Dear Customer,
Please read this manual before using the product.
Thank you for choosing this product. We would like you to achieve the optimal efficiency
from this high quality product which has been manufactured with state of the art tech-
nology. To do this, carefully read this manual and any other documentation provided
before using the product and keep it as a reference.
Heed all information and warnings in the user manual. This way, you will protect yourself
and your product against the dangers that may occur.
Keep the user manual. Include this guide with the unit if you hand it over to someone
else.
The following symbols are used in the user guide:
Hazard that may result in death or injury.
NOTICE A hazard that may cause material damage to the product or its
surroundings
Important information or useful tips on operation.
Read the user manual.
58 6048 0000/AI UK 2/2

2 /29 EN Refrigerator / User Guide
1 Safety Instructions 3
1.1 Purpose of usage . . . . . . . . . . . . . . . . . . 3
1.2 Safety of children, vulnerable persons and
pets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Electrical safety . . . . . . . . . . . . . . . . . . . 3
1.4 Handling Safety . . . . . . . . . . . . . . . . . . . 4
1.5 Installation Safety . . . . . . . . . . . . . . . . . . 4
1.6 Operational safety . . . . . . . . . . . . .5
1.7 Maintenance and cleaning safety . . . . . . 6
1.8HomeWhiz . . . . . . . . . . . . . . . . . . . . . . . 6
1.9 Lighting . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Environmental instructions 7
2.1 Compliance with the WEEE Directive and
Disposing of the Waste Product: . . . . . . . . 7
2.2 Compliance with RoHS Directive . . . . . . . . . . 7
2.3 Package information. . . . . . . . . . . . . . . . . . . 7
3 Your Refrigerator 8
4 Installation 9
4.1 The right place for installation . . . . . . . . . . . . 9
4.2 Attaching the plastic wedges . . . . . . . . . . . . 9
4.3 Adjustment of the feet. . . . . . . . . . . . . . . . . 10
4.4 Electrical connection. . . . . . . . . . . . . . . . . . 11
5 Preparation 12
5.1 What to do for energy saving . . . . . . . . . . . 12
5.2 First operation . . . . . . . . . . . . . . . . . . . . . . 12
6 Operating the Product 13
6.1 Turning off the product . . . . . . . . . . . . . . . . 13
6 Operation of the Product 14
6.2 Indicator panel . . . . . . . . . . . . . . . . . . . . . . 14
6.3 Indicator panel . . . . . . . . . . . . . . . . . . . . . . 17
6.4Deodoriser Module . . . . . . . . . . . . . . . . . . . 19
(FreshGuard) . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.5 Humidity controlled crisper (EverFresh+) . . . 20
6.6 Blue Light/HarvestFresh . . . . . . . . . . . . . . . 20
6.7 Using the water fountain . . . . . . . . . . . . . . 21
6.8 Filling the water tank of the water fountain 21
6.9 Cleaning the water tank . . . . . . . . . . . . . . . 21
6.10 Dairy (cold storage) bin . . . . . . . . . . . . . . . 23
6.11 Crisper . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.12 Ionizer . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.13 Odour filter . . . . . . . . . . . . . . . . . . . . . . . 23
6.14 Icematic and ice storage box. . . . . . . . . . . 23
6.15 Freezing fresh food. . . . . . . . . . . . . . . . . . 24
6.16 Recommendations for storing frozen foods 24
6.17 Deep freezer details . . . . . . . . . . . . . . . . . 24
6.18 Placing the food . . . . . . . . . . . . . . . . . . . . 25
6.19 Door open alert . . . . . . . . . . . . . . . . . . . . 25
6.20 Illumination lamp . . . . . . . . . . . . . . . . . . . 25
7 Maintenance and cleaning 26
7.1 Stainless Steel External Surfaces. . . . . . . . . 26
7.2 Cleaning of the Products with Glass Doors. . 26
7.3 Preventing Odours. . . . . . . . . . . . . . . . . . . 27
7.4 Protecting Plastic Surfaces . . . . . . . . . . . . 27
7 Maintenance and cleaning 27
8 Troubleshooting 28

3 / 29 EN
Refrigerator / User Guide
1 Safety Instructions
 This section includes the safety instructions
necessary to prevent the risk of personal injury
or material damage.
 Our company shall not be held responsible for
damages that may occur if these instructions
are not observed.
Installation and repair operations shall always
be performed by Authorized Service.
Always use genuine spare parts and
accessories.
Original spare parts will be provided for 10
years, following the product purchasing date.
Do not repair or replace any part of the
product unless specified expressly in the user
manual.
Do not perform any modifications on the
product.
1.1 Purpose of usage
 This product is not intended for commercial
use and it shall not be used out of its intended
purpose.
This product is intended for operating interiors,
such as households or similar.
For example;
- In the staff kitchens of the stores, offices and
other working environments,
- In farm houses,
- In the units of hotels, motels or other resting
facilities that are used by the customers,
- In hostels, or similar environments,
- In catering services and similar non-retail ap-
plications.
This product shall not be used in open or enclosed
external environments such as vessels, balconies
or terraces. Exposing the product to rain, snow,
sunlight and wind may cause risk of fire.
1.2 Safety of children, vulnerable
persons and pets
 This product may be used by children aged 8
years and older and persons with underdevel-
oped physical, sensory or mental capabilities or
lack of experience and knowledge if they have
been given supervision or instruction concern-
ing use of the appliance in a the product safe
way and the hazards involved.
 Children between 3 and 8 years are allowed
to put and take out food to/from the cooler
product.
 Electrical products are dangerous for children
and pets. Children and pets must not play with,
climb on, or enter the product.
 Cleaning and user maintenance should not be
performed by children unless there is someone
overseeing them.
 Keep the packaging materials away from chil-
dren. Risk of injury and suffocation.
 Before disposing of old products that shall not
be used any more:
1. Unplug the power cord from the mains socket.
2. Cut the power cord and remove it from the appli-
ance together with the plug.
3. Do not remove the racks and drawers from the
product to prevent children from getting inside the
appliance.
4. Remove the doors.
5. Store the product so that it shall not be tipped over.
6. Do not allow children to play with the scrapped
product.
 Do not dispose of the product by throwing it
into fire. Risk of explosion.
 If there is a lock available in the product’s door,
keep the key out of children's reach.
1.3 Electrical safety
 The product shall not be plugged into the outlet
during installation, maintenance, cleaning, re-
pair, and transportation operations.
 If the power the cord is damaged, it shall be
replaced by authorized service only to avoid
any risk that may occur.
 Do not tuck the power cord under the product
or to the rear of the product. Do not put heavy
items on the power cord. The power cord
should not be bent, crushed, and come into
contact with any heat source.
 Do not use an extension cord, multi-plug or
adaptor to operate your product.
 Portable multi sockets or portable power sup-
plies may overheat and cause fire. Thus, do not
have a multi-plug behind or in the vicinity of
the product.

4 /29 EN Refrigerator / User Guide
Safety instructions
 The plug shall be easily accessible. If this is
not possible, a mechanism that meets the
electrical legislation and that disconnects all
terminals from the mains (fuse, switch, main
switch, etc.) shall be available on the electrical
installation.
 Do not touch the plug with wet hands.
 When unplugging the appliance, don't hold the
power cord, but the plug.
1.4 Handling Safety
 This product is heavy, do not handle it by your-
self.
 Do not hold the product from its door while
handling the product.
 Be careful not to damage the cooling system
and the pipes while handling the product. Do
not operate the product if the pipes are dam-
aged, and contact an authorized service.
1.5 Installation Safety
 Contact the Authorized Service for the prod-
uct's installation. To prepare the product for in-
stallation, see the information in the user guide
and make sure the electric and water utilities
are as required. If the installation is not suit-
able, call a qualified electrician and plumber to
have them make the necessary arrangements.
Otherwise, electric shock, fire, issues with the
product or injuries may occur.
 Check for any damage on the product before
installing it. Do not have the product installed if
it is damaged.
 Place the product on a level and hard sur-
face and balance with the adjustable legs.
Otherwise, the refrigerator may tip over and
cause injuries.
 The product shall be installed in a dry and ven-
tilated environment. Do not keep carpets, rugs
or similar floor covers under the product. This
may cause risk of fire as a result of inadequate
ventilation!
 Do not block or cover ventilation holes.
Otherwise, power consumption may be in-
creased and damage to your product may
occur.
 Do not connect the product to supply systems
such as solar power supplies. Otherwise, dam-
age to your product may occur as a result of
the abrupt voltage fluctuations!
 The more refrigerant a refrigerator contains,
the bigger its installation room shall be. In
very small rooms, a flammable gas-air mixture
may occur in case of a gas leak in the cooling
system. At least 1 m³of volume is required for
each 8 grams of refrigerant. The amount of the
refrigerant available in your product is specified
in the Type Label.
 The installation place of the product shall not
be exposed to direct sunlight and it shall not be
in the vicinity of a heat source such as stoves,
radiators, etc.
If you cannot prevent installation of the product in
the vicinity of a heat source, you shall use a suit-
able insulation plate and the minimum distance to
the heat source shall be as specified below.
- At least 30 cm away from heat sources such
as stoves, heating units and heaters, etc.,
- And at least 5 cm away from electric ovens.
 Your product has the protection class of I. Plug
the product in a grounded socket that conforms
with the Voltage, Current and Frequency values
specified in the type label. The socket outlet
shall be equipped with a fuse with a rating of
10 A – 16 A. Our company shall not be respon-
sible for the damages that shall be incurred as
a result of operating the product without ensur-
ing ground and electrical connections made as
per local or national regulations.
 The product's power cable must be unplugged
during installation. Otherwise, risk of electric
shock and injury may occur!
 Do not plug the product to loose, broken, dirty,
greasy sockets or sockets that has come out
their seats or sockets with a risk of water con-
tact.
 Place the power cord and hoses (if available) of
the product so that they shall not cause a risk of
tripping over.
 Penetration of humidity to live parts or to the
power cord may cause short circuit. Thus, do not
use the product in humid environments or in ar-
eas where water may splash (e.g. garage, laun-
dry room, etc.) If the refrigerator is wet by water,
unplug it and contact an authorized service.
 Do not connect your refrigerator to power sav-
ing devices. These systems are harmful for the
product.
