Refrigerator
User Manual
INVDMMY BK-683720 EI-683720 MB-683720 EI NB-683721 EI
683721EDI

Please read this manual before using the product!
Dear Valued Customer,
We wish you to get the best results from your product that has been manufactured meticulously at modern plants
and tested with detailed quality control checks.
For this reason, we recommend that you read this user manual thoroughly before starting the product. If you hand
over the product to someone else, please remember to give the user manual as well.
This manual will help you use your appliance in a fast and safe way.
• Please read this user manual carefully before installing and using the product.
• Always follow the applicable safety instructions.
• Keep the user manual in an easily accessible place for further use.
• Please read all the other documents provided with the product.
Please keep in mind that this manual may apply to several product models. This manual expressly indicates the
differences between various models.
CImportant information and
useful hints.
ARisk of injury and property
damage.
BRisk of electric shock.
Packaging materials of
this product has been
manufactured from recyclable
materials in accordance with
the National Environment
Regulations.
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
.The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/

2 /25EN Refrigerator / User Manual
1- Safety Instructions 3
1.1 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 - Safety for children, vulnerable persons and
pets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 - Electrical safety . . . . . . . . . . . . . . . . . . . . . 3
1.4 - Transportation safety . . . . . . . . . . . . . . . . . 3
1.5 - Installation safety . . . . . . . . . . . . . . . . . . . . 3
1.6- Operational safety. . . . . . . . . . . . . . . . . . . . 4
1.7- Maintenance and cleaning safety. . . . . . . . . 5
1.8- HomeWhiz . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.9- Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.10 Technical information for Wifi + Bluetooth. . . 6
2 Your Refrigerator 7
3 Installation 8
3.1. Appropriate location for installation . . . . . . . . . . . 8
3.2. Installing the plastic wedges . . . . . . . . . . . . . . . . 8
3.3. Adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4. Electrical connection. . . . . . . . . . . . . . . . . . . . . . 9
4 Preparation 10
4.1. Things to be done for energy saving . . . . . . . . . 10
4.2. Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5 Operating the product 11
5.1. Indicator panel . . . . . . . . . . . . . . . . . . . . . . . . . 11
5.2. Indicator panel . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.3. Ice machine . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.4. Icematic. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.5. Ice tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.6. Deodoriser Module . . . . . . . . . . . . . . . . . . . . . . 16
(FreshGuard) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.7. Chiller compartment . . . . . . . . . . . . . . . . . . . . . 17
5.8. Crisper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.9. Blue light/HarvestFresh. . . . . . . . . . . . . . . . . . . 17
5.10.Using the water dispenser . . . . . . . . . . . . . . . . 18
5.11.Filling the water dispenser's tank . . . . . . . . . . . 18
5.12.Cleaning the water tank . . . . . . . . . . . . . . . . . . 18
5.13.Drip tray. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.14.Humidity-controlled crisper (Ever Fresh). . . . . . . 20
5.15.Freezing fresh food. . . . . . . . . . . . . . . . . . . . . . 20
5.16.Recommendations for preserving the frozen food21
5.17.Deep-freeze information . . . . . . . . . . . . . . . . . . 21
5.18.Placing the food . . . . . . . . . . . . . . . . . . . . . . . . 21
5.19.Door open warning. . . . . . . . . . . . . . . . . . . . . . 21
5.20.Illumination lamp . . . . . . . . . . . . . . . . . . . . . . . 21
6 Care and Cleaning 22
6.1. Avoiding Bad Odours . . . . . . . . . . . . . . . . . . . . 22
6.2. Protection of plastic surfaces . . . . . . . . . . . . . . 22
6.3. Cleaning the Inner Surface . . . . . . . . . . . . . . . . 22
6.4. Stainless Steel Outer Surfaces . . . . . . . . . . . . . 22
6.5. Cleaning Products with Glass Doors . . . . . . . . . 23
6 Care and Cleaning 23
7 Troubleshooting 24

3 /25 EN
Refrigerator / User Manual
• This section contains safety instructions that will
help get protected against risks of personal injury or
property damage.
• Our company shall not be responsible for damages
that may arise when these instructions are not
followed.
Installation and repair procedures must always be
performed by the manufacturer, authorised service agent
or a qualified person specified by the importer.
Only use original parts and accessories.
Original spare parts will be provided for 10 years,
following the product purchasing date.
Do not repair or replace any part of the product unless
specified expressly in the user manual.
Do not make any technical modifications to the product.
1.1 Intended Use
• This product is not suitable for commercial use and
it must not be used out of its intended use.
This product is designed to be used in houses and
indoor places.
For example:
- Personnel kitchens in stores, offices and other
working environments,
- Farm houses,
- Areas used by customers at hotels, motels and
other types of accommodation,
- Bed&breakfast type hotels, boardinghouses,
- Catering and similar non-retail applications.
This product should not be used outdoors with or without
a tent above it such as boats, balconies or terraces. Do
not expose the product to rain, snow, sun or wind.
There is the risk of fire!
1.2 - Safety for children, vulnerable
persons and pets
• This product can be used by children at and above 8
years old and by persons with limited physical, sen-
sory or mental capabilities or who lack experience
and knowledge provided that they are supervised or
trained on the safe use of the product and the risks
it brings out.
• Children aged from 3 to 8 years are allowed to load
and unload refrigerating products.
• Electrical products are dangerous for children and
pets. Children and pets must not play with, climb or
enter the product.
• Cleaning and user maintenance should not be per-
formed by children unless they are supervised by
someone.
• Keep packaging materials away from children. There
is the risk of injury and suffocation!
• Before disposing of the old or obsolete product:
1. Unplug the product by gripping from the plug.
2. Cut the power cable and remove it from the appliance
together with its plug
3. Do not remove the shelves or drawers so that it is harder
for children to enter the product.
4. Remove the doors.
5. Keep the product in a way that it will not tip over.
6. Do not allow children play with the old product.
• Never throw the product into fire for disposal. There
is the risk of explosion!
• If there is a lock on the door of the product, the key
should be kept out of the reach of children.
1.3 - Electrical safety
• The product must be unplugged during installation,
maintenance, cleaning, repairing and moving pro-
cedures.
• If the power cable is damaged, it must be replaced
by a qualified person specified by the manufacturer,
authorised service agent or importer in order to avo-
id potential dangers.
• Do not squeeze the power cable under or behind the
product. Do not place heavy objects on the power
cable. Power cable must not be bent excessively,
pinched or get in contact with any heat source.
• Do not use extension cords, multi-sockets or adap-
ters to operate the product.
• Portable multi-sockets or portable power sources
can overheat and cause fire. Therefore, do not keep
any multi-sockets behind or near the product.
• Plug must be easily accessible. If this is not possib-
le, the electrical installation to which the product is
connected must contain a device (such as a fuse,
switch, circuit breaker, etc.) which conforms to the
electrical regulations and disconnects all poles from
the grid.
• Do not touch the power plug with wet hands.
• Remove the plug from the socket by gripping the
plug and not the cable.
1.4 - Transportation safety
• Product is heavy; do not move it alone.
• Do not hold its door when moving the product.
• Pay attention not to damage the cooling system
or the piping during transportation. If the piping is
damaged, do not operate the product and call the
authorised service agent.
1.5 - Installation safety
• Call the authorised service agent for installation of
the product. To make the product ready for use,
check the information in the user manual to make
sure that the electricity and water installations are
suitable. If they are not, call a qualified electrician
and plumber to have the necessary arrangements
1- Safety Instructions

Instructions for safety and environment
4 / 25 EN Refrigerator / User Manual
made. Otherwise, there is the risk of electric shock,
fire, problems with the product, or injury!
• Prior to installation, check if the product has any
defects on it. If the product is damaged, do not
have it installed.
• Place the product on a clean, flat and solid surface
and balance it with adjustable feet. Otherwise, the
product may tip over and cause injuries.
• The installation location must be dry and well ven-
tilated. Do not place carpets, rugs or similar covers
under the product. Insufficient ventilation causes
the risk of fire!
• Do not cover or block the ventilation openings.
Otherwise, power consumption increases and your
product may get damaged.
• Product must not be connected to supply systems
such as solar power supplies. Otherwise, your
product may get damaged due to sudden voltage
changes!
• The more refrigerant a refrigerator contains, the
larger the installation location must be. If the ins-
tallation location is too small, flammable refrigerant
and air mixture will accumulate in cases of refrige-
rant leakage in cooling system. The required space
for each 8 gr of refrigerant is 1 m³ minimum. The
amount of refrigerant in your product is indicated
on the Type Label.
• Product must not be installed in places exposed to
direct sunlight and it must be kept away from heat
sources such as hobs, radiators, etc.
If it is inevitable to install the product close to a heat
source, a suitable insulation plate must be used in
between and the following minimum distances must be
kept to the heat source:
- Minimum 30 cm away from heat sources such as
hobs, ovens, heater units or stoves,
- Minimum 5 cm away from electric ovens.
• Protection class of your product is Type I. Plug the
product in a grounded socket that conforms the
voltage, current and frequency values stated on
the type label of the product. The socket must be
equipped with a 10 A – 16 A circuit breaker. Our
company shall not be liable for any damages that
will arise when the product is used without groun-
ding and electrical connection in accordance with
the local and national regulations.
• Product must not be plugged in during installation.
Otherwise, there is the risk of electric shock and
injury!
• Do not plug the product in sockets that are loo-
se, dislocated, broken, dirty, greasy or bear the
risk of getting in contact with water.
• Route the power cable and hoses (if any) of the
product in a way that they do not cause risk of
tripping over.
• Exposing the live parts or power cable to humi-
dity may cause short circuit. Therefore, do not
install the product in places such as garages or
laundry rooms where humidity is high or water
may splash. If the refrigerator gets wet with
water, unplug it and call the authorised service
agent.
• Never connect your refrigerator to energy sa-
ving devices. Such systems are harmful to your
product.
1.6- Operational safety
• Never use chemical solvents on the product.
There is the risk of explosion!
• If the product malfunctions, unplug it and do not
operate until it is repaired by the authorised ser-
vice agent. There is the risk of electric shock!
• Do not place flame sources (lit candles, cigaret-
tes, etc.) on or close to the product.
• Do not climb on the product. There is the risk of
falling and getting injured!
• Do not damage the pipes of the cooling system
with sharp or penetrating objects. The refrigerant
that might come out when the refrigerant pipes,
pipe extensions or surface coatings are punctu-
red causes skin irritations and eye injuries.
• Unless recommended by the manufacturer, do
not place or use electrical devices inside the
refrigerator/deep freezer.
• Be careful not to trap your hands or any other
part of your body in the moving parts inside the
refrigerator. Pay attention not to squeeze your
fingers between the door and the refrigerator.
Be careful when opening and closing the door
particularly if there are children around.
• Never eat ice cream, ice cubes or frozen food
right after removing them from the refrigerator.
There is the risk of frostbite!
• When your hands are wet, do not touch the inner
walls or metal parts of the freezer or the food
stored therein. There is the risk of frostbite!
• Do not place tins or bottles that contain carbo-
nated drinks or freezable liquids in the freezer
compartment. Tins and bottles may burst. There
is the risk of injury and material damage!
