
from the gas. Gas may cause frostbite
if it contacts your skin.
For Products With Water Fountain / Ice Maker
 Use only drinking water. Do not fill the water
tank with fruit juice, milk, fizzy beverages,
alcoholic beverages or any other liquids
incompatible for use in the water fountain. This
may cause risk to your health and safety.
 Do not allow the children to play with the water
dispenser or Ice Maker to prevent accidents
and injuries.
 Do not insert your fingers or other objects
inside the hole of the water dispenser, ice
channel or inside the container of the Ice
Maker. This may cause injuries or material
damages.

7 / 32 EN
Refrigerator / User Guide
Important safety and environment instructions
1.7 Maintenance and
cleaning safety
 Do not pull by the door handle if you
shall move the product for cleaning
purposes. Handle may cause injuries
if it is pulled too hard.
 Do not clean the product by spraying
or pouring water on the product and
inside the product. Risk of electric
shock and fire.
 Do not use sharp or abrasive tools
to clean the product. Do not use
materials such as household cleaning
agents, detergents, gas, gasoline,
alcohol, wax, etc.
 Use cleaning and maintenance
agents that are not harmful for food
only inside the product.
 Do not use steam or steamed
cleaning materials for cleaning the
product and thawing the ice inside it.
Steam contacts the live areas in your
refrigerator and causes short circuit
or electric shock!
 Take care to keep water away from
the electronic circuits or lighting of
the product.
 Use a clean, dry cloth to wipe the dust
or foreign material on the tips of the
plugs. Do not use a wet or damp piece
of cloth to clean the plug. Otherwise,
risk of fire or electric shock may occur.
1.8HomeWhiz
(May not be applicable for all models)
 Follow the safety warnings even if
you are away from the product while
operating the product via HomeWhiz
app. Also, pay attention to the
warnings in the app.
1.9 Lighting
(May not be applicable for all models)
 Contact an authorized service when
you shall replace the LED / bulb using
for lighting.

8 / 32 EN Refrigerator / User Guide
2 Environmental instructions
2.1 Compliance with the WEEE
Directive and Disposing
of the Waste Product:
This product complies with EU WEEE Directive
(2012/19/EU). This product bears a classification
symbol for waste electrical and electronic equip-
ment (WEEE).
This symbol indicates that this product
shall not be disposed with other house-
hold wastes at the end of its service life.
Used device must be returned to offical
collection point for recycling of electrical
and electronic devices. To find these collection sys-
tems please contact to your local authorities or re-
tailer where the product was puchased. Each
household performs important role in recovering
and recycling of old appliance. Appropriate disposal
of used appliance helps prevent potential negative
consequences for the environment and human
health.
2.2 Compliance with RoHS Directive
The product you have purchased complies with EU
RoHS Directive (2011/65/EU). It does not contain
harmful and prohibited materials specified in the
Directive.
2.3 Package information
Packaging materials of the product are
manufactured from recyclable materials
in accordance with our National
Environment Regulations. Do not dis-
pose of the packaging materials together with the
domestic or other wastes. Take them to the pack-
aging material collection points designated by the
local authorities.

9 / 32 EN
Refrigerator / User Guide
1- Freezer compartment door shelves
2- Cooler compartment door shelves
3- Egg Holder
4- Water fountain
5- Legumes dispenser
6- Cooler compartment small door shelves
7- Bottle shelf
8- Adjustable stands
9- Crisper, Crisper separator and ethylene filter
10- The dairy (cold storage) compartment
11- Filter
12- Glass shelves
13- Fan
14- Icematics
15- Freezer compartment glass shelf
16- Freezer compartment
17- Cooler compartment
3 Your Refrigerator
C*Optional: Figures in this user guide are schematic and may not be exactly match your product. If your
product does not comprise the relevant parts, the information pertains to other models.
*1
*2
*4
*5
6
7
88
9
*10
11
*12
13
*14
15
16
17
3

10 / 32 EN Refrigerator / User Guide
4 Installation
4.1 The right place for installation
Your product requires adequate air circulation to
function efficiently. If the product will be placed in an
alcove, remember to leave at least 5 cm clearance
between the product and the ceiling, rear wall and
the side walls.
If the product will be placed in an alcove, remember
to leave at least 5 cm clearance between the
product and the ceiling, rear wall and the side
walls. Check if the rear wall clearance protection
component is present at its location (if provided with
the product). If the component is not available, or
if it is lost or fallen, position the product so that at
least 5 cm clearance shall be left between the rear
surface of the product and the wall of the room.
The clearance at the rear is important for efficient
operation of the product.
4.2 For Products With Water
Fountain / Ice Maker

used. Do not use the old hose sets. Do not extend
the hoses!

Do not perform installation on the hot water inlet.
The pressure for the cold water inlet shall be 80 PSi
(550 kPa) maximum. If your water pressure exceeds
80Psi or has a water impact effect, use a pressure
limiting valve on your mains system. Ask help from
professional plumbers if you do not know how to
control your water pressure.
High pressure may cause damage to the hose
connections and pose a risk of flooding.

freezing of hoses. The operating water temperature
interval shall be 0.6°C (33°F) minimum and 38°C
(100°F) maximum. There is a risk of flooding if the
hose is cracked/perforated.
AWARNING: Do not use extension or multi
sockets in power connection.
BWARNING: The manufacturer assumes
no responsibility for any damage caused
by the work carried out by unauthorized
persons.
BWARNING: The product's power cable
must be unplugged during installation.
Failure to do so may result in death or
serious injuries!
A
WARNING: : If the door span is too
narrow for the product to pass, remove
the door and turn the product sideways; if
this does not work, contact the authorized
service.

vibration.

heater, stove and similar sources of heat and at
least 5 cm away from electric ovens.

keep in damp environments.

function efficiently. If the product will be placed
in an alcove, remember to leave at least 5 cm
distance between the product and the ceiling
and the walls.
4.3 Attaching the plastic wedges
Use the plastic wedges in the provided with
the product to provide sufficient space for air
circulation between the product and the wall.
1. To attach the wedges, remove the screws on
the product and use the screws provided with the
wedges.

11 / 32 EN
Refrigerator / User Guide
Installation
2. Attach 2 plastic wedges on the ventilation cover as
shown in the figure.
4.4 Adjustment of the feet
If the product is not in balanced position, adjust the
front adjustable stands by rotating right or left.
4.5 Electrical connection
AWARNING: Do not use extension or
multi sockets in power connection.
BWARNING: Damaged power cable
must be replaced by Authorized
Service.
 Our firm will not assume responsibility for any
damages due to usage without earthing and
power connection in compliance with national
regulations.
 The power cable plug must be easily
accessible after installation.
C
Hot surface warning!
The side walls of your product are
equipped with cooler pipes to enhance
the cooling system. High pressure fluid
may flow through these surfaces, and
cause hot surfaces on the side walls.
This is normal and it does not require
servicing. Be careful when you contact
these areas.

12 / 32 EN Refrigerator / User Guide
5 Preparation
5.1 What to do for energy saving
mehmet
AConnecting the product to electronic
energy-saving systems is harmful, as it
may damage the product.
 For a freestanding appliance; ‘this refrigerating
appliance is not intended to be used as a built-
in appliance.
 Do not keep the refrigerator doors open for
long periods.
 Do not place hot food or beverages into the
refrigerator.
 Do not overfill the refrigerator; blocking the
internal air flow will reduce cooling capacity.
 Depending on the product's features;
defrosting frozen foods in the cooler
compartment will ensure energy saving and
preserve food quality.
 Since hot and humid air will not directly
penetrate into your product when the doors
are not opened, your product will optimize
itself in conditions sufficient to protect your
food. Functions and components such as
compressor, fan, heater, defrost, lighting,
display and so on will operate according to
the needs to consume minimum energy under
these circumstances.
 Food shall be stored using the drawers in the
cooler compartment in order to ensure energy
saving and protect food in better conditions.
5.2 First operation
Before using your refrigerator, make sure the
necessary preparations are made in line with
the instructions in "Safety and environment
instructions" and "Installation" sections.
 Keep the product running without placing any
food inside for 12 hours and do not open the
door, unless absolutely necessary.
ARead the “Safety Instructions” section first!
CA sound will be heard when the
compressor is engaged. It is normal to
hear sound even when the compressor is
inactive, due to the compressed liquids
and gasses in the cooling system.
CIt is normal for the front edges of the
refrigerator to be warm. These areas are
designed to warm up in order to prevent
condensation.
CFor some models, indicator panel turns
off automatically 1 minutes after the door
closes. It will be reactivated when the door
is open or any button is pressed.

13 / 32 EN
Refrigerator / User Guide
6 Operating the Product
 Do not use any mechanical tools or any
other tools than the recommendations of the
manufacturer to speed up the thawing operation.
 Do not use parts of your refrigerator such
as the door or drawers as a support or a step.
This may cause the product to trip over or its
components to be damaged.
 The product shall be used for storing food
only.
 Turn off the water valve if you will be away
from home (e.g. at vacation) and you will not be
using the Ice Maker or the water dispenser for a
long period of time. Otherwise, water leaks may
occur.
6.1 Turning off the product

period;
- unplug it,
- remove the food to prevent odours,
- wait until the ice is thawed,
- clean the inside and wait until it is dried.
- leave the doors open to prevent damage to internal
body plastics.

14 / 32 EN Refrigerator / User Guide
6 Operation of the Product
6.2 Indicator panel
Indicator panels may vary depending on the model of your product.
Audial and visual functions of the indicator panel will assist in using the refrigerator.
C*Optional: Figures in this user guide are schematic and may not be exactly match your product. If your
product does not comprise the relevant parts, the information pertains to other models.
*2 *5
6
34
*1
10
7
*9 8
1- Support Service Key
2- Quick Freezing Key/ Handle Light Function Setting Key
3- Fault Condition Indicator
4- Energy Saving (Display Off) Indicator
5- Freezing Compartment Temperature Setting Key
6- Compartment Conversion Key
7- Cooling Compartment Temperature Setting Key
8- Cooling Compartment OFF (Vacation) Function Key
9- Wireless Key
10-
Key for Resetting Wireless Connection Settings

15 / 32 EN
Refrigerator / User Guide
Using the product
1. Support Service Key
Press this button for 3 seconds to activate the support
service. Detailed information on the support service is
provided in the “Support Service Feature” section.
2. Quick Freezing Key
When the quick freeze key is pressed, the LED on the
key is illuminated and the quick freeze function shall
be activated. Freezing compartment temperature is set
to -27 Celcius. Press the key again to cancel function.
The quick freezing function shall be automatically
cancelled after 52 hours. To freeze a large amount of
fresh food, press the quick freeze key before placing
the food in the freezer compartment.
*Handle Light Function Setting Key
Handle light function might be switched between
open and closed modes by pressing quick freezing
button ( ) for 3 seconds. In the closed mode, the
handle light is only activated when the appliance
door is opened and it goes out after a while after
the door is closed. In the open mode, the handle
light is activated when the appliance door is
opened, the handle light stays on dimly after a while
after the door is closed. The handle light function is
set to the ex-factory closed mode.
3. Fault Condition Indicator
This indicator ( ) shall be active when your
refrigerator cannot perform adequate cooling or in
case of any sensor error. “E” shall be displayed on
the Freezing Compartment temperature indicator
and figures such as 1,2,3... shall be displayed on the
cooling compartment temperature indicator. These
figures provide information to the authorized service on
the error that has occurred.
Exclamation mark may be displayed when you load
warm food to the freezing compartment or keep the
door open for a long period of time. This is not a fault,
this warning shall be removed when the food is cooled
down or when any key is pressed.
4. Energy Saving (Display Off) Indicator
Energy saving function is enabled automatically and
the energy saving symbol ( ) is displayed when
the door of the product is not opened or closed for
some period of time. When the energy saving function
is active, all symbols on the screen other than the
energy saving symbol shall be turned off. When the
energy-saving function is active, pressing any key or
opening the door will deactivate the energy-saving
function and the display signals will return to normal.
The energy-saving function is a function activated
ex-factory and cannot be cancelled.
5. Freezing Compartment Temperature Setting
Key
Temperature setting is made for cooler compartment.
Pressing this key will enable the freezer compartment
temperature to be set at -15,-16,-18,-19,-20,-22,-
24 Celcius.
6. Compartment Conversion Key
When the compartment conversion key is pressed for
3 seconds, freezer compartment switches between
cooler, off, and freezer modes respectively. When it is
operated as cooling compartment, the temperature
of the compartment may be set at 8,7,6,5,4,3,2
and 1 Celcius. In case of OFF mode, compartment
temperature indicator shall display “- -”.
7. Cooling Compartment Temperature Setting
Key
Allows setting of temperature for cooler compartment.
Pressing this key will enable the cooling compartment
temperature to be set at 8,7,6,5,4,3,2 and 1 Celcius.
8. Cooling Compartment OFF (Vacation) Function
Key
Press the key for 3 seconds to activate the vacation
function. Vacation mode is activated and the LED
on the key is illuminated. “- -” shall be displayed on
the Cooling Compartment temperature indicator and
the cooling compartment does not actively perform
cooling. You shall not keep your food in the cooling
compartment when this function is activated. The
other compartments continue to cool according to the
set temperatures. Press the key for 3 seconds again
to cancel this function.
9. Wireless Key
This key is used to make a wireless connection with
your product via HomeWhiz mobile app.

16 / 32 EN Refrigerator / User Guide
Using the product
When the key is pressed for a long period (3
seconds), the wireless connection symbol on the
display/screen flashes slowly (with intervals of 0.5
seconds). The home network is initialized on the
product this way.
After achieving wireless connection with the product,
wireless connection symbol ( ) illuminates
continuously.
When the initial connection is established, you may
activate/deactivate the connection with a short press
on this key. The wireless connection symbol shall flash
quickly (at 0.2 second intervals) until the connection
is established. When the connection is active, the
wireless network symbol shall light up continuously.
If the connection cannot be established for a long
period, check your connection settings and refer to
the “Troubleshooting” section provided in the user
manual.
HomeWhiz application shall be used for wireless
connection. Installation steps are described on the
application during installation.
You may access the application by reading the QR
code available on the HomeWhiz label on the product.
Application is offered through App Store for IOS
devices, and through Play Store for Android devices.
Visit https://www.homewhiz.com/ for detailed
information.’
10. Key for Resetting Wireless Connection
Settings
To reset the wireless connection settings, press Quick
freezing ( ) and wireless connection ( ) keys
simultaneously for 3 seconds. All user information
recorded previously are removed on a product where
wireless connection settings are reset/restored to
factory defaults.

17 / 32 EN
Refrigerator / User Guide
Using the product
6.3 Support Service Feature
*May not be available in all models
Support Service is a feature that allows you to create
a request for our expert representatives through a
special offer on your white goods products. After the
request to be created with the Support Service button,
our expert customer representatives will be able to
call you from your mobile phone number that you
have registered in the HomeWhiz application and help
you about all your questions.
6.4 Entering Phone Number
for Support Service
To ensure that your customer representative
may call you after creating a request by pressing
Support Service button, you shall share your mobile
phone number with the application. You may add
or change your mobile phone number through
the communication menu on the HomeWhiz
application.
6.5 Creating a Request Via
Support Service
To create a Support Service request, your product
must be connected to the internet.
1. Ensure that you have an internet connection on
the product and you have entered your mobile phone
number via HomeWhiz application.
2. Press the support service key for 3 seconds.
3. Support Service symbol shall start to blink.
4. When your request is delivered to the customer
representative successfully, Support Service symbol
shall constantly illuminate.
5. Your customer representative shall call you via the
telephone number that you have specified on the
HomeWhiz application.
6. The symbol shall turn off when the call is
completed.
7. If your request does not reach the customer
representative successfully, the light of the symbol
will turn off after a while. In this case, follow the
guides in the troubleshooting step.
6.6 Cancelling a Support
Service Request
If you want to cancel your support service request,
your request shall be delivered to the customer
representative successfully and the symbol shall
be illuminated constantly. To cancel;
1. Press the support service button for 3 seconds.
2. Support Service symbol shall start to blink.
3. Symbol shall turn off when your request is
cancelled successfully.
4. If your request does not cancel, Support Service
symbol shall constantly illuminate again.
6.7 Troubleshooting
When you press the support service button, the
light of the symbol does not illuminate constantly,
turned off immediately or if it is constantly blink:
1. Ensure that your product is connected to the
internet.
2. Ensure that you have a HomeWhiz account and
that you have entered your mobile phone number via
HomeWhiz application.
3. Ensure the accuracy of the phone number that you
registered to the HomeWhiz application.
4. If the internet connection is not available, this
feature does not work. Check your home internet
connection.
Info:
 When you press the support service key; If the
wireless connection is off, it shall be turned on
automatically.
 You will not be allowed to turn off your
product’s wireless connection, while the
Support Service process is in progress.
 When the Support Service operation is
complete; Wireless connection shall continue
unless you turn it off.

18 / 32 EN Refrigerator / User Guide
Using the product
6.8 Humidity controlled
crisper (EverFresh+)
(Optional)
Thanks to the humidity controlled crisper,
vegetables and fruits may be stored for a longer
period at an environment with ideal humidity
conditions. With the humidity setting system with
3 options in front of your crisper, you may control
the humidity inside the compartment as per the
food you store. We recommend you to store your
food by selecting vegetable option when you store
vegetables only, fruit option when you store fruit
only and mixed option when you store mixed food.
We recommend that the vegetables and fruits
shall not be stored in bags to improve the storage
period of the food and to better benefit from the
humidity control system. Leaving them in plastic
bags causes vegetables to rot in a short time.
We recommend that cucumbers and broccolis,
in particular, are not stored in closed bags. In
situations where contact with other vegetables is
not preferred, use packaging materials such as
paper that has a certain level of porosity in terms
of hygiene.
When placing the vegetables, place heavy and
hard vegetables at the bottom and light and soft
ones on the top, taking into account the specific
weights of vegetables.
Do not put fruits that have a high ethylene gas
production such as pear, apricot, peach and
particularly apple in the same crisper with other
vegetables and fruits. The ethylene gas coming out
of these fruits might cause other vegetables and
fruits to mature faster and rot in a shorter period
of time.
6.9 Blue Light/HarvestFresh
(Optional)
For Blue light,
Vegetables and fruit stored in crispers illuminated
with blue light continue to perform photosynthesis
and retain their levels of C vitamin thanks to the
effect of the wavelength of the blue light.
For HarvestFresh,
Vegetables and fruit stored in crispers illuminated
with HarvestFresh technology retain their vitamin
levels (vitamins A and C) for a longer period thanks
to the cycles of blue, green, red lights and dark
that simulate the cycle of the day.
When the door of your refrigerator is opened dur-
ing the dark period of the HarvestFresh technology,
your refrigerator shall sense this automatically and
illuminate the crisper with one of the blue, green
or red lights respectively for your convenience. The
dark period shall be continued when you close the
door of your refrigerator so that it shall represent
the night period of the day cycle.

19 / 32 EN
Refrigerator / User Guide
Using the product
6.10 Anti-Odour Module
(FreshGuard)
(This feature is optional)
Anti-odour module removes odour that occur
inside your refrigerator before it permeates on the
surfaces. Thanks to this module positioned on
the roof the fresh food compartment, bad odour is
removed while the air is actively passed through
the odour filter, and the air cleaned in the filter
is directed back to the fresh food compartment.
Thus, undesired odour that may occur during the
storage of food inside the refrigerator is removed
from the environment before it permeates on the
surfaces.
This feature is provided with the fan, LED and
odour filter placed inside the module. Anti-
odour module shall be automatically activated
periodically. If the door of the fresh food
compartment is opened while the module is
active, fan is stopped temporarily, and it continues
to operate when the door is closed. In case of a
power failure, anti-odour module starts to operate
when the power is restored.
İnfo: To prevent bad odours that may occur with
the mixture of odours from different food, we
recommend you to store aromatic food such as
cheese, olives and delicatessen in their packaging
and with their lids closed. For the safety of other
food stored and to prevent bad odours, we
recommend you to remove the food that you have
observed to be spoilt from the refrigerator as soon
as possible.
